Installation Guide
IND327
Lumination®LED Luminaire
Construction Frame
(LRX Series)
BEFORE YOU BEGIN
Read these instructions completely and carefully.
WARNING/AVERTISSEMENT
RISK OF ELECTRIC SHOCK
• Turn power o before inspection, installation or removal.
• Properly ground electrical enclosure.
RISK OF FIRE
• Follow all NEC and local codes.
• Use only UL approved wire for input/output connections.
Minimum size 18 AWG or 14 AWG for continuous runs.
RISQUES DE DÉCHARGES ÉLECTRIQUES
• Coupez l’alimentation avant d’’inspecter, installer ou déplacer le luminaire.
• Assurez-vous de correctement mettre à la terre le boîtier d’alimentation
électrique.
RISQUES D’INCENDIE
• Respectez tous les codes NEC et codes locaux.
• N’utilisez que des ls approuvés par UL pour les entrées/sorties de connexion.
Taille minimum 18 AWG ou 14 AWG pour les rangées continues.
Save These Instructions
Use only in the manner intended by the manufacturer. If you have any questions, contact the manufacturer.
Prepare Electrical Wiring
Electrical Requirements
The LED luminaire must be connected to the mains supply
according to its ratings on the product label.
NOTICE
Lamp Housings LRXS4, LRXS6, LRXS8 may be assembled with part FRAMExS. When Lamp Housings LRXS4, LRXS6, LRXS8 is assembled with Part
FRAMExS the nal assembly complies with UL 1598 category IFAO recessed luminaire requirements. LRX products are suitable for wet location
covered ceiling only.
Les boîtiers de lampes LRXS4, LRXS6, LRXS8 peuvent être montés avec la pièce FRAMExS. Lorsque les boîtiers des lampes LRXS4, LRXS6, LRXS8 sont
montés avec la pièce FRAMExS, le montage inal respecte les exigences des luminaires encastrés de la catégorie IFAO de la norme UL 1598. LRX
produits conviennent pour emplacement humide couverte au plafond uniquement.
Grounding Instructions
The grounding and bonding of the overall system shall be
done in accordance to local electric code of the country
where the luminaire is installed.

LED.com
© 2023 Current Lighting Solutions, LLC. All rights reserved. Information and specifications subject to change
without notice. All values are design or typical values when measured under laboratory conditions.
Page 2 of 4
(Rev 05/19/23)
IND327-Lumination-LRX-Series-Square-LED-Luminaire-Installation-Guide_R01
Lumination®(LRX - Series) Installation Guide
Components
Cut the appropriate size hole into ceiling tile.
12
L-brackets
Mounting brackets
Place side L-brackets on existing frame screws and tighten
with screwdriver on both sides of the frame. Then attach
mounting brackets to both L-brackets with wing nuts
(provided).
Adjust frame aperture size to be suitable for xture, ensure
the xture center installed. Then tighten both mounting
bracket wing nuts.
3
Adjust aperture
4
Slide hanger bars through adjustable mounting brackets.
1
2
3
456
2
1
3456
Provided Item Qty.
1 Frame (4-inch, 6-inch or 8-inch) 1
2 Mounting brackets 2
3 L-Bracket 2
4 U-Bracket 1
5 Adjustable Bracket 2
6 Wing nut 7
NOTE: Part 4 is only for LRX EMBB version
Frame Installation
Fixture Size Square Hole Size
LRXS4 4.9-5.2 inch x 4.9-5.2 inch
LRXS6 5.95-7.5 inch x 5.95-7.5 inch
LRXS8 7.95-9.5 inch x 7.95-9.5 inch

LED.com
© 2023 Current Lighting Solutions, LLC. All rights reserved. Information and specifications subject to change
without notice. All values are design or typical values when measured under laboratory conditions.
Page 3 of 4
(Rev 05/19/23)
IND327-Lumination-LRX-Series-Square-LED-Luminaire-Installation-Guide_R01
Lumination®(LRX - Series) Installation Guide
Lumens Setting Switch
Option A: Mount xture by attaching hanger bars to T-Grid
ceiling (BH3 SKU 94890).
Option B: Mount xture with ½” EMT conduit.
Note: Supplied by 3rd party.
5
Bars Conduit
A B
6
Adjust height and
tighten wing nut
Adjust xture height to be ush with ceiling and tighten
both mounting bracket wing nuts.
Input and dimming
wires from J-box
AC line and dimming wires
0-10 Volt Dimming (Optional)
Gray0-10V –
0-10V +
Violet
To 0-10V
Dimmer
LED
Driver
Wiring Diagram
L
NLRX
Fixture
Black
White
GroundGreen/Yellow
7
Connect conduit end with input leads to existing junction box and make proper connections. Connect the black, white, and green/yellow
wires of the input leads to the black, white and green wires using twist-on wire connectors and close junction box.
Optional dimmer: When connecting with dimming controller, wires must be run through another separate knockout hole. Connect the
violet (dimming +) and gray (dimming -) wires to the violet and gray wires of the xture.
NOTE: Please cover dimming leads with wire nuts if you won’t connect with dimming leads.
LRX-Series Mounting
Maximum Quantity Of Fixtures That Can Be
Connected With One Dimmer
NOTE: For 1000/650lm product, default output lumen is 1000lm.
Push switch up to activate 650lm.
No. Dimmer Type
Maximum
Fixture
Quantity
1QSN - 4T16 - S 80
2GRX TV1 with Grak Eye QS Main Unit 520
3NTFTV/NFTV/DVTV with PP - 120 40
4 TVM2 Module 80
5TVI - LMF -2S 35

LED.com
© 2023 Current Lighting Solutions, LLC. All rights reserved. Information and specifications subject to change
without notice. All values are design or typical values when measured under laboratory conditions.
Page 4 of 4
(Rev 05/19/23)
IND327-Lumination-LRX-Series-Square-LED-Luminaire-Installation-Guide_R01
Lumination®(LRX - Series) Installation Guide
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation. CAN ICES-005 (A) / NMB-005 (A).
Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference
to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to
correct the interference at his own expense.
Connect the two quick connectors and reassemble the
connector box.
8
Reassemble
connector box
Connect plugs:
3 pole to 3 pole
2 pole to 2 pole
9
Spring
Load springs into upright position by twisting the springs
upward and carefully insert the xture to the hole of the
frame. Verify reector trim is ush with ceiling.
NOTE: Please make sure the spring rides on the bracket
with the arrow mark.
CAUTION
RISK OF PERSONAL INJURY - Operators shall ensure no appendages
are in the path of the torsion springs as they are a pinch hazard when
released. The springs will release when the arm is exed downward. Be
cautious that no body part is in the path of the spring when released.
RISQUE DE BLESSURE CORPORELLE - Les techniciens veilleront à
ce qu’aucun appendice ne se trouve sur le chemin des ressorts de
torsion, car ils présentent un risque de pincement lorsqu’ils sont
libérés. Les ressorts seront libérés au moment de échir le bras vers le
bas. Faites attention à ce qu’aucune partie du corps ne se trouve sur le
chemin du ressort à sa libération.
