Gima 35134 User manual

MULTI-PARAMETER PATIENT MONITOR
M35134-GB-Rev.5-10.20
User Manual
PROFESSIONAL MEDICAL PRODUCTS
35134
Gima S.p.A.
Via Marconi, 1 - 20060 Gessate (MI) Italy
[e-mail] - [e-mail]
www.gimaitaly.com
Made in China
0476

I
Preface
Manual Purpose
The instructions for safe operation of product in keeping with its function and intended use are contained in this
manual. In order to operate product properly, and to protect both the patient and operator from injury,
compliance with this manual is first priority.
Based on the maximum configuration, some contents of this manual may not apply to your product. Please keep
in touch with the manufacturer or your local sales if you have any question.
As an indispensable portion of the product, this manual should always be placed near the equipment so that it
can be got easily when needed.
Only clinical professionals, anyone who are under their guidance of people who have been trained adequately
can use this monitor. The unauthorized or the untrained are forbidden to operate the product.
Intended Audience
This Manual applies to clinical professionals with knowledge medical procedures, practices and terminology
required for monitoring of critically ill patients.
Illustrations
Setup or data displayed on your monitor may not be necessarily shown in all illustrations within this Manual,
illustration are used only as examples.
All names mentioned in this Manual and illustrations are fictitious. Any similarity is purely coincidental.

II
Terms used in this User Manual:
"View": Main screen when there is no any pop-up window.
"Long press": The operation pressing shortcut key for over 3 seconds.
"SpO2": Oxygen saturation.
Notes:
This patient monitor can be customized with different functional modules, therefore, the monitor you
purchased may not cover all operations described.
Caution:
Federal law restricts this device to sale by or on the order of a physician.

III
Table of Contents
Chapter 1 Safety .....................................................................................................................................................1
1.1 Safety Information.......................................................................................................................................1
1.1.1 Warnings...........................................................................................................................................1
1.1.2 Cautions............................................................................................................................................2
1.1.3 Notes ................................................................................................................................................2
1.2 Equipment Symbols.....................................................................................................................................4
1.2.1 Symbol/Icon on the Device...............................................................................................................4
1.2.2 Icons List on the Screen....................................................................................................................5
Chapter 2 The Basics ..............................................................................................................................................7
2.1 Monitor Description ....................................................................................................................................7
2.1.1 Product Name and Model ................................................................................................................7
2.1.2 Intended Use ....................................................................................................................................7
2.1.3 Features............................................................................................................................................7
2.2 Main Unit.....................................................................................................................................................9
2.3 Display Screen .......................................................................................................................................... 13
2.3.1 Information Area ........................................................................................................................... 14
2.3.2 Parameter Area and Waveform Area ............................................................................................ 14
Chapter 3 Operations ............................................................................................................................................. 16
3.1 Installation................................................................................................................................................ 16
3.1.1 Unpacking and Checking ............................................................................................................... 16
3.1.2 Environmental Requirements........................................................................................................ 16
3.2 Getting Started ......................................................................................................................................... 17
3.2.1 Connecting to Power Source ......................................................................................................... 17
3.2.2 Turning the Monitor On................................................................................................................. 18
3.2.3 Starting Monitoring ....................................................................................................................... 18
3.3 Turning the Monitor Off ........................................................................................................................... 19
3.4 Using Keys................................................................................................................................................. 19
3.4.1 Shortcut Key .................................................................................................................................. 19
3.5 Using the Main Menu............................................................................................................................... 19
3.5.1 How to Select the Menu Item ....................................................................................................... 19

