Goldmedal ReadyPop Jr 2783-00-000 User manual

© 2021 Gold Medal Products Co.
Part No. 110281
10700 Medallion Drive, Cincinnati, Ohio 45241-4807 USA
ReadyPop® Jr.
Model No.: 2783-00-000 (010, 020, 030)
Instruction Manual

ReadyPop®Jr. Model No.: 2783-00-000 (010, 020, 030)
Page 2
gmpopcorn.com
Table of Contents
SAFETY PRECAUTIONS ...................................................................................................................................3
INSTALLATION INSTRUCTIONS ...................................................................................................................5
Inspection of Shipment .......................................................................................................................................5
Manual .......................................................................................................................................................................5
Model Description.................................................................................................................................................5
Items Included with this Unit ...........................................................................................................................5
Setup...........................................................................................................................................................................6
Install Chute Assembly ..................................................................................................................................7
Coil and Corn Pan Removal (Installation) ...................................................................................................8
Reinstall Corn Pans.........................................................................................................................................8
Corn Pan Removal ...........................................................................................................................................8
Electrical Requirements .....................................................................................................................................9
Before You Plug In Machine ..............................................................................................................................9
OPERATING INSTRUCTIONS ...................................................................................................................... 10
Controls and Their Functions........................................................................................................................10
Operating Instructions .....................................................................................................................................11
Care and Cleaning .................................................................................................................................... 12
Daily Kettle Cleaning Instructions...............................................................................................................12
Daily Unit Cleaning Instructions...................................................................................................................13
Troubleshooting....................................................................................................................................... 14
Agitator Set Collar Adjustment............................................................................................................ 16
THE FOLLOWING SECTIONS ARE FOR QUALIFIED SERVICE PERSONNEL ONLY ............ 17
MAINTENANCE INSTRUCTIONS ................................................................................................................ 17
ORDERING SPARE PARTS............................................................................................................................ 18
Replacing Broken Glass....................................................................................................................................18
8 oz. Kettle 49472N (if equipped) – Agitator Assembly View.............................................................19
8 oz. Kettle 49472N (if equipped) – Kettle Bottom Assembly ............................................................20
Cabinet Exterior – Front View.......................................................................................................................21
Cabinet Exterior – Rear View.........................................................................................................................22
Door Hardware Kit 61380 – Individual Component Breakdown.................................................... 23
Cabinet Interior – Hanger Assembly........................................................................................................... 24
Cabinet Interior – Corn Pans.......................................................................................................................... 25
Dome Interior – Electrical Components....................................................................................................26
Safety Labels.........................................................................................................................................................27
Accessories ........................................................................................................................................................... 27
Wiring Diagram ........................................................................................................................................ 28
WARRANTY...................................................................................................................................................... 29

ReadyPop®Jr. Model No.: 2783-00-000 (010, 020, 030)
Page 3
gmpopcorn.com
SAFETY PRECAUTIONS
DANGER
Machine must be properly grounded to prevent electrical shock to personnel.
Failure to do so could result in serious injury, or death.
Make sure all machine switches are in the OFF position before plugging the
equipment into the receptacle. Keep cord and plug off the ground and away
from moisture. Always unplug the equipment before cleaning or servicing.
DO NOT immerse any part of this equipment in water.
DO NOT use a water jet or excessive water when cleaning.
008_012221
DANGER
Improper installation, adjustment, alteration, service, or maintenance can
cause property damage, injury, or death. Any alterations to this equipment
will void the warranty and may cause a dangerous condition. This appliance
is not intended to be operated by means of an external timer or separate
remote-control system. NEVER make alterations to this equipment. Read the
Installation, Operating, and Maintenance Instructions thoroughly before
installing, servicing, or operating this equipment.
014_020416
WARNING
To avoid burns, DO NOT touch the kettle or any heated surface.
DO NOT place or leave objects in contact with heated surfaces.
013_092414
WARNING
ALWAYS wear safety glasses when servicing this equipment.
010_010914
WARNING
No user serviceable parts inside. Refer servicing to qualified service
personnel.
011_051514
WARNING
Read and understand operator’s manual and all other safety instructions
before using this equipment. To order copies of the operator’s manual go to
gmpopcorn.com or write to Gold Medal Products Co., 10700 Medallion Drive,
Cincinnati, OH 45241 USA 1-(800)-543-0862
022_060215

