Grandstream Networks GXV3240 User manual

Grandstream Networks, Inc.
126 Brookline Ave, 3rd Floor
Boston, MA 02215. USA
Tel : [phone] - 9300
Fax: [phone] - 1987
www.grandstream.com
For Warranty and RMA information, please visit www.grandstream.com
GXV3240
IP Multimedia Phone for AndroidTM
Quick Installation Guide
HDMI, the HDMI Logo, and High-Denition
Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing LLC in the United
States and other countries.
TM
*Android is a Registered Trademark of Google, Inc.

Content
English..............................................................................1
简体中文..........................................................................9
Español............................................................................17
Français...........................................................................25
Deutsch...........................................................................33
Italiano............................................................................41
Русскй.............................................................................49
Português........................................................................57

1 2
The GXV3240 is not pre-congured to support or
carry emergency calls to any type of hospital, law
enforcement agency, medical care unit (“Emergency
Service(s)”) or any other kind of Emergency Service.
You must make additional arrangements to access
Emergency Services. It is your responsibility to pur-
chase SIP-compliant Internet telephone service, prop-
erly congure the GXV3240 to use that service, and
periodically test your conguration to conrm that it
works as you expect. If you do not do so, it is your re-
sponsibility to purchase traditional wireless or landline
telephone services to access Emergency Services.
GRANDSTREAM DOES NOT PROVIDE CON-
NECTIONS TO EMERGENCY SERVICES VIA THE
GXV3240. NEITHER GRANDSTREAM NOR ITS
OFFICERS, EMPLOYEES OR AFFILIATES MAY
BE HELD LIABLE FOR ANY CLAIM, DAMAGE, OR
LOSS. YOU HEREBY WAIVE ANY AND ALL SUCH
CLAIMS OR CAUSES OF ACTION ARISING FROM
OR RELATING TO YOUR INABILITY TO USE THE
GXV3240 TO CONTACT EMERGENCY SERVICES,
AND YOUR FAILURE TO MAKE ADDITIONAL AR-
RANGEMENTS TO ACCESS EMERGENCY SER-
VICES IN ACCORDANCE WITH THE IMMEDIATELY
PRECEDING PARAGRAPH.
PACKAGE CONTENTS:
EN
PRECAUTIONS:
WARNING: Please DO NOT power cycle the GXV3240 during system boot
up or rmware upgrade. You may corrupt rmware images and cause the unit to
malfunction.
WARNING: Use only the power adapter included in the GXV3240 package.
Using an alternative non-qualied power adapter may possibly damage the unit.
1 X GXV3240 Main Case 1 X Handset 1 X Phone Cord
1 X Ethernet Cable 1 X 12V Power Adapter 1 X Phone Stand
1 X Quick
Installation Guide
1 X Wall Mount 1 X Screen
Cleaning Cloth
12V

3 4
CONNECTING THE PHONE:
OVERVIEW:
PHONE SETUP:
GXV3240 represents the future in personal IP multimedia communication, featur-
ing Android™ Operating System 4.2 and its vast number of 3rd party applications,
a 4.3” (480x272) capacitive touch screen, a tiltable mega-pixel CMOS sensor,
dual Gigabit network ports, integrated Wi-Fi, PoE and Bluetooth. The GXV3240
delivers superior HD audio & video, leading edge telephony features and integra-
tion of rich Web content with access to the rapidly growing Android™ applications
base and automated provisioning. GXV3240 redenes the desktop communica-
tion experience with a raised level of innovation and integration of state-of-art real
time video conferencing, personalized rich media presentation & delivery, popular
Web and social networking applications and advanced business productivity tools.
1. Attach the wall mount to the slots on the back of the phone;
2. Attach the phone to the wall via the wall mount hole;
3. Pull out the tab from the handset cradle (see gure below);
4. Rotate the tab and plug it back into the slot with the extension up to hold the
handset while the phone is mounted on the wall.
Installing The Phone (Wall Mount):
1. Connect the handset and main phone case with the phone cord;
2. Connect the LAN port of the phone to the RJ-45 socket of a hub/switch or a rou-
ter (LAN side of the router) using the Ethernet cable;
3. Connect the 12V DC output plug to the power jack on the phone; plug the power
adapter into an electrical outlet. If PoE switch is used in step 2, this step could
be skipped;
4. The LCD will display booting up or rmware upgrading information. Before con-
tinuing, please wait for the main screen display to show up;
5. Using the web conguration interface or from the menu of the touch screen, you
can further congure network connection using static IP, DHCP and etc.
HDMI Port
PC
Port
LAN
Port
Handset
Port
Power Headset
Port
SD Card Slot
USB Port
Slots for the wall mount
and phone stand
Tab with extension up
Handset Rest
Tab with extension down
Attach the phone stand to the back of the phone where there is a slot for the
phone stand. Upper part and bottom part are available for two angels.
Installing The Phone (Phone Stand):
EXT
Port

