GE OEC 9800 C-Arm Setup guide

OEC 9800® C-Arm
Illustrated Parts Manual
00-881712-02
Contents Installation Service Schematics Periodic Maintenance Illustrated Parts

2
OEC 9800 C-Arm Illustrated Parts Manual
Contents Installation Service Schematics Periodic Maintenance Illustrated Parts
This manual may not be reproduced in whole or in part, without written permission of GE OEC Medical Systems,
Inc.
The contents of this document are accurate at the time of publication. However, changes in design and additional
features can, at any time, be incorporated in the hardware and software and may not be reflected in this version of
the document. Contact GE OEC Technical Support for clarification, if discrepancies arise.
OEC and OEC 9800 are registered trademarks of GE OEC Medical Systems, Inc. Other products and company
names mentioned herein are the property of their respective owners.
The OEC 9800 C-Arm is covered under one or more of the following U.S. and foreign patents:
5,596,228;5,426,683;5,506,882;5,583,909;4,797,907;07/638,176.
OtherU.S. and foreignpatents pending.
Made in the U.S.A.
© 1999, 2001
GE OEC Medical Systems, Inc.
384 Wright Brothers Drive
Salt Lake City, Utah 84116
U.S.A.
All rights reserved

3
OEC 9800 C-Arm Illustrated Parts Manual
Contents Installation Service Schematics Periodic Maintenance Illustrated Parts
Introduction
Purpose
This manual contains information on the OEC 9800 C-Arm. It serves as an aid to field service engineers and technicians
in locating parts and identifying part numbers. It is not a complete parts list and should not be used as a substitute for a
bill of materials.
NOTE: The item numbers on the illustrations do not match the item numbers on the assembly drawings or the
item numbers on the Bills of Materials.
Intended Audience
This manual is intended for the properly trained engineer or technician who designs, installs, maintains or calibrates the
[ProductName].
Removing or installing parts should not be attempted by anyone who is not specifically trained by GE OEC Medical
Systems,Inc.
How to Use this Manual
This manual is formatted and intened for CD distribution. This manual is organized using navigation screens. Click on
the section of interest and then refer to the table of contents on the front page to locate the information you require.

4
OEC 9800 C-Arm Illustrated Parts Manual
Contents Installation Service Schematics Periodic Maintenance Illustrated Parts
Manual Revision History
Rev Dash Date Change Description
A -01 September, 1999 Manufacturing release.
B -02 December, 1999 Added Super C, and incorporated editorial changes.
C -02 February, 2001 Format changes.

5
OEC 9800 C-Arm Illustrated Parts Manual
Contents Installation Service Schematics Periodic Maintenance Illustrated Parts
Table of Contents
Introduction................................................................................................................................................................3
Purpose ...............................................................................................................................................................3
Intended Audience...............................................................................................................................................3
How to Use this Manual .......................................................................................................................................3
Revision History ........................................................................................................................................................4
Figure1. Covers Parts List......................................................................................................................................8
Covers Exploded View ............................................................................................................................9
Figure 2. II, Camera Parts List...............................................................................................................................10
II, Camera Exploded View......................................................................................................................11
Figure3. X-Ray Tube, Collimator Parts List ..........................................................................................................12
X-Ray Tube, Collimator Exploded View .................................................................................................13
Figure4. Internal Cover Parts List.........................................................................................................................14
Internal Cover Exploded View ...............................................................................................................15
Figure5. Battery,PowerParts List ........................................................................................................................16
Battery, Power Panel Exploded View .....................................................................................................17
Figure6. StatorCapaitor/Transformer Parts List ...................................................................................................18
Stator Capaitor/Transformer Exploded View ..........................................................................................19
Figure7. Power Panel Parts List...........................................................................................................................20
Power Panel Exploded View..................................................................................................................21
Figure8. Electronics Parts List .............................................................................................................................22
Electronics Exploded View ....................................................................................................................23
Figure9. Card Rack Parts List ..............................................................................................................................24
Card Rack Exploded View.....................................................................................................................25
Figure 10. IGBT/Snubber, Tank Parts List ...............................................................................................................26
IGBT/Snubber, Tank Exploded View ......................................................................................................27
Figure 11. Power Supply Parts List.........................................................................................................................28
Power Supply Exploded View................................................................................................................29