ReadyPop®Jr. Model No.: 2783-00-000 (010, 020, 030)
Page 4
gmpopcorn.com
WARNING
Only personnel trained and experienced in the equipment operation may
operate this equipment. 012V_012221
WARNING
This machine is NOT to be operated by minors.
007_010914
CAUTION
If the supply cord is damaged, it must be replaced by Gold Medal Products Co.,
its service agent or similarly qualified persons in order to avoid a hazard.
039_080614
Note:Improvements are always being made to Gold Medal’s equipment. This information
may not be the latest available for your purposes. It is critical that you call Gold Medal’s
Technical Service Department at 1-800-543-0862 for any questions about your
machine operations, replacement parts, or any service questions. (Gold Medal
Products Co. does not assume any liability for injury due to careless handling and/or
reckless operation of this equipment.) General images may be used in manual for
reference only.

ReadyPop®Jr. Model No.: 2783-00-000 (010, 020, 030)
Page 5
gmpopcorn.com
INSTALLATION INSTRUCTIONS
Inspection of Shipment
After unpacking, check thoroughly for any damage which may have occurred in transit. Claims
should be filed immediately with the transportation company. The warranty does not cover
damage that occurs in transit, or damage caused by abuse, or consequential damage due to the
operation of this machine, since it is beyond our control (reference warranty in back of manual).
Manual
Read and understand the operator’s manual and all other safety instructions before using this
equipment. To order copies of the operator’s manual go to gmpopcorn.com or write to Gold
Medal Products Co., 10700 Medallion Drive, Cincinnati, OH 45241 USA 1-(800)-543-0862.
Model Description
ReadyPop®Jr. is a popcorn popper/dispenser available for countertop use. Front counter features
doors/popping controls opposite of customer side; back counter has doors/popping controls on
customer side. Unit is also available without a kettle for the option of using an existing, compatible
kettle as indicated below.
2783-00-000: 8 oz. ReadyPop Jr. – 8 oz. kettle, front counter unit
2783-00-010: 8 oz. ReadyPop Jr. – 8 oz. kettle, back counter unit
2783-00-020:ReadyPop Jr. – no kettle, front counter cabinet. Only for use with Gold Medal
Products Kettle #49472N, #56000, or #58000.
2783-00-030:ReadyPop Jr. – no kettle, back counter cabinet. Only for use with Gold Medal
Products Kettle #49472N, #56000, or #58000.
Items Included with this Unit
Knob (PN 47120)
Knob Plate (PN 114868)
(for RH Popper Door)
Knob (PN 47120)
Screw
(PN 42227
)
(for Old Maid Pan)
Flavacol Measure
6.5 cc (PN 47678)
Aluminum
Scoop
(PN 2071)
Instruction Manual
and Registration
Warranty Card
1/3 Cup Oil
Measure
(PN 47150)
1 Cup Corn
Measure
(PN 47147)
Knob (PN 47120)
Tee Bolt
(PN 75267)
(for
LH Popper Door)
Black Crutch Tip
(PN 49123) one tip
Metal Chute
(PN 116725)
Chute Cover
(PN
114322)
Cover Knobs
(PN
12793)
Chute Door
(PN 116668)

ReadyPop®Jr. Model No.: 2783-00-000 (010, 020, 030)
Page 6
gmpopcorn.com
Setup
This unit has been tested at the factory.
1. Remove all packaging and tape prior to operation—remove any protective covering
on the plastic panels. Remove accessories and carefully remove kettle packed in
cabinet interior.
2. Place unit on a sturdy, level countertop or base.
3. Unit has 4 glide feet preinstalled at the factory (Figure A). Install a Black Crutch Tip on
each foot. Firmly push crutch tip over glide until it covers glide entirely.
4. Tilt kettle and insert into hanger arms, then allow kettle to return naturally to an
upright position (Figure B).
5. Plug kettle lead into receptacle located on ceiling of cabinet interior. Align keyed or hook
shaped prong with the correct opening, then push plug all the way in and twist or rotate
to lock in place.
To unplug, untwist kettle plug before attempting to pull from receptacle.
6. Doorknobs are shipped in accessories pack. Install a knob with tee bolt on the LH
popper door. Install the door bracket and knob on the RH door (Figure C). The door
brackets can be locked to help prevent product tampering (lock to be provided by
customer). Install knob with screw on old maid pan.
Black Crutch Tip
Glide (pre-installed
at the factory).
Kettle shown mounted
in hanger arms.
Kettle lead plugged in.
1. Align prongs with
receptacle.
2. Insert plug fully.
3. Twist plug to lock
into receptacle.
Door Lock
Brackets
Figure A
Figure B
Figure C
Tab holds LH
door closed.
Install plate on RH door.
Screw on knob
to hold plate.

