Product Related Questions
HandyTone Series FAQs
Q: What are the main differences between the 7 models of Handytones?
Features
HT286
HT386
HT486
HT488
HT503
HT496
HT502
Ethernet Ports
1 RJ45
(LAN)
1 RJ45
(LAN)
2 RJ45
(LAN/WAN
)
2 RJ45
(LAN/WAN
)
2 RJ45
(LAN/WAN
)
2 RJ45
(LAN/WAN
)
DHCP/NAT/Route
r
No
No
Yes
Yes
Yes
Yes
FXS Port
1
2
1
1
2
2
FXO Port
No
No
No
1
No
No
PSTN Pass-
through Port
No
Yes
Yes
Yes
No
No
Remote
Configuration
TFTP/HTT
P
TFTP/HTT
P
TFTP/HTTP
TFTP/HTTP
TFTP/HTTP
TFTP/HTTP
Q: Can you explain the use of 'PSTN pass through' and 'FXO port'?
PSTN Pass through port:
What it can do:
Local manual switching between PSTN and IP mode on a per call basis.
User can switch to PSTN line by pressing *00 (or the configured strings) for each call
before they are placed. The device will revert back to the default IP mode once the phone
is hung up.
It can allow a PSTN call to ring/call the phone connected to the FXS port.
It also serves as a life line in case of power outage.
What it CANNOT do:
Terminate a VoIP call into the PSTN port
Allow a call from PSTN to route other VoIP devices (different from the FXS phone) over
the IP network
Automatically route calls made by the local user to PSTN line
Note: On the HT486 Rev 1.0, the PSTN port is only a life line port that switches to the PTSN
network only when there is a loss of power.
FXO port:
It can support all the functions of a PSTN pass through plus:

Terminate a VoIP call into the PSTN port
Allow a PSTN call to call either the FXS phone or other VoIP devices over the IP
network
Route call automatically and transparently to PSTN line according to user configuration
Q: Can I call from FXS1 port to FXS2 port?
Yes, they can communicate with each other by dialing the respective extension number. Both
FXS ports need a valid sip account registered on the server.
Q: How can I disable hook/flash?
On the Advanced Settings page, there is a field On-Hook Threshold. One on the selections for
this field is 'Hook/Flash OFF', this option will disable hook/flash on the phone connected to the
ATA. To switch to a second channel, press FLASH button on the phone, instead of doing
hook/flash.
Note: This feature is not available on older hardware revision models.
Q: What hardware revision is my Handytone?
At the bottom of the device, there will be a white sticker. On this sticker will be a note:
'Rev: x.0' where x is the Hardware Revision
You can also get this information under the Status tab of the Web Configuration pages.
Your hardware revision is very important information. Depending on your hardware revision, it
may/may not be able to upgrade to the latest release.
Ex. HT286 Rev 2.0 upgrades up to 1.0.7.19 firmware, while Rev 3.0 can upgrade to the latest
release.
Note: Once there is a new hardware revision out in the market, the older revision is no more
manufactured or sold.
Q: How do I access the Web Configuration pages (for HT486/496/488)?
Please disconnect all connections to the HT486/HT496/HT488 and follow the instructions
below:
1. Connect the analog touch-tone phone to the HT.
2. Connect power supply.
3. Connect the Ethernet cable between the INTERNET Source (ex. Router, Modem) and the
WAN port on the HT.
4. Connect another Ethernet cable between your PC and the LAN port on the HT
5. Wait for 30 seconds till your PC gets an IP ADDRESS (192.168.2.2)
6. Now, open Internet Explorer and type in 192.168.2.1, you should see Grandstream Login
Screen pop up.
7. Enter 'admin' as the password
8. Go to Advanced Settings page and switch "Enable WAN port HTTP access" to YES, hit
'Update' and then 'Reboot'.