6
OEC 9800 C-Arm Illustrated Parts Manual
Contents Installation Service Schematics Periodic Maintenance Illustrated Parts
Figure 12. Control Panel, L-Arm Parts List..............................................................................................................30
Control Panel, L-Arm Exploded View.....................................................................................................31
Figure 13. Control Panel Parts List .........................................................................................................................32
Control Panel Exploded View ................................................................................................................33
Figure 14. L-Arm Parts List (1of 3) ..........................................................................................................................34
L-Arm Exploded View (1of 3) .................................................................................................................35
Figure 15. L-Arm Parts List (2 of 3)..........................................................................................................................36
L-Arm Exploded View (2 of 3) ................................................................................................................37
Figure 16. L-Arm Parts List (3 of 3)..........................................................................................................................38
L-Arm Exploded View (3 of 3) ................................................................................................................39
Figure 17. 9”Flip Flop Parts List ............................................................................................................................40
9”Flip Flop Exploded View ...................................................................................................................41
Figure 18. 12”Flip Flop Parts List ..........................................................................................................................42
12”Flip Flop Exploded View .................................................................................................................43
Figure 19. Vertical Column, Cross Arm Parts List ...................................................................................................44
Vertical Column, Cross Arm Exploded View..........................................................................................45
Figure 20. Cross Arm Brake Parts List ....................................................................................................................46
Cross Arm Brake Exploded View...........................................................................................................47
Figure 21. Cross Arm Housing Mount Parts List .....................................................................................................48
Cross Arm Housing Mount Exploded View ............................................................................................49
Figure 22. Cross Arm Brake, Bearing Parts List......................................................................................................50
Cross Arm Brake, Bearing Exploded View ............................................................................................51
Figure 23. Cross Arm Bearings Parts List ...............................................................................................................52
Cross Arm Bearings Exploded View......................................................................................................53
Figure 24. Rear Steering Parts List (1 of 2) .............................................................................................................54
Rear Steering Exploded View (1 of 2)....................................................................................................55
Figure 25. Rear Steering Parts List (2 of 2) .............................................................................................................56
Rear Steering Exploded View (2 of 2)....................................................................................................57

7
OEC 9800 C-Arm Illustrated Parts Manual
Contents Installation Service Schematics Periodic Maintenance Illustrated Parts
Figure 26. Rear Brake Parts List .............................................................................................................................58
Rear Brake Exploded View....................................................................................................................59
Figure 27. Front Caster Parts List............................................................................................................................60
Front Caster Exploded View ..................................................................................................................61
Figure 28. Steering Chain, Cable Pusher Parts List ...............................................................................................62
Steering Chain, Cable Pusher Exploded View ......................................................................................63
Figure 29. Rear Caster Parts List............................................................................................................................64
Rear Caster Exploded View...................................................................................................................65
Figure 30. Super C II, Camera Parts List (1 of 2).....................................................................................................66
Super C II, Camera Exploded View (1 of 2)............................................................................................67
Figure 31. Super C II, Camera Parts List (2 of 2).....................................................................................................68
Super C II, Camera Exploded View (2 of 2)............................................................................................69
Figure 32. Super C X-Ray Tube Parts List ..............................................................................................................70
Super C X-Ray Tube Exploded View .....................................................................................................71
Figure 33. Super C Collimator Parts List.................................................................................................................72
Super C Collimator Exploded View .......................................................................................................73
Figure 34. Super C L-Arm Parts List .......................................................................................................................74
Super C L-Arm Exploded View ..............................................................................................................75
Figure 35. Super C Flip Flop Parts List...................................................................................................................76
Super C Flip Flop Exploded View..........................................................................................................77

