GMI CBL-5464-0.M User manual

CBL-5464-0.M
TOOLS REQUIRED FOR ASSEMBLY
Socket set, Open end wrench set, Cordless drill with
3/8" socket bit (Magnetic recommended).
BEFORE ASSEMBLING THE WORKBENCH
Read through the assembly instructions to
familiarize yourself with the order in which the
parts are assembled. We suggest that you clear
& vacuum the area where the bench is to be
assembled. It is important that the bench is
assembled in the same sequence as instructed.
STEP 1
STEP 2
Attach the back brace to each
of the legs in 2 places. Bolts
should go thru the back brace
into the leg.
Use four 5/16 x 1" Hex Head
Bolts & four 5/16 Lock Nuts.
Attach the shelf to the back brace
in 3 places using #8 x 5/8 black
screws.
Attach the shelf to the legs using
two 5/16 x 3/4" Hex Head Bolts &
two 5/16 Lock Nuts per leg.
Bolts should go thru the shelf
into the leg. Shelf to
Leg
Shelf to
Back Brace

STEP 3
STEP 4
Locate a flat & clean surface to work
on. You may want to lay down a
blanket to avoid scratching the tops.
Connect the two halves of your
Maple top using (5) Draw Bolts.
Insert the Draw Bolts in the routered
slots as shown in Figure 1.
Make sure the 2 tops are even before
you fully tighten the bolts.
Figure 1
Figure 2
Attach 2 counter top mounting
brackets to the top of each leg.
Attach using three 5/16 x 4" Hex
Head Bolts with three 5/16 Lock Nuts
per leg.
STEP 5
Turn maple top over and center over base
assembly. 64” dimension of the top will run
the width of the work station. Fasten top to
base using the #14 x 1 lag screws.
