Gamma+ SPKLEKO600 User manual

Bi-color Die-casting Aluminum GL-
SPKLEKO600

OVERVIEW
Thank you for using our product, this unit is designed for indoor using, its widel used for stage, building, disco, etc. as high
power led effects lighting, this unit can be operated as a single unit or multiple units for large applications. Direct input of
DMX512 signal to unit to allow it controlled by any DMX controller, powerful internal programs and friendly and convenient
operation interface allows customers to program freely to any different lighting project requirements for installation or
showing.
This high power par can has gotten the nice sculpt, efficient, save electricity and durable。
This product complies with the following standards:
Technical Parameter:
 LED POWER: 600W
 LED Color: 3000K - 6000K
 Led Lamp: Imported Led
 Voltage: AC100-240V
 Max.power consumption: 390W
 Fixed Lens: 19°/26°/36°/50°(optional)
 LED Life Time: over 50,000 hours
 Iris: optional
 Dimming Curve: 4 kinds
 Dimming Mode Frequency: 500HZ - 25000HZ optional
 Strobe :1-25times/sec
 Focus: Can be adjusted by hand
 Technology: High-quality optical system , glass reflector
 Light body: Die Casting Aluminum
 Body color: Black
 Feature of housing: sturdy and durable,corrosion-resistance and Oxidation resistance.
 Control Protocol: DMX
 Control System: DMX, Master/Slave
 DMX Channels: 2CH
 Working Temperature: -30~40℃
 Cooling system: No noise fan (copper tube)
 IP Grade: IP20

1. Product Introduction
1.1.Product Feature
2 kinds of running model
External control mode (Slave model)
DMX 512 controller control(2 kinds channel modes)
Master/salve model control (auto match the signal from controller and the Master light, no
need to set by menu)
static mode (Master model)
It can fix any color without the controller ,also work this color with strobe
Non-linear dimmer and linear dimmer
The speed of dimmer can be set under the controller control
Screen Protect
It will enter blank screen without any operate on the keyboard in 30 seconds . Press any keys then
it can quit screen protection.
Temperature Protection
It can be set to temperature protection mode
Speed of the Fan
The fan will start to work when the working temperature reach 40 degree, and the speed will be
changed according to the change of temperature.
Can be Reverse display
1.2. Multi-light working in the same time
When using controller to control multi lights to work in strobe, the controller just send the channel data .
The strobe effect will be depend on each light itself . And please take attention for the follow situation:
1. There will be many situations make the lights are not synchronization in the beginning. (For
example: the different time of opening the light , or different time of them connect to the controller) .In this
case, you can change value of the controller( for example push 20 to 0, and back to 20), then it can be
synchronization.
2. Due to crystal frequency of different lights are not the same exactly, so it may not be
synchronization after long time.
3. If need to keep synchronization for long time, there are two ways to do so:
A. Using the controller to edit program make the strobe, auto run effect,then they must be
synchronization.
B. Using the Maser/Slave model

2. Main Menu
2.1. Main Menu
2.2. Operation Status
Mode
Display
Description
DMX Mode
Dxxx
Dstand for DMX mode
Temperature
Mode
M-WP
Mstand for stand Master, WPstand forWhite
Point
Reverse Display
Running Status
Vice Menu Button

3. DMX Menu & Channel data
3.1 DMX menu
Enter DMX mode:
1. If you are in DMX mode,the main menu will turn into DMX menu automatically after 5 seconds
2. Menu of DMX address (DMX mode) will turn into DMX menu automatically after 5 seconds
Quit DMX mode
1. Screw mode: Press knob 2.
2. Touch mode: Touch any area out of “DMX”in DMX menu (press “DMX”is enter the menu for
setting DMX address)
DMX Menu Operation:
1. DMX mode: When the DMX 512 signal is connected correctly and the data of channel 1 which is
bigger than 0, use the received DMX data value for dimmer and temperature control (See the channel
data sheet). This moment knob 1 and knob 2 can not be used in dimmer; knob 1 only use for menu
operation. For example, Changing the DMX address: press knob 1 to enter or exit the editing status.
(Turn left or right for changing the dmx address)
2. Screw mode: When disconnect DMX signal or the channel 1 data is 0, can use knob 1 for the
dimmer, knob 2 for color temperature.