8
OEC 9800 C-Arm Illustrated Parts Manual
Contents Installation Service Schematics Periodic Maintenance Illustrated Parts
Item Part Number Description Qty
1 12-225108-08 Screw, SEMS, Spring,Pan, Torx,8x32,1 4
2 00-879829-01 Cover,Front,Top 1
3 12-225108-08 Screw, SEMS, Spring,Pan, Torx,8x32,1 4
4 00-881292-01 Cover,Leg,Front 1
5 12-311114-12 Screw, NA, Socket,Hex, 1/4-20,3/4, SZC,8 2
6 12-225160-06 Screw, SEMS, Spring,Pan, Torx,10x32 4
7 12-225108-06 Screw, SEMS, Spring,Pan, Torx,8x32,3/8,SZC 3
8 00-880428-01 Cover,Front,Right 1
9 12-313915-26 Screw, NA, Socket, Hex,5/16-18,1 3/4, SBO, 8 4
10 00-880897-01 End Cap,Cross Beam 2
11 12-225160-06 Screw, SEMS, Spring,Pan, Torx,10x32 2
12 00-876038-01 Cover, Cross Beam 1
13 13-311106-00 Nut, Hex-Lock-External-T, 6-32, SST, NA, A=.313 2
14 00-879830-01 Assembly, Rear Cover 1
15 00-876692-02 Cover, Label,Back Door 1
16 12-311115-20 Screw, NA, Socket,Hex, 5/16-18,1, SZC, 8 3
17 00-877505-01 Spacer, Cover, Label 1
18 00-877478-01 Panel,Label 1
19 00-877388-02 Stiffner, Cover Label 1
20 00-880427-01 Cover,Front,Left 1
21 12-225108-06 Screw, SEMS, Spring,Pan, Torx,10x32 3
22 00-901627-02 Assembly,Hand Control, 4 Button 1
23 00-881060-02 Assembly, Footswitch 1
Figure 1. Covers Parts List

9
OEC 9800 C-Arm Illustrated Parts Manual
Contents Installation Service Schematics Periodic Maintenance Illustrated Parts
Figure 1. Covers Exploded View
1
2
21
20
34
5
6
7
8
10
9
12
11
13
14
15
16
17
18
19
22
23

10
OEC 9800 C-Arm Illustrated Parts Manual
Contents Installation Service Schematics Periodic Maintenance Illustrated Parts
Item Part Number Description Qty
1 12-311114-12 Screw, NA,Socket, Hex, 1/4-20, 3/4, SZC,8 2x
2 00-880691-01 Machining,Cover, Camera 1
3 00-881130-01 Weight,Counter, Rear,9-Inch 1
4 12-225108-08 Screw,SEMS, Spring,Pan, Torx, 8x32, 1 2
5 00-880854-01 Shield,Camera, EMI, 9-Inch 1
6 12-225106-06 Screw,SEMS, Spring,Pan, Torx, 6x32, 3/8,SCZ 8
7 51-500507-00 Hardware Kit, Connector, Jack,Socket,Set, 4-40,.50L 2
8 00-880688-01 Weldment, Mount, Connector,Camera, Cover 1
9 00-877690-01 Shield,Cover, Camera 1
10 12-312060-08 Screw,NA,Socket,Hex,10-32, 1/2, SST 3
11 12-225106-20 Screw,SEMS, Spring,Pan, Torx, 6-32,1, SCZ 4
12 00-879126-01 Assembly, CCD Camera, 1K x 1K, 9" 1
12 00-879127-01 Assembly, CCD Camera, 1K x 1K, 12" 1
13 22-429863-00 Standoff,Hex,M/F,1/4-20,3.250L,SST 12
14 00-901226-02 Intensifier, Image,HX, Rear Mount, 9" 1
14 00-901083-01 Intensifier, Image,HX, Rear Mount, 12" 1
15 00-871303-01 Gasket, X-Ray Grid 1
16 00-901200-01 Grid,X-Ray, 10.1, 9-Inch 1
17 12-215004-05 Screw,Machine,Flange,Torx,4-40, 5/16, SZC 6
18 12-225108-12 Screw,SEMS, Spring,Pan, Torx, 8x32, 3/4,SCZ 4
19 00-881075-01 Handle C 2
20 12-225108-12 Screw,SEMS, Spring,Pan, Torx, 8x32, 3/4,SCZ 4
21 12-311114-12 Screw, NA,Socket, Hex, 1/4-20, 3/4, SZC,8 4
22 00-881193-01 Assembly, Mount, Image Intensifier,9-Inch 1
23 12-313915-20 Screw,NA,Socket,Hex,5/16-18, 1, SBO,8 4
Figure 2. II, Camera Parts List

11
OEC 9800 C-Arm Illustrated Parts Manual
Contents Installation Service Schematics Periodic Maintenance Illustrated Parts
Figure 2. II, Camera Exploded View
1
2
3
54
6
8
7
9
11
12
14
10
13
15
16
17
19 18
20
18
19
21
23
22

