GABBY LEONA User manual

LEONA DRESSER
ASSEMBLY INSTRUCTION
PARTS :
HARDWARE : TOOLS REQUIRED:
Date: 23-01-2020 Page 1 of 3
F
4 PCS
Feet
1 PC
E
Body
HARDWARE INCLUDE :
1. 2 Anti Tip Kit
A. 4 -Small Screw
B. 4- Large Screw
C. 4-Bracket
D. 2-Retention Belt
PARTS INCLUDE :
E. 1 –Body
F. 4 –Feet
1 Anti Tip Kit
2 Set
Screwdriver

LEONA DRESSER
ASSEMBLY INSTRUCTION
- Put the dresser top side down on a clean protected work surface where the unit can be
assemble.
- Insert the pre-mounted bolt insert of the feet into the female insert nut of the base and turn
the feet clockwise until it get light.
- If the floor is uneven adjust the levelers located at the underside of the Feet, to do this lift Up
the side that need to be elevated to provide access to the levelers, turn the leveler until
adequate contact with the floor.
Page 2 of 3
STEP 1
Body
Feet
STEP 2

LEONA DRESSER
ASSEMBLY INSTRUCTION
Attach the Brackets (C) horizontally to the top of the back of the Dresser using the Small Screws (A).
Screw the remaining Brackets (C) vertically 1 inch below the brackets attached to the Dresser
using the large screws (B).The Large Screws (B) should be screwed into a stud in the wall. Align the
Brackets vertically and string in the Retention Belt (D). Confirm Strap is securely laced and locked.
Page 3 of 3
Wall
A
B
C
D
