GE BT22 Series User manual

Installation Guide
imagination at work
(For BT22 Series of CE version)
LED Luminaires
BEFORE YOU BEGIN
Read these instructions completely and carefully.
Save These Instructions
Use only in the manner intended by the manufacturer. If you have any questions, contact the manufacturer.
Tools and components required:
• Phillips head screwdriver.
• UL approved conduit tting.
• UL approved twist-on wire connectors.
Prepare Electrical Wiring
Electrical Requirements
• LED driver must be supplied with 220-240 VAC, 50/60 Hz and connected to an individual properly grounded branch circuit,
protected by a 15 or 20 ampere circuit breaker. Use Min. 75 °C supply conductor.
Grounding Instructions
• The grounding and bonding of the overall system shall be done in accordance with National Electric Code (NEC) Article 600
and local codes.
WARNING
RISK OF ELECTRIC SHOCK
• Turn power off before inspection, installation or removal.
• Properly ground electrical enclosure.
RISK OF FIRE
• Follow all NEC or IEC and local codes.
• Use only UL or IEC approved wire for input/output connections.
Minimum size 18 AWG (0.75 mm2).

Unit Installation
Electrical Connections
2
4
2Install the unit into the reserved
hole in the ceiling.
Remove knockout and insert
grommet. Unscrew the strain
relief.
Replace electrical enclosure cover.
1
1
Carefully unpack unit from its
packaging. Properly inspect for
defects before installing. Wear
work gloves to prevent dirt and
oil from being transferred to the
luminaire.
Remove electrical enclosure cover. 3Connect the AC line according to
the L-N-G label to the terminal
block through the strain relief.
Screw the strain relief tightly to x
the cable.
905306
GE Lighting Solutions • www.gelightingsolutions.com
GE Lighting Solutions, LLC is a subsidiary of the General Electric Company. Lumination is a trademark of GE Lighting Solutions, LLC. The GE brand and logo are trademarks of the General Electric Company.
© 2013 GE Lighting Solutions, LLC. Information provided is subject to change without notice. All values are design or typical values when measured under laboratory conditions.
Grommet
Strain relief
Optional: Attach the supplied
L-shape safety brackets to the
back of the xture. Hang the unit
through the holes of the bracket
with a cable.
3