12
OEC 9800 C-Arm Illustrated Parts Manual
Contents Installation Service Schematics Periodic Maintenance Illustrated Parts
Item Part Number Description Qty
1 00-880706-01 Cover,Collimator 1
2 00-877031-01 Clip, Collimator Cover 1
3 12-225160-12 Screw, SEMS, Spring, Pan, Torx, 10-32, 3/4, SZC 2
4 00-879575-01 Collimator, Secondary, 9-Inch, 3 Pot 1
5 12-225108-06 Screw,NA, Socket, Hex, 10-32,3/4, SZC 4
6 00-880430-02 Assembly, Collimator, Base Unit 1
7 12-211114-14 Screw,NA, Socket, Hex, 1/4-20, 7/8,SZC, 8 6
8 00-876567-02 Bumper,X-Ray Mount 1
9 12-225106-06 Screw,SEMS,Spring,Pan, Torx, 6-32,3/8,SZC 6
10 22-678482-00 Ring, Retaining,Internal,Spl, 2.312 SST 1
11 00-880838-01 Collimator, Primary 9-Inch 1
12 00-880855-01 Spacer, Foam, primary, Collimator 1
13 00-877286-01 Cover, X-Ray Tube 1
14 00-881519-01 Assembly,X-Ray Tube,ExternalMount 1
15 00-901753-01 Assembly,ThermalSwitch (not exploded for clarity) 1
16 12-225160-10 Screw,NA, Socket, Hex, 10-32,5/8, SZC 2
17 00-875607-01 Cover, High Voltage Cable 1
18 00-901141-01 Cable, High Voltage Control, Standard (not exploded orshown for clarity) 1
19 00-901141-03 Cable, High Voltage Control, Super C& Cardiac (notexploded or shown forclarity) 1
20 00-877320-02 Assembly, Skin Spacer (not shown) 1
21 00-881499-01 Assembly,Temp Sensor, X-Ray (notexploded or shown for clarity) 1
Figure 3. X-Ray Tube, Collimator Parts List

13
OEC 9800 C-Arm Illustrated Parts Manual
Contents Installation Service Schematics Periodic Maintenance Illustrated Parts
Figure 3. X-Ray Tube, Collimator Exploded View
1
2
3
4
5
6
7
8
10
11
12
13
14
9
17
16
15

14
OEC 9800 C-Arm Illustrated Parts Manual
Contents Installation Service Schematics Periodic Maintenance Illustrated Parts
Item Part Number Description Qty
1 00-879982-01 Cover,Generator Driver 1
2 20-840090-00 Fan, Axial,Blo, 12VDC, 25CFM,3050RPM 1
3 12-255106-22 Screw, SEMS, Spring, Pan, Torx,6-32,1-1/4,SZC 3
4 00-881125-01 Duct,Fan 1
5 12-225108-08 Screw, SEMS, Spring, Pan, Torx,8-32,1/2, SZC 2
6 12-225106-08 Screw, SEMS, Spring, Pan, Torx,6-32,1/2, SZC 4
7 00-879694-01 Cover, Front,Card Rack 1
8 12-225108-08 Screw, SEMS, Spring, Pan, Torx,8-32,1/2, SZC 8
9 00-879992-01 Cover,Componenttray 1
10 14-181110-00 Washer, Plain, #10, SST, MS15795-808,ID=.221 1
11 12-225108-06 Screw, SEMS, Spring, Pan, Torx,8-32,3/8, SZC 1
12 12-225108-06 Screw, SEMS, Spring, Pan, Torx,8-32,3/8, SZC 9
13 00-881127-01 Ring, Expansion Chamber 1
14 12-225104-04 Screw, SEMS, Spring, Pan, Torx,4-40,1/4, SZC 4
Figure 4. Internal Cover Parts List

15
OEC 9800 C-Arm Illustrated Parts Manual
Contents Installation Service Schematics Periodic Maintenance Illustrated Parts
Figure 4. Internal Cover Exploded View
1
2
3
4
5
14
13
12
11 10
6
7
9
8

