Goldmedal 2552 User manual

© 2016 Gold Medal Products Co. Part No. 49749
Instruction Manual
10700 Medallion Drive, Cincinnati, Ohio 45241-4807 USA
PopMaxx 12/14 oz. Popper
Model No. 2552, 2552KC

PopMaxx
12/14 oz. Popper Model No. 2552 and 2552KC
Page 2
gmpopcorn.com
SAFETY PRECAUTIONS
DANGER
Machine must be properly grounded to prevent electrical shock to personnel.
Failure to do so could result in serious injury, or death.
DO NOT immerse any part of this equipment in water.
DO NOT use excessive water when cleaning.
Keep cord and plug off the ground and away from moisture.
Always unplug the equipment before cleaning or servicing.
Make sure all machine switches are in the OFF position before plugging the
equipment into the receptacle.
008_051514
DANGER
Improper installation, adjustment, alteration, service, or maintenance can
cause property damage, injury, or death. Any alterations to this equipment will
void the warranty and may cause a dangerous condition. This appliance is
not intended to be operated by means of an external timer or separate
remote-control system. NEVER make alterations to this equipment. Read the
Installation, Operating, and Maintenance Instructions thoroughly before
installing, servicing, or operating this equipment.
014_020416
WARNING
To avoid burns, DO NOT touch the kettle or any heated surface.
DO NOT place or leave objects in contact with heated surfaces.
013_092414
WARNING
ALWAYS wear safety glasses when servicing this equipment.
010_010914
WARNING
No user serviceable parts inside. Refer servicing to qualified service
personnel.
011_051514
WARNING
Read and understand operator’s manual and all other safety instructions
before using this equipment. To order copies of the operator’s manual go to
gmpopcorn.com or write to Gold Medal Products Co., 10700 Medallion Drive,
Cincinnati, OH 45241 USA 1-(800)-543-0862
022_060215

PopMaxx
12/14 oz. Popper Model No. 2552 and 2552KC
Page 3
gmpopcorn.com
SAFETY PRECAUTIONS (continued)
WARNING
DO NOT allow direct contact of this equipment by the public when used in
food service locations. Only personnel trained and experienced in the
equipment operation may operate this equipment.
Carefully read all instructions before operation.
012_010914
WARNING
This machine is NOT to be operated by minors.
007_010914
Note: Improvements are always being made to Gold Medal’s equipment. This
information may not be the latest available for your purposes. It is critical that
you call Gold Medal’s Technical Service Department at -800-543-0862 for any
questions about your machine operations, replacement parts, or any service
questions. (Gold Medal Products Co. does not assume any liability for injury due
to careless handling and/or reckless operation of this equipment.)

PopMaxx
12/14 oz. Popper Model No. 2552 and 2552KC
Page 4
gmpopcorn.com
INSTALLATION INSTRUCTIONS
Inspection of Shipment
After unpacking, check thoroughly for any damage which may have occurred in transit. Claims
should be filed immediately with the transportation company. The warranty does not cover
damage that occurs in transit, or damage caused by abuse, or consequential damage due to the
operation of this machine, since it is beyond our control (reference warranty in back of manual).
Manual
Read and understand the operator’s manual and all other safety instructions before using this
equipment. To order copies of the operator’s manual go to gmpopcorn.com or write to Gold
Medal Products Co., 0700 Medallion Drive, Cincinnati, OH 4524 USA -(800)-543-0862.
Model Description
2552: 2/ 4 oz. PopMaxx Popper, with Popcorn Decal.
2552KC: 2/ 4 oz. PopMaxx Popper with Pappy’s Decal, and special kettle for popping
Pappy’s Kettle Corn.
Items Included with this Unit
Measure
14.7 cc
12 oz. Corn
Measure
Black
Crutch Tips
Bulb
for
Cabinet
nterior
Knobs with Tee Bolts
(for Popper Doors)
Knob with Screw
(for Old Maid Pan)
Measure
1/2 Cup
Popcorn Decal (2552 only)
Salt Shaker
(2552KC only)
Timer
(2552KC only) Pappy’s Label (2552KC only)
Pappy’s
nstruction Labels
(2552KC only)
Aluminum
Scoop

