FRAME IT ALL Center Circle 16' x 16' User manual

800002104, 800002104-AB1, 800002104-AB2
800003104, 800003104-AB1, 800003104-AB2
800004104, 800004104-AB1, 800004104-AB2
RAISED GARDEN BED
16’ x 16’ Center Circle
Layout your Boards along the borderline and connect each
Board together by inserting the top of the stake through the
bracket loops with the stake pointing to the sky. This enables
you to freely position your border to get your desired location.
Customer Service: 1800-914-9835 |
[email protected]m
© Frame It All. All Rights Reserved.
2 LEVEL KIT CONTAINS:
•Composite Boards 4’ x 34
•Composite Boards 2’ x 8
•Composite Curved Boards x 12
•Cut Composite Board (Gate) x 4
•Stacking Brackets x 96
•4-way Bracing Brackets x 16
•Stacking Stakes x 52
•Plugs x 244
•Finishing Caps x 8
•Adapter cap x 18
•Animal barrier gate (4ft) x 2
•Animal barrier Fencing x 56ft
•Gate to Board Connector x 8
ASSEMBLY INSTRUCTIONS –Level 1
STEP 1:
Assemble the Boards by sliding one end of Board into channel end
of one of the brackets. Use plugs to cover the holes on both sides to
lock the bracket in place.
1. Connect 18 x 4ft Boards with Stacking Brackets on
both ends in alternating orientation.
2. Connect 4x 2ft Boards with a stacking bracket on
one end and a mid-section 4-way bracket on the
other end in alternating orientation.
3. Connect 4x 4ft Boards with a stacking bracket on
one end and a top 4-way bracket on the other end
in alternating orientation.
4. Connect 6 x Curved boards with stacking brackets
on both ends in alternating orientation .
(Bracket all curved boards exactly as shown to the right)
FOR INDOOR & HARD SURFACE:
If you plan to assemble raised bed on a hard surface, use
hacksaw to remove the spike of each stake. Use these cut
down stakes for the base level only of your raised garden.
Trim stake spike with
hacksawfor use indoor
or on hard surfaces
How the Joints Work
Use plugs (included)
to cover the holes on
both side of Boards
Use plugs to
cover the holes
–two plugs are
required per
bracket (1 on
each side)
Use a Capto
complete the
top level.
Use stacking
stakes for
ground level
frames and
stacking
additional levels.
Use stacking
stake when
creating a
multi-level
Stacking stake fit
into the tops other
Stacking stakes
3-Way Connection:
Combine a top 4-way
bracket, mid-section 4-
way bracket and
stackingbracket.
2 LEVELS
3 LEVEL KIT CONTAINS:
•Composite Boards 4’ x 50
•Composite Boards 2’ x 12
•Composite Curved Boards x 18
•Cut Composite Board (Gate) x 8
•Stacking Brackets x 144
•4-way Bracing Brackets x 32
•Stacking Stakes x 78
•Plugs x 336
•Finishing Caps x 8
•Adapter Cap x 18
•Animal barrier gate (4ft) x 2
•Animal barrier Fencing x 56ft
•Gate to Board Connector x 8
•Metal Gate Brace with Screws x 4
4 LEVEL KIT CONTAINS:
•Composite Boards 4’ x 66
•Composite Boards 2’ x 16
•Composite Curved Boards x 24
•Cut Composite Board (Gate) x 12
•Stacking Brackets x 192
•4-way Bracing Brackets x 24
•Stacking Stakes x 104
•Plugs x 448
•Finishing Caps x 8
•Adapter Cap x 18
•Animal barrier gate (4ft) x 2
•Animal barrier Fencing x 56ft
•Gate to Board connector x 8
•Metal Gate Brace with Screws x 8
1
2
3
4
Recommended Tools:
- Hammer
- Power Drill
- Flathead Screwdriver

STEP 5:
Connect the boards for your second level in the quantity and orientation as shown below.
1. Connect 16 x 4ft Boards with Stacking Brackets on
both ends in alternating orientation.
2. Connect 4x 2ft Boards with a stacking bracket on
one end and a mid-section 4-way bracket on the
other end in alternating orientation.
3. Connect 4x 4ft Boards with a stacking bracket on
one end and a top 4-way bracket on the other end
in alternating orientation.
4. Connect 2 x 2ft boards with a stacking bracket on one
end and a mid-section 4-way bracket on the other end in
the same position.
5. Connect 2 x 4ft boards with a stacking bracket on
one end and a top 4-way bracket on the
other end in the same position.
6. Connect 6 x Curved boards with stacking brackets
on both ends in alternating orientation .
(Bracket all curved boards exactly as shown to the right)
7. Connect 4 x Cut gate Boards with a stacking bracket
on the board end with pre-drilled holes.
ASSEMBLY INSTRUCTIONS –Level 1 Continued
Step 2: Layout the Boards for the first level according to the number of the
board in Step 1.
Note: It is especially important to layout Boards 2 & 3in the exact orientation
shown in the diagram below.
The gate Board (Board 1) on level 1 is kept uncut for 2” profile boards to act as a
level surface for the gate to swing on. You can choose to cut this Board if you want
it to be apart of the swinging gate.
IMPORTANT: If you connect any brackets incorrectly, they can be removed by
inserting a flathead screwdriver into the opening of the snap-lock plugs, pushing into
the nub and twisting upwards.
Step 3: When connecting the boards for the first level, insert the stacking
stakes upside down so the stake is pointing to the sky. This will allow you to
adjust the shape of your frame before driving the stakes into the ground.
1
2
Step 4: Once you finish with the adjustments of your base level frame, flip
over the stakes and hammer them into the ground.
1
1
1
1
1
1
1
11
11
3
3
3
3
21
22
1
4
4
1
3
2
4
5
6
7

Step 6: Before stacking your boards, lay them out around your 1st level frame.
NOTE: Stacking stakes will be used for all additional levels and can insert into
the top of existing stakes.
Step 7. Start your 2nd level by connecting the 2/5/7 joint first.
Have the bracket for the gate board (7) on the bottom of the
joint as shown in the picture to the left. Then continue from
this point stacking the remaining 2nd level boards.
Skip to step 1 of the Animal Barrier assembly if you are
assembling a 2-level bed design.
1
1
1
1
1
1
1
1
11
11
3
3
2
2
6
6
4
5
5
4
77
77
Step 8: Repeat steps 5, 6, & 7 for each additional level of your design.
ASSEMBLY INSTRUCTIONS –Animal Barrier Gate
NOTE: Part 12 will not be used
if installing the gate to Board
connector
Quantities doubled for 2 level Barrier
Step 1: Install an adapter cap (Part 21) on top of each of the 10 joints on your final level.

Repeat Steps 2, 3, & 4 for the second gate entrance.
STEP 4a: Take 2 board to timber connectors and fasten them on either side of
the bottom animal barrier gate pole with the screws provided and a power drill.
This will allow the animal barrier gate and board gate to swing as a complete
door. If you are installing this connector onto one-inch profile boards, insert the
spacer block in between the gate to board connector and board before drilling
in your screws.
STEP 4b: For a 3-level design, take your metal gate brace and fasten it over 2 of the
left gate boards with the screws provided and a power drill. Install the gate braces
on the inside portion of the garden and make sure that the screw holes are not over
the edge where the 2 boards meet (see picture).
Repeat this step for the right gate.
For a 4-level design, install an additional gate brace on each door.