9. Disconnect your PC from the LAN port and connect it to any other port on your Router
within the same LAN Segment
10. Type in the actual IP ADDRESS of the HT (You can look this up by pressing *** on the
phone, and then 02) on Internet browser, access the Web Configuration page as you did earlier
and configure the device by filling in the information given by your Internet Telephony Service
Provider (ITSP).
Q: How do I setup a 3-way conference call?
Setting up a 3-way conference calling between parties using an HT, A and B is easy:
1. HT calls A
2. HT talks to A
3. HT presses FLASH or hook/flash and gets a new dialtone
4. A is on Hold
5. HT dials *23 and number for B
6. HT talks to B
7. HT presses FLASH or hook/flash to initiate the 3-way calling
Q: How do I perform attend transfer?
Attend Transfer from A to B through HT:
1. A calls HT
2. HT talks to A
3. HT presses FLASH or does hook/flash to get new dialtone.
4. A is on Hold
5. HT calls B
6. HT talks to B
7. HT hangs up to perform the Attend Transfer.
8. A and B are in call now.
Q: Which phone will ring if there is an incoming call on my wire (fixed) line (HT386)?
The Phone connected to FXS1 port will ring when there is an incoming call on the Fixed Line.
Q: How do I make or receive PSTN calls on my HT (for HT486/386/488)?
When receiving a call, the phone connected to the HT simply rings. When placing a call, dial the
'PSTN Line Access Code' first, as configured on the Web Configuration Page (by default it is
*00), and then dial the desired PSTN number.

Q: How do I ensure my 911 calls are directed over the PSTN network and implement a dial
plan for specific area codes without dialing a (1) prefix?
Create the following string under Dial Plan Configuration option under FXS PORT configuration
page:
{L: 404x+| L:770x+ | L:678x+| L:911 | x+}
Please note that only HT503 supports this feature.
Q: What is the led pattern of a HT502/503?
Power led ON indicates power is connected
WAN led ON indicates port activity
LAN led ON indicates PC (or LAN) port activity
Phone1/2 or Line led indicates status of the respective FXS port or FXO in case of
HT503. ON is Busy, OFF is available and slow blinking there is a voice mail for that
port.
Slow blinking of WAN and LAN together means the product’s firmware is in upgrading or
provisioning state.
BudgeTone Series FAQs
Q: What are the differences between BudgeTone-101, 102 and 200 models?
The BT model 101 (also called BT100) and 102 have the same software functions and the only
difference is that model 101 has one Ethernet interface and model 102 has two Ethernet
interfaces i.e. the PC port (to be connected to your computer) and normal LAN port (to be
connected to your Internet Source.). These 2 ports are bridged together similar to a HUB. BT-
200 is higher end version with Router feature and capable of supporting 100Mbps connections.
BudgeTone Model
BT101
BT102
BT200
LAN Interface
1 x RJ45
2 x RJ45
2 x RJ45
Bandwidth
10Mbps
10Mbps
10/100Mbps
Router Feature
No
No
Yes
Q: What Codecs are supported by BudgeTone Series Phones?
BudgeTone Phones support a wide range of Codecs:
BT101 and BT102 support:

1. PCMU or g711(a/µ law)
2. G.729 A/B
3. G.723.1
4. G.722 (wideband)
5. G.726-32
6. iLBC
BT200 supports PCMU, PCMA, g729 A/B, g723.1 and GSM codecs.
Q: How do I configure a Public or Static IP address using the phone menu?
This is a very crucial configuration. Generally we recommend configuring via DHCP since it’s
the easiest method of configuration. But nevertheless that is the reason configuring Public/Static
IP on Grandstream Products is as easy as it gets.
Press the MENU button and go through options 1 to 5 carefully. For each option make the
necessary change, for ex. option 1 should be dhcp off, option 2 should be the static IP address,
option 3 is the subnet mask, 4 is the gateway/router IP address and lastly and most importantly 5
is the DNS Server IP address. All these IP addresses need to be entered in 12 digit format i.e.
192168001029 for 192.168.1.29.
Absolutely! Here is a simple example of performing 3 way conferencing on BT phones:
A, B and C need to talk in a conference call. A will be performing the 3-way conference call
using his new BudgeTone Phone.
1. A calls B
2. A presses CONFERENCE and gets a new dialtone while B is on Hold
3. A calls C
4. A presses CONFERENCE again to initiate the Conference Call
5. A, B and C are in conference!
Q: How do I perform attend transfer and blind transfer using BudgeTone Phones?
Example: B needs to transfer a call from A to C.