PopMaxx
12/14 oz. Popper Model No. 2552 and 2552KC
Page 5
gmpopcorn.com
Setup
This unit has been tested at the factory.
. Remove all packaging and tape prior to operation. Remove accessories and carefully
remove kettle packed in cabinet interior.
2. Place unit on a sturdy, level base.
3. The Popper blower vents out top of unit, allow adequate clearance for airflow.
4. Unit has 4 glide feet preinstalled at the factory (see image below). Install a Black
Crutch Tip on each foot. Firmly push crutch tip over glide until it covers glide entirely.
5. Tilt kettle and insert into hanger arms, then allow kettle to return naturally to an
upright position (see image below).
6. Plug kettle lead into receptacle located on ceiling of cabinet interior. Align keyed or
hook shaped prong with the correct opening, then push plug all the way in and twist
or rotate to lock in place. To unplug, untwist kettle plug before attempting to pull from
receptacle.
7. Door knobs are shipped in accessories pack. Install a door knob with tee bolt on each
popper door; install knob with screw on old maid pan.
8. Carefully install light bulb (do not over-tighten) into lamp holder located in cabinet
interior. Ensure unit is OFF and unplugged before installing or changing bulb
(reference Electrical Requirements section).
9. Apply Popcorn decal to unit.
0. Model 2552KC - Mount Timer (use Velcro provided) and Instruction Labels to popper
in desired locations.
. After setup, unit should be cleaned prior to use (see Care and Cleaning section).
Black Crutch Tip
Glide
(pre
-
installed
at the factory)
General images shown for reference only.
Kettle shown mounted
in hanger arms.
Kettle lead
shown plugged
into kettle
receptacle.

PopMaxx
12/14 oz. Popper Model No. 2552 and 2552KC
Page 6
gmpopcorn.com
Electrical Requirements
The following power supply must be provided:
2552, 2552KC: 20 V~, 380 W, 60 Hz
DANGER
Machine must be properly grounded to prevent electrical shock to personnel.
Failure to do so could result in serious injury, or death.
DO NOT immerse any part of this equipment in water.
DO NOT use excessive water when cleaning.
Keep cord and plug off the ground and away from moisture.
Always unplug the equipment before cleaning or servicing.
Make sure all machine switches are in the OFF position before plugging the
equipment into the receptacle.
008_051514
A certified electrician must furnish sufficient power for proper machine operation and install any
supplied receptacle. We recommend this equipment be on a dedicated and protected circuit.
Failure to wire properly will void the warranty and may result in damage to the machine. It is Gold
Medal Products Co.’s recommendation that this machine be plugged directly into a wall outlet. The
use of extension cords is not recommended due to safety concerns, and may cause sacrificed
and/or reduced performance. Make sure cord is located to prevent a trip hazard or unit upset.
Before You Plug In Machine
. Make sure all machine switches are OFF before plugging equipment into receptacle.
2. Make sure wall outlet can accept the grounded plugs (where applicable) on the power
supply cord.
3. The wall outlet must have the proper polarity. If in doubt, have a competent
electrician inspect the outlet and correct if necessary.
4. DO NOT use a grounded to un-grounded receptacle adapter (where applicable).
5. Install unit in a level position.
CAUTION
If the supply cord is damaged, it must be replaced by Gold Medal Products Co.,
its service agent or similarly qualified persons in order to avoid a hazard.
039_080614

PopMaxx
12/14 oz. Popper Model No. 2552 and 2552KC
Page 7
gmpopcorn.com
OPERATING INSTRUCTIONS
Controls and Their Functions
KETTLE HEAT SW TCH
Two position, ON/OFF lighted rocker switch - supplies power to the heating elements in the
popping kettle. The green switch light ON indicates there is power to the kettle heating
element.
KETTLE MOTOR SW TCH
Two position, ON/OFF lighted rocker switch - supplies power to the kettle agitator motor
and exhaust blower. The Kettle Motor Switch MUST be ON at all times when there is
popcorn (popped or un-popped) in the kettle. The green switch light ON indicates there is
power to the agitator motor and exhaust blower.
L GHTS/WARMER SW TCH
Two position, ON/OFF lighted rocker switch - supplies power to the interior cabinet light,
and heat element for the corn pan.
Kettle Heat Switch
Kettle Motor Switch
Lights/Warmer
Switch

