Galvin Engineering Haws 7777-A Instruction sheet

Version 4.1, 13th Aug. 2021, Page 1of 6
GalvinSafe®Pedestal Floor Mtd, Axion®MSR Eye/Face
Wash Head, S/Steel Bowl, Hand Act, (HAWS)
PRODUCT CODE:
Galvin Engineering: 190.82.11.12
HAWS: 7777-A
PRE - INSTALLATION
LOCATION OF UNIT: The Model 190.82.11.12 (7777-A) Stainless Steel combination
Shower Eye/Face Wash should be installed in close proximity to potential accident
areas. It should be clearly identified, free from obstructions and easy to access.
SUPPLY LINE: The minimum recommended line size is 1/2” BSPT with 210 –600 kPa
flowing pressure. Where sediment or mineral content is a problem, an inlet filter is
recommended.
PLUMBING CONNECTIONS: Inlet supply is female 1/2” BSPT. Waste outlet is male 1-
1/4”BSPT.
INSTALLATION
Refer to installation drawing to clarify installation procedure.

Version 4.1, 13th Aug. 2021, Page 2of 6
PARTS BREAKDOWN
ITEM
ITEM CODE
DESCRIPTION
1
190.92.22.20
BOWL
2
190.91.12.32
EMERGENCY EYE SAFETY
SIGN
3
190.92.41.30
VALVE ASSEMBLY
4
190.91.22.12
FOOT TREADLE (OPTIONAL)
5
190.92.12.10
EYE/FACE WASH ASSEMBLY
6
190.91.80.33
TEST TAG
7
-
L-STRAINER*
8
-
SS DUST COVER ASSEMBLY*
(OPTIONAL)
* spare parts will require special order or may not be
available (contact Galvin engineering for more details).

Version 4.1, 13th Aug. 2021, Page 3of 6

Version 4.1, 13th Aug. 2021, Page 4of 6
For more information about GalvinSafe®(Haws) products, see our website.
TROUBLESHOOTING
PROBLEM
REPAIR CHECKLIST
1. No Flow.
1. Check the main shut-off valve.
2. Insufficient water flow
2. a. Verify minimum 210 kPa flowing
supply line pressure.
b. Probable clogging of flow control due
to inadequate line flushing. Unscrew
eye/face wash head and remove the
four screws to disassemble head.
Clean flow control and reassemble
Head.
c. Remove plug located on L –Strainer
using a 9/16” wrench to access clean
filter screen.
3. Eye/face wash streams do not meet
desired eye level.
3. Possible blocked flow control, see above
solution. Possible non-leveled eye/face
wash assembly
4. Water does not drain properly.
4. Check the main waste line of your
building to see if it does handle the
capacity required for the entire drainage
system.

Version 4.1, 13th Aug. 2021, Page 5of 6

`
Version 4.1, 13th Aug. 2021, Page 6of 6
WARRANTY
The warranty set forth herein is given expressly and is the only warranty given by the Galvin Engineering Pty
Ltd. With respect to the product, Galvin Engineering Pty Ltd makes no other warranties, express or implied.
Galvin Engineering Pty. Ltd. hereby specifically disclaims all other warranties, express or implied, including but
not limited to the implied warranties of merchantability and fitness for a particular purpose.
Galvin Engineering Pty Ltd products are covered under our manufacturer’s warranty available for download
from www.galvinengineering.com.au Galvin Engineering Pty Ltd expressly warrants that the product is free
from operational defects in workmanship and materials for the warranty period as shown on the schedule in
the manufacturer’s warranty. During the warranty period, Galvin Engineering will replace or repair any
defective products manufactured by Galvin Engineering without charge, so long as the terms of the
Manufacturer’s warranty are complied with.
The remedy described in the first paragraph of this warranty shall constitute the sole and exclusive remedy for
breach of warranty, and Galvin Engineering Pty Ltd shall not be responsible for any incidental, special or
consequential damages, including without limitation, lost profits or the cost of repairing or replacing other
property which is damaged if this product does not work properly, other costs resulting from labour charges,
delays, vandalism, negligence, fouling caused by foreign material, damage from adverse water conditions,
chemical, electrical or any other circumstances over which Galvin Engineering has no control. This warranty
shall be invalidated by any abuse, misuse, misapplication, improper installation or improper maintenance or
alteration of the product.