ReadyPop®Jr. Model No.: 2783-00-000 (010, 020, 030)
Page 7
gmpopcorn.com
7. Install the chute assembly as described below.
8. Make sure the Corn Pans and Coil Assembly are in position for use (see image below).
9. After setup, unit should be cleaned prior to use (see Care and Cleaning section).
Make sure Coil
Assembly
is FULLY
fitted on Motor Shaft.
Align flat side of Shaft to Coil
Assembly Plate to install.
Corn Pans (2 side pans,
1
bottom pan)
See next section for complete corn pan removal and reinstallation.
Install Chute Assembly
General
images shown for reference.
1. Insert both tabs on chute flap into
slots in cabinet.
2. Allow flap to swing down into
place—make sure flap swings freely.
3. Fit metal chute over the 4 threaded
studs.
4.
Install plastic chute cover and secure
with the 4 knobs provided.
Twist knobs until finger tight only.
1
2
Chute must sit flush
against cabinet.

ReadyPop®Jr. Model No.: 2783-00-000 (010, 020, 030)
Page 8
gmpopcorn.com
Coil and Corn Pan Removal (Installation)
Corn Pan Removal
Side Corn Pan
To reinstall: Insert corn
pan tabs into slots.
To reinstall: ALIGN flat side
of shaft to coil assembly plate.
Pan opening for
motor shaft.
Tab Slots
Tab Slots
Coil Assembly
1. Remove both side corn pans—
lift by handle to remove.
2. Slide coil assembly off motor shaft.
3. Lift out bottom corn pan—lift by
handles to remove.
Reinstall
Corn Pans
4. Insert bottom corn pan.
a) Fit corn pan over motor shaft.
b) Insert corn pan tabs into slots.
5. Reinstall coil assembly (reference
step 2 above).
6. Reinstall side corn pans (reference
step 1 above).

ReadyPop®Jr. Model No.: 2783-00-000 (010, 020, 030)
Page 9
gmpopcorn.com
Electrical Requirements
The following power supply must be provided (reference unit Data Plate for Wattage requirement):
120 V~, 60 Hz
DANGER
Machine must be properly grounded to prevent electrical shock to personnel.
Failure to do so could result in serious injury, or death.
Make sure all machine switches are in the OFF position before plugging the
equipment into the receptacle. Keep cord and plug off the ground and away
from moisture. Always unplug the equipment before cleaning or servicing.
DO NOT immerse any part of this equipment in water.
DO NOT use a water jet or excessive water when cleaning.
008_012221
A certified electrician must furnish sufficient power for proper machine operation and install any
supplied receptacle (reference unit Data Plate for model specific Volts AC, Hertz, and Wattage
requirements). We recommend this equipment be on a dedicated and protected circuit. Failure
to wire properly will void the warranty and may result in damage to the machine. It is Gold Medal
Products Co.’s recommendation that this machine be plugged directly into a wall outlet. The use of
extension cords is not recommended due to safety concerns, and may cause sacrificed and/or
reduced performance. Make sure cord is located to prevent a trip hazard or unit upset.
Before You Plug In Machine
1. Make sure all machine switches are OFF before plugging equipment into receptacle.
2. Make sure wall outlet can accept the grounded plugs (where applicable) on the power
supply cord.
3. The wall outlet must have the proper polarity. If in doubt, have a certified electrician
inspect the outlet and correct if necessary.
4. DO NOT use a grounded to un-grounded receptacle adapter (where applicable).
5. Install unit in a level position.
CAUTION
If the supply cord is damaged, it must be replaced by Gold Medal Products Co.,
its service agent or similarly qualified persons in order to avoid a hazard.
039_080614