PopMaxx
12/14 oz. Popper Model No. 2552 and 2552KC
Page 8
gmpopcorn.com
Popping Corn Instructions
This section describes instructions for popping Standard (salted) popcorn, and for popping
Pappy’s Kettle Corn.
Amount of Popcorn and Oil
The popper is equipped with a corn, salt, and oil measure. We recommend flavored and colored
coconut oil. Popcorn popped in coconut oil stays fresh longer and does not leave black deposits in
the kettle like other oils. Use only top quality, fresh popcorn from reputable suppliers.
Kettle Size
Popcorn Charge
Oil Charge
Flavacol (Salt)
2 oz.
2 oz. (355 ml)
4 oz. ( 8 ml)
Tblsp. ( 5cc)
For best results use Mega-Pop® 2 oz. premeasured pouches (Item# 2839).
Popping Standard (Salted) Popcorn
. Turn all switches ON.
2. To determine when kettle is ready to pop corn (about 4 minutes), test pop three
kernels of corn in one ounce (30 ml) of popping oil. When kernels pop, kettle is ready.
3. Lift kettle lid and load Mega-Pop® premeasured popcorn and oil pouch, or pour in
popcorn and Flavacol, then add oil in premeasured amount. Close lid.
4. When corn has finished popping, gently dump the popcorn.
5. On final kettle of corn, turn Kettle Heat Switch OFF just as lids are forced open by the
popping corn. This procedure saves electricity, since kettle has plenty of heat, and helps
eliminate smoke/odor from any oil residue that remains after popping has stopped.
6. When finished popping, turn KETTLE HEAT and KETTLE MOTOR switches OFF.
NEVER LEAVE THE HEAT ON WHEN YOU ARE NOT POPP NG CORN!

PopMaxx
12/14 oz. Popper Model No. 2552 and 2552KC
Page 9
gmpopcorn.com
Popping Pappy’s Kettle Corn (Timer included with Unit)
tems needed: Popcorn, oil, Pappy’s Kettle Corn Mix (Item No. 2545CT, /2 gallon container),
and Diamond Crystal Popcorn Salt (Item No. 2070CT, 2 oz. container). DO NOT use popcorn
seasoning salt when popping Pappy’s Kettle Corn.
Gold Medal recommends white coconut oil for popping Pappy’s Kettle Corn (colored oil can change
the popcorn color). Popcorn popped in coconut oil stays fresh longer and does not leave black
deposits in the kettle like other oils. Use only top quality, fresh popcorn from reputable suppliers.
Kettle Size
Popcorn Amount
Oil Amount
Pappy’s Mix Amount
2 oz.
2 oz.
5 oz.
7
-
8 oz.
. Turn all switches ON.
2. To determine when kettle is ready to pop corn (about 4 minutes), test pop three
kernels of corn in one ounce (30 ml) of popping oil. When kernels pop, kettle is ready.
3. Lift kettle lid and pour in popcorn and oil (use amounts specified above, adjust as
needed for desired taste). DO NOT add Salt (salt is added after popping). Close lid.
4. Start timer, pre-set for 30-45 seconds (see Countdown Timer Instructions below).
5. When timer goes OFF, add Pappy’s Mix to kettle (use amount specified above). If
popping has just started, close the right door of popper cabinet, and carefully/quickly
add Pappy’s mix through the left door. Close kettle lid, then re-open the right door.
Caution: Due to the potential of getting hit with hot popcorn seeds, we recommend
using eye protection for this step.
6. When the corn has nearly finished popping, gently dump the popcorn.
7. Immediately shake on Diamond Crystal Salt and mix thoroughly.
8. On final kettle of corn, turn Kettle Heat Switch OFF just as lids are forced open by the
popping corn. This procedure saves electricity, since kettle has plenty of heat, and helps
eliminate smoke/odor from any oil residue that remains after popping has stopped.
9. When finished popping, turn KETTLE HEAT and KETTLE MOTOR switches OFF.
NEVER LEAVE THE HEAT ON WHEN YOU ARE NOT POPP NG CORN!
0. Clean kettle when finished popping kettle corn, and prior to popping standard popcorn.
Countdown Timer Instructions
. Press MIN and SEC together to reset timer to zero.
2. Use MIN and SEC buttons to set time.
3. Press START button to start or stop.
4. The alarm will sound for 60 seconds or press any key to stop alarm. The timer will
return to the set time.