Attend Transfer:
1. A and B are in a call
2. B needs to transfer the call to C
3. B presses FLASH to get new dialtone
4. B calls C while A is on Hold
5. Now, B can transfer the call from A to C by pressing TRANSFER and then hanging up.
6. A and C are in a call now!
Blind Transfer:
1. A and B are in a call
2. B needs to Blind transfer the call to C
3. B presses TRANSFER and gets new dialtone; A is on Hold.
4. B dials number for C
5. Call is transferred to C
Q: How do I configure voice-mail on the BudgeTone?
There is a field called Voice Mail User ID on the ‘Advanced Settings’ page. You need to
configure this field with your voice mail account number ex.8500. Now, if you need to access
Voice Mail simply press the Message Button on the device and it will connect to the Voice Mail
Inbox. In case of a new voice mail left in your inbox, the LED will start to blink RED.
Q: Does the BudgeTone have the Off hook Auto-Dial and Auto-Answer feature?
BudgeTone 100 and BT200 models support both these features.
Q: Does the BudgeTone support distinctive ringtone feature using ALERT-INFO Method?
Currently, BT phones support Distinctive Ringing for 3 specific Phone
Numbers/Extensions/User IDs. You will find this setting on Advanced Settings Page. Basically
you can configure 3 extensions with a Ringtone each and then whenever incoming call is from
one of these numbers, that configured Ringtone will play. The BT200 model supports Distinctive
Ringtones using SIP ALERT-INFO header.
BT200 supports the Alert-Info mapping to the 3 custom ring tone files. For example, if you
configure the custom ring tone 1 user id to “priority” (instead of a real user ID), that ring tone
will be used if we receive INVITE with Alert-Info header in the following format:

Alert-Info:;info=priority
Q: Does the BudgeTone support Syslog Server setting?
Yes, under Advanced Settings page, you will see Syslog Server and Syslog Level fields to setup
Syslog message retrieval. Syslog messages are very helpful in debugging any errors with the
device.
Q: Where do I view my Call History ex. Missed/Incoming/Outgoing Calls?
You can check Received/Missed Calls along with Outgoing calls made, on the Phone by
unhooking the receiver and then pressing CALLERS and CALLED resp. For more detailed Call
information you can log onto the web configuration pages, and check the Status page.
Q: How do I make a call using only the IP Address?
BT101 and BT102 models:
1. Off-hook the receiver or press speakerphone.
2. Press the MENU button
3. Now dial the IP Address in 12 digit format ex.192168001029
4. Press SEND.
BT200:
This model has the ability to dial an IP address under the same LAN segment by simply pressing
the last octet in the IP address.
In the Advanced Settings page there is an option "Use Quick IP-call mode", by default it is set to
No. When this option is set to YES, and #XXX is dialed, where X is 0-9 and XXX <=255, phone
will make direct IP call to aaa.bbb.ccc.XXX where aaa.bbb.ccc comes from the local IP address
REGARDLESS of subnet mask.
#XX or #X are also valid so leading 0 is not required (but OK).
For example:
192.168.0.2 calling 192.168.0.3 just dial #3 follow by SEND or #
192.168.0.2 calling 192.168.0.23 just dial #23 follow by SEND or #
192.168.0.2 calling 192.168.0.123 just dial #123 follow by SEND or #
192.168.0.2 dial #3 and #03 and #003 has same effect --> call 192.168.0.3

