Galvin Engineering Haws GalvinSafe Axion 8100-A Instruction sheet

Version 3.2, 21th Sept. 2021, Page 1of 6
GalvinSafe®Free Standing Drench Shower, Pull
Rod, Axion®MSR ABS Shower (HAWS)
PRODUCT CODE:
Galvin Engineering: 190.81.12.32
HAWS: 8100-A
PRE - INSTALLATION
LOCATION OF UNIT: The Model 190.81.12.32 (8100-A) Emergency Shower should be
installed in close proximity to potential accident areas. It should be clearly identified, free
from obstructions and easy to access.
SUPPLY LINE: The minimum recommended line size is 1-1/4” BSP with 210 –600 kPa
flowing pressure. Where sediment or mineral content is a problem, an inlet filter is
recommended.
PLUMBING CONNECTIONS: Inlet supply is male 1-1/4” BSPT.

Version 3.2, 21th Sept. 2021, Page 2of 6
PARTS BREAKDOWN
ITEM
ITEM CODE
DESCRIPTION
1
190.92.00.10
SHOWER HEAD
2
190.92.04.30
VALVE ASSEMBLY
3
-
EMERGENCY SHOWER SAFETY
SIGN*
4
190.92.30.20
PULL ROD
5
-
FLOOR FLANGE*
6
-
STRIPE TAPE*
7
190.91.80.33
TEST TAG
* spare parts will require special order or may not be
available (contact Galvin engineering for more details).

Version 3.2, 21th Sept. 2021, Page 3of 6
INSTALLATION PROCEDURE
Refer to Installation Drawing for clarification. Check parts list to ensure all required
parts are included. Use an AS 4020 approved pipe joint sealant on all connections.
STEP 1: Prepare the emergency shower foundation by using the floor flange as a
template. Locate the three holes for the 3/8-16 UNC x 6” anchor bolts. (Not
supplied). They should extend 1” above the floor level.
STEP 2: Once the concrete foundation is ready (dry), assemble the floor flange to the
anchor bolts; then securely fasten with 3/8-16 UNC Hex nuts and 3/8”
washers (Not supplied). Seal and tighten floor flange and (1-1/4”) tee making
certain the waste tee is facing the proper location and the foot control holes
are facing side to side.
STEP 3: Assemble nipple (1-1/4” x 33”) to the tee and tighten with a pipe wrench.
STEP 4: Assemble in the following order:
Attach intermediate coupling to nipple (1-1/4” x 33”)
Attach plugged nipple (1-1/4” x 24”) and tee (1-1/4”) onto the coupling.
Attach nipple (1-1/4” x 24”) onto the tee.
Attach tee (1-1/4” x 1-1/4” x 1”) onto nipple.
Attach nipple (1” x 9”) valve assembly onto tee (1-1/4” x 1-1/4” x 1”)
Attach street elbow (1”) and nipple (1” x 12-1/2”)
Attach nipple onto valve.
STEP 5: Attach the showerhead onto street elbow (1”).
STEP 6: Assemble the sign onto the unit. Use the strap, screws, washers and nuts
provided to mount the sign onto the upright. The sign should be
positioned for maximum visibility.
STEP 7: Insert the plug into the optional supply line tee that is not used. Before
connecting the supply water line to the emergency shower; CHECK IF THE
ASSEMBLY IS RIGIDLY TIGHTENED AND FLUSH THE LINE
THOROUGHLY.

Version 3.2, 21th Sept. 2021, Page 4of 6
Version 3, 30th June

Version 3.2, 21th Sept. 2021, Page 5of 6
For more information about GalvinSafe®(Haws) products, see our website.
TROUBLESHOOTING
PROBLEM
REPAIR CHECKLIST
1. No Flow.
1. Check the main shut-off valve.
2. Insufficient water flow at shower
2. a. Verify minimum 210 kPa flowing supply
line pressure.
b. Probable clogging of flow control
inside shower head. Unscrew shower head
off elbow and clean rubber flow control.
3. Water does not drain properly.
3. Check your drain system for debris. Check
the main waste line of your building to see
if it does handle the capacity required for
the entire drainage system
4. Water leak between joints or fittings.
4. Tighten loose connections. If leak persists,
the application of hot water will sometimes
reseat improperly applied joint compound.
After 30 minutes wait and retest. A
persistent leak will necessitate reassembly
and additional sealant.

``
Version 1, 12th April 2021, Page 6of 6
Version 3.2, 21th Sept. 2021, Page 6of 6
WARRANTY
The warranty set forth herein is given expressly and is the only warranty given by the Galvin Engineering Pty
Ltd. With respect to the product, Galvin Engineering Pty Ltd makes no other warranties, express or implied.
Galvin Engineering Pty. Ltd. hereby specifically disclaims all other warranties, express or implied, including but
not limited to the implied warranties of merchantability and fitness for a particular purpose.
Galvin Engineering Pty Ltd products are covered under our manufacturer’s warranty available for download
from www.galvinengineering.com.au Galvin Engineering Pty Ltd expressly warrants that the product is free
from operational defects in workmanship and materials for the warranty period as shown on the schedule in
the manufacturer’s warranty. During the warranty period, Galvin Engineering will replace or repair any
defective products manufactured by Galvin Engineering without charge, so long as the terms of the
Manufacturer’s warranty are complied with.
The remedy described in the first paragraph of this warranty shall constitute the sole and exclusive remedy for
breach of warranty, and Galvin Engineering Pty Ltd shall not be responsible for any incidental, special or
consequential damages, including without limitation, lost profits or the cost of repairing or replacing other
property which is damaged if this product does not work properly, other costs resulting from labour charges,
delays, vandalism, negligence, fouling caused by foreign material, damage from adverse water conditions,
chemical, electrical or any other circumstances over which Galvin Engineering has no control. This warranty
shall be invalidated by any abuse, misuse, misapplication, improper installation or improper maintenance or
alteration of the product.
