DOCUMENT PURPOSE
This User Guide describes the basic concept and tasks necessary to use and configure your
GXP2130/GXP2140/GXP2160/GXP2170/GXP2135. This document will cover the topic of phone
installation, making basic calls and connecting phone to devices. To learn the advanced features and
configurations, please visit http://www.grandstream.com/support to download the
latest “GXP2130/GXP2140/GXP2160/GXP2170/GXP2135 Admin Guide”.

GXP2130/GXP2140/GXP2160/GXP2170/GXP2135 USER GUIDE Page 5 of 57
GUI INTERFACE EXAMPLES
http://www.grandstream.com/sites/default/files/Resources/gxp21xx_web_gui.zip
1. Screenshot of Login Page
2. Screenshots of Status Pages
3. Screenshots of Accounts Pages
4. Screenshots of Settings Pages
5. Screenshots of Network Pages
6. Screenshots of Maintenance Pages
7. Screenshots of Phonebook Pages

GXP2130/GXP2140/GXP2160/GXP2170/GXP2135 USER GUIDE Page 6 of 57
GNU GPL INFORMATION
GXP2130/GXP2140/GXP2160/GXP2170/GXP2135 firmware contains third-party software licensed under
the GNU General Public License (GPL). Grandstream uses software under the specific terms of the GPL.
Please see the GNU General Public License (GPL) for the exact terms and conditions of the license.
Grandstream GNU GPL related source code can be downloaded from Grandstream web site from:
http://www.grandstream.com/sites/default/files/Resources/gxp_gpl_color.tar.gz .

GXP2130/GXP2140/GXP2160/GXP2170/GXP2135 USER GUIDE Page 7 of 57
CHANGE LOG
This section documents significant changes from previous versions of user manuals for
GXP2130/GXP2140/GXP2160/GXP2170/GXP2135. Only major new features or major document updates
are listed here. Minor updates for corrections or editing are not documented here.
FIRMWARE VERSION 1.0.6.9
For GXP2135 only
FIRMWARE VERSION 1.0.6.2
For GXP2170 only
FIRMWARE VERSION 1.0.1.19
Added GXP2130
FIRMWARE VERSION 1.0.0.17
This is the initial version for GXP2140/GXP2160

GXP2130/GXP2140/GXP2160/GXP2170/GXP2135 USER GUIDE Page 8 of 57
This page intentionally left blank

GXP2130/GXP2140/GXP2160/GXP2170/GXP2135 USER GUIDE Page 9 of 57
WELCOME
Thank you for purchasing Grandstream GXP2130/GXP2140/GXP2160/GXP2170/GXP2135 Enterprise IP
Phone. GXP2130/GXP2140/GXP2160/GXP2170/GXP2135 is a state-of-the-art enterprise grade IP phone.
GXP2170 features 12 dual-color line keys(can be digitally programmed as up to 48 provisionable
BLF/fast-dial keys). GXP2135 features 8 dual-color line keys(can be programmed as up to 32
provisionable BLF/fast-dial keys). GXP2140/GXP2160/GXP2170 features 4.3 inch TFT Color LCD, 5
programmable context-sensitive soft keys, dual Gigabit network ports, integrated PoE and Bluetooth,
5-way conference, and Electronic Hook Switch (EHS). GXP2135 supports 2.8 inch TFT Color LCD, 4
programmable context-sensitive soft keys, 5-way voice conference and EHS with Plantronics headsets.
GXP2130 supports 2.8 inch TFT Color LCD, 4 programmable context-sensitive soft keys, 4-way voice
conference and EHS with Plantronics headsets. Also, this series can support up to 3 lines for GXP2130, 4
lines for GXP2140, 6 lines for GXP2160, 12 lines for GXP2170, and 8 lines for GXP2135. The
GXP2130/GXP2140/GXP2160/GXP2170/GXP2135 delivers superior HD audio quality, rich and leading
edge telephony features, personalized information and customizable application service, automated
provisioning for easy deployment, advanced security protection for privacy, and broad interoperability with
most 3rd party SIP devices and leading SIP/NGN/IMS platforms. The
GXP2130/GXP2160/GXP2170/GXP2135 supports presence and Busy Lamp Field (BLF) in the
Multi-Purpose Keys as well. The GXP2140/GXP2170 is expandable with one to 4 expansion modules. The
GXP2130/GXP2140/GXP2160/GXP2170/GXP2135 is the perfect choice for enterprise users looking for a
high quality, feature rich multi-line executive IP phone with advanced functionalities and performance.
Caution:
Changes or modifications to this product not expressly approved by Grandstream, or operation of this
product in any way other than as detailed by this User Manual, could void your manufacturer warranty.
Warning:
Please do not use a different power adaptor with the GXP2130/GXP2140/GXP2160/GXP2170/GXP2135
as it may cause damage to the products and void the manufacturer warranty.

