fully Remi User manual

Remi standing desk
Assembly instructions
For assembly assistance,
call 888-508-3725
or email [e-mail]

Thank you for choosing a Remi desk
from Fully.
Cautions and Use
Before starting
Specs
In the box
Assembly
Handset
Contact
1
2
2
3
3
10
11

Cautions
Voltage
Converters
Use & liability
1
Please read this manual carefully. If this desk changes hands, please provide this manual to the new
owner.
Make sure the desk top is not touching any obstacles or walls and that no obstacles are in the desk’s
path. Make sure all cords are an appropriate length to accommodate the full range of height
adjustment.
Keep children away from desk components. There is risk of injury and electric shock.
Do not sit or stand on the desk frame. Do not crawl or lie under the desk frame.
Do not open or modify any of the components, including the Lifting Columns,
Control Box, or Handset. Doing so risks electric shock and voids any warranty claims.
Placing objects taller than 24” underneath the desk will obstruct the desk’s movement
and may result in physical damage.
Using a voltage converter could cause damage to the desk and is considered improper use.
Resulting damage is not covered by the warranty.
Verify the voltage of the Control Box as labeled to avoid damage. Alternative voltage Control
Boxes are available from Fully.
This Remi height adjustable desk has electric motors and is designed for use in dry work environ-
ments only.
This Remi desk is adjustable so it can be positioned at an optimal ergonomic height.
Any extracurricular use is at user’s own risk.
Under no circumstances does the manufacturer accept warranty claims or liability
claims for damage caused by improper use or handling of the desk frame.
Fully, LLC. All rights reserved.
On a padded or carpeted area, take all of the items out of your
Remi frame box and confirm that nothing is missing. Reference
the included parts listings on page 3.
Before starting
Specs
2
Tools
Hex Wrench
Phillips Screw Driver
(Not Included)
Height range (w/o desk top)
Travel speed
Operating noise
Load capacity
Duty cycle
Frame width min/max
26.25” - 45.75”
1.1”/sec
<53 dB
220 lb
10%
36”–66”
Remi Adjustable Height
Standing Desk—Frame Only
CAUTION
NO IMPACT DRIVERS OR OTHER HIGH TORQUE
EQUIPMENT ARE TO BE USED.
!

Step 1
Remi standing desk
E—Feet x2C—Frame End x2
Box 1
Box 2
B—Control Box
I—Medium Machine Screw x8
L—Washers x10
F—Memory Handset
J—Small Countersunk Screw x8
D—Center Rail (Pre-Installed)
A—Lifting Column x2
G—Leg Cable
N—Set Screws (Pre-Installed) x4M—Hex Wrench
H—Power Cable
K—Wood Screw x14
3
D—Center Rail (Pre-Installed)
1234M
C—Frame End x2
Step 2
4
K—Wood Screw x10
N—Set Screws (Pre-Installed) x4
M—Hex Wrench
*Front of the Desk
CAUTION
NO IMPACT DRIVERS OR OTHER HIGH TORQUE
EQUIPMENT ARE TO BE USED.
!
L—Washers x10

Step 3
5
A—Lifting Column x2
!
Tighten screws in an
“X-Direction.”
1
4
3
2
J—Small Countersunk Screw x8
M—Hex Wrench
Step 4
6
E—Feet x2
I—Medium Machine Screw x8
M—Hex Wrench
!
Tighten screws in an
“X-Direction.”
1
4
3
2

Step 5
7
F—Memory Handset
1234M
Left Side Right Side
Memory Handset (“F”) can be mounted on the Left or Right Side.
K—Wood Screw x2
Step 6
8
B—Control Box
K—Wood Screw x2

Step 8
9
Step 7
G—Leg Cable
H—Power Cable
F HS M1 M2
“G“
“F“
“G“
F—Memory Handset
1234M
G—Leg Cable
G—Leg Cable
H—Power Cable
Remi handset
LED Display Up/Down Presets M Buttom
10
Setup
Initial calibration
Before you start using your desk normally, you’ll need to get all the parts synced. Don’t worry — it’s easy.
With Memory Preset Handset
1. Press and hold the DOWN button until the display reads RST. Release.
2. Press and hold the DOWN button again, this time until the desk first lowers slightly, then rises slightly, and finally stops. Release
the DOWN button.
3. You can now use your desk. See page 2 for tips on making the most of your Memory Preset Handset.
Setting memory presets
1. Adjust the desk to the desired height.
2. Press M (the display will show S -).
3. Press a number 1 – 4.
4. Pressing that number will return your desk to the programmed height. By default, the desk will continue to move on its own
once you’ve activated the preset, though pressing any other button will stop this movement. If you prefer to change this behav-
ior, please refer to “Toggle between One Touch and Constant Touch Presets” on page 4.

Version 90.014.01.1068v.C