ReadyPop®Jr. Model No.: 2783-00-000 (010, 020, 030)
Page 10
gmpopcorn.com
OPERATING INSTRUCTIONS
Controls and Their Functions
KETTLE HEAT SWITCH
ON/OFF lighted rocker switch - supplies power to the heating element in the kettle. The
green switch light ON indicates there is power to the kettle heating element.
KETTLE MOTOR SWITCH
ON/OFF lighted rocker switch - supplies power to the kettle agitator motor. The kettle
motor must always be on when there is popcorn (popped or un-popped) in the kettle.
LIGHTS/WARMER SWITCH
ON/OFF lighted rocker switch - supplies power to the interior cabinet light, corn pan heat
element, and dispense button.
DISPENSE BUTTON
Lighted Push Button Switch – powers the coil assembly for dispensing popcorn.
POWEROFF CONTROL
The control automatically turns the kettle heat off after 15 minutes of idle time (no popcorn
popped). This prevents the kettle heat element and thermostat from cycling OFF-ON if the
Kettle Heat Switch is left on—it saves power and extends the kettle element/thermostat life.
•When the Kettle Heat Switch is turned ON, and the kettle thermostat switches OFF,
the control’s 15 minute timer starts—the timer resets after each batch of popcorn.
•The green Kettle Heat Switch light blinks OFF-ON to indicate kettle auto shut-OFF.
•To restart kettle heating, cycle the Kettle Heat Switch OFF-ON.
Kettle Heat
Switch
Kettle Motor
Switch
Lights/Warmer
Switch
Dispense
Button
Dispense
Chute

ReadyPop®Jr. Model No.: 2783-00-000 (010, 020, 030)
Page 11
gmpopcorn.com
Operating Instructions
This unit is easy to use and provides a convenient, sanitary way for customers to self-serve
portions of popcorn.
1. Turn Lights/Warmer Switch ON (turns on display lights, crisper, and supplies power to
the dispense button).
2. Load unit with popcorn (maximum of 6 batches in
cabinet), see popping instructions below.
3. Lock the popper doors—helps prevent
product tampering (see image).
4. Hold a container under the dispense chute to
receive popcorn; press dispense button for
desired amount of corn.
Popping Corn Instructions
The popper is equipped with a corn, salt, and oil measure. We recommend flavored and colored
coconut oil. Popcorn popped in coconut oil stays fresh longer and does not leave black deposits in
the kettle like other oils. Use only top quality, fresh popcorn from reputable suppliers.
Raw Popcorn Charge: Use corn measure provided (ex: for 8 oz. Kettle, use 8 oz. corn)
Recommended Oil Volume:
Oil volume is approx. 30% of corn amount (ex: for 8 oz. corn, use 2.6 oz. oil)
Flavacol (Salt) Amount: Use small Flavacol scoop provided.
Premeasure all ingredients (adjust as needed for desired taste), or for best results use the 8 oz.
Mega-Pop®premeasured popcorn and oil pouch, Item No. 2838 (or pouch made for your kettle size).
1. Turn all switches ON.
2. To determine when kettle is ready to pop corn (about 4 minutes), test pop three
kernels of corn in one ounce (30 ml) of popping oil. When kernels pop, kettle is ready.
3. Lift kettle lid, pour in popcorn and Flavacol, then add oil; close lid.
4. When corn has finished popping, gently dump the popcorn. (To minimize unpopped
kernels, allow corn to finish popping before dumping the kettle.)
Popping Tip: On final batch, turn Kettle Heat Switch OFF just as lids are forced open
by the popping corn (kettle has plenty of heat to finish popping). This helps
eliminate smoke/odor from any oil residue remaining in kettle.
5. When finished popping, turn KETTLE HEAT and KETTLE MOTOR switches OFF.
NEVER LEAVE THE HEAT ON WHEN YOU ARE NOT POPPING CORN!
Units with a kettle heat auto shut-off feature will automatically shut kettle heat OFF after
15 min. of idle time (no popcorn popped). To restart heating, cycle the Heat Switch OFF-ON.
Door Lock
Brackets
Tab holds LH
door closed.

