Product Installation Guidelines
Version 1.1, 13 May 2021, Page 1of 4
Ezy-Push®CP-BS Lead Safe™ Timeflow Push Button
Replacement Cartridge –Adjustable
(Suit 173.61.55.00 and TP08045PA)
PRODUCT CODES:
- 173.92.55.00
SPECIFICATIONS
−The Ezy-Push®time flow cartridge has a unique self-closing operation.
−Smooth round designs to facilitate easy clean and help reduce dirt and bacteria growth.
−Water saving, easy to operate and low maintenance.
−Adjustable time flow.
IMPORTANT: All Ezy-Push®Push Button taps are tested in accordance with AS/NZS 3718 and leave our
premises in good working order.
Note: Run time is based on 500kPa, 5 litres per minute @ 22 degrees Celsius. Time will vary plus or minus
30% based on water temperatures, pressures, flow rates and water quality.
As ‘lead free’ is not currently defined by low in Australia and New Zealand, we have based our definition of Lead Safe™ on the requirements of s1417 of the USA’s Safe Drinking Water Act
(SDWA) and the relevant US standards NSF61 / NSF372. The SDWA defines ‘lead free’ as “not more than a weighted average of 0.25% lead when used with respect to the wetted surface of
pipes, pipe fittings, plumbing fittings and fixtures”.
TECHNICAL DATA
Inlet
M26 x 19 TPI - Male
Outlet
N/A
Headwork
Time Flow Cartridge
Working Pressure Range (kPa)
Min
100
Max
500
Working Temperature Range (°C)
Min
5
Max
65
Nominal Flow Rate (LPM)
N/A
Construction
Brass
Finish
Chrome
Time (s)
0 –30 Adjustable
NOTE: Galvin Specialised continually strive to improve their products. Specifications may change without notice.

© Galvin Engineering Pty Ltd
Product Installation Guidelines
Version 1.1, 13 May 2021, Page 2of 4
PRE-INSTALLATION
MOUNTING DETAILS
Note: Before installation, all lines must be
flushed. We recommend that a line strainer be
installed prior to taps to eliminate any foreign
material.
INSTALLATION
IMPORTANT: Galvin Specialised products must be installed in accordance with these installation
instructions and in accordance with AS/NZS 3500, the PCA and your local regulatory requirements. Water
and/or electrical supply conditions must also comply to the applicable national and/or state standards. Failing
to comply with these provisions shall void the product warranty and may affect the performance of the
product.
Fit cartridge assembly
−Fit the cartridge into the body (supplied separately) as shown.
−Tighten the cartridge assembly down firmly. Do not over tighten as this could restrict or stop the flow.
If this occurs loosen the cartridge by ¼ of a turn.
−Connect the water lines & turn on water.
Check for leaks and correct operation.

© Galvin Engineering Pty Ltd
Product Installation Guidelines
Version 1.1, 13 May 2021, Page 3of 4
ADJUSTING TIME FLOW
1. Disassemble
−Dismount the button head
−Remove the grub screw with a 1.5 mm
allen-key (not supplied)
2. Adjust stop-ring
−Turn the stop-ring clockwise to increase flow
time or anti-clockwise to reduce it.
3. Fix position
−Orientate the stop ring to allow the refitting
of the grub screw
4. Reassemble
−Reassemble completely paying attention to
align the hole in the spindle with the grub screw

© Galvin Engineering Pty Ltd
Product Installation Guidelines
Version 1.1, 13 May 2021, Page 4of 4
TROUBLESHOOTING
PROBLEM
CAUSE
RECTIFICATION
Water is not flowing or
inconsistent flow.
Blocked flow restrictor/dirt in the
cartridge/water supply not on.
Remove flow regulator from the inlet and
remove debris. Install an inline strainer to
stop further blockages. Ensure water
supply is turned on.
Continous flow of
water.
Top assembly cartridge loose or
internally obstructed or damaged.
Remove cartridge, clean with water and
re-grease spindle if required.
Rate of flow
inadequate.
The flow restrictor may not be
satisfactory due to inadequate supply
pressure.
Remove flow restrictor and replace with a
flow restrictor of different capacity to suit
(available from Galvin Specialised).
Button hard to activate.
Mains pressure may be too high.
Reduce mains pressure to below 500kPa
(70 PSI).
No time flow –water
shuts off upon release.
Small spring at the bottom of the
cartridge piston dislodged.
Relocate spring, regrease spindle if
required.
WARRANTY
The warranty set forth herein is given expressly and is the only warranty given by the Galvin Engineering Pty
Ltd. With respect to the product, Galvin Engineering Pty Ltd makes no other warranties, express or implied.
Galvin Engineering Pty. Ltd. hereby specifically disclaims all other warranties, express or implied, including but
not limited to the implied warranties of merchantability and fitness for a particular purpose.
Galvin Engineering Pty Ltd products are covered under our manufacturer’s warranty available for download
from www.galvinengineering.com.au Galvin Engineering Pty Ltd expressly warrants that the product is free
from operational defects in workmanship and materials for the warranty period as shown on the schedule in
the manufacturer’s warranty. During the warranty period, Galvin Engineering will replace or repair any
defective products manufactured by Galvin Engineering without charge, so long as the terms of the
Manufacturer’s warranty are complied with.
The remedy described in the first paragraph of this warranty shall constitute the sole and exclusive remedy for
breach of warranty, and Galvin Engineering Pty Ltd shall not be responsible for any incidental, special or
consequential damages, including without limitation, lost profits or the cost of repairing or replacing other
property which is damaged if this product does not work properly, other costs resulting from labour charges,
delays, vandalism, negligence, fouling caused by foreign material, damage from adverse water conditions,
chemical, electrical or any other circumstances over which Galvin Engineering has no control. This warranty
shall be invalidated by any abuse, misuse, misapplication, improper installation or improper maintenance or
alteration of the product.
