Grandstream GXP2160
and Elastix Server
Setup Guide

PaloSanto Solutions
Grandstream GXP2160 Server Setup Guide
2
1.0 Setup Diagram
Figure 1-1 is a setup diagram for a single IP phone Grandstream GXP2160 configuration.
The phone is setup as a SIP telephony device.
Figure 1-1. Setup Diagram
2.0 Host PC Environment
Table 2-1. Host Server Environment Details
Description
Hardware Type
Elastix Appliance ELX-Series
Hardware Version
ELX-5000
Software Type
Elastix
Software Version
2.4
3.0 Test Setup Equipment
Table 3-1. Test Setup Equipment
Equipment
Model
Version
IP (SIP) Phone
N/A
N/A
Grandstream
GXP2160
1.0.0.17
Switch
N/A
N/A

PaloSanto Solutions
Grandstream GXP2160 Server Setup Guide
3
4.0 Setup Procedure
To set up the Elastix Server for the Grandstream GXP2160
1. Go to the web address of the Elastix Server Login page. The web address is
determined by the customer, for this guide we have used the IP address 192.168.5.186
2. On the Login page, type the username and password for an administrative user into
the Username and Password fields, see Figure 4-1. The username and password are
determined by the customer.
Figure 4-1. Login
3. Press Enter or click on the Submit button to go to Elastix’s Dashboard
4. Once inside, click on the PBX tab on the menu at the top of the screen

PaloSanto Solutions
Grandstream GXP2160 Server Setup Guide
4
Figure 4-2. Dashboard
5. Click on the Submit button to add an extension, see Figure 4-3. This will take you to
the Add SIP Extension page.
Figure 4-3. Add an Extension
6. On the Add SIP Extension page (Figure 4-4), fill in the following information:
• User Extension (100 in this example)
• Display Name (‘GrandstreamGXP2160’in this example)
• secret (‘h7Dka3Rf9si0t’in this example)

PaloSanto Solutions
Grandstream GXP2160 Server Setup Guide
5
Figure 4-4. Add SIP Extension
7. Click on “Submit” button at the end of the page, and you will see a similar page on
Figure 4-5 displaying the “Apply Configuration Changes Here” pink ribbon on top of
the screen. Click on there to apply changes.
Figure 4-5
8. With this you have just finished creating a SIP extension that will be used by the
Grandstream GXP2160 to register with the Elastix Server. Repeat Steps 5 through 7 to
similarly create another extension (different values on Step 6) to be used by the IP (SIP)
Phone to register as well (extension 101 in this example). Once you finished you will
see something similar to Figure 4-6.

PaloSanto Solutions
Grandstream GXP2160 Server Setup Guide
6
Figure 4-6
9. You will need to enter the information from the extension created on the Elastix
Server into the Grandstream Phone.
For the initial configuration, refer to the Grandstream GXP2160 User Manual found at:
http://www.grandstream.com/index.php/products/ip-voice-telephony/enterprise-ip-
phones/gxp2160
Factory default settings
IP Addressing
DHCP
Web Access Username
admin
Web Access Password
admin
10. Log in to the Grandstream GXP2160 WebUI by pointing your browser to the
Grandstream Phone’s IP address.
11. When prompted, enter the Web Access Password to accesss to the WebUI (Figure 4-
7).
Figure 4-7 Grandstream WebUI
To register the Grandstream GXP2160 Phone we have two methods: Manual
Configuration and Autoprovisioning using Elastix’s Endpoint Configurator.

PaloSanto Solutions
Grandstream GXP2160 Server Setup Guide
7
MANUAL CONFIGURATION
1. Use the information from the Add SIP Extension page (Figure 4-4) to enter the
following necessary information on “Account => Account 1” section of the
Grandstream Phone WebUI (Figure 4-8):
Account Active: Yes
Account Name: GrandstreamUser
SIP Server: Elastix Server’s IP Address (192.168.5.186 in this example)
SIP User ID: 100
Authenticate ID: 100
Authenticate Password: (‘h7Dka3Rf9si0t’ in this example)
Figure 4-8. Account
2. Once you have entered the required information, click on ‘Save and Apply’ button
located at the end of the page.
3. To check the correct registration of the phone, go to “Status” section. You should see
your phone registered (Figure 4-9). If the phone is not registered, make sure you’ve
entered the correct information.

PaloSanto Solutions
Grandstream GXP2160 Server Setup Guide
8
Figure 4-9. Status
3. Configure the other IP (SIP) Phone with the correct parameters.
4. To test the Grandstream GXP2160, pick up the previously configured IP (SIP) Phone
and call the GXP2160’s extension number (101 in this example). When the call is
established, speak into the phone and verify that the other IP (SIP) Phone can hear your
voice. Check this by calling from both ends.
This step completes the manual procedure.

PaloSanto Solutions
Grandstream GXP2160 Server Setup Guide
9
AUTOPROVISIONING USING ELASTIX’S ENDPOINT
CONFIGURATOR
Note: Endpoint Configurator support available starting Elastix 2.5 RC
1. After installation, in the Elastix Web Interface go to “PBX => Batch Configurations
=> Endpoint Configurator”. See figure 4-10
Figure 4-10. Endpoint Configurator
2. Type the network address where the phone is located and click on the magnifying
glass. This will generate a list with all the phones available in that network. See
figure 4-11.
Figure 4-11. List of endpoints
3. In the row where the phone you want to autoprovision is located (find it according
to either its MAC or IP Address):
Mark the checkbox
From the drop-down list, select the correct Phone Model if it is not detected
automatically
Click on the link “[Configure x.x.x.x]” to set the parameters to configure the
phone.
4. After clicking in the configuration link, you will see a window with many tabs
according to what you want to configure. In this case we will configure a SIP
account. Go to the tab “Accounts” and drag the accounts you want to assign from

PaloSanto Solutions
Grandstream GXP2160 Server Setup Guide
10
left to right. Then click on Apply button. See figure 4-12.
Figure 4-12. Accounts configuration
5. After configuring you will see that the status field of the phone has changed. See
figure 4-13
Figure 4-13. List of endpoints
6. Now with the phones selected, click on the button “Apply Configuration” located
next to the magnifying glass button. A message will be shown saying the operation
was successful. See figure 4-14.

PaloSanto Solutions
Grandstream GXP2160 Server Setup Guide
11
Figure 4-14. Configuration successful
7. Your phone will reboot, and when it boots up it should be registered with Elastix
with the accounts you set. This step completes the procedure.