ReadyPop®Jr. Model No.: 2783-00-000 (010, 020, 030)
Page 12
gmpopcorn.com
Care and Cleaning
DANGER
Machine must be properly grounded to prevent electrical shock to personnel.
DO NOT immerse in water. DO NOT clean appliance with a water jet.
Always unplug the equipment before cleaning or servicing.
025_111616
WARNING
To avoid serious burns, DO NOT touch the kettle while it is hot!
028_082715
Good sanitation practice demands that all food preparation equipment be cleaned regularly (only
use non-toxic, food grade cleaners).
For surfaces needing further cleaning or degreasing, Watchdog Stainless Cleaner (Item No. 2088)
or Watchdog Concession Equipment Degreaser (Item No. 2580) is available for use accordingly.
For any cleaning products used, follow the manufacturer’s instructions on the product. DO NOT
use oven cleaners or abrasive materials as they will damage parts of machine.
Note: It is extremely important to follow all cleaning procedures, otherwise parts
damage and equipment failure will result. The warranty does not cover parts that
are damaged due to improper cleaning.
Daily Kettle Cleaning Instructions
1. Turn all switches OFF and unplug the unit.
CAUTION: A hot kettle will cause burns if you touch it. Allow kettle to cool at least 1
hour before attempting to clean. DO NOT use ice or water to cool down a hot
kettle! Severe kettle damage will result and steam burns may occur!
2. When cool, wipe outside of kettle clean using a clean, soft cloth and Gold Medal
Watchdog Stainless Cleaner (Item No. 2088). DO NOT use oven cleaners or abrasive
materials as they will damage the kettle.
3. Mix 2 tablespoons (29.6 ml) of Gold Medal’s Heat’n Kleen (Item No. 2095) in 1 gallon
(3.8 L) of water.
4. Only pour enough of the Heat’n Kleen pre-mixed solution into the kettle to fill it 1/2 inch
(12.7 mm) deep (it is not necessary to use the entire gallon at once).
5. Plug in unit and turn kettle heat ON. When solution starts to boil, turn kettle heat OFF.
6. Allow kettle to cool at least 1 hour, then dump solution into a bucket, do not spill any
in the interior of machine.

ReadyPop®Jr. Model No.: 2783-00-000 (010, 020, 030)
Page 13
gmpopcorn.com
7. Rinse kettle interior with clean water and a clean cloth.
8. Dump any water remaining into a bucket (do not spill any in the interior of machine),
then wipe the kettle interior clean with a clean dry cloth.
For an extra dirty kettle, the process may be repeated; or, after turning kettle heat OFF,
allow solution to sit in kettle overnight. The next morning, finish the cleaning steps.
9. With unit OFF and unplugged, use a clean SLIGHTLY damp cloth (wring ANY EXCESS
water from cloth before use) and wipe the kettle lead cord clean. DO NOT get moisture
into the kettle lead-in cord, severe damage will result.
10. After kettle cleaning, check to be sure the crossbar fasteners on the kettle are securely
tightened.
Daily Unit Cleaning Instructions
1. Turn machine OFF, unplug unit and allow it to cool before attempting to clean.
2. Remove the old maid pan, coil assembly, and corn pans—take them to the sink to
clean with soap and water, then rinse and dry.
To remove coil and corn pans: (refer to Coil and Corn Pan Removal in Installation section)
1. Remove any remaining popcorn.
2. Remove the 2 side corn pans.
3. Slide coil assembly off motor shaft.
4. Lift the bottom corn pan out of unit.
3. As needed, use a vacuum under corn pan to remove any debris.
4. Clean area above the corn pans using a clean, SLIGHTLY damp cloth to remove any
grease from glass and cabinet (cloth may be SLIGHTLY dampened with soap and
water, then wipe again with clean water to remove any remaining cleaner).
5. Clean glass panels with glass cleaner. Gold Medal Watchdog Glass Cleaner (Item No.
2588) is recommended.
Ammonia cleaners will damage plastic doors/panels. Only use a non-ammonia cleaner,
such as Gold Medal Watchdog Glass Cleaner (Item No. 2588).
6. Reinstall the clean and dry pans/accessories.
7. Check the kettle lead cord, make sure it is fully plugged into the kettle receptacle and
the plug is fully twisted to lock it into place.