PopMaxx
12/14 oz. Popper Model No. 2552 and 2552KC
Page 10
gmpopcorn.com
Care and Cleaning
DANGER
Machine must be properly grounded to prevent electrical shock to personnel.
DO NOT immerse in water.
Always unplug the equipment before cleaning or servicing.
025_020314
WARNING
To avoid serious burns, DO NOT touch the kettle while it is hot!
028_082715
Good sanitation practice demands that all food preparation equipment be cleaned regularly (only
use non-toxic, food grade cleaners). A clean looking, well-kept machine is one of the best ways of
advertising your product.
Note: It is extremely important to follow all of the cleaning procedures, otherwise parts
damage and equipment failure will result. The warranty does not cover parts that
are damaged due to improper cleaning.
Daily Kettle Cleaning Instructions
CAUT ON: A hot kettle will cause burns if you touch it with your hand. Allow kettle to cool
at least hour before attempting to clean. DO NOT use ice or water to cool
down a hot kettle! Severe kettle damage will result!
. When cool, wipe the outside of the kettle with a clean, soft cloth. DO NOT use oven
cleaners or abrasive materials as they will damage the kettle.
2. Every night, mix Gold Medal’s Heat’n Kleen solution (Item No. 2095), 2 tablespoons
per gallon of water. It is not necessary to use the entire gallon at once; only use
enough to fill the kettle /2 inch deep.
3. Turn the kettle heat ON. When the water starts to boil, turn the kettle heat OFF.
4. Allow to cool for at least hour, then dump the solution into a bucket and wipe the
inside of the kettle with a clean cloth. Make sure all of the solution goes into the
bucket; do not spill any in the interior of the machine.
For an extra dirty kettle, the process may be repeated; or, after turning the kettle heat
OFF, allow solution to sit in the kettle overnight. The next morning, dump the solution
into a bucket and wipe the inside of the kettle with a clean cloth.
5. With the unit OFF and unplugged, wipe the kettle lead cord with a clean SLIGHTLY damp
cloth. DO NOT get moisture into the kettle lead-in cord, severe damage will result.

PopMaxx
12/14 oz. Popper Model No. 2552 and 2552KC
Page 11
gmpopcorn.com
Daily Unit Cleaning Instructions
. Turn machine OFF, unplug unit and allow it to cool before attempting to clean.
2. Clean all pans/accessories in order to sanitize them before each use.
3. Take a clean, SLIGHTLY damp cloth and wipe excess grease from glass and cabinet.
4. Wipe stainless steel parts with a clean cloth and cleaner designed for stainless steel,
such as Gold Medal Watchdog Stainless Cleaner (Item No. 2088).
DO NOT use oven cleaners or abrasive materials as they will damage parts of machine.
5. Clean glass panels with glass cleaner. Gold Medal Watchdog Glass Cleaner (Item No.
2588) is recommended.
Ammonia cleaners will damage plastic doors/panels. Use only non-ammonia cleaners,
such as Gold Medal Watchdog Glass Cleaner (Item No. 2588).
Filter Cleaning Instructions
The popcorn machine is equipped with an efficient and durable filtration system. The filter
should be cleaned every -2 weeks to maintain maximum efficiency.
Steps to Clean Filter
Step 1: Turn unit OFF and allow it to cool
before removing filter. Filter is located
inside the popcorn machine, above the
popping kettle.
Step 2:
Remove filter by gripping the filter
itself and pulling straight down.
Step 3:
Clean filter in warm soapy water
,
then rinse and allow to dry overnight.
Replace filter by putting it into the slot and
pushing upward. Make sure the filter frame
is flush with the ceiling of the popper (as
shown above).