GXP2130/GXP2140/GXP2160/GXP2170/GXP2135 USER GUIDE Page 10 of 57
This document is subject to change without notice. The latest electronic version of this user manual is
available for download here:
http://www.grandstream.com/support
Reproduction or transmittal of the entire or any part, in any form or by any means, electronic or print, for
any purpose without the express written permission of Grandstream Networks, Inc. is not permitted.

GXP2130/GXP2140/GXP2160/GXP2170/GXP2135 USER GUIDE Page 11 of 57
PRODUCT OVERVIEW
FEATURE HIGHTLIGHTS
Table 1: GXP2130/GXP2140/GXP2160/GXP2170/GXP2135 FEATURES IN A GLANCE
GXP2130
3 lines
2.8 inch (320x240) TFT color LCD
4 programmable soft keys
Bluetooth V2.1 (GXP2130v2 only)
8 programmable Multi-Purpose Keys
4-way conference
GXP2140
4 lines
4.3 inch (480x272) TFT color LCD
5 programmable soft keys
Bluetooth V2.1
5-way conference
Expansion board
GXP2160
6 lines
4.3 inch (480x272) TFT color LCD
5 programmable soft keys
Bluetooth V2.1
5-way conference
24 programmable Multi-Purpose Keys
GXP2170
12 dual-color line keys that can be digitally
programmed as up to 48 provisionable
BLF/fast-dial keys
4.3 inch (480x272) TFT color LCD
5 programmable soft keys
Bluetooth V2.1
5-way conference
Expansion board

GXP2130/GXP2140/GXP2160/GXP2170/GXP2135 USER GUIDE Page 12 of 57
GXP2135
8 dual-color line keys that can be digitally
programmed as up to 32 provisionable
BLF/fast-dial keys
2.8 inch (320x240) TFT color LCD
4 programmable soft keys
Bluetooth V2.1
5-way conference
Table 2: GXP2130/GXP2140/GXP2160/GXP2170/GXP2135 COMPARISON GUIDE
Features
GXP2130
GXP2140
GXP2160
GXP2170
GXP2135
LCD Display
320x240
480 x 272
480 x 272
480 x 272
320x240
LCD Backlight
Yes
Yes
Yes
Yes
Yes
Number of Lines
3
4
6
12
8
Programmable
Hard Keys
8
N/A
24
48
32
Programmable
Soft Keys
4
5
5
5
4
Extension
Module
N/A
Yes, up to 4 EXT
Boards
N/A
Yes, up to 4 EXT
Boards
N/A

