Goldmedal Unifloss 3034 User manual

Part No. 13054
UNIFLOSS
Floss Stand Instruction Manual
Models 3034, 3034GT, 3035, 3035BC, 3035BN, and 3119
Cincinnati, OH 45241-4807 USA

SAFETY PRECAUTIONS
DANGER
Machine must be properly grounded to prevent electrical shock to personnel.
Failure to do so could result in serious injury, or death.
DO NOT immerse any part of this equipment in water.
DO NOT use excessive water when cleaning.
Keep cord and plug off the ground and away from moisture.
Always unplug the equipment before cleaning or servicing.
Make sure all machine switches are in the OFF position before plugging the
equipment into the receptacle.
008_051514
DANGER
Improper installation, adjustment, alteration, service, or maintenance can
cause property damage, injury, or death. Any alterations to this equipment
will void the warranty and may cause a dangerous condition. This appliance
is not intended to be operated by means of an external timer or separate
remote-control system. NEVER make alterations to this equipment. Read the
Installation, Operating, and Maintenance Instructions thoroughly before
installing, servicing, or operating this equipment.
014_020416
WARNING
Floss head rotates at high speeds. Operator MUST keep hands and face
clear of the floss head to avoid injury. Operator must wear eye protection.
Keep all spectators at a reasonable distance, and use a Floss Bubble for
added customer protection.
015_062714
WARNING
Keep all foreign objects out of floss head. To avoid eye injury, DO NOT fill
floss head with sugar while the head is on and rotating.
016_010914
WARNING
Burn Hazard. DO NOT touch spinner head. Allow to cool before cleaning or
servicing. Avoid contact with molten sugar.
006_092414
WARNING
ALWAYS wear safety glasses when servicing this equipment.
010_010914

SAFETY PRECAUTIONS (continued)
WARNING
No user serviceable parts inside. Refer servicing to qualified service
personnel.
011_051514
WARNING
Read and understand operator’s manual and all other safety instructions
before using this equipment. To order copies of the operator’s manual go to
gmpopcorn.com or write to Gold Medal Products Co., 10700 Medallion Drive,
Cincinnati, OH 45241 USA 1-(800)-543-0862
022_060215
WARNING
DO NOT allow direct contact of this equipment by the public when used in
food service locations. Only personnel trained and experienced in the
equipment operation may operate this equipment.
Carefully read all instructions before operation.
012_010914
WARNING
This machine is NOT to be operated by minors.
007_010914
Note: Improvements are always being made to Gold Medal’s equipment. This information
may not be the latest available for your purposes. It is critical that you call Gold Medal’s
Technical Service Department at -800-543-0862 for any questions about your
machine operations, replacement parts, or any service questions. (Gold Medal
Products Co. does not assume any liability for injury due to careless handling and/or
reckless operation of this equipment.) General images may be used in manual for
reference only.

Unifloss Floss Stands
ALL MODELS #3034, #3035 AND #3119
1
INSTALLING A UNIFLOSS STAND
There are two halves to the Unifloss Stand. For free-standing installations, use the base and
merely set the unit's top half on it, as shown in the drawing below. For in-counter installations, place
the top section of the Unifloss Stand over a cut-out in your countertop. A shelf is required under the
counter to set the floss machine on. For countertop cut-out size and shelf location, request drawing
numbers B-3374 and C-3418 from Gold Medal Products Company.
After the top half of the Unifloss Stand is in position, tilt the floss machine and position the spinner
head in the center of the cut-out. Make sure shipping support angles are removed as indicated in the
installation section of this manual.
Place the spun aluminum pan over the floss head of the machine. Re-center the machine to provide
equal spacing between the pan and cut-out.
After connecting the power supply cords, you are ready to make cotton candy. See OPERATING
INSTRUCTIONS in the floss manual.
ELECTRICAL REQUIREMENTS
All export Unifloss Tops are equipped with a 16 amp, 230 volt power supply cord for use with single
phase A.C. current. These units must be grounded in accordance with local codes.
CHECKING SHIPMENT
Remove carton from Unifloss Top. Check unit thoroughly for any damage which may have occurred
in transit. Claims should be filed immediately with the transportation company. Remove all tape and
packing material.
a

Unifloss Floss Stands
Care and Cleaning
1. Reference the Floss Unit Manual for instructions on cleaning the floss machine.
2. Wipe stainless steel parts with a clean cloth and cleaner designed for stainless steel,
such as Gold Medal Watchdog Stainless Cleaner Item No. 2088).
DO NOT use oven cleaners or abrasive materials as they will damage parts of machine.
3. Clean glass panels with glass cleaner. Gold Medal Watchdog Glass Cleaner Item No.
2588) is recommended.
Ammonia cleaners will damage plastic doors/panels. Use only non-ammonia cleaners,
such as Gold Medal Watchdog Glass Cleaner Item No. 2588).
1A ALL MODELS #3034, #3035, and #3119

Unifloss Floss Stands
ALL MODELS #3034, #3035 AND #3119
2
ORDERING SPARE PARTS
1. Identify the desired part by checking it against the photos, illustrations, and/or the parts list.
2. When ordering, please include part number, part name, and quantity desired.
3. Please include your model name and machine serial number (located on the machine name-
plate) with your order.
4. Address all parts orders to: Parts Department
Gold Medal Products Co.
10700 Medallion Drive
Cincinnati, Ohio 45241-4807
or, place orders at:
[phone]
Fax: [phone]
E-mail: [email protected]
NOTE: We do not ship glass. Obtain glass from a local glass shop or hardware store. Always
purchase double strength glass in the following sizes:
Unit Front Glass Side Glass
Regular Unifloss 241/4" x 261/8"24
7/16" x 261/8"
Antique Unifloss 231/16" x 261/8"23
1/16" x 261/8"
MAINTENANCE INSTRUCTIONS
THE FOLLOWING SECTIONS OF THIS MANUALARE
INTENDED ONLY FOR QUALIFIED SERVICE PERSONNEL
WHO ARE FAMILIAR WITH ELECTRICAL EQUIPMENT. THESE
ARE NOT INTENDED FOR THE OPERATOR.
Adequate eye protection must be used when servicing this
equipment to prevent the possibility of injury.
Do NOT immerse the equipment in water.
Unplug your machine before servicing.
a