PopMaxx
12/14 oz. Popper Model No. 2552 and 2552KC
Page 12
gmpopcorn.com
Troubleshooting
ssue
Possible Cause
Solution
Power to the Unit
A.
Power to
the
Unit
A.
Make sure the
unit’s power
cord is plugged in.
Kettle Does Not Heat
A.
Power to the Kettle
A.
Make sure kettle lead
-
in cord is plugged in and
twisted to lock into the kettle receptacle.
B.
Kettle Heat Switch
B.
Have a qualified service person c
heck the
voltage to and from the Kettle Heat Switch; if
switch is defective, replace it.
C.
Heating Element
C.
Heating element in the kettle may
be burned
out. Check with a qualified service person for
inspection/repair.
Long Popping Cycles
(Longer than 4 minutes for
Salt Popcorn)
A.
Low Voltage
A.
If the machine is operated on low voltage, this
could cause the kettle not to reach the proper
operating temperature. Check with a qualified
electrician.
B.
Inadequate Supply Lines
B.
Inadequately sized electrical supply lines
or
use of extension cord, in addition to being a
fire hazard, would also prevent the kettle from
reaching the proper operating temperature.
Check with a qualified electrician.
C.
Inferior Corn
C.
Inferior quality corn would result in longer
popping cycles. Use only top quality hybrid
popcorn from reputable suppliers. Even then,
if you let your corn pick up moisture or dry
out, your popping cycles will be slow.
Kettle Agitator
Shaft not
Rotating
A.
Kettle Motor Switch
A.
If the kettle agitator shaft is not rotating,
DO NOT pop corn. Make sure the Kettle Motor
Switch is ON. If the switch is ON, and the shaft
is not rotating, the switch or motor may be
faulty, contact qualified service personnel for
inspection/repair.
B.
Kettle Agitator
S
haft
/Stir
Blade not rotating. (Unit
must be OFF, unplugged
and cool prior to
checking or adjusting
the agitator assembly.)
B.
If the kettle agitator shaft is not rotating,
DO NOT pop corn. Check the clearance
between the kettle bottom and the stir blade;
it should be /32” (use a dime). To adjust,
reference the Agitator Set Collar Adjustment
section.

PopMaxx
12/14 oz. Popper Model No. 2552 and 2552KC
Page 13
gmpopcorn.com
Agitator Set Collar Adjustment
The following instructions describe how to properly adjust set collars on an agitator assembly
with a floating stir rod.
Step 1:
Make sure machine is OFF and
unplugged, then allow unit to cool completely
before attempting to adjust the agitator height.
Step 2: Loosen the set screw in each set collar
to be adjusted.
Step 3: With the kettle mounted in the popper,
adjust the shaft so the Agitator’s Spur Gear
contacts half of the Drive Motor Spur Gear
(reference Spur Gear Placement image at right).
DO NOT set spur gears at full gear contact; it
can cause binding as the kettle is dumped.
Step 4: Once shaft is positioned correctly,
re-tighten the set screw in the set collar above
the crossbar to secure in place.
Step 5: Adjust clearance between the bottom of
the crossbar and the lower set collar to /32”
(thickness of a dime); then re-tighten set screw
to secure in place (see image below).
Step 6: Adjust set collar for agitator weight to
be between 3/ 6” to /4” above the agitator
weight. Once adjusted, re-tighten set screw to
secure in place.
Drive Motor
Spur Gear
Agitator’s Spur Gear
Agitator’s Spur Gear
should set halfway
up on Drive Motor
Spur Gear.
Set Collar
w/Set screw
Agitator shown for general image
reference only (lids not shown for
clarity).
Adjust clearance to
thickness of a dime.
3/16” to 1/4” max.
Spur Gear Placement
Steps to Adjust Set Collars
Set Collar above Crossbar
Lower Set Collar
(below Crossbar)
Set Collar
(for Agitator Weight)
Agitator Weight
Stir Rod
Crossbar

PopMaxx
12/14 oz. Popper Model No. 2552 and 2552KC
Page 14
gmpopcorn.com
MAINTENANCE INSTRUCTIONS
DANGER
Machine must be properly grounded to prevent electrical shock to personnel.
Failure to do so could result in serious injury, or death.
DO NOT immerse any part of this equipment in water.
DO NOT use excessive water when cleaning.
Keep cord and plug off the ground and away from moisture.
Always unplug the equipment before cleaning or servicing.
Make sure all machine switches are in the OFF position before plugging the
equipment into the receptacle.
008_051514
DANGER
Improper installation, adjustment, alteration, service, or maintenance can
cause property damage, injury, or death. Any alterations to this equipment will
void the warranty and may cause a dangerous condition. This appliance is
not intended to be operated by means of an external timer or separate
remote-control system. NEVER make alterations to this equipment. Read the
Installation, Operating, and Maintenance Instructions thoroughly before
installing, servicing, or operating this equipment.
014_020416
WARNING
No user serviceable parts inside. Refer servicing to qualified service
personnel.
011_051514
CAUTION
THE FOLLOWING SECTIONS OF THIS MANUAL ARE INTENDED ONLY
FOR QUALIFIED SERVICE PERSONNEL WHO ARE FAMILIAR WITH
ELECTRICAL EQUIPMENT. THESE ARE NOT INTENDED FOR THE
OPERATOR.
027_010914