ReadyPop®Jr. Model No.: 2783-00-000 (010, 020, 030)
Page 14
gmpopcorn.com
Troubleshooting
Issue
Possible Cause
Solution
No Power to the Unit
A. No Power to the Unit
A. Make sure the unit’s power cord is plugged in.
Kettle Does Not Heat
A. Power to the Kettle
A. Make sure kettle lead-in cord is plugged in and
twisted to lock into the kettle receptacle.
B. Kettle Heat Switch
B. Have a qualified service person check the
voltage to and from the Kettle Heat Switch; if
switch is defective, replace it.
C. PowerOff Control
C. Units with the PowerOff Control feature, kettle
heat will automatically shut OFF after 15
minutes of idle time (no popcorn popped).
The small green neon light in the Kettle Heat
Switch will blink OFF-ON to indicate the kettle
has been automatically turned OFF.
To restart kettle heating, cycle the Heat Switch
OFF-ON. Reference the Controls and Their
Functions section of this manual.
D. Heating Element
D. Heating element in the kettle may be burned
out. Check with a qualified service person for
inspection/repair.
Long Popping Cycles
(Longer than 4 minutes for
Salt Popcorn)
A. Low Voltage
A. If the machine is operated on low voltage, this
could cause the kettle not to reach the proper
operating temperature. Check with a qualified
electrician.
B. Inadequate Supply Lines
B. Inadequately sized electrical supply lines or
use of extension cord, in addition to being a
fire hazard, would also prevent the kettle from
reaching the proper operating temperature.
Check with a qualified electrician.
C. Inferior Corn
C. Inferior quality corn would result in longer
popping cycles. Use only top quality hybrid
popcorn from reputable suppliers. Even then,
if you let your corn pick up moisture or dry
out, your popping cycles will be slow.
Kettle Agitator Shaft not
Rotating
If the kettle agitator shaft is
not rotating, DO NOT pop
corn.
A. Kettle Motor Switch
A. Make sure the Kettle Motor Switch is ON. If the
switch is ON, and the shaft is not rotating, the
switch or motor may be faulty, contact
qualified service personnel for
inspection/repair.
B. Kettle Agitator Shaft/Stir
Blade not rotating. (Unit
must be OFF, unplugged
and cool prior to
checking or adjusting
the agitator assembly.)
B. Kettles with a FLOATING Stir Rod – lift the
agitator weight and check the clearance
between the shaft and the kettle bottom; it
should be a minimum of 1/32” (1 mm)
(thickness of a dime).
To make shaft adjustments, reference the
Agitator Set Collar Adjustment section.

ReadyPop®Jr. Model No.: 2783-00-000 (010, 020, 030)
Page 15
gmpopcorn.com
Issue
Possible Cause
Solution
No Popcorn Dispensed
A. Dispense Button/Motor
A. Make sure the unit is plugged in to supply
power to the Dispense Button. Check if the
Dispense Button LED is ON. If the LED is ON,
and popcorn does not dispense when the
button is pushed, the button or the motor
may be faulty, contact qualified service
personnel for inspection/repair.
B. Coil Assembly not
installed correctly
B. Coil Assembly not installed correctly,
reference Initial Setup section for instructions
to properly install coil assembly on motor
shaft.
C. Dispense Chute
C. Make sure the dispense chute opens freely to
allow coil assembly to dispense popcorn.