IV
3.6 Data Uploading......................................................................................................................................... 20
Chapter 4 Screen Display........................................................................................................................................ 21
4.1 SpO2 Trend Data List Screen..................................................................................................................... 21
4.1.1 Screen Description......................................................................................................................... 21
4.1.2 Operating Instructions................................................................................................................... 21
4.2 NIBP Data List Screen ............................................................................................................................... 21
4.2.1 Screen Description......................................................................................................................... 21
4.2.2 Operating Instructions................................................................................................................... 22
4.3 Screen Display for Graphic Trend ............................................................................................................. 22
4.3.1 How to View the Graphic Trend .................................................................................................... 22
4.3.2 Operation Instructions................................................................................................................... 24
4.4 Screen Display for Waveform Recall......................................................................................................... 24
4.4.1 Operation Instructions................................................................................................................... 25
4.5 Screen Display for Arrhythmia Event List ................................................................................................. 27
4.5.1 Operation Instructions................................................................................................................... 27
4.6 Screen Display for System Setting ............................................................................................................ 28
4.6.1 How to Select the System Setup Item ........................................................................................... 28
4.7 Display Color Settings ............................................................................................................................... 28
4.7.1 How to Change the Parameter Color............................................................................................. 29
4.8 File Management Screen.......................................................................................................................... 29
4.8.1 How to Add a New Patient ............................................................................................................ 29
4.9 OxyCRG Screen ......................................................................................................................................... 30
4.9.1 Operation Instructions................................................................................................................... 30
4.10 Event List Screen..................................................................................................................................... 31
4.10.1 Screen Description....................................................................................................................... 31
4.10.2 Operating Instructions................................................................................................................. 31
4.11 MC Calculator ......................................................................................................................................... 31
4.11.1 Medicine Dosage Calculator........................................................................................................ 31
4.12 Tourniquet Function ............................................................................................................................... 34
4.12.1 Operation Instructions ................................................................................................................ 34
Chapter 5 Parameter Settings ................................................................................................................................ 35

V
5.1 System Parameter Settings....................................................................................................................... 35
5.2 Network Related Settings ......................................................................................................................... 36
5.3 ECG Related Settings ................................................................................................................................ 37
5.4 Temperature Related Settings .................................................................................................................. 38
5.5 NIBP Related Settings ............................................................................................................................... 39
5.6 SpO2Related Settings ............................................................................................................................... 40
5.7 Respiration Related Settings..................................................................................................................... 40
Chapter 6 Alarms.................................................................................................................................................... 42
6.1 Alarm Categories ...................................................................................................................................... 42
6.2 Alarm Levels ............................................................................................................................................. 42
6.3 Alarm Indicators ....................................................................................................................................... 43
6.3.1 Alarm lamp .................................................................................................................................... 44
6.3.2 Alarm message .............................................................................................................................. 44
6.3.3 Highlighting Numeric..................................................................................................................... 44
6.3.4 Audible Alarm Tones...................................................................................................................... 44
6.3.5 Alarm Status Symbols:................................................................................................................... 44
6.3.6 Changing Alarm Volume ................................................................................................................ 45
6.4 Understanding the Alarm Setting............................................................................................................. 45
6.4.1 High and Low Alarm Setting Range ............................................................................................... 45
6.4.2 Factory Default Alarm Limit Setting Value..................................................................................... 47
6.5 Testing Alarms .......................................................................................................................................... 47
6.6 When an Alarm Occurs............................................................................................................................. 47
Chapter 7 ECG Monitoring ..................................................................................................................................... 49
7.1 Introduction.............................................................................................................................................. 49
7.2 Safety Information.................................................................................................................................... 49
7.3 Preparing to Monitor ECG ........................................................................................................................ 50
7.3.1 Preparing the Patient and Device.................................................................................................. 50
7.3.2 ECG Electrodes Placement............................................................................................................. 51
7.4 Understanding the ECG Display................................................................................................................ 52
7.5 Changing ECG Settings.............................................................................................................................. 53
7.6 About Arrhythmia Detection and Template Learning .............................................................................. 53

VI
7.6.1 Understand the ARR Type.............................................................................................................. 54
7.7 About S-T Segment Monitoring................................................................................................................ 55
7.8 Freezing Waveform................................................................................................................................... 56
7.9 Factors Affecting ECG signal ..................................................................................................................... 56
Chapter 8 Monitoring Respiration (RESP) .............................................................................................................. 57
8.1 Introduction.............................................................................................................................................. 57
8.2 Safety Information.................................................................................................................................... 57
8.3 Understanding the RESP Display .............................................................................................................. 57
8.4 Changing RESP Settings ............................................................................................................................ 58
Chapter 9 Monitoring NIBP .................................................................................................................................... 59
9.1 Introduction.............................................................................................................................................. 59
9.1.1 The Oscillometric Blood Pressure Measurement .......................................................................... 59
9.1.2 The Oscilometric method vs. the Korotkoff Sound Method.......................................................... 59
9.2 Safety Information.................................................................................................................................... 59
9.3 Measurement Limitations ........................................................................................................................ 60
9.4 Measurement Mode................................................................................................................................. 60
9.5 Setting Up the NIBP Measurement .......................................................................................................... 61
9.5.1 Preparing to Measure NIBP ........................................................................................................... 61
9.5.2 Starting and Stopping Measurements........................................................................................... 61
9.5.3 Factors Affecting NIBP Measurement............................................................................................ 62
9.6 Understanding the NIBP Numerics........................................................................................................... 62
9.7 Changing NIBP Settings ............................................................................................................................ 63
Chapter 10 Monitoring Oxygen Saturation (SpO2) ................................................................................................. 64
10.1 Introduction............................................................................................................................................ 64
10.2 Safety Information.................................................................................................................................. 64
10.3 Apply the Sensor .................................................................................................................................... 65
10.4 Using Probe and Sensor.......................................................................................................................... 66
10.5 Understanding the SpO2and PR Display ................................................................................................ 68
10.6 Changing SpO2and PR Settings .............................................................................................................. 68
Chapter 11 Monitoring Temperature..................................................................................................................... 69
11.1 Introduction............................................................................................................................................ 69