PopMaxx
12/14 oz. Popper Model No. 2552 and 2552KC
Page 15
gmpopcorn.com
ORDERING SPARE PARTS
. Identify the needed part by checking it against the photos, illustrations, and/or
parts list.
2. Use only approved replacement parts when servicing this unit.
3. When ordering, please include part number, part name, and quantity needed.
4. Please include your model number, serial number, and date of manufacture (located
on the machine nameplate/data plate) with your order.
5. Address all parts orders to:
Parts Department
Gold Medal Products Co.
0700 Medallion Drive
Cincinnati, Ohio 4524 -4807
Or, place orders by phone or online:
Phone: [phone]
(5 3) 769-7676
Fax: [phone]
(5 3) 769-8500
E-mail: [email protected]
Web Page: gmpopcorn.com

PopMaxx
12/14 oz. Popper Model No. 2552 and 2552KC
Page 16
gmpopcorn.com
Replacing Broken Glass
Broken glass panels can be easily replaced. Gold Medal Products Co. does not ship glass. It can be
obtained from a local glass shop, always purchase tempered glass.
GLASS D MENS ONS (Height x Width x Thickness)
Front and Side Glass: 2 /4” X 6 7/8” X /8” (3 Pieces)
. With the machine OFF, unplug the unit and allow it to cool before attempting to
replace any glass.
2. Carefully remove all loose pieces of broken glass.
3. Pull out Magnetic Clip (located above glass panel in cabinet interior) to remove (see
Figure A below).
4. Slide glass panel up under top ridge, then swing the bottom of the panel out and lower
it away from unit (see Figures A and B below).
5. Carefully remove the rest of the broken glass.
6. Remove all rigid glass channels from around the glass to be replaced, set channels
aside for reuse.
7. Apply decals (if desired) to the new glass panel.
8. Slide rigid glass channels over the exposed edges of the new glass panel.
9. Carefully slide new glass panel up under top ridge, then lower it into the bottom channel.
0. Reinstall magnetic clip above the new panel in cabinet interior.
Figure A
-
Remove magnetic
clip located above glass panel.
Figure C
–
Swing bottom of
glass panel out, then lower
it away from unit.
Figure B
-
Slide
glass panel
up under top ridge.
Magnetic
Clip
General images shown for glass
installation reference only.

PopMaxx
12/14 oz. Popper Model No. 2552 and 2552KC
Page 17
gmpopcorn.com
12/14 oz. Kettle Assembly (58014, 58014KC) – Agitator Assy. View
tem Part Description Part Number
58014, 58014KC
/4
-
20 X /2 THUMB SCREW
6 059
2
8
-
32 X 3/8 FL HD PH MS
20065
3
KETTLE & SHELL BLOCK
6 0 3
4
DUMP HANDLE
–
BLOCK WELDMENT
88769
5
DUMP HANDLE KNOB
47 0
6
8
-
32
X FL HD PH MS
20068
7
LID & AGITATOR ASSY (Complete Assembly)
580 6
8
KETTLE CROSSBAR ASSEMBLY
580 5
9
FRONT
KETTLE LID
47720
0
REAR KETTLE LID
47 9
AGITATOR BEARING HUB
43434
2
NEEDLE BEARING
47 06
3
SPUR GEAR KIT (Includes 2 gears with
set
screws. Always replace Agitator Spur Gear and
Kettle Drive Motor Gear as a set.)
47059K
4
SET SCREW # 0
-
32 X 3/ 6
4 742
5
2/ 4 OZ.
AGITATOR SHAFT
697 2
6
SET COLLAR 5/ 6 ID 5/8 OD
46649
7
AGITATOR WEIGHT
697 5
8
6 OZ.
STIR ROD
69806
15
16, 14
18 17
Co
mplete Agitator Assembly
( ncludes Lids)
11
12
13*
14
*See Parts
List note.
8 9 10
7
4
1
6
See Kettle
Bottom
Assembly.
Complete Kettle Assembly
Overall Kettle 6105 4EX
Crossbar Assembly 56000
4 5
1
3
2