Note: If you have a SIP Server configured, Direct IP-IP call will still work. However, if you are
using STUN, Direct IP-IP call will also use STUN.
Q: How do I ignore an incoming call?
Yes, if you press the MUTE/DEL key whilst receiving an incoming call, it will be rejected and
forwarded to your Voice Mail (if configured).
Note: This feature is available only on BT200 model.
GXP Series FAQs
Q: The GXP Series supports multiple languages. Which languages are available?
The GXP Series has a language pak that supports English, Spanish, German, French, Polish,
Italian, others as requested. The language pack is available on the Firmware Section and is
updated regularly.
Q: For the Call Log, how many entries are allowed for dialed, missed, etc.?
The call log stores up to 50 entries in each call log (incoming|outgoing|missed). All GXP models
are the same.
Q: Does the availability of some features depend on the associated PBX? Which ones?
The end-user can choose to support advanced call features locally (on the phone) or choose the
PBX (or server) to support them. Please use the GUI Account Page settings to select or deselect
this feature. Call features include call forward (all types), transfer (all types), hold, mute, DND
and conference.
Q: Is call recording supported? Does this require an add-on device?
If the server or PBX supports call recording, we can support it. The GXP Series does not require
additional add-on devices to support this feature. Call recording is supported by all models if the
PBX or server supports it.
Q: For the address book, how many entries can be stored?
Up to 500 entries in the phonebook. XML sync is dependent on the size of the XML file and is
limited by current memory allocation. The address book is supported on all GXP models.
Q: Does the display show the call duration or a voice mail count?
Call duration is displayed during an active call. Each line has an individual voicemail and
number of voicemails is displayed for each line. Call duration and number of voicemails is
supported by all GXP models.
Q: How do I use the paging or intercom feature on the GXP Series?
For GXP20xx, on the Client side, the following two fields (Account Page) need to be set to Yes.

Allow Auto Answer by Call-Info
Turn Off speaker on Remote disconnect
For GXP21xx/GXP1450, on the Client side, the following field (Accoung Page) needs to be set
to Yes.
Allow Auto Answer by Call-Info
Note: The PBX Server has to support this feature to make it work.
Q: Is the GXP2020 Expansion Module compatible with the GXP2120/GXP2110 models?
Yes, it is compatible. However, the GXP2120/2110 has a special EXT port on the back which
requires a different extension cable (Included with the GXP2020 Expansion Module).
Q: Why am I getting a strange icon with a down arrow going into a basket [_]?
This symbol is stating that the phone is writing files to the call record detail file. This occurs
when the phone is either idle for 5 minutes or when the call records reach greater than 100 calls.
Q: What configuration changes on the web-gui require a reboot?
Under Basic and Account settings you are not required to reboot the phone. If changes were
made under Advanced settings only the network changes require a reboot. The following
parameters do not require a reboot:
Admin Password
STUN Server
Phonebook XML Download
Offhook Auto Dial
Call Progress Tones
Custom ring tone 1 - 3, used if incoming caller ID is set
Intercom User ID
Disable Call-Waiting
Disable Call-Waiting Tone
Disable Direct IP Calls
Use Quick IP-call mode
Disable Conference
Enable MPK sending DTMF
Disable Transfer
Auto Attended Transfer
Display Language

GXP2000 FAQs
Q: What are the differences between the BudgeTone Series and the GXP2000?
The GXP2000 SIP Enterprise phone has more feature functionality than the BT Series.
Functionally, the GXP2000 has multiple accounts, GUI Interface, Busy Lamp Field (BLF), speed
dial, dual 10/100Mbps Ethernet ports, POE, etc. Please reference the GXP2000 User Manual for
more information.
Q: What Codecs are supported by the GXP2000?
The GXP2000 supports a wide range of Codecs:
1. PCMU or G.711(a/µ law)
2. G.729 A/B
3. G.723.1
4. GSM
Q: How many VoIP accounts can I have on the GXP2000?
The GXP2000 IP phone is capable of having a maximum of 4 different SIP (VoIP) Accounts.
These accounts may be different extensions on the same Server or different Servers from
different Service Providers. The 7 functional buttons on the right side of the phone are speed
dial buttons.
Note: When Line1 to Line4 are busy with calls, next incoming call will light up on the first
function key (Speed Dial-1). You can pick the call up by pressing the function key like a Line
button. For outgoing calls, press the button under the cradle (i.e. on-hook and off-hook) to get a
new dialtone.
Q: How can I configure BLF (Busy Lamp Field) on the 7 speed dial buttons of the
GXP2000?
The Speed Dial buttons can also be configured for Asterisk™ BLF feature which allows you to
realize if a particular extension is busy with a call or idle. To configure this on the GXP2000,
select Asterisk™ BLF from the drop down box next to Key Mode for a configured Speed Dial
contact on the Basic Settings page. Now, on the Phone, if the LED next to the respective button
lights up Red, it means the extension is Busy; if it flashes Red it indicates an incoming call on
that extension.
>Q: Can I display any custom text along with my extension number on the phone LCD?

