3ENGLISH
INTRODUCTION
In accord with Regulation (EU) 2017/745, this product
ispartoftheCLASSIMEDICALDEVICES.Youshould
carefully read this manual before using this medical
device.
DESCRIPTION
This item is a folding couch in chromed steel with a
suitcase,resinpaddingandre-retardantfabriccovering
(black colour). Supplied with a velvet bag for easy
transport.Designedforhomevisitsortherapiesinclinics
wherearenocouch.
A.
A B
Closedsuitcasesittingside
B.Closedsuitcasebackrestside
Bag/coveringmade fromthe samefabric asthe couch
mattress
ASSEMBLY INSTRUCTIONS:
1. Laydownthesuitcasewiththehandleontheupper
side.
2. Openthesuitcase.
3. Openthelegsofthebedcompletely.
4. Only when the legs are completely open and xed,
Turnthebedinthecorrectpositionofuse.
TECHNICAL DATA
Measurement
Opencm187.5x64
(68withhandle)x71.5h
Closecm93x68x14
Weight 16.5kg(withbox18kg)
Max capacity 100kg
WARNINGS!
-Check the locking nuts are tightened.
-Observe the maximum ow rates indicated in the
data sheets.
-Avoid direct contact with open wounds.
-Not for use in open environments.
-When adjusting the height of the couch and the
back, make sure that no one inserts hands, legs or
anything into the movement area: CRUSHING RISK!
-Lay the patient only when the net (seat and back) is
completely horizontal.
-Move the bed without lifting it from the oor.
-Before moving the bed, unlock the wheels.
MAINTENANCE AND CLEANING
-Use only original spare parts.
-Periodically check all xing points.
-To preserve at best, it is recommended to avoid
prolonged exposure to sunlight, to contact and deposit
in saline and very humid environments.
-Wash the stainless steel surfaces with soapy water and
use appropriate disinfectants.
-Rinse with a damp cloth and dry thoroughly.
-Do not spill on the surface cleaners containing chlorine
or ammonia, fatty and oily substances.
-Do not use cleaning utensils containing iron. If necessary
disinfection only use suitable non-corrosive products.
CLEANING RULES FOR COATING:
Clean with damp soapy cloth and rinse well with
clean water. Do not use solvents, bleaches, synthetic
detergents,polishesoraerosolspray.Attention:Normally
syntheticleatherlightcoloursshouldnotcomeincontact
withnoxedclouredclothes(suchasjeansandsimilar)
nottocausestainsandringsthatcannotbecleanedup.
Keep away from
sunlight
Medical Device
compliant with
Regulation (EU)
2017/745
Product code Consult instructions
for use
Caution: read
instructions
(warnings)
carefully
Lot number
Keep in a cool, dry
place Manufacturer
Medical Device
GIMA WARRANTY TERMS
TheGima12-monthstandardB2Bwarrantyapplies.
