fully Jarvis User manual

Jarvis standing desk – narrow
Assembly instructions
For assembly assistance,
visit fully.com/instructions,
contact us at 888-508-3725
or [e-mail]

Thank you for choosing a Jarvis desk from Fully.

3
Cautions and use
Before starting
Contact
In the box
Assembly
Initial calibration & reset
Custom settings
Using your own desktop
4
5
6
13
14
15

4
Please read this manual carefully. If this desk changes hands,
please provide this manual to the new owner.
Make sure the desktop is not touching any obstacles or walls
and that no obstacles are in the desk’s path. Make sure all
cords are an appropriate length to accommodate the full
range of height adjustment.
Keep children away from the desk components. There is risk
of injury and electric shock.
Do not sit or stand on the the desk frame. Do not crawl or lie
under the desk frame.
Do not open or modify any of the components, including
the Lifting Columns, Control Box, or Handset. Doing so risks
electric shock and voids any warranty claims.
Placing objects taller than 20” underneath the desk will
obstruct the desk’s movement and may result in physical
damage.
Cautions
Voltage converters
Using a voltage converter could cause damage to the desk,
and is considered improper use. Resulting damage is not
covered by the warranty.
Verify the voltage of the Control Box as labeled to avoid
damage. Alternative voltage Control Boxes are available
from Fully.
Use & liability
This Jarvis height adjustable desk has electric motors and
is designed for use in dry work environments only.
This Jarvis desk is adjustable so it can be positioned at an
optimal ergonomic height. Any extracurricular use is at
user’s own risk.
Under no circumstances does the manufacturer accept
warranty claims or liabilityclaims for damage caused by
improper use or handling of the desk frame.
Jarvis is a registered trademark of Fully, LLC.
All rights reserved.
North America
Portland, Oregon
888-508-3725
[e-mail]
fully.com
Europe
Ghent, Belgium
[e-mail]
fully.eu/contact
fully.eu
Contact
On a padded or carpeted area, take all of the items out of
your Jarvis frame box and confirm that nothing is missing.
Reference the included parts listings on page 5.
Before starting
If you are using your own desktop, refer to page 15 for
instructions before beginning assembly.
Using your own desktop
Tools
3mm
Hex Wrench
4mm
Hex Wrench
Phillips Screwdriver
(not included)

5
Parts
*Not to scale
4 mm
Box 1
Box 2
Desktop box
Lifting Column x2
A
Frame End x2
D
Right Side Bracket
H
Wood Screw x12
L
Desktop Screw x9
for Fully bamboo desktops
P
Desktop
SDesktop Screw x9 (Extra) T
Desktop Screw x9
for all other Fully desktops
QNoise Attenuation
Grommet x5 (Extra)
R
Medium Machine
Screw x12
MSmall Machine Screw x8 NDesktop Washer x9 O
Left Side Bracket
ILeg Extension Cable JCable Clip x10 K
Memory Handset
or Up/Down
EFoot x2 FCenter Rail x2 G
Control Box
BPower Cable C

6
N
D
A
Dx4
N
A
1
2
4 mm
M
H
1
Hx2
M
14 mm

7
3
4
4 mm
N
D
A
Dx4
N
A
4 mm
M
3
G
Ix2
M
3

8
O
2
S
5
1
S
4
G
!
6
x4
O
x2
G
4
S
4 mm
2x4
L
Use wood screws if you
have your own desktop.
Use silver screws with
all other Fully desktops.
x4
P
Use black screws with
Fully bamboo desktops.
x4
Q
OR OR
! ! !

9
4
O
S
7
8
3 mm
x4
O
=
=
O
S
4 mm
4
Tighten pre-installed screws
Skipping this step will result
in stability issues.
!
x4
L
Use wood screws if you
have your own desktop.
Use silver screws with
all other Fully desktops.
x4
P
Use black screws with
Fully bamboo desktops.
x4
Q
OR OR
! ! !

10
L
E
L
E
Ex2
L
B
42”
30", 36"
LB
x2
L
9
10
Pro tip: You may need to position
the control box elsewhere
to accommodate accessories.