ReadyPop®Jr. Model No.: 2783-00-000 (010, 020, 030)
Page 16
gmpopcorn.com
Agitator Set Collar Adjustment
The following instructions describe how to properly adjust set collars on an agitator assembly
with a floating stir rod.
Drive Motor
Spur Gear
Agitator’s Spur Gear
(
should set halfway up on
Drive Motor Spur Gear)
Set Collar
w/Set screw
Spur Gear Placement
Needle Bearing
(
should set at least
halfway into Gear Block)
Gear Block
1. Turn machine OFF, unplug unit, and allow
it to cool completely before attempting
to adjust the agitator height.
2.
Loosen the set screw in each set collar to
be adjusted.
3.
With the kettle mounted in the popper,
adjust the shaft so the Spur Gears are
halfway engaged, and the Needle Bearing
is at least halfway engaged in the gear
block (reference image at right).
DO NOT set spur gears at full gear contact; it
can cause binding as the kettle is dumped.
4.
Snug tighten only, the set screw in set collar
above the crossbar to hold position. Then, lift
the agitator weight and check the clearance
between the shaft and the kettle bottom. If
there is adequate clearance, fully tighten the
set screw to secure set collar in place.
5.
Adjust clearance between the bottom of the
crossbar and the lower set collar to 1/32”
(1 mm) (thickness of a dime); then re-tighten
set screw to secure in place (reference image).
6.
Adjust set collar for agitator weight to be
between 3/16” to 1/4” (4.8 to 6.4 mm) above
the agitator weight.
Once adjusted,
re-tighten set screw
to secure in place.
Agitator shown for general
image reference
only (lids
not shown for clarity).
Adjust clearance to 1/32”
(1 mm)
(thickness of a dime)
3/16” to 1/4” max.
(4.8 to 6.4 mm)
Steps to Adjust Set Collars
Set Collar above Crossbar
Lower Set Collar
(below Crossbar)
Set Collar
(
for
Agitator Weight)
Agitator Weight
Stir Rod
Crossbar
Agitator Shaft

ReadyPop®Jr. Model No.: 2783-00-000 (010, 020, 030)
Page 17
gmpopcorn.com
THE FOLLOWING SECTIONS ARE FOR QUALIFIED SERVICE PERSONNEL ONLY
MAINTENANCE INSTRUCTIONS
DANGER
Machine must be properly grounded to prevent electrical shock to personnel.
Failure to do so could result in serious injury, or death.
Make sure all machine switches are in the OFF position before plugging the
equipment into the receptacle. Keep cord and plug off the ground and away
from moisture. Always unplug the equipment before cleaning or servicing.
DO NOT immerse any part of this equipment in water.
DO NOT use a water jet or excessive water when cleaning.
008_012221
DANGER
Improper installation, adjustment, alteration, service, or maintenance can
cause property damage, injury, or death. Any alterations to this equipment
will void the warranty and may cause a dangerous condition. This appliance
is not intended to be operated by means of an external timer or separate
remote-control system. NEVER make alterations to this equipment. Read the
Installation, Operating, and Maintenance Instructions thoroughly before
installing, servicing, or operating this equipment.
014_020416
WARNING
No user serviceable parts inside. Refer servicing to qualified service
personnel.
011_051514
CAUTION
THE FOLLOWING SECTIONS OF THIS MANUAL ARE INTENDED ONLY
FOR QUALIFIED SERVICE PERSONNEL WHO ARE FAMILIAR WITH
ELECTRICAL EQUIPMENT. THESE ARE NOT INTENDED FOR THE
OPERATOR.
027_010914

ReadyPop®Jr. Model No.: 2783-00-000 (010, 020, 030)
Page 18
gmpopcorn.com
ORDERING SPARE PARTS
1. Identify the needed part by checking it against the photos, illustrations, and/or
parts list. (General images may be used in manual for reference only.)
2. Use only approved replacement parts when servicing this unit.
3. When ordering, please include part number, part name, and quantity needed.
4. Please include your model number, serial number, and date of manufacture (located
on the machine nameplate/data plate) with your order.
5. Address all parts orders to Parts Department, Gold Medal Products Co., 10700
Medallion Drive, Cincinnati, Ohio 45241-4807
or place orders by phone or online:
Phone: [phone]
[phone]
Fax: [phone]
[phone]
E-mail: [email protected]
Web Page: gmpopcorn.com
Replacing Broken Glass
Broken glass panels can be easily replaced. Gold Medal Products Co. does not ship glass. It can be
obtained from a local glass shop, always purchase tempered glass.
GLASS DIMENSIONS (Height x Width x Thickness)
Front Glass
22.375” x 16.938” x .125” (568.3 mm x 430.2 mm x 3.2 mm)
Side Glass (2 pieces)
22.375 x 14.938” x .125” (568.3 mm x 379.4 mm x 3.2 mm)
1. Turn machine OFF, unplug unit and allow it to cool before attempting to replace glass.
2. Remove all loose pieces of glass (popper units: kettle may be removed to change glass).
3. Place a bungee (or large rubber band) around the unit to help hold the corner posts in
place, then remove dome.
4. Remove all rigid glass channels from around glass to be replaced, set channels aside
for reuse.
Note: The rigid channels may be wedged in the corner posts or top and bottom glass
extrusions and must be removed before new glass can be installed.
5. Carefully remove the rest of the broken glass.
6. Apply decals (if desired) to new glass panel.
7. Slide rigid glass channels over exposed sides and bottom of new glass panel.
8. Lift motor plate just enough to allow the new glass panel to slide into the corner posts
and down into the bottom glass extrusion.
9. Carefully lower the motor plate until the top glass extrusion secures glass in place.
10. Reinstall dome and remove bungee (popper units: reinstall kettle if removed).