GXP2130/GXP2140/GXP2160/GXP2170/GXP2135 USER GUIDE Page 13 of 57
GXP2130/GXP2140/GXP2160/GXP2170/GXP2135 TECHNICAL SPECIFICATIONS
Table 3 GXP2130 TECHNICAL SPECIFICATIONS
Protocols/Standards
SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP, ICMP, DNS (A
record, SRV, NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, SIMPLE, LLDP,
LDAP, TR-069, 802.1x, TLS, SRTP, IPv6
Network Interfaces
Dual switched auto-sensing 10/100/1000 Mbps Gigabit Ethernet ports with
integrated PoE
Graphic Display
2.8 inch (320x240) TFT color LCD
Bluetooth
Yes, Bluetooth V2.1 (GXP2130v2 only, GXP2130v1 does not support Bluetooth)
Feature Keys
3 line keys with up to 3 SIP accounts, 8 speed-dial/BLF extension keys with
dual-color LED, 4 programmable context sensitive softkeys, 5 navigation/menu
keys, 11 dedicated function keys for: MESSAGE (with LED indicator),
PHONEBOOK, TRANSFER, CONFERENCE, HOLD, HEADSET, MUTE,
SEND/REDIAL, SPEAKERPHONE, VOL+, VOL-
Voice Codec
Support for G.729A/B, G.711µ/a-law, G.726, G.722 (wide-band), and in-band and
out-of-band DTMF (in audio, RFC2833, SIP INFO)
Auxiliary Ports
RJ9 headset jack (allowing EHS with Plantronics headsets)
Telephony Features
Hold, transfer, forward, 4-way conference, call park, call pickup,
shared-call-appearance (SCA), bridged-line-appearance (BLA), downloadable
phonebook (XML, LDAP, up to 2000 items), call waiting, call log (up to 500
records), customization of screen, off-hook auto dial, auto answer, click-to-dial,
flexible dial plan, hot desking, personalized music ringtones and music on hold,
server redundancy and fail-over
Sample Applications
Weather, currency, GMI available for advanced custom application development
HD audio
Yes, both on handset and speakerphone
Base Stand
Yes, allow 2 angle positions
Wall Mountable
Yes
QoS
Layer 2 (808.1Q, 802.1p) and Layer 3 (ToS, DiffServ, MPLS) QoS
Security
User and administrator level passwords, MD5 and MD5-sess based
authentication, AES based secure configuration file, SRTP, TLS, 802.1x media
access control
Multi-language
English, Arabic, Chinese, Croatian, Czech, Dutch, German, French, Hebrew,
Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Slovenia,
Spanish, Turkish
Upgrade/Provisioning
Firmware upgrade via TFTP/HTTP/HTTPS, mass provisioning using TR-069 or
encrypted XML configuration file
Power & Green
Energy Efficiency
Universal power adapter included: Input:100-240VAC ;
Output: +12VDC, 0.5A ;
Integrated Power-over-Ethernet (802.3af)

GXP2130/GXP2140/GXP2160/GXP2170/GXP2135 USER GUIDE Page 14 of 57
Physical
Dimension: 193mm (W) x 211mm (L) x 84.5 mm (H);
Unit weight: 0.78kg ; Package weight: 1.3kg
Temperature and
Humidity
32-104℉/ 0～40℃, 10-90% (non- condensing)
Package Content
GXP2130 phone, handset with cord, base stand, universal power supply, network
cable, Quick Start Guide
Compliance
FCC Part15 Class B, EN55022 ClassB, EN61000-3-2, EN61000-3-3, EN55024,
EN60950-1, AS/NZS CISPR22 Class B
Table 4: GXP2140 TECHNICAL SPECIFICATIONS
Protocols/Standards
SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP, ICMP, DNS (A
record, SRV, NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, SIMPLE, LLDP,
LDAP, TR-069, 802.1x, TLS, SRTP, IPv6
Network Interfaces
Dual switched auto-sensing 10/100/1000 Mbps Gigabit Ethernet ports with
integrated PoE
Graphic Display
4.3 inch (480x272) TFT color LCD
Bluetooth
Yes, Bluetooth V2.1
Feature Keys
4 line keys with up to 4 SIP accounts, 5 programmable context sensitive softkeys,
5 navigation/menu keys, 11 dedicated function keys for : MESSAGE (with LED
indicator), PHONEBOOK, TRANSFER, CONFERENCE, HOLD, HEADSET,
MUTE, SEND/REDIAL, SPEAKERPHONE, VOL+, VOL-
Voice Codec
Support for G.729A/B, G.711µ/a-law, G.726, G.722 (wide-band), iLBC(pending)
and in-band and out-of-band DTMF (in audio, RFC2833, SIP INFO)
Auxiliary Ports
RJ9 headset jack (allowing EHS with Plantronics headsets), USB, extension
module port
Telephony Features
Hold, transfer, forward, 5-way conference, call park, call pickup,
shared-call-appearance (SCA)/bridged-line-appearance (BLA), downloadable
phonebook (XML, LDAP, up to 2000 items), call waiting, call log (up to 500
records), customization of screen, off-hook auto dial, auto answer, click-to-dial,
flexible dial plan, hot desking, personalized music ringtones and music on hold,
server redundancy and fail-over
Sample Applications
Weather, currency, GMI available for advanced custom application development
HD audio
Yes, both on handset and speakerphone
Extension Module
Yes, can power up up to 4 GXP2200EXT modules which features a 128x384
graphic LCD, 20 quick-dial/BLF keys which dual-color LED, 2 navigation keys,
and less than 1.2W power consumption per unit.
Base Stand
Yes, allow 2 angle positions
Wall Mountable
Yes
QoS
Layer 2 (808.1Q, 802.1p) and Layer 3 (ToS, DiffServ, MPLS) QoS
Security
User and administrator level passwords, MD5 and MD5-sess based

