Gotrax SHIFT S1 User manual

SHIFT S1 E-BIKE
USER MANUAL

CONGRATULATIONS
ON YOUR
PURCHASE!
This user manual will help you assemble and operate your new Shift S1
Electric Bike. Be sure to read ALL OF THE INFORMATION in this manual
before riding.
NOTE TO ALL RIDERS UNDER 18 YEARS OF AGE: It’s very important that you
get parental permission before riding your Shift S1 Electric Bike.

ALWAYS wear a helmet when riding your S1 Electric Bike.
Make sure your e-bike has a full battery before taking it out to ride.
Always be aware of local road laws, and follow them.
Do not ride the e-bike under the influence of drugs or alcohol.
Always respect pedestrians.
Do not ride under wet conditions. The e-bike may slide from under
your feet causing injury. Wet conditions may damage the electronics
and void the warranty.
DON’T RIDE UNTIL YOU READ THIS:
i
01

WARNING MESSAGE
1. Avoid water - The e-bike is not waterproof. The electronics may be damaged due
to water and water damage is not covered by our warranty. Riding in wet conditions is
also very dangerous and may result in injury.
2. Abuse - We do not cover physical damage due to negligent care and extreme
riding.
3. Whenever you ride the Gotrax SHIFT S1 Electric Bike , you risk severe injury or
even death from loss of control, collisions, and falls. Use caution and ride at your own
risk.
4. Do not modify the product from the manufacturers original design.
5. Keep hands and all body parts away from moving parts while operating the
hoverboard.
6. Before riding - be sure to check the e-bike over and make sure the e-bike is
operating correctly before each use.
7. Before riding - be sure to check that the braking system is functioning properly;
also be sure to check that all safety labels are in place and you understand the safety
warnings.
8. Before riding - be sure that any and all axle guards, chain guards, or other
covers or guards supplied by the manufacturer are in place and in serviceable
condition.
9. Before riding - be sure to check that the tires are in good condition, inflated
properly, and have sufficient tread remaining.
10. Never exceed the 264 lb (120 kg) maximum load rating.
11. The S1 Electric Bike should never be used by children under the age of 16.
12. Maximum Speed - Your S1 Electric Bike goes the maximum speed of 20 mph.
02

UNPACK
Y each of these items in your S1 E-Bike box :
1. S1 E-Bike
2. S1 Approved Power Adapter / Charging Unit
3. 1 - 5mm Allen Wrench
4. 1 - 2.5mm Allen Wrench
5. S1 Battery
6.
7.
2 - Pedals
1 - wrench
Remove all packing material, then inspect each item for any
accidental damage that may have occurred during shipping.
3
5
6
4
7
03

GET TO KNOW
YOUR ELECTRIC BIKE
Top Speed:
Distance per Charge:
Weight Range Up To:
Battery Type:
Battery Charger:
Charge Time:
Motor Power:
Power Requirements:
20 mph
18 Miles
264lbs
36V 7.8AH
DC 42V 1.5A
about 5.5 hours
250W
AC 100-240V ~ 50/60Hz
04

ASSEMBLE YOUR ELECTRIC
BIKE
1. Hold the bike and unfold the
front frame. ( insert figure)
2. You will hear a click once the
frame is unfolded. Lock the clamp
and turn the clamp to the left to
tighten. ( insert figure)
05

Install the Handlebars
Adjust the brake position
and accelerator position to
fix them firmly.
Hold the tiller fliplock to the
upright position to ensure
the tiller is locked into
position.
06

Use the 5mm Allen Wrench to loosen the
screws and the fixed cover.
Adjust the Tiller Height
Adjust the pedal
Flip the pedal 90 degrees parallel to the floor
07

Loosen the seat post clamp, adjust the seat
properly, lock the clamp to tighten the seat
in place.
Adjust the Seat Height
Lock the password and remove the battery
Loose code lock line:
Enter the default password of 0000,
Press the switch button.
Automatic spring unlocking cord
Take the battery:
Enter the default password 0000,
Press the switch button,
There was a click. Turn the cipher,
After 90 degrees, lift the battery case.
08

Use the 15mm spanner to mount the pedals.
Notice: Turn the left pedal counterclockwise
to tighten; Turn the right pedal clockwise to
tighten.
Install Pedals
09

