Galvin Engineering Ezy-Drink CP Lead Safe 2 in 1 Bottle Filler & Bubbler Hob... Instruction sheet

© Galvin Engineering Pty Ltd
Product Installation
Guideline
s
Version 1, 13
th
June 2023, Page 1 of 4
Ezy-Drink
®
CP Lead Safe
™
2 in 1 Bottle Filler & Bubbler
Hob Mount
PRODUCT CODE
- 170.00.13.00
SPECIFICATIONS
 2 in 1 design with bottle filler and bubbler.
 Drinking taps are designed to operate at full mains pressure.
 The rubber mouthguard is resistant to fungal and bacterial attack and has a high resistance to sunlight.
 Vandal resistant push buttons.
 Adjustable built-in flow restrictor.
IMPORTANT: All Ezy-Drink
®
2 in 1 taps are tested in accordance with AS/NZS 3718 and leave our premises
in good working order.
*As ‘lead free’ is not currently defined by law in Australia and New Zealand, we have based our definition of Lead Safe™ on the requirements of s1417 of the USA’s Safe Drinking
Water Act (SDWA) and the relevant US standards NSF61 / NSF372. The SDWA defines ‘lead free’ as “not more than a weighted average of 0.25% lead when used with respect
to the wetted surface of pipes, pipe fittings, plumbing fittings and fixtures”.
WARNINGS: Special attention to be paid on notes, photos, images, or drawings of assembly steps marked
with the warning symbol.
TECHNICAL DATA
Inlet ½” BSP Female
Outlet Rubber Mouthguard/Bottle Filler
Headwork Push Button
Working Pressure Range (kPa) Min 50
Max 500
Working Temperature Range (°C) Min 5
Max 60
Nominal Flow Rate (LPM) 2.98
Construction Brass
Finish Chrome
NOTE: Galvin Engineering continually strive to improve their products. Specifications may change without
notice.
TOOLS REQUIRED
 Power drill
 Wrench
 Screwdriver

© Galvin Engineering Pty Ltd
Product Installation
Guidelines
Version 1, 13
th
June 2023, Page 2 of 4
PRE-INSTALLATION
 Anti-rotation can be achieved (if required) by using the M4 holes in the flange.
Note: Before installation, all lines must be flushed.
We recommend that a line strainer be installed prior to drinking taps to eliminate any foreign material.

© Galvin Engineering Pty Ltd
Product Installation
Guidelines
Version 1, 13
th
June 2023, Page 3 of 4
INSTALLATION
INSTALLATION COMPLIANCE: Galvin Engineering products must be installed in accordance with these
installation instructions and in accordance with AS/NZS 3500, the PCA and your local regulatory requirements.
Water and/or electrical supply conditions must also comply to the applicable national and/or state standards.
Failing to comply with these provisions shall void the product warranty and may affect the performance of the
product.
1. Fit tap assembly
 Fit the tap as shown above.
 When applying thread tape or sealant to the inlet, ensure the opening is not obscured. Failure to do so
may restrict or block the flow restrictor, affecting the flow of water.
2. Flow adjustment
 To adjust water flow
1. Remove the blanking screw
2. Adjust the water flow by turning the
regulator screw. Test both the bubbler
water height and bottle filler flow.
3. Replace blanking screw
Note: The full range from minimum flow to
maximum flow is only ¼ turn
3. Testing
Once the drinking tap has been installed,
test for leaks and correct operation.
Regulating
Sc
rew
Blanking
Screw

© Galvin Engineering Pty Ltd
Product Installation
Guidelines
Version 1, 13th June 2023, Page 4 of 4
TROUBLESHOOTING
PROBLEM CAUSE RECTIFICATION
Inconsistent flow Blocked top assembly Remove top assembly and clean
Water is not flowing from tap Water is turned off Turn on water
Blocked flow regulating screw Remove flow regulating screw and clean
Continuous flow Top assembly loose or internally
obstructed or damaged
Remove top assembly, clean with water
and re-grease spindle if required
Rate of flow inadequate The flow regulating screw may
not be adjusted correctly
Remove blanking screw and adjust flow
regulating screw as described
Button hard to press The mains pressure may be too
great
Reduce to below 500kPa (70PSI).
Regrease spindle if required
WARRANTY
The warranty set forth herein is given expressly and is the only warranty given by the Galvin Engineering Pty
Ltd. With respect to the product, Galvin Engineering Pty Ltd makes no other warranties, express or implied.
Galvin Engineering Pty. Ltd. hereby specifically disclaims all other warranties, express or implied, including
but not limited to the implied warranties of merchantability and fitness for a particular purpose.
Galvin Engineering Pty Ltd products are covered under our manufacturer’s warranty available for download
from www.galvinengineering.com.au Galvin Engineering Pty Ltd expressly warrants that the product is free
from operational defects in workmanship and materials for the warranty period as shown on the schedule in
the manufacturer’s warranty. During the warranty period, Galvin Engineering will replace or repair any
defective products manufactured by Galvin Engineering without charge, so long as the terms of the
Manufacturer’s warranty are complied with.
The remedy described in the first paragraph of this warranty shall constitute the sole and exclusive remedy
for breach of warranty, and Galvin Engineering Pty Ltd shall not be responsible for any incidental, special or
consequential damages, including without limitation, lost profits or the cost of repairing or replacing other
property which is damaged if this product does not work properly, other costs resulting from labour charges,
delays, vandalism, negligence, fouling caused by foreign material, damage from adverse water conditions,
chemical, electrical or any other circumstances over which Galvin Engineering has no control. This warranty
shall be invalidated by any abuse, misuse, misapplication, improper installation or improper maintenance or
alteration of the product.