VII
11.2 Safety Information.................................................................................................................................. 69
11.3 Making a TEMP Measurement ............................................................................................................... 69
11.4 Understanding the TEMP Display........................................................................................................... 70
11.5 Changing TEMP Settings......................................................................................................................... 70
Chapter 12 Screen Display for Remote Observation .............................................................................................. 71
12.1 Default Remote Screen........................................................................................................................... 71
12.2 NIBP Screen Display................................................................................................................................ 72
12.3 Screen Display with ECG Waveforms only .............................................................................................. 73
12.4 Five Channels Real-time Waveforms and Trends on the Same Screen .................................................. 75
12.5 Parameter Screen ................................................................................................................................... 76
Chapter 13 Battery ................................................................................................................................................. 78
13.1 Overview ................................................................................................................................................ 78
13.2 Battery Maintenance.............................................................................................................................. 78
13.3 Battery Recycling .................................................................................................................................... 79
Chapter 14 Cleaning and Disinfection.................................................................................................................... 80
14.1 Cleaning the Device and Accessories ..................................................................................................... 80
14.2 Disinfecting the Device and Accessories ................................................................................................ 81
Chapter 15 Maintenance........................................................................................................................................ 82
15.1 Daily Examination................................................................................................................................... 82
15.2 Routine Maintenance ............................................................................................................................. 82
15.3 ECG Verification...................................................................................................................................... 83
15.4 Pressure Accuracy Verification ............................................................................................................... 83
16 Accessories ........................................................................................................................................................ 86
17 Technical Specifications .................................................................................................................................... 87
17.1 ECG ......................................................................................................................................................... 87
17.2 RESP........................................................................................................................................................ 88
17.3 TEMP ...................................................................................................................................................... 88
17.4 NIBP........................................................................................................................................................ 88
17.5 SpO2........................................................................................................................................................ 89
17.6 Pulse Rate............................................................................................................................................... 89
17.7 S-T Segment............................................................................................................................................ 90

VIII
17.8 Data Recording ....................................................................................................................................... 90
17.9 Other Technical Specifications................................................................................................................ 90
17.10 Classification......................................................................................................................................... 90
17.11 Operating Environment ........................................................................................................................ 91
17.12 Storage ................................................................................................................................................. 91
17.13 Transportation ...................................................................................................................................... 91
17.14 Packaging.............................................................................................................................................. 92
Chapter 18 Troubleshooting .................................................................................................................................. 93
18.1 No Display on the Screen ....................................................................................................................... 93
18.2 Excessive ECG Signal Interference or too Thick Baseline........................................................................ 93
18.3 No Blood Pressure and Pulse Oxygen Measures.................................................................................... 93
18.4 System Alarm.......................................................................................................................................... 93
18.5 Alarm Problems...................................................................................................................................... 93
18.6 Power Supply Failure .............................................................................................................................. 94
A Alarm Information ........................................................................................................................................... 95
B Status/Error during NIBP Monitoring............................................................................................................... 96
C EMC Compliance .............................................................................................................................................. 97