CHARGE YOUR
ELECTRIC BIKE
Before using the E-Bike, you must fully charge the battery.
Charging port
10

1. Check Battery Level : Press the power
display button quickly, The charge position
is on the back side of the bike as shown in
the picture.
2. Plug the charging cable into the charging hole(make sure the
connection is dry). Insert the charging plug into the port.
3. The charger box will have a green light when fully charged and a
red light when charging.
4. When you are done charging be sure cover the charging port to
keep it clear of dust and debris.
11

HOW TO USE THE BATTERY SAFETY LOCK
Step 1- How to reset the anti-theft combination lock
1. Unlock the anti-theft device with default code 0000.
2. Slide the reset button to the above(Set mode).
3. Set a new code by turning the dials (Please shoot a photo to
remember the password).
4. Slide the code reset button to the below.
5. Adjust the password Dials to prevent the password from leaking
Step 2- To remove the battery from fixed support:
1.Enter the safety code
2. Press the locking button
3.Turn the lock and remove the battery
1Locking button
2Dials
3Code reset button
12

SCOOTER CONSOLE FUNCTIONS
• Main display contents of the instrument:
Gear, charge, 3.7Miles boost.
• Button function:
Power key (S key), shift down key
13

• The function of the middle button is as follows:
• The function of the - & + buttons
• To power on: Press the button once for 3 seconds to turn on
the screen, once the screen is on so is the bike.
• To power off: Press the button for 3 seconds until the screen
is off, once the screen is off so is the bike.
• The Shift S1 e-bike has 5gears.
Press the s button to go up in gear.
Press the - button to go down in gear.
• 1st Gear - 6 MPH
• 2nd Gear - 9 MPH
• 3rd Gear - 12.5 MPH
• Push Mode - Power on the E-Bike, long press the - button for
3 seconds to engage push mode. Use this when you need a
hill assist.
• 4rd Gear - 15.5 MPH
• 5rd Gear - 20 MPH
14

RIDING TIPS
1. You will want to start riding your S1 with one foot on the pedal and
one foot on the ground. Use your foot on the ground to push off
and at the same time, press the throttle button to begin movement.
2. Press the brake-throttle to slow down or stop.
3. The Electric Bike performs best when on a smooth surface e.g.
4. carparks, smooth roads, footpaths, & bike lanes.
5. Always clean your Electric Bike (wheels, body..etc.), it’s a machine
and it needs to be maintained.
6. Do not press the throttle while walking with the E-Bike beside you.
7. Be aware of the terrain you are riding on, watch out for curbs and
obstacles!
15

PUTTING YOUR E-BIKE
AWAY / FOLDING
Before folding the e-bike, make sure that the scooter is powered
off.
Unfold the clamp on the body of the e-bike and fold the bike in
half. Turn the clamp on the tiller of the e-bike upwards and fold
the tiller and handlebars down. Secure the wheels together and
16

MAINTENANCE AND REPAIR
If you regulary clean and maintain your electric E-bike, it will extend its
life.
Cleaning and storage: If the E-Bike is dirty, wipe it clean with a soft damp
cloth.
Brake Adjustments & Service: If you notice you need brake adjustments
or any service on your Shift S1 Electric Bike, contact our customer service
team and we will adjust and repair your e-bike. Do not repair your Shift S1
yourself, this can void your warranty and you risk damaging the e-bike.
Tires: When there is a low pressure in the tire, or the pressure of the two
tires is different, please inflate it in time. Make sure the pressure of the two
tires is the same. The default Front & Back tire pressure is 35 to 45 psi.
If you need to change a tire because of tire burst, please contact the
authorized agent or after sales department for maintenance. (you can also
go to the bicycle repair shop.)
17

DO NOT use alcohol, gasoline, kerosene, or other corrosive chemical
solvents to clean the E-Bike. It can severely damage the appearance
and structure of the E-Bike. Please do not use a pressure washer as it
may also cause damage to the electronics.
Storage: When you’re not using your E-Bike store in a dry and cool
location. Avoid storing your E-Bike outdoors because sun exposure can
damage it’s appearance and may cause wear on the life of the battery
and tires.