11
11
(Optional)
x10
C
J
K
90° plug
J
!
JCx10
K

12
12
F
M
x2
x2
FMx8 4 mm
13
Optional

13
14 Before you start using your Jarvis, you’ll need to get all
the parts synced. Don’t worry — it’s easy.
Initial calibration & reset
1. Touch the Fully logo located on the front face of the Up/
Down handset until Jarvis reaches its lowest position.
Release.
2. Press and hold the Fully logo for about 10 seconds. Release.
3. Press and hold the Fully logo again, this time until the Jarvis
first lowers slightly, then rises slightly, and finally stops.
Remove your finger from the handset.
4. You can now use your Jarvis.
1. Press and hold the icon until Jarvis reaches its lowest
position. Release.
2. Press and hold the icon until the display reads RESET.
3. Press and hold the icon again, this time until Jarvis first
lowers slightly, then rises slightly, and finally stops. Release
the icon.
4. You can now use your Jarvis.
To raise desk - touch one finger to the underside of the handset.
Hold it there until the desk reaches the desired height.
To lower desk - touch one finger to the Fully logo on the front
of the handset. Hold finger in place until the desk reaches the
desired height.
To program your memory presets, raise or lower your Jarvis to
your preferred height. Then, press the Micon followed by one
of the four numbers you want to preset. This number will return
Jarvis to your preferred height from now on.
Up/Down Handset Programmable Memory Handset
Using Up/Down Handset Programming memory presets

14
Custom settings for Programmable Memory Handset
LED DisplayUp/Down Presets M Button
To begin, access the menu by holding down Mfor 3 seconds
until Lock/Unlock desk appears on screen. Use the 5and 
icons to navigate through the menu. ‘1’ selects the feature you
want to change and also confirms your selection. ‘4’ takes you
back to the main menu.
To help prevent damage, Jarvis is outfitted with an accelerometer
that stops it if it runs into something. You can set the sensitivity
with the anti-collision options.
Adjust the screen brightness on your memory handset to the
level that suits you—and your eyes.
You can also adjust the button brightness on your memory
handset. Choose from 3 different brightness levels to help you
navigate through your presets and menu options.
Use One touch to move your Jarvis to a memory preset
height with the touch of a button, or use Constant touch and
keep your finger on the button until Jarvis gets to the memory
preset height.
To calibrate your handset’s height display, lower Jarvis all the way
down and then use a tape measure to determine the height from
the top of your desktop to the floor. Select the Calibrate height
menu option and use the 5and icons to adjust the height
readout to match your previously measured height.
To lock Jarvis and prevent any further changes to the height or
menu settings use Lock. Unlock will allow you to once again use
all of Jarvis’s features.
If you want to limit how high your Jarvis can go, set a Max
height limit. Simply raise Jarvis to the desired maximum
height and navigate to Max height on the menu, then press
‘1’ to confirm.
To limit how low your Jarvis can go, set a Minimum height limit.
Move Jarvis to the desired minimum height and navigate to
Min height on the menu, then press ‘1’ to confirm.
Prefer to work in centimeters instead of inches? Choose the unit
of measurement you’d like under the Units menu option.
Getting started Anti-collision
Screen brightness
Button brightness
Memory preset mode
Calibrate height
Lock/unlock Jarvis
Max height
Min height
Units

15
Short Foot Long Foot
YQ-14X
YQ-141
Bottom view of Foot:
Using your own desktop
2”
2” 5.5”
2”
2” 6.75”
There’s no one right way to position your frame on your
desktop but there are a few things you’ll want to keep in mind.
Generally speaking, the desktop should be centered over the
frame side-to-side, and positioned slightly forward of center
(towards the user) front-to-back.
First, determine if your Jarvis has a short or long foot.
Short Foot: Engraved with YQ-140
Recommended for desktops 24”–27” deep.
Long Foot: Engraved with YQ-141
Recommended for desktops 27”–30” deep.
The maximum distance from the front desktop edge to the first
hole in the Side Bracket is 5.5”.
The maximum distance from the front desktop edge to the first
hole in the Side Bracket is 6.75”.

16
In our experience, desks have better lateral stability the further
apart the legs are. We position the screw holes for the Side
Brackets 2 inches in from the sides of the desktop. This leaves
about 1” of desktop overhang and maximizes lateral stability.
Placing the holes at least 2 inches in from the sides lowers the
chance that your desktop will split during drilling.
Depending on the rigidity and strength of your desktop
material you can leave more of it overhanging the Side Brackets.
For example, on our 78” tops the Side Bracket holes are 5” in
from the edge with 4” of overhang.
The easiest way to position your own desktop on Jarvis is to
partially assemble the frame and use it as a guide. This frame
assembly is easier to maneuver than the entire frame and will
allow you to see exactly how things line up and where all of the
holes should be.
1. Lay your desktop on a padded workspace with the
underside facing up, and the front of the desktop
towards you.
2. Without the Lifting Columns, attach the Side Brackets to
the Frame Ends as shown in Steps 2 and 4, on pages 6
and 7.
3. Slide the Center Rails into the Frame Ends.
4. Position the frame assembly on the underside of your
desktop, with the screw holes in the Side Brackets 2” or
more from the side edges of the top, and the front-most
hole appropriate depth from the front (user-facing) edge
of the top.
Side-to-side position
Laying it out

17

version 40000487V.E
Everything you need
to find your work flow
