Galvin Engineering GalvinSafe 190.41.12.12 Instruction sheet

Version 3.1, 13th Aug. 2021, Page 1of 5
GalvinSafe®Drench Shower, Wall Mounted, Pull Rod,
Axion®MSR ABS Shower (HAWS)
PRODUCT CODE:
Galvin Engineering: 190.41.12.12
HAWS: 8123-A
PRE - INSTALLATION
LOCATION OF UNIT: The Model 190.41.12.12 (8123-A) Emergency Shower should be
installed in close proximity to potential accident areas. It should be clearly identified, free
from obstructions and easy to access.
SUPPLY LINE: The minimum recommended line size is 1” BSPT with 210 –600 kPa
flowing pressure. Where sediment or mineral content is a problem, an inlet filter is
recommended.
PLUMBING CONNECTIONS: Inlet supply is female 1” BSPT.
INSTALLATION
Refer to installation drawing to clarify installation procedure.

Version 3.1, 13th Aug. 2021, Page 2of 5
PARTS BREAKDOWN
ITEM CODE
ITEM DESCRIPTION
190.91.80.33
TEST TAGS
190.92.30.20
PULL ROD
190.92.04.30
VALVE ASSEMBLY
190.92.00.10
SHOWER HEAD
-
SP177 SHOWER SIGN*
*spare part will require special order or may not be available (contact Galvin engineering for more details).

Version 3.1, 13th Aug. 2021, Page 3of 5

Version 3.1, 13th Aug. 2021, Page 4of 5

``
Version 3.1, 13th Aug. 2021, Page 5of 5
For more information about GalvinSafe®(Haws) products, see our website.
TROUBLESHOOTING
PROBLEM
REPAIR CHECKLIST
1. No Flow.
1. Check the main shut-off valve.
2. Insufficient water flow
2. a. Verify minimum 210 kPa flowing
supply line pressure
b. Probable clogging of flow control due
to inadequate line flushing. Unscrew
showerhead off of elbow and clean
rubber flow control.
WARRANTY
The warranty set forth herein is given expressly and is the only warranty given by the Galvin Engineering Pty
Ltd. With respect to the product, Galvin Engineering Pty Ltd makes no other warranties, express or implied.
Galvin Engineering Pty. Ltd. hereby specifically disclaims all other warranties, express or implied, including but
not limited to the implied warranties of merchantability and fitness for a particular purpose.
Galvin Engineering Pty Ltd products are covered under our manufacturer’s warranty available for download
from www.galvinengineering.com.au Galvin Engineering Pty Ltd expressly warrants that the product is free
from operational defects in workmanship and materials for the warranty period as shown on the schedule in
the manufacturer’s warranty. During the warranty period, Galvin Engineering will replace or repair any
defective products manufactured by Galvin Engineering without charge, so long as the terms of the
Manufacturer’s warranty are complied with.
The remedy described in the first paragraph of this warranty shall constitute the sole and exclusive remedy for
breach of warranty, and Galvin Engineering Pty Ltd shall not be responsible for any incidental, special or
consequential damages, including without limitation, lost profits or the cost of repairing or replacing other
property which is damaged if this product does not work properly, other costs resulting from labour charges,
delays, vandalism, negligence, fouling caused by foreign material, damage from adverse water conditions,
chemical, electrical or any other circumstances over which Galvin Engineering has no control. This warranty
shall be invalidated by any abuse, misuse, misapplication, improper installation or improper maintenance or
alteration of the product.