Yes, any text entered on the ‘Name’ field along with the ‘User ID’ will be displayed on the LCD
in Bold (for Account 1 only). Under Basic Settings, field ‘Display Clock instead of Date’ should
be set to No.
Q: Can I enable/disable recording of missed calls?
Yes, on each Account Page, there is a field for ‘Disabling Missed Calls’. If set to Yes, ‘Missed
Calls’ for that Account will not be recorded anymore.
Q: Does the GXP2000 have ‘intuitive dialing’ and call log for previously dialed and
received calls?
The GXP2000 has a call log with only last 20 records stored and will be reset once the phone
reboots. Just off hook and press the left and right arrow key you should see that. There is no
intuitive dialing yet but we hope to implement address book function in the new firmware
release.
Q: How do I use the paging or intercom feature on the GXP2000?
On the Client side, the following two fields (Account Page) need to be set to Yes.
Allow Auto Answer by Call-Info
Turn Off speaker on Remote disconnect
Note: The PBX Server has to support this feature to make it work.
Q: How do I make a call using the IP Address only?
This phone has the ability to dial an IP address under the same LAN segment by simply pressing
the last octet in the IP address.
In the Advanced Settings page there is an option "Use Quick IP-call mode", by default it is set to
No. When this option is set to YES, and #XXX is dialed, where X is 0-9 and XXX <=255, phone
will make direct IP call to aaa.bbb.ccc.XXX where aaa.bbb.ccc comes from the local IP address
REGARDLESS of subnet mask.
#XX or #X are also valid so leading 0 is not required (but OK).
For Example:
192.168.0.2 calling 192.168.0.3 just dial #3 follow by SEND or #
192.168.0.2 calling 192.168.0.23 just dial #23 follow by SEND or #

192.168.0.2 calling 192.168.0.123 just dial #123 follow by SEND or #
192.168.0.2 dial #3 and #03 and #003 has same effect --> call 192.168.0.3
Note: If you have a SIP Server configured, Direct IP-IP call will still work. However, if you are
using STUN, Direct IP-IP call will also use STUN.
Q: How do I ignore an incoming call?
Yes, if you press the MUTE/DEL key whilst receiving an incoming call, it will be rejected and
forwarded to your Voice Mail (if configured).
Q: Does the GXP2000 support PoE?
Yes, the GXP2000 supports Power over Ethernet It can accept either pins 7/8(+), 4/5(-) or 7/8(-),
4/5(+). The injector voltage must above 48VDC. When you use PoE power you must take away
5V power adaptor.
Q: Does the GXP2000 support Distinctive Ringtone using ALERT INFO method?
The GXP2000 supports the Alert-Info mapping to the 3 custom ring tone files. For example, if
you configure the custom ring tone 1 user id to “priority” (instead of a real user ID), that ring
tone will be used if we receive INVITE with Alert-Info header in the following format:
Alert-Info: ;info=priority
Q: How do I configure my GXP2000 for Daylight Savings?
The "Automatic Daylight Saving Time Rule" shall have the following syntax:
start-time;end-time;saving
Both start-time and end-time have the same syntax:
month,day,weekday,hour,minute
month: 1,2,3,..,12 (for Jan, Feb, .., Dec)
day: [+|-]1,2,3,..,31