GXP2130/GXP2140/GXP2160/GXP2170/GXP2135 USER GUIDE Page 15 of 57
authentication, AES based secure configuration file, SRTP, TLS, 802.1x media
access control
Multi-language
English, Arabic, Chinese, Croatian, Czech, Dutch, German, French, Hebrew,
Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Slovenia,
Spanish, Turkish
Upgrade/Provisioning
Firmware upgrade via TFTP/HTTP/HTTPS, mass provisioning using TR-069 or
encrypted XML configuration file
Power & Green
Energy Efficiency
Universal power adapter included:
Input:100-240V ; Output: +12V, 1A ;
Integrated Power-over-Ethernet (802.3af)
Max power consumption: 6W (without GXP2200EXT), 10W(with 4 cascaded
GXP2200EXTs )
Physical
Dimension: 222mm (W) x 210mm (L) x 93mm (H); Unit weight: 0.98kg; Package
weight: 1.55kg
Temperature and
Humidity
32-104℉/ 0～40℃,10-90% (non- condensing)
Package Content
GXP2140 phone, handset with cord, base stand, universal power supply, network
cable, Quick Start Guide
Compliance
FCC Part15 Class B, EN55022 ClassB, EN61000-3-2, EN61000-3-3, EN55024,
EN60950-1, AS/NZS CISPR22 Class B
Table 5: GXP2160 TECHNICAL SPECIFICATIONS
Protocols/Standards
SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP, ICMP, DNS (A
record, SRV, NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, SIMPLE, LLDP,
LDAP, TR-069, 802.1x, TLS, SRTP, IPv6
Network Interfaces
Dual switched auto-sensing 10/100/1000 Mbps Gigabit Ethernet ports with
integrated PoE
Graphic Display
4.3 inch (480x272) TFT color LCD
Bluetooth
Yes, Bluetooth V2.1
Feature Keys
6 line keys with up to 6 SIP accounts, 24 speed-dial/BLF extension keys with
dual-color LED, 5 programmable context sensitive softkeys, 5 navigation/menu
keys, 11 dedicated function keys for : MESSAGE (with LED indicator),
PHONEBOOK, TRANSFER, CONFERENCE, HOLD, HEADSET, MUTE,
SEND/REDIAL, SPEAKERPHONE, VOL+, VOL-
Voice Codec
Support for G.729A/B, G.711µ/a-law, G.726, G.722 (wide-band), iLBC(pending)
and in-band and out-of-band DTMF (in audio, RFC2833, SIP INFO)
Auxiliary Ports
RJ9 headset jack (allowing EHS with Plantronics headsets), USB
Telephony Features
Hold, transfer, forward, 5-way conference, call park, call pickup,
shared-call-appearance (SCA)/bridged-line-appearance (BLA), downloadable
phonebook (XML, LDAP, up to 2000 items), call waiting, call log (up to 500