Operator ’s Manual for Patient Monitor
1
Chapter 1 Safety
1.1 Safety Information
The safety statements presented in this chapter refer to the basic safety information that the operator of the monitor
shall pay attention to and abide by. There are additional safety statements in other chapters or sections, which may be
the same as or similar to the followings, or specific to the operations.
Warning: indicates a potential hazard or unsafe practice that, if not avoided, could result in
death or serious injury.
Caution: indicates a potential hazard or unsafe practice that, if not avoided, could result in
minor personal injury or product/property damage.
☞Note: provides application tips or other useful information to ensure that you get the most
from your product.
1.1.1 Warnings
WARNING for PACEMAKER PATIENTS: Although the pacemaker pulse inhibition function is available in this
device, the heart rate meter may continue to count the pacemaker rate during occurrences of cardiac arrest or
some arrhythmias. Do not rely entirely upon rate meter ALARMS. Keep pacemaker patients under close
surveillance. See this manual for disclosure of the pacemaker pulse rejection capability of this instrument.
Disconnect the monitor and sensors from the patient before MRI scanning. Use them during MRI could cause
burns or adversely affect on the MRI image or the monitor’s accuracy.
If uncertain about the accuracy of any measurement, firstly check the patient’s vital signs by any alternative
means, and then make sure the monitor is functioning properly.
The monitor is intended only as an adjunct in patient assessment. It must be used in conjunction with clinical
signs and symptoms.
Monitoring a single person at a time.
The monitor is defibrillation-proof. Verify that the accessories can function safely and normally and the
monitor is grounded properly before conducting defibrillation.
The monitor is not suitable for use in the presence of flammable anesthetic mixture with air, oxygen or nitrous
oxide.
Each time the monitor is used, check the alarm limits to ensure that they are appropriate for the patient being
monitored.
The alarm limit value shall be within the measuring range, or it may disable the alarm system. Please refer to
the related chapter for alarm limit range.
A HAZARD can exist if different alarm presets are used for the same or similar device in a single area.

Operator ’s Manual for Patient Monitor
2
Do not silence the audible alarm if patient safety may be compromised.
The monitor is prohibited from applying to those who have severe hemorrhagic tendency or who are with
sickle cell disease for they may develop partial bleeding when this monitor is used to take the blood pressure
measurement.
All the connecting cables and tubes of the applying parts should be kept away from the patient's cervix to
prevent any possible suffocation of the patient.
To prevent the risk of the short circuit and to ensure the ECG signal quality, the device must be properly
grounded.
The device should be considered an early warning device as a trend towards patient deoxygenation is indicated,
blood samples should be analyzed by a laboratory CO-oximeter to completely understand the patient's
condition.
Although biocompatibility tests have been performed on all the applied parts, some exceptional allergic
patients may still have anaphylaxis. Do NOT apply to those who have anaphylaxis.
Please peruse the relative content about the clinical restrictions and contraindication.
It is recommended that the clinical operator regularly test device and accessories. And the visual and auditory
alarm signal can be checked by intentionally disconnect accessories or by setting it at Demo mode to simulate
alarm event.
Do not allow service or maintenance on the device while used in patient.
1.1.2 Cautions
All the parts of the monitor should NOT be replaced at will, substitution of a component different from that
supplied by the manufacturer might result in measurement error. If necessary, please use the components
provided by the manufacturer or those that are of the same model and standards as the accessories along with
the monitor which are provided by the same factory, otherwise, negative effects concerning safety and
biocompatibility etc. may be caused. No modification of this device is allowed.
The accessories which can be used repeatedly should have a thorough cleanness before it is used to another
patient. Please refer to the related chapter for maintenance method.
If the monitor falls off accidentally, please do NOT operate it before its safety and technical indexes have been
tested minutely and positive testing results obtained.
Do not immerse the monitor or its accessories in liquid to clean.
The system might not meet its performance specifications if stored or used outside the manufacturer’s
specified temperature and humidity ranges.
1.1.3 Notes
☞All combinations of equipment must be in compliance with the standard IEC 60601-1.
☞Please do not position the device so that it is difficult to connect the plug of the power cord.

Operator ’s Manual for Patient Monitor
3
☞After the life cycle of the monitor and its accessories has been met, disposal should be accomplished following
national and/or local requirements.
☞If the user requires more information such as circuit diagrams, parts list and product descriptions, for repairs
carried out by qualified technical personnel, please contact us.
☞ECG arrhythmia analysis function and S-T segment monitoring have not been CE certified.

