Gotrax Xr Elite User manual

Xr Elite
USER MANUAL
ELECTRIC SCOOTER

Congratulations
on your purchase!

This user manual will help you assemble and
operate your new Electric Scooter. Be sure to read
ALL OF THE INFORMATION in this manual
before riding.
NOTE TO ALL RIDERS UNDER 18 YEARS OF
AGE: It’s very important that you get parental
permission before riding your electric scooter.

ALWAYS wear a helmet when riding your Electric Scooter.
Make sure your scooter has a full battery before taking it out to
ride.
Always be aware of local road laws, and follow them.
Do not ride the scooter under the inuence of drugs or alcohol.
Always respect pedestrians.
Do not ride under wet conditions. The scooter may slide from under
your feet causing injury. Wet conditions may damage the electronics
and void the warranty.
Don’t ride until you read this

1. Avoid water - The scooter is not waterproof. The electronics may
be damaged due to water and water damage is not covered by our
warranty. Riding in wet conditions is also very dangerous and may result
in injury.
2. Abuse - We do not cover physical damage due to negligent care and
extreme riding.
3. Whenever you ride the GOTRAX electric scooter, you risk
severe injury or even death from loss of control, collisions, and falls. Use
caution and ride at your own risk.
4. Do not modify the product from the manufacturer’s original design.
5. Keep hands and all body parts away from moving parts while
operating the scooter.
6. Before riding - be sure to check the scooter over and make sure the
scooter is operating correctly before each use.
7. Before riding - be sure to check that the braking system is functioning
properly; also be sure to check that all safety labels are in place and
you understand the safety warnings.
Warning Message

8. Before riding - be sure that any and all axle guards, chain guards, or
other covers or guards supplied by the manufacturer are in place and in
serviceable condition.
9. Before riding - be sure to check that the tires are in good condition,
inated properly, and have sufcient tread remaining.
10. Never exceed the 220 lb (100 kg) maximum load rating.
11. The electric scooter should never be used by children under the age of 13.
12. Maximum Speed - Your electric scooter goes the maximum speed of
15.5 mph.

Unpack
You should nd each of these items in your box:
1. Electric Scooter
2. Console & Handlebars
3. Approved Power Adapter / Charging Unit
4. 4mm Allen Wrench
5. Tire Gauge Pipe
6. Screws (x2)
Remove all packaging material, then inspect each item for any
accidental damage that may have occurred during shipping.
1
2
34
6
5

Get to know your scooter
The electric scooter comes partially assembled.
Specications
Top Speed:
Distance per Charge:
Weight Range Up To:
Battery Type:
Battery Charger:
Charge Time:
Motor Power:
Power Requirements:
15.5mph
18 Miles
220lbs
36V 7.8AH
DC 42V 2.0A
4 hours
300W
AC 100-240V~50/60HZ
Disc Brake
Rear Reector
Fender Buckle
Kickstand
Hub Motor
Folding System
Battery Pipe
Hook
Headlight
Handle Brake
Charger Port
Console
Accelerator

Press down on the rear fender, separate the
folding hook and fender buckle, then lift the tiller
upright (as shown in the gure). Once the scooter
is locked in the upright position, verify by gently
trying to fold.
Place the console into the top of the tiller.
TOOLS YOU’LL NEED: 4 mm Allen Key Wrench (included).
Take the cord that is attached to the hook and
bring it to the front of the tiller. Pull the handbrake
towards you and insert the round metal piece into
the opening. String the small silver cord through
the solid piece of the handbrake. Make sure the
metal piece on the red cord is pushed fully into
the handbrake.
Use an Allen wrench to loosen the screws located
at the hook and detach. Once you’ve removed the
hook and screws, make sure to remove the cover
from the top of the tiller.
Assemble Your Scooter
1
4
2
3

Grab the red cord and hook and bring it back
behind the tiller and reattach the hook to the back
of the tiller using the screws and an Allen wrench.
( The red cord should go around the tiller.)
5

Charge Your Scooter
Before using the scooter, you must fully charge the battery.
1. Open the rubber charging port cover.
2. Insert the charging plug into the port.
3. The charger box will have a green light when
fully charged and a red light when charging.
4. When you are done charging be sure cover the
charging port to keep it clear of dust and debris.
5. Charging Time: 4 hours
Charging Requirement: Make sure to charge your scooter in conditions
that do not exceed 104 degrees Fahrenheit or below 32 degrees
Fahrenheit.