GXP2130/GXP2140/GXP2160/GXP2170/GXP2135 USER GUIDE Page 16 of 57
records), customization of screen, off-hook auto dial, auto answer, click-to-dial,
flexible dial plan, hot desking, personalized music ringtones and music on hold,
server redundancy and fail-over
Sample Applications
Weather, currency, GMI available for advanced custom application development
HD audio
Yes, both on handset and speakerphone
Base Stand
Yes, allow 2 angle positions
Wall Mountable
Yes
QoS
Layer 2 (808.1Q, 802.1p) and Layer 3 (ToS, DiffServ, MPLS) QoS
Security
User and administrator level passwords, MD5 and MD5-sess based
authentication, AES based secure configuration file, SRTP, TLS, 802.1x media
access control
Multi-language
English, Arabic, Chinese, Croatian, Czech, Dutch, German, French, Hebrew,
Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Slovenia,
Spanish, Turkish
Upgrade/Provisioning
Firmware upgrade via TFTP/HTTP/HTTPS, mass provisioning using TR-069 or
encrypted XML configuration file
Power & Green
Energy Efficiency
Universal power adapter included:
Input:100-240V ; Output: +12V, 1A;
Integrated Power-over-Ethernet (802.3af)
Max power consumption: 6W
Physical
Dimension: 222mm (W) x 210mm (L) x 93mm (H); Unit weight: 0.98kg; Package
weight: 1.62kg
Temperature and
Humidity
32-104℉/ 0～40℃,10-90% (non- condensing)
Package Content
GXP2160 phone, handset with cord, base stand, universal power supply, network
cable, Quick Start Guide
Compliance
FCC Part15 Class B, EN55022 ClassB, EN61000-3-2, EN61000-3-3, EN55024,
EN60950-1, AS/NZS CISPR22 Class B
Table 6: GXP2170 TECHNICAL SPECIFICATIONS
Protocols/Standards
SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP, ICMP, DNS (A
record, SRV, NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, SIMPLE, LLDP,
LDAP, TR-069, 802.1x, TLS, SRTP, IPv6
Network Interfaces
Dual switched auto-sensing 10/100/1000 Mbps Gigabit Ethernet ports with
integrated PoE
Graphic Display
4.3 inch (480x272) TFT color LCD
Bluetooth
Yes, Bluetooth V2.1
Feature Keys
12 line keys with up to 6 SIP accounts or 48 provisionable BLF/fast-dial keys, 5
programmable context sensitive softkeys, 5 navigation/menu keys, 11 dedicated
function keys for: MESSAGE (with LED indicator), PHONEBOOK, TRANSFER,

GXP2130/GXP2140/GXP2160/GXP2170/GXP2135 USER GUIDE Page 17 of 57
CONFERENCE, HOLD, HEADSET, MUTE, SEND/REDIAL, SPEAKERPHONE,
VOL+, VOL
Voice Codec
Support for G.729A/B, G.711µ/a-law, G.726, G.722 (wide-band), in-band and
out-of-band DTMF (in audio, RFC2833, SIP INFO)
Auxiliary Ports
RJ9 headset jack (allowing EHS with Plantronics headsets), USB, extension
module port
Telephony Features
Hold, transfer, forward, 5-way conference, call park, call pickup,
shared-call-appearance (SCA)/bridged-line-appearance (BLA), downloadable
phonebook (XML, LDAP, up to 2000 items), call waiting, call log (up to 500
records), customization of screen, off-hook auto dial, auto answer, click-to-dial,
flexible dial plan, hot desking, personalized music ringtones and music on hold,
server redundancy and fail-over
Sample Applications
Weather, currency, news
GMI available for advanced custom application development
HD audio
Yes, both on handset and speakerphone
Extension Module
Yes, can power up up to 4 GXP2200EXT modules which features a 128x384
graphic LCD, 20 quick-dial/BLF keys which dual-color LED, 2 navigation keys,
and less than 1.2W power consumption per unit.
Base Stand / Wall
Mountable
Yes, allow 2 angle positions
QoS
Layer 2 (808.1Q, 802.1p) and Layer 3 (ToS, DiffServ, MPLS) QoS
Security
User and administrator level passwords, MD5 and MD5-sess based
authentication, AES based secure configuration file, SRTP, TLS, 802.1x media
access control
Multi-language
English, Arabic, Chinese, Croatian, Czech, Dutch, German, French, Hebrew,
Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Slovenia,
Spanish, Turkish
Upgrade/Provisioning
Firmware upgrade via TFTP/HTTP/HTTPS, mass provisioning using TR-069 or
encrypted XML configuration file
Power & Green
Energy Efficiency
Universal power adapter included:
Input:100-240V; Output: +12V, 1.0A ;
Integrated Power-over-Ethernet (802.3af)
Max power consumption: 5.4W (without GXP2200EXT) or 9.2W (with 4 cascaded
GXP2200EXTs)
Physical
Dimention: 228mm (W) x 206mm (L) x 46.5mm (H);
Unit weight: 0.98kg; Package weight: 1.55kg
Temperature and
Humidity
0 ~ 40ºC (32 ~ 104ºF ), 10 ~ 90% (non-condensing)
Package Content
GXP2170 phone, handset with cord, base stand, universal power supply, network
cable, Quick Start Guide