16
OEC 9800 C-Arm Illustrated Parts Manual
Contents Installation Service Schematics Periodic Maintenance Illustrated Parts
Item Part Number Description Qty
1 12-225108-06 Screw,SEMS, Spring, Pan, Torx, 8-32, 3/8,SZC 2
2 00-879870-01 Assembly, Stator Capacitor/Transformer 1
3 12-225108-06 Screw,SEMS, Spring, Pan, Torx, 8-32, 3/8,SZC 4
4 00-879124-01 Assembly, Power Panel 1
5 00-880519-01 Gasket, Lemo Connector 1
6 12-225109-10 Screw,SEMS, Spring, Pan, Torx, 8-32, 5/8,SZC 4
7 00-879325-01 PCB, Power/MotorRelay 1
8 12-225108-06 Screw,SEMS, Spring, Pan, Torx, 8-32, 3/8,SZC 1
9 00-880406-02 Assembly,Capacitor/Power Module 1
10 00-900589-01 Battery Pack 1
11 00-875583-01 Retainer, Battery 2
Figure 5. Battery, Power Panel Parts List

17
OEC 9800 C-Arm Illustrated Parts Manual
Contents Installation Service Schematics Periodic Maintenance Illustrated Parts
Figure 5. Battery, Power Panel Exploded View
1
2
See figure 6
3
4
See figure 7
5
6
7
9
8
11
10

18
OEC 9800 C-Arm Illustrated Parts Manual
Contents Installation Service Schematics Periodic Maintenance Illustrated Parts
Item Part Number Description Qty
1 12-225108-06 Screw,SEMS, Spring, Pan, Torx, 8-32, 3/8,SZC 4
2 00-901193-01 Transformer, Stator/Precharge 1
3 00-879792-01 Bracket, Mounting,Transformer 1
4 00-879980-01 Plate,Multi-Output, Transformer 1
5 12-225108-08 Screw,SEMS, Spring, Pan, Torx, 8-32, 1/2,SZC 4
6 00-901148-02 Transformer, Multi-Output 1
7 12-225108-08 Screw,SEMS, Spring, Pan, Torx, 8-32, 1/2,SZC 1
8 41-599065-00 Capacitor,AC Motor,40uF, 330VAC, 10%, Terminals 1
9 41-599057-00 Capacitor,AC Motor,30uF, 240VAC, Terminals 1
10 00-880759-01 Plate, Capacitor Clamp 1
11 55-700477-00 Circuit Breaker, 1A, SPST, 250VAC, PanelMounting 1
12 12-225108-06 Screw,SEMS, Spring, Pan, Torx, 8-32, 3/8,SZC 3
Figure 6. Stator Capacitor/Transformer Parts List

19
OEC 9800 C-Arm Illustrated Parts Manual
Contents Installation Service Schematics Periodic Maintenance Illustrated Parts
Figure 6. Stator Capaitor/Transformer Exploded View
1
2
3
12
10
11
4
5
6
7
9
8

20
OEC 9800 C-Arm Illustrated Parts Manual
Contents Installation Service Schematics Periodic Maintenance Illustrated Parts
Item Part Number Description Qty
1 00-879021-01 Assembly, Power/SignalInterface, PCB 1
2 13-311106-00 Nut,Hex-Lock-External, 6-32, SST, NA, A=.313 2
3 15-608092-00 Terminal, Ring,Crimp, 16-14,#6,LRB6 1
4 22-012002-00 Clamp Cable/Wire, 5/8D, .50W,NYL 1
5 12-225106-06 Screw,SEMS,Spring,Pan, Torx, 6-32,3/8,SZC 1
6 00-901393-01 Power Supply, +5/+12/+-15 1
7 12-225106-06 Screw,SEMS,Spring,Pan, Torx, 6-32,3/8,SZC 1
8 22-012004-00 Clamp Cable/Wire, 1D, .50W,NYL 1
9 15-608092-00 Terminal, Ring,Crimp, 16-14,#6,LRB6 1
10 13-311106-00 Nut,Hex-Lock-External, 6-32, SST, NA, A=.313 1
11 12-225106-06 Screw,SEMS,Spring,Pan, Torx, 6-32,3/8,SZC 4
12 00-879455-01 Cable Assembly, Backplane -Hand/Foot Switch 1
13 00-879455-01 Cable Assembly, Backplane -Hand/Foot Switch 1
14 67-430003-00 Indicator Lamp, Neon, 125V, Green 1
15 00-879455-01 Cable Assembly, Backplane -Hand/Foot Switch 1
16 00-879793-01 Weldment,Power Panel 1
17 00-901683-01 Key,Mainframe, 9800,with OECLogo (not shown) 1
Figure 7. Power Panel Parts List
