CBL-5464-8.M
STEP 1
Nylock Nut
5/16 x 3/4”
Hex Head Bolt
STEP 2
Figure 1
Figure 2
TOOLS REQUIRED FOR ASSEMBLY
Socket set w/ 1/2” socket, Open end wrench set,
Cordless drill with 5/16" socket bit (Magnetic
recommended), 1/8” Drill bit, & Tape measure.
BEFORE ASSEMBLING THE WORKBENCH
Assembly of this bench will require 2 people.
Read through the assembly instructions to
familiarize yourself with the order in which the
parts are assembled. We suggest that you clear
& vacuum the area where the bench is to be
assembled. It is important that the bench is
assembled in the same sequence as instructed.
HARDWARE & GMI COMPONENTS
All assembly hardware is provided.
**Units are difficult to move once assembled.
Begin assembly in the bench's final location**
CAUTION: If cabinets are numbered. Be sure
to keep the cabinets in sequential order.
Each station contains 4 individual locker cabinets.
First connect the cabinets side-to-side using (8) lock
nuts and bolts (4 bolts/nuts to connect a pair of cabinets).
Then push them back- to-back and
connect using (8) lock nuts and bolts.
HARDWARE: 5/16" x 3/4" Bolts & Lock Nuts.
Locate a flat & clean surface to work
on. You may want to lay down a
blanket to avoid scratching the tops.
Connect the two halves of your
Maple top using (5) Draw Bolts.
Insert the Draw Bolts in the routered
slots as shown in Figure 1.
Make sure the 2 tops are even on the
finished top side before you fully
tighten the bolts.
Fully tighten all draw bolts.

STEP 4 STEP 3
Position 4 strips of the brown fiberboard material on top
of the cabinet as shown. The strips will create a small air gap
between the cabinet and worksurface to allow air flow
around the top.
Carefully flip the top right side up & place on
the cabinets as shown to the right.
Adjust top so that it sits centered on the
cabinets.
Mounting holes should be pre-drilled into the
wood top, 1” deep.
Attach using (4) #10 x 1" Lag
screws per cabinet.
Becasue the wood top is a natural product
it can expand and contract due to being
exposed to moisture or environmental changes
in humidity. When tightening the lag bolts it
is recomended to first tighten and then back
the bolt out 1/4 turn. This will allow the top
to expand and contract to help minimize any
cracking or warping that may occur.
Failure to properly mount the top will void
warranty.
#10 x 1”
Lag Bolt