weekday: 1, 2, 3, .., 7 (for Mon, Tue, .., Sun), or 0 which means the daylight saving rule is not
based on week days but based on the day of the month.
hour: hour (0-23),
minute: minute (0-59)
If "weekday" is 0, it means the date to start or end daylight saving is at exactly the given date. In
that case, the "day" value must not be negative.
If "weekday" is not zero and "day" is positive, then the daylight saving starts on the first "day"th
iteration of the weekday (1st Sunday, 3rd Tuesday etc).
If "weekday" is not zero and "day" is negative, then the daylight saving starts on the last "day"th
iteration of the weekday (last Sunday, 3rd last Tuesday etc).
The ‘savings time’ is in the unit of minutes. The saving time may also be preceded by a negative
(-) sign if subtraction is desired instead of addition.
The default value for "Automatic Daylight Saving Time Rule" shall be set to
"03,02,7,02,00;11,1,7,02,00;60" which is the rule for US.
Q: Which headset models do you recommended to work with your GXP Series Phone?
Most “noise canceling” enabled headsets are compatible with the GXP series. We recommend
VXI, Jabra, HelloDirect and Plantronics headsets. We have tested with Jabra GN9350,
Plantronics CS70N, Plantronics M12, M10, M22 and VXI10V Tuffset, etc.
Q: How do you configure "event list BLF" on the GXP Series?
You will need to configure a "event list BLF" URI on your server side if the server supports it.
(i.e.: [email protected])
On the GXP, under account page, fill in the ""event list BLF" field with the URI without the
domain. (i.e.: BLF1006).
Under Basic Settings, please select "event list BLF", choose account number, monitored number,
etc.
Q: Is the GXP2000 extension module compatible with the other GXP series phones?

No, the GXP2000 extension module is only compatible with the GXP2000. Extension modules
for other GXP phones will be available in 2008.
GXV3000 FAQS
Q: What service providers or platform support the GXV3000?
ITSPs with pure SIP proxy (e.g. Iptel’s SER); or ITSPs with hybrid SIP proxy (e.g. Digium
Asterisk™ R1.4, SBC or OBP) but supporting H.264 and H.263 when manipulating media.
Q: What are the functions of the USB ports?
The 2 USB interfaces are USB 2.0 host ports. The USB interface can be used for external USB
device like flash to store captured image, ring tones, phone address books (not implemented yet),
etc.
When a USB flash drive is connected to the USB 2.0 port, an icon will display in the lower
section of the LCD.
Q: Do I need a service provider? Can I make IP-to-IP call between video phones?
Yes, you need to have an Internet Telephony Service Provider (ITSP). You can also use “Direct
IP Call” to talk to each other in an ad hoc fashion without a SIP proxy. “Direct IP Call” can be
made between two phones if:
both phones have public IP addresses, or
both phones are in a same LAN/VPN using private or public IP addresses, or
both phones can be connected through a router using public or private IP addresses (with
necessary port forwarding or DMZ)
To make a direct IP call, press OK button to bring up MAIN MENU. Select “Direct IP Call”.
Press OK key to bring up the input interface and then key in the 12-digit target IP address. Press
OK key to initiate call.
For example: If the target IP address is 192.168.1.60 and the port is 5062 (e.g.
192.168.1.60:5062), input the following: 192*168*1*60#5062 - “*” key represent “.” and “#”
key represent “:”. Press OK to dial out.
Or, you can select:
Use Quick IP-call mode:
No Yes
Then use “#xxx#” to call where xxx is the last octet of the IP address if both phones are in the
same LAN.
For example: If the target IP address is 192.168.1.60 and use default port 5060, then you can
just off hook the phone and press “#60#” or “#60” followed by SEND key to make the quick IP

call. This is very useful in an enclosed LAN environment where you can assign static IP based
on, for example, room number in a building.
Q: How do I set up the video phone when my internet bandwidth connection is very low?
You need at least 128kbps bandwidth in both directions (uplink and downlink) to make the
GXV-3000 work with good picture quality.
If using less than 128kbps, for example 96kbps bandwidth, you can configure: Frame Rate to 5
(lowest) and Video Bit Rate to 64kbps or even 32kbps (lowest), to see if the video quality is
acceptable in your network environment. Otherwise, please upgrade your bandwidth as you don’t
have enough physical data pipe to run the video data stream.
Detailed raw data rate (without using video codec compression) can be roughly calculated as
follows:
If the LCD is 320x240 for QVGA and one pixel needs one bit (black or white) to present
(actually it is more because of color), then the data capacity for ONE frame is: 320 x 240 = 76.8
kbps.
If the frame rate is 5 frames per second, then the total data stream (raw data for video without
compression) is: 76.8 x 5 = 384 kbps.
Also, you need to add the additional audio data rate (details please refer to Codec FAQ ):
With the H.264 codec, the video data can be compressed. But to ensure good picture quality
having the necessary bandwidth is the KEY to a good picture because so much data that needs
to be transmitted simultaneously in both directions.
Q: What is the meaning of the letters displayed on the LCD screen when a call is made?
PCMU/H.264U: This means the Audio / Video codec used in the call. It shows audio is using
G.711 µlaw (PCMU) and video is using H.264 video codec.
86K/15FU: This shows RECEIVING video bandwidth used in the call (OSD always shows
other side bandwidth used and suppose you should know your own sending video bandwidth as
this video bit rate is configured by you in the configurations).
For example: “86K/15F” means you are receiving video bit rate using 86Kbps and 15F means it
is using 15 frame per second to send the video.
The top left and right time stamp shows “current time” and “call duration”.
Q: Can I connect a TV monitor to the GXV-3000?