Unifloss Floss Stands
ALL MODELS #3034, #3035 AND #3119
3
PARTS LIST - MINI UNIFLOSS STANDS
3034 3034GT
Mini Gold Mini
Part No. Part No. Description
13154 13154 Glass retaining strip, front
13155 13155 Glass retaining strip, rear
13002 13004 Top extrusion frame
13085 13085 Base cabinet
13003 13107 Bottom extrusion frame
37514 37514 Swivel caster with lock
37515 37515 Swivel caster
13071 13071 Cut-out panel for base extrusion
41092 41092 Eagle insignia
41093 41093 Script nameplate
13063 13063 Shipping carton, bottom
13148 13148 Shipping carton, top
47132 47132 Vinyl glass channel
13147 13147 Sneeze guard
13071 13071 Cut-out panel
13153 13143 Corner post
a

Unifloss Floss Stands
ALL MODELS #3034, #3035 AND #3119
4
PARTS LIST - UNIFLOSS STANDS
#3035BC #3035 Back Counter
Part No. Part No. Description
12072 12072 End cap
13002 13002 Top frame
13003 13003 Bottom frame
13009 13009 Fan blade
13010 13010 Motor fan
13013 13013 Aluminum mesh filter
13028 13028 Fan mount bracket
13036 13036 Protective cover, light tube
13045 13045 Filter mount frame assembly
13046 13046 Light bracket for animated sign
13049 13052 Canopy assembly
13062 13062 Shipping carton, top
13071 13071 Cut-out panel
13075 13075 Animated sign face
13076 13076 Disc, animated sign
13077 13077 Motor
13078 13078 Top trim
13079 13079 Right side trim
13080 13080 Left side trim
13081 13081 Coupling, motor & sign
13087 13087 Decal front glass
13152 13152 Corner cover
22038 22038 Power supply cord
39016 39016 Fluorescent light tube
41020 41020 Light tube holder
41021 41021 Light tube holder w/ starter
41022 41022 Light ballast
41023 41023 Light starter
47178 47178 Corner post
47201 47201 On/off switch
47236 47236 Bushing snap
47592 47592 Rear glass retainer
47593 47593 Front glass retainer
47694 47694 Rigid channel 227/8"
47697 47697 Rigid channel 2913/16"
76026 76026 Strain Relief
a

Unifloss Floss Stands
ALL MODELS #3034, #3035 AND #3119
5
PARTS LIST - NEON UNIFLOSS STANDS
#3035BN
Part No. Description
12072 End cap
13002 Top frame
13003 Bottom frame
13009 Fan blade
13010 Motor fan
13013 Aluminum mesh filter
13028 Fan mount bracket
13036 Protective cover for light tube
13039 Bottom support angle
13040 Stainless canopy assembly
13042 Filter mount weld assembly
13062 Shipping carton, top
13065 Fan housing weld assembly
13071 Cut-out panel
13152 Corner cover
13204 Glass support
22038 Power supply cord
39016 Fluorescent light tube
41020 Light tube holder
41021 Light tube holder w/ starter
41022 Light ballast
41023 Light starter
43147 Neon cotton candy sign
47178 Corner post
47201 Switch on/off
47236 Bushing snap
47243 Top support angle
47592 Rear glass retainer
47593 Front glass retainer
47694 Rigid channel 227/8"
47697 Rigid channel 2713/16"
76026 Strain relief
a

Unifloss Floss Stands
ALL MODELS #3034, #3035 AND #3119
6
PARTS LIST  ANTIQUE UNIFLOSS STANDS
#3119
Part No. Description
13009 Fan blade
13010 Fan motor
13013 Aluminum mesh filter
13028 Fan mount bracket
13071 Cut-out panel
13101 Lower top frame
13103 Filter mount frame
13105 Fan housing assembly
13107 Bottom frame, gold
13115 Shipping carton, top
13117 Dimmer switch nameplate
13118 Blower switch nameplate
13152 Corner cover
13157 Reflector flood
22038 Power supply cord
41643 Light mount bracket, long
47047 Lamp holder
47201 Switch on/off
47236 Bushing snap
47309 Corner post, gold
47401 Top left ornament assembly
47406 Upper top frame
47418 Top inspection cover
47422 Clear light bulb
47423 Dimmer switch
47429 U-clip
47434 Light sockets
47439 Top right ornament assembly
47592 Rear glass retainer
47593 Front glass retainer
47694 Rigid channel 227/8"
47697 Rigid channel 2713/16"
76026 Strain relief
FOR MACHINES MANUFACTURED IN 1998 WITH AMUSEMENT RIDE LIGHTING:
13014 Label, rocker switch
42798 Switch, lighted rocker
48127 Lower top frame
48495 Box, rocker switch, two cutouts
48474 Base, socket
48475 Ring, socket
48476 Cap, small lens, clear
48490 Body, small lens, clear
48491 Light bulb, E-14, T5
49480 Shield, light