GXP2130/GXP2140/GXP2160/GXP2170/GXP2135 USER GUIDE Page 18 of 57
Compliance
FCC Part 15 (CFR 47) Class B; EN55022 Class B, EN55024, EN61000-3-2,
EN61000-3-3, EN 60950-1, EN62479, AS/NZS CISPR 22 Class B, AS/NZS
CISPR 24, RoHS; UL 60950 (power adapter)
Table 7: GXP2135 TECHNICAL SPECIFICATIONS
Protocols/Standards
SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP, ICMP, DNS (A
record, SRV, NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, SIMPLE, LLDP,
LDAP, TR-069, 802.1x, TLS, SRTP, IPv6
Network Interfaces
Dual switched auto-sensing 10/100/1000 Mbps Gigabit Ethernet ports with
integrated PoE
Graphic Display
2.8 inch (320x240) TFT color LCD
Bluetooth
Yes, Bluetooth V2.1
Feature Keys
8 line keys with up to 4 SIP accounts or 32 provisionable BLF/fast-dial keys, 4
programmable context sensitive softkeys, 5 navigation/menu keys, 11 dedicated
function keys for: MESSAGE (with LED indicator), PHONEBOOK, TRANSFER,
CONFERENCE, HOLD, HEADSET, MUTE, SEND/REDIAL, SPEAKERPHONE,
VOL+, VOL
Voice Codec
Support for G.729A/B, G.711µ/a-law, G.726, G.722 (wide-band), in-band and
out-of-band DTMF (in audio, RFC2833, SIP INFO)
Auxiliary Ports
RJ9 headset jack (allowing EHS with Plantronics headsets)
Telephony Features
Hold, transfer, forward, 5-way conference, call park, call pickup,
shared-call-appearance (SCA)/bridged-line-appearance (BLA), downloadable
phonebook (XML, LDAP, up to 2000 items), call waiting, call log (up to 500
records), customization of screen, off-hook auto dial, auto answer, click-to-dial,
flexible dial plan, hot desking, personalized music ringtones and music on hold,
server redundancy and fail-over
Sample Applications
Weather, currency, news
GMI available for advanced custom application development
HD audio
Yes, both on handset and speakerphone
Base Stand / Wall
Mountable
Yes, allow 2 angle positions
QoS
Layer 2 (808.1Q, 802.1p) and Layer 3 (ToS, DiffServ, MPLS) QoS
Security
User and administrator level passwords, MD5 and MD5-sess based
authentication, AES based secure configuration file, SRTP, TLS, 802.1x media
access control
Multi-language
English, Arabic, Chinese, Croatian, Czech, Dutch, German, French, Hebrew,
Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Slovenia,
Spanish, Turkish
Upgrade/Provisioning
Firmware upgrade via TFTP/HTTP/HTTPS, mass provisioning using TR-069 or
encrypted XML configuration file

GXP2130/GXP2140/GXP2160/GXP2170/GXP2135 USER GUIDE Page 19 of 57
Power & Green
Energy Efficiency
Universal power adapter included: Input:100-240VAC ; Output: +12VDC, 0.5A ;
Integrated Power-over-Ethernet (802.3af)
Max power consumption 3W
Physical
Dimention: 228mm (W) x 206mm (L) x 46.5mm (H);
Unit weight: 0.98kg; Package weight: 1.55kg
Temperature and
Humidity
0 ~ 40ºC (32 ~ 104ºF ), 10 ~ 90% (non-condensing)
Package Content
GXP2135 phone, handset with cord, base stand, universal power supply, network
cable, Quick Start Guide
Compliance
FCC Part 15 (CFR 47) Class B; EN55022 Class B, EN55024, EN61000-3-2,
EN61000-3-3, EN 60950-1, EN62479, AS/NZS CISPR 22 Class B, AS/NZS
CISPR 24, RoHS; UL 60950 (power adapter)
