TABLE OF CONTENTS
Safety Information ........................………………………………………………………......….3
Package Contents .............................…………………………………………………………..4
Hardware Contents .............................…………………………………………………...........5
Preparation .......................................….…………………..……………………….….....5 - 6
Initial Installation ............................................……………………...………..................6 - 7
Wiring ...............................................................................................……......................8 - 9
Final Installation ............………………….………….....................................................9 - 12
Using Fan Without Light Kit (Optional) ......................................................................................12
Fan Operation ..............................................……………………………......................12 - 13
Care and Maintenance .......................………………………......………...….....…..............13
Troubleshooting ...........................................………...……………………..….........…........14
Warranty ........................…………………………………….………………..............…......….15
Replacement Parts List .......................………………………......………...….....….............16

3
SAFETY INFORMATION
READ AND SAVE THESE INSTRUCTIONS
Please read and understand this entire manual before attempting to assemble, install or operate
the product. If you have any questions regarding the product, please call customer service at
1-800-527-1292, 8:30 a.m.-5:00 p.m., CST, Monday-Friday.
1. Before you begin installing the fan, disconnect the power by removing fuses or turning off
circuit breakers.
2. CAUTION: Read all instructions and safety information before installing your new fan.
Review the accompanying assembly diagrams.
3. WARNING: To avoid personal injury, the use of gloves may be necessary while handling
fan parts with sharp edges.
4.Make sure that all electrical connections comply with local codes, ordinances, the National
Electrical Code and ANSI/NFPA 70-199. Hire a qualified electrician or consult a do-it-yourself
wiring handbook, available at Lowe's, if you are unfamiliar with installing electrical wiring.
5.Make sure the installation site you choose allows a minimum clearance of 7 feet from the
blades to the floor and at least 30 in. from the end of the blades to any obstruction.
6. WARNING: To reduce the risk of fire, electrical shock, or personal injury, mount fan to
outlet box marked "ACCEPTABLE FOR FAN SUPPORT" and use mounting screws provided with
the outlet box. Most outlet boxes commonly used for the support of lighting fixtures are not
acceptable for fan support and may need to be replaced. Consult a qualified electrician if in
doubt. Secure the box directly to the building structure. The outlet box and its support must be
able to support the moving weight of the fan (at least 35 lbs.). Do NOT use a plastic outlet box.
7.After you install the fan, make sure that all connections are secure to prevent the fan from
falling.
8. WARNING: To reduce the risk of fire, electrical shock, or personal injury, wire connectors
provided with this fan are designed to accept only one 12 gauge house wire and two lead wires
from the fan. If your house wire is larger than 12 gauge or there is more than one house wire to
connect to the two fan lead wires, consult an electrician for the proper size
wire connectors to use.
9. WARNING: To reduce the risk of fire or electric shock, do not use the fan with
any solid state speed control device or control fan speed with a full range dimmer switch.
10. WARNING: To reduce the risk of fire, electric shock, or personal injury, do not bend
the blade arms when installing them, balancing the blades, or cleaning the fan. Do not insert
objects between the rotating fan blades.
11. WARNING: To reduce the risk of personal injury, use only parts provided with this
fan. The use of parts OTHER than those provided with this fan will void the warranty.
12.The net weight of this fan including the light kit is: 18,3 lbs. (8,3 kg).

4
PACKAGE CONTENTS
IMPORTANT REMINDER: You must
use the parts provided with this fan for
proper installation and safety.
AC
I
L
H
F
G
DE
B
J K
Part Description Quantity
A Motor Housing 1
B Mounting Bracket 1
C Extra Switch Housing 1
D Motor Assembly 1
E Light Kit Fitter 1
F Glass Shade 4
G
Blade Arm 5
H Blade 5
I
Candelabra Base Bulb 4
J Pull Chain Extension 2
(in hardware pack)
K Plastic Lock Tab 1
L Socket Ring 4
(attached to light kit fitter)

HARDWARE CONTENTS
Part Description Quantity Part Shown to Size
Motor Screw (10 in motor; 1 in hardware pack) 11
3/16 Blade Screw (in hardware pack) 16
5.4M/M Lock Washer (10 in motor; 11
1 in hardware pack)
Blade Washer (in hardware pack) 16
E3 Wire Connector (in hardware pack) 4
Motor Housing Mounting Screw
(attached to mounting bracket)
AA
5
BB
CC
DD
EE
1. Before beginning assembly, installation or operation of product, make sure all parts are
present. Compare parts with package contents list and diagram above. If any part is missing or
damaged, do not attempt to assemble, install or operate the product.
Estimated Assembly Time: 120 minutes
Tools Required for Assembly (not included):electrical tape, Phillips screwdriver, pliers, safety
glasses, stepladder, wire strippers.
Helpful Tools (not included):A/C tester light, tape measure, do-it-yourself wiring handbook
(available at Lowe’s), wire cutters.
PREPARATION
FF 4