Operator ’s Manual for Patient Monitor
4
1.2 Equipment Symbols
1.2.1 Symbol/Icon on the Device
Item Symbol/Icon Description
1 Power switch
2 ECG lead key
3 Alarm Silence key
4 Freeze/ Unfreeze key
5 Start/Cancel NIBP measurement
6 Display view key
7 AC power indicator
8 Working power supply indicator
9 Type CF applied parts with defibrillation-proof
10 Warning --- refer to User Manual
11 Type BF applied parts with defibrillation-proof
12 Equipotential grounding terminal
13 SN Serial number
14 Battery cover
15 USB data cable connector (used for data upload)
16 Network interface (used for connecting to Central Monitoring System)
17
Icon of DC power supply socket with polarity indication.
DC Power supply socket indication with rated voltage and current.
18 Manufacturer
19 Manufacturing date

Operator ’s Manual for Patient Monitor
5
20
The following definition of the WEEE label applies to EU member states
only.
This symbol indicates that this product should not be treated as
household waste. Bu ensuring that this product is disposed of correctly,
you will help prevent bringing potential negative consequences to the
environment and human health. For more detailed information with
regard to returning and recycling this product, please consult the
distributor from whom you purchased it.
21
This mark means that this device is fully in conformance with the
Council Directive Concerning Medical Devices 93/42/EEC.
22 Authorized representative in the European Community
1.2.2 Icons List on the Screen
Icon/info. Description
Alarm sound is mute/off
Waveform frozen symbol
Cross cursor for S-T segment measurement
Heart-beat symbol
Breath symbol
AC Power supply and the battery is fully charged.
The red blinking exclamatory mark means battery will be used out soon and needs to
charged. Alarm information area will show "Low Battery" message.
Charging status
/ / One/two/ full grid battery voltage left
S-T +..... The measured S-T value
PI Perfusion index
% Unit of SpO2
mmHg/kPa Unit of blood pressure
Bpm Unit of heart rate or pulse rate
rpm Unit of respiration rate
℃/℉Unit of temperature

Operator ’s Manual for Patient Monitor
6
mm/s Unit of waveform sweeping speed
NOTE: some symbols may not appear on your equipment

Operator ’s Manual for Patient Monitor
7
Chapter 2 The Basics
2.1 Monitor Description
2.1.1 Product Name and Model
Product name: Patient Monitor
Product Model: See Label in page I
2.1.2 Intended Use
This Patient Monitor is a multi-functional instrument designed for monitoring the vital physiological signs of adult,
pediatric and neonate patients. With the functions of real-time recording and displaying parameters, such as ECG,
heart rate (HR), non-invasive blood pressure (NIBP), functional oxygen saturation (SpO2), respiration (RESP), body
temperature (TEMP), as well as the optioned monitoring functions, it allows comprehensive analysis of patient’s
physiological conditions.
Note: This patient monitor can be configured with different parameters, the monitor you purchase may not cover all
functions described above.
This device is applicable for use in hospitals and clinical institutions. The operation should be performed by
qualified professionals or under their guidance. Anyone unauthorized or untrained must not perform any
operation on it.
The physiological waveforms and parameters and the alarm information displayed by the monitor are only for
the reference of operators, but cannot be used directly to determine the clinical treatment.
Contraindication: please see each section.
2.1.3 Features
This patient monitor can be used to monitor patient’s physiological parameters including ECG, heart rate (HR),
non-invasive blood pressure (NIBP), oxygen saturation (SpO2), Pulse rate (PR), respiration and temperature. It has the
following features:
It is lightweight, easy to carry and operate;
7″ high-resolution (800 × 480 pixel) color TFT (refer to the monitor you purchased) to display multiple traces of
signal waveforms for ECG, plethysmogram and respiratory waveform;
User-friendly and intuitive display interface, multiple configuration of ECG waveform display:
Main monitoring screen view: displays the information of main waveforms and parameters visually.
Observing screen view: heart rate value and SpO2value display in big fonts, and displays one trace of ECG
waveform.

Operator ’s Manual for Patient Monitor
8
Seven traces of ECG waveforms on one screen view: displays 7 traces of ECG waveforms for different leads
and monitoring parameters simultaneously on one screen.
Five channels of real-time waveforms and two hours’ trends screen view: intuitive knowing the physiological
status of patient.
oxyCRG screen: displays heart rate trend, SpO2trend, respiration trend or waveform simultaneously on
oxyCRG screen, to know the instantaneous the change of physiological parameters of respiration.
The cuff can be also used as a tourniquet, which is convenient and practical in use as an additional function,
and different cuff pressure can be set according to patient’s condition.
Automatic analysis of 20 types of arrhythmia, manual measurement of S-T segment while ECG waveform
frozen or automatic measurement while monitoring;
Up to 1000 hours trend data storage for parameter of ECG, S-T, TEMP, SpO2, RESP and NIBP;
Up to 2000 groups of arrhythmia events’ can be stored, as well as the corresponding HR , TEMP, SpO2, and RR;
Up to 12000 groups of NIBP measurement can be stored, as well as the corresponding HR, TEMP, RR SpO2and
PR while the blood pressure measurement is taken, it can be recalled by list table or graphic trend.
Up to 60 hours of ECG waveform storage (non-volatile) and can be reviewed;
Accurate NIBP measurement with over-pressure protection;
Unique pulse oximetry technique achieves accurate SpO2and PR measurement;
Visual and audible alarm, recall of alarm events;
Flexible high and low alarm limits setting operation;
Real-time monitoring of battery capacity, when the battery power is insufficient, low battery voltage alarm
indication will display on LCD screen.
Easy to configure the display color, font and waveforms layout for user customization;
Protection against defibrillator discharge and resistance against the interference from electro-surgical unit;
Pacemaker pulse detection and inhibition functions are available;
Patient type can be selected among “Adult”, “Pediatric” and “Neonate” in setup menu;
Optional networking capability for connecting to the central workstation;
Note: This patient monitor can be configured with different parameters, the monitor you purchase may not cover all
functions described above.