3.2 Channel data
Channel
Data
Function
Mark
Channel 2 data mnemonic
1
0
Screw Mode
Knob 1 is for dimmer
1~255
Dimmer
2
0~11
3000K
Color temperature 1
8 = 1*8
Totally 31 kinds of color
temperature.
Quick color: If you need
the color of N, then take
the data value of N*8. For
example you need the
color 1: 1*8, to push the
channel data in 8.
12~19
3100K
Each 8 data is for a
color temperature
16 = 2*8
20~235
3200K~5800K
(V = N*8)
236~24
3
5900K
240 = 30*8
244~25
5
6000K
Color temperature 31
248 = 31*8
4.Vice Menu
4.1 Master Mode:
Menu
State
Operation
Intensity
Dimmer󴔩0~100%󴔪
Press knob 1 to enter or exit the editing of address
data. (Turn left or right for changing the data)
White Point
Color temperature󴔩3000~6000K󴔪
4.2 Status
Software
Name of software
Version
Version
Temperature
Show the current temperature of the fixture
DMX Status
Show“OK”󴔩 Slave󴔭with DMX signal󴔪󴔭“ NONE”󴔩 Slave󴔭without DMX signal󴔪、 “Master”
󴔩Master󴔪
……
󴔩other󴔪

4.3 Setting
Menu
State
Option
Mark
Touch Screen Calibration
Touch Screen
Calibration
Dimmer Frequency
Choose the
dimmer frequency
2700K
……
Increase or decrease
with data of 100K
6500K
Dimmer Curve
Choose the
dimmer curve
Standard
Incandescent
Linear
Quick
Over Temperature
Set the protect
temperature
45~95
Increase or decrease
with data of 5
Backlight
Adjust the
Backlight
brightness
10%~100%
Increase or decrease
with data of 5%
Backlight Timeout
Set the screen
protect time
screen protect or screen
protect after 5~60 seconds
Increase or decrease
with data of 5
Load Factory Settings
Reset
5.Operation
5.1 Screw operation
For example of changing the brightness under the master mode
1. In main menu, turn the knob 1 and choose Master, press knob 1 for enter.
2. In the menu of white point, turn the knob 1, choose the Intensity
3. Press knob 1 enter editing status.
4. Turn knob 1 for choosing the brightness (Long press for increase or decrease continuously)
5. Press knob 1 exit edit status.

SAFETY WARNING
1. Warning
﹡Every person involved with the installation , operation and maintenance of this device has to be qualified .
﹡User must follow the instructions of this manual
﹡Unqualified person can not open the housing cover and operate the device , or the dealer will not accept liability for any
resulting defects or problems.
﹡The device against rain and moisture
2. Waring notes :
﹡Power supply : AC 100V-240V , 50/60Hz
﹡Make sure the power switch is off , the power plug , outlet and the earth connection is in well condition before connecting
the device with the mains.
﹡Please use qualified power plug and the outlet. Never connect the power cord of this device with other electrical
equipment.
﹡During move and installation , make sure the device not crashed with metal parts and other tough materials.
﹡Always disconnect from the mains, when the device is on the installation and dismantled
﹡The minimum distance between light-output and the illuminated surface must be more than 50cm
﹡The device must only be installed on a non-flammable surface . In order to safeguard sufficient ventilation , leave 50cm of
free space around the device . Please note that heat-sensitive objects may be deformed or damaged by the emitted heat .
﹡During the operation the housing becomes very hot ! Do not operate the device for 15 minutes after switching off .
﹡The maximum ambient temperature Ta = 45℃must never be exceeded , The maximum housing temperature Tb = 80℃
must never be exceeded .
﹡For indoor use
﹡Replace any visible cracked protective shield , filters and lens .
﹡The protective shiel, filters and lens will require weekl cleaning as smoke Cfluid tends to building up residues , reducing
the light Coutput ver quickl.
DISCLAIMER
1. The device is with one year warranty . The warranty period appear non-artificial quality problem, this company is
responsible for free maintenance
2. User violate operation caused the machine failure, this is user responsibility.
3. If due to the wrong operation or intense impact caused product destroy even safety accidents, the manufacturer does not
undertake any responsibility
4. Prohibit replaced product components by any person, therefore caused any consequences will be whose responsible
Please contact us freely when you need our related products or information...