5 6
Tips For Using the Keypad:

Message Waiting
Indicator
Hold
Message
Transfer
Volume
Send
Speaker
Conference
Menu
Back
Home
Backspace
Phonebook
Standard
Keypad
PHONE CONFIGURATION:

1. Ensure your phone is properly powered up and connected to the Internet;
2. The IP address of the phone will show in the main screen when pressing the
Home button;
3. Type the phone’s IP address in your PC’s browser (see gure in the next page);
4. The default username and password for administrator are “admin” and “admin”.
The default username and password for user are “user” and “123”;
5. In the web GUI, select Account 1/2/3/4/5/6 page to congure Account name, SIP
Server, SIP User ID, Authenticate ID and Authenticate Password to register the
account on the GXV3240.
1. Make sure the phone is properly powered up and in idle screen;
2. Tap on the LCD MENU icon to access GXV3240’s applications and settings;
3. Select Settings->Advanced Settings->Account. Tap on one of the Account to
congure Account name, SIP Server, SIP User ID, SIP Auth ID, SIP Auth Pass-
word to register account on the GXV3240. After successfully registered, the ma-
in screen will be shown as the gure below;
4. Follow the LCD Menu options to congure other settings on the phone. For exa-
mple, to congure static IP on the GXV3240, set up static IP address via LCD
Menu->Settings->Wireless & Network->Ethernet Settings;
5. Please contact your ITSP (Internet Telephony Service Provider) for additional
settings that may be necessary to congure the phone.
Headset
Mute

7 8
The GXV3240 uses GXP2200EXT as the extension module. The extension mod-
ule is an ideal solution for the busy enterprise environment looking to add the
ability to receive and dispatch calls efciently. Each GXP2200EXT extension mod-
ule has 20 programmable buttons, Left and Right buttons, supporting 40 Multiple
Purpose Keys to be congured. GXV3240 supports up to 4 extension modules,
adding 160 fully programmable phone extensions to the phone.
Note: The GXP2200EXT is an additional accessory for the GXV3240. Therefore,
the GXP2200EXT (including extension module accessories for installation) is not
included in the GXV3240 box. For detailed information about the GXP2200EXT,
please refer to the link below:
http://www.grandstream.com/support
Note: For the detailed user manual, please download from:
http://www.grandstream.com/support

1. Login the GXV3240 web GUI and congure multiple purpose keys for extension
board 1/2/3/4 under web GUI->Advanced Settings->MPK EXT Settings page;
2. On the GXV3240 extension board (i.e., GXP2200EXT), press LEFT or RIGHT
button to browse all the MPKs’ status in different pages;
3. For more conguration information, please refer to the GXV3240 user manual
and the GXP2200EXT user manual.
3. Connect the GXP2200EXT to the GXV3240 via the EXT port using the RJ11-
RJ11 cable provided with the GXP2200EXT;
4. Install the phone stands on the GXV3240 and the GXP2200EXT;
5. Power up the GXV3240. The GXP2200EXT will show the booting up screen
with version information and connecting status;
6. After successfully booting up, the extension board will stay in idle. Press and
hold the LEFT button for 3 seconds to check the version information and status.