Operator ’s Manual for Patient Monitor
9
2.2 Main Unit
Front Panel
Figure 2.1 Front Panel
Note: The appearance described in this manual may be a little different with the monitor you purchased,
for example, the operation keys may be located at the right side of the front panel. But the operating
procedure is the same. Therefore, please refer to the monitor in your hand for details.
1. Power switch: Press it for 3 seconds to start the monitor or turn off the monitor.
2. ～
～
～-
-
-AC power indicator: When it is light it means that AC power supply is being used
3. -Built-in DC power indicator:
When both AC and DC indicators are on, it means that AC power supply is applicable, and the battery is
being recharged. If only DC indicator is on, it means that the battery is being used.
4. ECG lead: Press to shift the ECG lead circulatory among I, II, III, aVR, aVL, aVF and V.
5. Alarm silence: Press key to enable or disable the system alarm silence function. During the
monitoring process, when an alarm event activates the system alarming, press “Alarm silence” key, then
the system alarm sound will be muted temporarily for 2 minutes. If a new type of alarm event occurs
during this silent period, the alarm sound will be resumed automatically to give audible alarm. If the
alarm event which triggers this alarming persists after the period of 2 minutes silence, the system alarm
sound will be activated as well.
The maximal period of alarm silence is 2 minutes.
6. Freeze: Press the key to freeze/unfreeze ECG waveform or the waveforms of ECG, SpO2and RESP
1 2 3 4 5 6 7 8 9
10

Operator ’s Manual for Patient Monitor
10
according to the device setting, and enter into ST segment measurement screen for analysis (on Observing
Screen).
7. NIBP: Press to start or stop NIBP measurement.
8. DISP: Click to shift the display modes or return to the Main Screen from other screens. Press it
to shift between Main Screen and Display 2 Screen which can be set in System Menu screen.
9. Navigation Knob:It is the major operating key of the system, which can be used to select functions or
parameters. Press and release it to shift the screen and to confirm the function or other operating tips.
10. Alarm indicator:
Indicator Color Alarm Level Alarm Event
Red flashing High priority alarm Parameter exceeding the limits, asystole or apnea
Yellow flashing Middle priority alarm Leads and probe off, VE RONT and SVE RONT
Yellow light Low priority alarm Other arrhythmia events
Green light Normal

Operator ’s Manual for Patient Monitor
11
Left and Right Panel
Figure 2.2 the left panel Figure 2.3 the right panel
Different ports are located in different positions of the monitor for operating convenience.
The cable and transducer ports are an the left panel, shown in Figure 2.2.
SpO2: SpO2probe connector
NIBP: NIBP hose connector
TEMP: TEMP probe connector
ECG/RESP: ECG cable connector
Symbol definition
With type BF applied parts and applicable during the defibrillator is used.
With type CF applied part and applicable during the defibrillator is used.
Caution. Please read the manual for details.
The power supply socket and ports are at the right panel, shown in Figure 2.3.
1. ：DC Power supply socket indication with rated voltage and current
2. ：Serial communication port which is used to network with central monitoring system
(optional).
3. ：USB port (used for data uploading). The user can upload data from the monitor to the PC
directly by connecting the specified USB data cable (optional) between the patient monitor and PC.
If the data cable is well connected between the PC and the Patient Monitor, the Patient Monitor
will be recognized automatically by PC as a disk device and prompt information will appear on the
computer, a removable disk named “PC-3000” appears on "My computer". Double click this disk,
you can see a data file which will be found out and retrieved later during the data uploading.