ReadyPop®Jr. Model No.: 2783-00-000 (010, 020, 030)
Page 19
gmpopcorn.com
8 oz. Kettle 49472N (if equipped) – Agitator Assembly View
Item Part Description
Part Number
49472N
1
ACORN NUT
47702
2
8-32 X 1/2 PHIL PAN M/S
47141
3
DUMP HANDLE RH
49314
4
DUMP HANDLE KNOB
47110
5
SPACER (For Dump Handle)
49362
6
8-32 X 1” SET SCREW
77933
7
LID & AGITATOR ASSY (Complete Assembly)
49906N
8
KETTLE CROSSBAR ASSEMBLY
49907N
9
FRONT LID W/FORMED LIFTER
49017
10
REAR KETTLE LID
49016
11
AGITATOR BEARING HUB
43434
12
NEEDLE BEARING
47106
13*
SPUR GEAR KIT (Includes 2 gears with set
screws. Always replace Agitator Spur Gear and
Kettle Drive Motor Gear as a set.)
47059K
14
SET SCREW #10-32 X 3/16
41742
15
6 OZ. AGITATOR SHAFT
69710
16
SET COLLAR 5/16 ID 5/8 OD
46649
17
6 OZ. STIR ROD
69714
18
AGITATOR WEIGHT
69715
15
16, 14
18
17
Complete Agitator Assembly (Includes Lids)
11
12
13*
14
*See Parts
List note.
3 4
8 9 10
7
1
2
**Apply Loctite 246 to
bottom of set screws
before installing.
5
1
8
6**
See Kettle
Bottom
Assembly.
Complete Kettle Assembly
Overa ll Kett le 560 00
AgitatorAssembly56000

ReadyPop®Jr. Model No.: 2783-00-000 (010, 020, 030)
Page 20
gmpopcorn.com
8 oz. Kettle 49472N (if equipped) – Kettle Bottom Assembly
Item Part Description
Part Number
49472N
1
8 OZ. KETTLE BOTTOM ASSEMBLY (Complete
Assembly - includes parts listed below)
49489N
2
KETTLE SHELL
49431
3
KETTLE LEAD ASSEMBLY
49328
4
6 OZ. KETTLE GASKET
49368
5
6 OZ. CLAD KETTLE
49596
6
HEAT ELEMENT 120V, 1125W
49529
7
ELEMENT CLAMP
49532
8
5/16-18 SERRATED LOCK NUT
49317
9
5/16-18 X 3/4 SQUARE HEAD BOLT
49446
10
8-32 x 5/16 SLOTTED HEX (fastens ground)
49594
11
8-32 TOP LOCK NUT (always replace if removed)
67943
12
8-32 x 1 SS HEX SC (holds Thermostat)
49076
13
450°F THERMOSTAT (includes two 6-32 Screws)
76089
14
THERMOSTAT SHUNT BAR
47193
15
525°F THERMOSTAT (includes two 6-32 Screws)
76702
Lock Nut View
2
3
Kettle Bottom Assembly
1
5
4
6
7
8, 9
10
15 13 14
Top Lock Nut - Fastens
thermostat.
Install Lock
Nut
with triangle in UP
position (as shown)
.
ONE TIME USE ONLY,
REPLACE NUT if
removed.
Thermostat
11
12
KettleBottom Assembly 49472N
ElementView 49472N
Element
View