1. On the back of the GXV3240 and the GXP2200EXT, there are slots for connec-
tor plate. Attach the connector plate between the slots for the GXV3240 and the
GXP2200EXT;
2. Apply the screws provided and securely tighten them in (see gure in the next
page);
CONNECTING GXV3240 EXTENSION MODULE:

1 X GXP2200EXT Board 1 X GXP2200EXT Stand 1 X RJ11-RJ11 Cable
1 X Connector Plate 4 X Screws 1 X Quick Installation Guide

9 10
GXV3240不预设对医院，执法机构，医疗中
心(急救服务)以及各种紧急服务的紧急通话服
务。用户必须自行设定紧急通话功能。用户必
须自行购买SIP兼容的网络电话服务，正确的设
定GXV3240使用该服务，并定期测试您的配置
以确保GXV3240如预期工作，否则请购买传统
无线或有线电话服务来拨打紧急通话。
Grandstream Networks 公司的GXV3240不支
持紧急通话服务。Grandstream Networks公
司、其管理者和员工以及其相关机构对此所造
成的任何索赔、损失或者损害都不负有任何法
律追究责任。在此，您将无权对任何以及所有
由于无法通过GXV3240拨打紧急电话以及没有
遵照前段文字描述而造成紧急通话失败的事件
提出诉讼。
设备包装清单：
ZH
注意事项：
警告：请不要在设备启动未完成的时候或设备的软件升级过程中断开电源。如上
所述的操作会导致话机本身的程序损坏，进而造成设备无法启动。
警告：请使用设备包装中的电源。使用其他没有经过认证的替代电源适配器有可
能对设备造成损害。
GXV3240话机（1台） 电话手柄（1个） 手柄连线（1根）
网线 （1根） 电源适配器 （1个） 桌面支架 （1个）
快速安装手册（1本）
12V
擦镜布（1块）墙体支架（1个）

11 12
电话的连接：
产品概览：
PC端口 网络端口
桌面支架插槽和墙体支架插槽
安装电话：
GXV3240是一台功能丰富的IP多媒体电话。它基于Android™ 4.2操作系统平台，
广泛支持第三方应用，使用480x272电容式触摸屏，可倾斜百万像素CMOS感应
摄像头，2个Gigabit网络接口，内嵌Wi-Fi，支持PoE供电和蓝牙。GXV3240具有
优异的高清晰语音质量和视频质量，完备的电话功能，集成了大量最新Android™
应用，并且支持自动配置。GXV3240是一款集实时视频会议、个性化多媒体信
息、社交网络应用和先进的商务工具于一体的理想智能桌面电话。
耳机端口
SD卡插槽
USB端口
1.将墙体支架插入电话背面的墙体支架插槽中；
2.通过墙体支架孔将话机固定在墙上；
3.将话机手柄槽下方的扣机零件取出（如下图）；
4.将该零件倒转，然后重新插入原处。此时零件凸出处在外，手柄可以垂直地稳
定扣入手柄槽中，不会滑落 。
安装电话墙体支架：
1.用手柄连线连接电话手柄和电话主机；
2.用网线连接电话的网络接口和外部网络接口（如：集线器或交换机上的RJ-45网
络接口）；
3.用12V电源适配器连接电话电源接口和交流电源插座。如果在第二步中使用了
PoE交换机，可忽略此步骤；
4.电话屏幕将会显示设备启动或固件升级信息。请耐心等待至主画面显示；
5.话机启动后，用户可以在主菜单或WEB浏览器进一步设置静态IP，DHCP等其
他配置，从而获得网络连接。
手柄端口
将桌面支架插入电话背面的支架插槽中。用户可以使用两排插槽中的一排，不同
的插槽用于不同的倾斜角度。
凸出处向上
话机手柄插槽
凸出处向下
安装电话桌面支架：
HDMI端口
扩展板端口 12V电源