PopMaxx
12/14 oz. Popper Model No. 2552 and 2552KC
Page 18
gmpopcorn.com
12/14 oz. Kettle Assembly (58014, 58014KC) – Kettle Bottom View
tem Part Description Part Number Part Number
58014
58014KC
2/ 4 OZ. KETTLE
BOTTOM ASSEMBLY
(includes parts listed below) 580 2 580 2KC
2
KETTLE SHELL
6 0 7
6 0 7
3
KETTLE LEAD ASSY
6 226
6 226
4
KETTLE GASKET
6 0 2
6 0 2
5
KETTLE INTEGRAL HTR 2/ 4
580
580
6
2/ 4OZ SHUNT BAR
77879
77879
7
8
-
32 TOP LOCK NUT
(always replace if removed)
67943
67943
8
482°F THERMOSTAT (includes two 6
-
32 screws)
76708
450F THERMOSTAT
(includes two 6
-
32 screws)
76089
9
THERMOSTAT SHUNT BAR
47 93
47 93
0
550°F THERMOSTAT (includes two 6
-
32 screws)
77 08
525F THERMOSTAT
(includes two 6
-
32 screws)
76702
9 10 8
Element
View
Lock Nut View
Top Lock Nut
-
Fastens
each thermostat and
ground. Install Lock Nut
with triangle in UP
position (as shown).
ONE T ME USE ONLY,
REPLACE NUT if
removed.
Thermostat
Welded Stud
7
Kettle Bottom As sembly
58220
Element View
58220
2
3
Kettle Bottom Assembly
1
5
4
6

PopMaxx
12/14 oz. Popper Model No. 2552 and 2552KC
Page 19
gmpopcorn.com
Cabinet Exterior – Front View
tem Part Description
Part Number
2552
2552K
C
DECAL, POPCORN
49777
GLASS DECAL PAPPYS
49 58KC
2
8
-
32 X 3/8 SLT. HWH M/S
42044
42044
3
DOME WELDMENT
77769
77769
4
2 5/ 6”
GLASS
CHAN
NNEL (used on the side
edges of the glass panels) 49844 49844
5
6 /4” GLASS CHANNEL (used on the top and
bottom edges of the glass panels) 74 72 74 72
6
GLIDE
47328
47328
7
0
-
24 X 3/4” HEX HEAD
4 3 4
4 3 4
8
CRUTCH TIP BLACK 70 DURO
49 23
49 23
8
6, 7
3
See Kettle
Assembly
Section
2
4
For Glass Panels,
see Replacing
Glass section.
5
1
2552
-
00
-
00
General image shown for parts reference only.

PopMaxx
12/14 oz. Popper Model No. 2552 and 2552KC
Page 20
gmpopcorn.com
Cabinet Exterior – Rear View
tem Part Description Part No.
MAGNETIC CATCH
4756
2
MAGNETIC CATCH BRACKET
4 340
3
MACNETIC BRACKET SHIM
38527
4
**
COMPLETE LH DOOR HARDWARE KIT
47054
5
**
COMPLETE RH DOOR HARDWARE KIT
47055
6
8
-
32 X /2 PHIL PAN M/S (f
astens male hinges to
the corner posts) 47 4
7
DOOR
77774
8
DROP PANEL
77730
9
OLD MAID PAN
49 00
0
LID LIFT KNOB
47 20
8
-
32” X 3/8” PH PAN W/SEMS
42227
2
STRAIN RELIEF SR
-
7W
-
2
67060
3
*
LEAD
-
IN CORD 5 AMP PLUG
87085
3
1, 2
4**
5** 6
7
For Labels, See
Safety Labels
Section 8
10, 11 9
*
CAUT ON: f supply cord is damaged,
it must be replaced by
Gold Medal Products Co., its service agent, or similarly
qualified persons in order to avoid a hazard.
13*
12
**
Complete
Door
Hardware Kit
(See next page for individual
component breakdown).
2387
-
00
-
0 0
General image shown
for parts reference only.