• To power the scooter on, press and hold the red button for 1
second.
• To power the scooter o, press and hold the red button for 5
seconds.
• To power the headlight on or o, press the red button for 1 second
while the scooter is powered on.
• The console on the Scooter displays speed in MPH, Battery life, and
what gear the scooter is currently in.
Scooter Console Functions

1. You will want to start riding your electric scooter with one foot on the
platform and one foot on the ground. Use your foot on the ground
to push off and at the same time, press the throttle button to begin
movement.
2. Press the handbrake to slow down or stop.
3. The scooters perform best when on a smooth surface e.g. carparks,
smooth roads, footpaths, & bike lanes.
4. Always clean your scooter (wheels, platform..etc.), it’s a machine and it
needs to be maintained.
5. Do not press the throttle while walking with the scooter beside you.
6. Be aware of the terrain you are riding on, watch out for curbs and
obstacles!
7. Cruise Control: To activate the cruise control press the right-hand throttle
down for 10 seconds. To deactivate the cruise control press either the
right-hand throttle or brake button to deactivate the cruise control.
Riding Tips

Before folding the scooter, make sure that the scooter is powered off.
Folding: Ensure the electric scooter is powered off, hold the tiller and
pull out the spring pin on the right folding panel then rotate the spring
pin counterclockwise. Insert the hook on the tiller into the loop on the
rear fender buckle. You may hear a click which indicates that you were
successful in folding and locking the scooter.
Unfolding: Press the rear fender and pull the tiller up to unfold the electric
scooter, the spring pin will insert itself in place within the folding lever to
lock the folding mechanism.
Putting Your Scooter
Away/Folding
1 2

If you regularly clean and maintain your electric scooter, it will
extend its life.
Cleaning and storage: If the scooter is dirty, wipe it clean with a soft
damp cloth.
Brake Adjustments & Service: If you notice you need brake
adjustments or any service on your scooter, contact our customer service
team and we will adjust and repair your scooter. Do not repair your
scooter yourself, this can void your warranty and you risk damaging the
scooter.
Tires: If you notice that the tire pressure is low, please ll to the
recommended PSI on the side of the tire. Recommended PSI: 50
DO NOT use alcohol, gasoline, kerosene, or other corrosive chemical
solvents to clean the scooter. It can severely damage the appearance and
structure of the scooter. Please do not use a pressure washer as it may also
cause damage to the electronics.
Storage: When you’re not using your scooter store in a dry and cool
location. Avoid storing your scooter outdoors because sun exposure can
damage it’s appearance and may cause wear on the life of the battery and
tires.
Maintenance & Repair

Tightening the Tiller: If you notice that the tiller is loose or wiggles while
riding, you can tighten the screws. Open the plastic cover, and use the
Allen wrench to tighten the screws as shown in the gure below.
Adjusting the Disc Brake: If the disc brake is too tight, use the 4MM
Allen wrench to loosen the screws counterclockwise. Pull the brake wire
to extend the brake wire and retighten the screws. If the disc brake is too
loose, loosen the screws and pull the brake wire to extend the brake wire
and retighten the screws.

Only use the approved GOTRAX power adapter to charge your scooter,
others may cause risk of re & equipment may be damaged.
Improper disposal of used batteries may seriously pollute the environment.
Please comply with local disposal regulations.
Make sure to store your scooter and power adapter in conditions that do
not exceed 122 degrees Fahrenheit or below -4 degrees Fahrenheit.
Warning - Risk of Fire - No User Serviceable Parts, The prolonged
exposure to UV Rays, Rain and the Elements may damage the enclosed
materials, store indoors when not in use.
Battery Information

We frequently update our user manuals at GOTRAX.com, and reserve the
rights to update and change manuals online.
Please contact our customer service team if you are
experiencing problems or need more detailed information.
They can be reached at GOTRAX.com
Warranty
For warranty information, please visit GOTRAX.com.
Troubleshooting

WWW.GOTRAX.COM
#RideGOTRAX

GOLABS, INC
GOTRAX.com
2201 Luna Rd.
Carrollton, TX 75006