13 14
使用GXV3240键盘：
信息指示灯
保持
静音
耳机
菜单
返回
主界面
电话簿
标准键盘
1.请确保电话与电源，电话与网络已正确连接；
2.用户可以按下“主界面”按键，电话的IP地址将会显示在话机屏幕主界面上；
3.在电脑浏览器中输入话机的IP地址（电话和电脑必须在同一个网段）。请参见
下页中图片；
4.默认管理员的用户名是“admin”，密码是“admin”；默认终端用户的用户名
是“user”，密码是“123”；
5.在WEB界面中，选择账号1/2/3/4/5/6页面，配置账号显示名、SIP服务器、
SIP用户ID、认证ID、认证密码等信息，可以在GXV3240上注册账号。
1.请确保电话已正常启动，并且显示空闲状态；
2.如下图所示，用户可以按下屏幕中间正下方的“菜单”图标，此时电话会显示
菜单（包括应用和设置等选项）；
3.进入设置->高级设置->账号，选择一个账号，配置账号显示名、SIP服务器、SIP
用户ID、认证ID、认证密码等信息注册账号。注册成功后，GXV3240屏幕主画
面将如下图所示；
4.按下主画面中菜单图标，使用菜单中各选项进行其它配置。例如，若需设置电
话静态IP地址，进入设置->网络->以太网设置；
5.如有其它需要的设置，请联系您的服务提供商。
消息
会议
转接
免提
音量
发送
电话的配置：
通过WEB浏览器配置GXV3240：
通过触摸屏配置GXV3240：
退格

15 16
GXV3240使用GXP2200EXT作为扩展板，为企业提供了有效处理大量频繁通话
的解决方案。每个GXP2200EXT扩展板支持20个可编程按键、左键和右键，可配
置40个多功能键。GXV3240支持最多4个扩展板，总共可配置和使用160个多功
能键。
注意：GXP2200EXT是GXV3240额外的配件。因此，GXP2200EXT及其安装配
件不包含在GXV3240包装盒中。欲获取更多详细的GXP2200EXT使用信息，请
参见以下链接：
http://www.grandstream.com/support
备注：欲获取详细的话机使用信息，请在以下链接中下载GXV3240用户手册。
http://www.grandstream.com/support
1.登陆GXV3240的WEB界面，进入高级设置->扩展板设置页面，选择相应扩展板
1、2、3、4的标签，配置该扩展板的多功能键；
2.在GXV3240扩展板上（即GXP2200EXT），按下左键或右键，可以浏览不同页
面的多功能键状态；
3.欲获取更多详细信息，请参考GXV3240用户手册和GXP2200EXT用户手册。
3.使用包装中的RJ11-RJ11连接线，一端接入GXV3240背面的EXT接口，一端接
入GXP2200EXT背面接口；
4.连接GXV3240桌面支架；连接GXP2200EXT桌面支架；
5.连接好后，启动GXV3240话机。GXP2200EXT将显示启动界面，版本信息和连
接状态；
6.启动成功后，GXP2200EXT将处于空闲状态。用户可以持续按住左键3秒，查看
版本信息和连接状态。
GXP2200EXT扩展板
（1个）
GXP2200EXT桌面支架
（1个）
RJ11-RJ11连接线
（1根）
连接板（1个） 螺丝（4个）
1.在GXV3240话机和GXP2200EXT背面，用户可以看到用于连接板的插槽。将连
接板放置于在话机和扩展板的插槽上；
2.将包装中的螺丝安装在连接板上，从而固定GXV3240话机和GXP2200EXT的连
接（请参见下页图示）；
连接GXV3240扩展板：
GXP2200EXT包装清单：
安装GXP2200EXT扩展板至GXV3240：
配置GXV3240扩展板：
快速安装手册（1本）