Yes.
Q: Can I broadcast the video from the GXV3000 into my local network?
No, if you mean live call broadcasting or multicasting in the LAN using the phone as source.
Yes, if you mean a video conference using server or MCU as source.
Also, you can configure the phone in “Video Surveillance” mode and get the video stream
packets in the same LAN via the monitor PCs. For more detailed information, please refer to the
“Video Surveillance” section of GXV-3000 User Manual.
Q: Can I take a snapshot of the image in the LCD monitor?
Yes. Once a USB flash drive is connected and ready for use (an icon will show up in lower part
of the LCD when it is ready), the user can save a snap shot or capture a picture on the LCD and
stored into the flash drive in YUV format. For detailed information, please refer to the
“Auxillary Ports” section of GXV-3000 User Manual.
GXV350x FAQS
Q: Why is the plug-in not displayed in Microsoft Internet Explorer?
Trouble Shooting 1: Is the Plug-in properly installed?
How to solve: You must install the plug-in when you access the web GUI of the GXV3501/3504
for the first time. here are two ways to install it:
A: Install the certified ActiveX control
B: Download the program or copy it from a disk, unzip the files to a temporary directory, go into
the directory, close Internet Explorer, double click on install.bat to install the Active X control

Q: Why can’t I access the GXV 3501/3504 web configuration interface?
Trouble Shooting 1: Is your internet service down?
How to solve: Connect a PC to the internet to test the connection
Trouble Shooting 2: Are the PC and the encoder on different subnets?
How to solve: Check the subnet mask and default gateway of the encoder and PC
Trouble Shooting 3: Is there conflict with another IP address?
How to solve: Try to change the IP address of the device
Trouble Shooting 4: Has the HTTP port been changed?
How to solve: Contact the administrator of the device for more information
Q: Why is video playback not working in the web interface?
Trouble shooting 1: The plug-in is not installed or is not installed properly
How to solve: Install the plug-in again
How can I use a cell phone to watch the video stream on the DVS?
You must set the video resolution to QCIF if you want to watch the DVS video stream from a
cell phone. Make sure to set the bit rate to 64kbps to ensure the best video quality.
Q: Why doesn’t the IP address of the device reset when I click the “Restore” button on
the Maintenance page?
The DVS could be installed in areas that are not easy to access. For example, it could be installed
on the roof of a building or the ceiling of an office. This makes it difficult to reinstall the device,
therefore the “Restore” function will not clear the IP address. Press the RESET button on the
device for at least 6 seconds until you hear a beep to perform a factory reset of all parameters
(including the IP address).

Q: Why can’t users watch the live video stream using a mobile phone or GSurf after
changing the HTTP Port of the device?
Make sure that the RTSP port of the device is set to 2000 plus the HTTP Port number. For
example, if the HTTP port is 88, then the RTSP port of the device that you configure on GSurf /
mobile phone should be 2088.
Q: How do you connect different types of detectors (such as infrared & smoke detectors) to
the DVS?
Sample connection diagrams are shown below:
Figure 1: Sample Alarm-in Connection Diagram 1
Figure 2: Sample Alarm-in Connection Diagram 2

Q: How do you connect Alarm equipment to the Alarm-Out connection on the DVS?
A Sample connection diagram is shown:

Q: How does PTZ work with the DVS?
Follow these steps to configure the PTZ function on the DVS:
1. Connect the PTZ device to the DVS. A sample connection diagram is shown below.
Figure: Sample PTZ Device Connection Diagram
