GXP-2010 IP Phone
Quick Installation Guide
WARNING: Please DO NOT power cycle the GXP-2010 when LED lights
are flashing during system boot up or firmware upgrade. You may corrupt
firmware images and cause the unit to malfunction.
WARNING: use only the power adapter included in the GXP-2010
package. Using an alternative non-qualified power adapter may possibly
damage the unit.
Overview
The new GXP-2010 Key System IP phone has a new sleek design and
delivers excellent call quality and enterprise grade feature set that includes
advanced XML capabilities, multi-party conferencing, multi-language support,
presence and BLF (busy lamp field), security protection, automated
provisioning, and broad compatibility with leading SIP platforms. The
GXP-2010 offers 4 lines, 18 programmable keys, 3 dynamic
context-sensitive XML soft keys, dual switched 10M/100Mbps auto-sensing
Ethernet ports with integrated PoE, and a large high-resolution backlit LCD
display. As with all models in the GXP Series, this model supports
comprehensive voice codecs and SRTP for privacy protection.
Equipment Packaging
Unpack and check all accessories.
The GXP-2010 phone package contains
1. One GXP-2010 Main Case
2. One Handset
3. One Phone Cord
4. One Universal Power Adaptor
5. One Ethernet Cable
6. One Phone Stand
7. Two Wall Mount Spacers

3
Connect the GXP-2010 Enterprise IP Phone
Please use the equipment included in the packaging. Using any other
power source may damage the product.
1. Connect the handset and main phone case with the phone cord.
2. Connect the LAN port of the phone to the RJ-45 socket of a hub/switch or
a router (LAN side of the router) using the Ethernet cable.
3. Connect the 5V DC output plug to the power jack on the phone; plug the
power adapter into an electrical outlet.
4. The LCD will display provisioning or firmware upgrade information.
Before continuing, wait for the date/time icon to light up.
5. Using the phone embedded web server or keypad configuration menu,
you can further configure the phone using either a static IP or DHCP.
Wall Mount
GXP-2010 can be wall mounted. For proper wall mounting please place the
two wall-mount spacers into the proper holes on the bottom of the GXP-2010
as show below:

4
Figure 2: Attach the wall-mount spacers to the GXP-2010
To position the phone on the wall, place two fixed hangers on the wall, hang
the back of the phone on the fixed hangers.
Figure 3: Location of the fixed hangers on GXP-2010
To use the handset, pull out the tab (extension downward) from the handset
cradle, rotate the tab and plug it back into the slot with the extension up to
hold the handset.
Figure 4: Placing tab for mounting phone to wall

5
Configuring the GXP-2010 using a Web Browser
•If DHCP is enabled in your network, the phone’s IP address will be displayed.
•Using a PC on the same network, type the IP address (from the screen
display) in the URL of your browser.
•The default administrator password is “admin”; the default end-user
password is “123”.
To configure the phone via the web browser, you will need the following
information:
1. IP address, subnet mask and gateway IP or available DHCP.
2. SIP server and/or Outbound Proxy FQDN or IP address.
3. User subscriber information: User ID, Authentication ID, Password
(provided by your VoIP service provider).
4. GXP2020 supports “Plug N Call” if your ITSP (Internet Telephony Service
Provider) provides this automatic provisioning service. Ensure the phone
has an internet connection (either DHCP or static IP in your internet ready
network), then power up the phone.
5. Please contact your ITSP for additional settings that may be necessary to
configure the phone.
Configure the GXP-2010 using the Keypad
1. Make sure the phone is idle.
2. Press the “OK” button to enter the keypad MENU to configure the phone.
3. Follow MENU options to configure the basic features of the phone – for
example: the IP address if using a static IP. For details, please check
GXP Series User Manual.
Using the Keypad
1. To enter the MENU, press round MENU button.
2. Navigate the menu by using the UP/DOWN and LEFT/RIGHT
3. Press the round MENU button to confirm a menu selection.
4. To delete an entry by pressing the MUTE button.
5. The phone automatically exits MENU mode with an incoming call, the
phone is off-hook or the MENU mode if left idle for 20 seconds

6
GXP-2010 Key Pad Configuration Menu
Call History Displays histories of incoming, dialed and missed
calls.
Status
Displays the network status, account statuses,
software version and MAC-address of the phone.
Phone Book Displays the phonebook.
Instant Messages Goes to Instant Messages if the Presence is
supported by the service provider or PBX
Direct IP call Displays the IP-call options menu.
Preference
Displays user preference sub-menu, such as ring
tone, ring volume, customized XML idle screen or
logo.
Config
Display configuration sub-menu, such as Network,
SIP account, audio codec, firmware upgrade path
and method and Factory Reset function, etc.
Factory Functions Extra diagnostic tools reside here.
Reboot Makes the phone reboot itself.
Exit Exit from this menu.