PREPARATION
Bulbs Required (included):4 candelabra base 60 watt max. bulbs
DANGER: When using an existing outlet box, make sure the outlet box is securely attached
to the building structure and can support the full weight of the fan. Failure to do this can result in
serious injury or death. The stability of the outlet box is essential in minimizing wobble and noise
in the fan after installation is complete.
CAUTION: Be sure outlet box is properly grounded and that a ground (green or bare) wire is
present.
2. After opening top of carton, remove mounting hardware package from foam inserts. Remove
motor from packing and place on carpet or on foam to avoid damage to finish.
CAUTION: Carefully check all screws, bolts and nuts on fan motor assembly to ensure that
they are secured.
A-15
1. Turn off circuit breakers and wall switch to the fan supply
line leads. (Fig. 1)
DANGER: Failure to disconnect power supply prior to
installation may result in serious injury or death.
6
INITIAL INSTALLATION
2. Check to make sure blades (H) will be at least 30 in. from
any obstruction and at least 7 ft. above the floor. (Fig. 2)
7 ft.
min.
30 in.
min.
Fig. 1
Fig. 2 H
3. Secure mounting bracket (B) to outlet box
using screws, spring washers, and flat
washers provided with the outlet box. (Fig. 3)
Pull wires from outlet box through center hole
in mounting bracket (B).
*Note: It is very important that you use the
proper hardware when installing the mounting
bracket (B) as this will support the fan.
B
Fig. 3

7
B
INITIAL INSTALLATION
4. Remove motor screws (AA) and lock
washers (CC) from underside of motor--save
to attach blade arms (G) later on. If there are
also plastic motor blocks, discard them at
this time. (Fig. 4) Motor
DCC
AA
Fig. 4
CC
AA
Motor Screw x 10
Hardware Used
5.4 M/M Lock Washer x 10
D
K
Fig. 5
Fig. 6
5. Install ball end of motor assembly (D) into
mounting bracket (B) opening. Align slot in ball
with tab in mounting bracket (A). (Fig. 5)
DANGER: Failure to align slot in ball with
tab in mounting bracket (B) may result in serious
injury or death.
6. To ensure the safety of the installation and to
prevent the motor assembly (D) from becoming
or coming loose, use the plastic lock tab (K).
Slide plastic lock tab (K) under bracket tabs so
that it will snap into place. (Fig. 6)
IMPORTANT: Keep in mind that it will require
some force to fully insert the plastic lock tab
(K) so that it does not move or come out
once in the correct position.
Bracket
Tab
B
Tab
D
Ball
Slot

CAUTION: Be sure wiring box is properly grounded
and that a ground (green or bare) wire is present.
8
WIRING
Fig. 1C
1. Choose wiring diagram (Fig. 1A, Fig. 1B or Fig. 1C) that
fits your situation and make appropriate wiring connections
as follows: [NOTE: For each wire connection below, use
one of the wire connectors (EE) provided, making sure to
screw wire connector (EE) on in a clockwise direction.]
1A. FAN AND LIGHT CONTROLLED BY PULL
CHAINS: Connect BLACK and BLUE wire from fan to
BLACK wire from ceiling. Connect WHITE wire from fan
to WHITE wire from ceiling. Connect GROUND
(GREEN) wire together from mounting bracket to
BARE/GREEN wire from ceiling. (Fig. 1A)
1B. FAN CONTROLLED BY PULL CHAIN, LIGHT BY
WALL SWITCH: If you intend to control the fan light with
a separate wall switch, connect BLACK wire from fan to
BLACK wire from ceiling. Connect BLUE wire from fan
to the BLACK wire from the independent wall switch for
the light. Connect WHITE wire from fan to WHITE wire
from ceiling. Connect GROUND (GREEN) wire together
from mounting bracket to BARE/GREEN wire from
ceiling. (Fig. 1B)
1C. FAN AND LIGHT CONTROLLED BY TWO WALL
SWITCHES: If you intend to control the fan and light with
separate wall switches, connect BLACK wire from fan to
BLACK wire from the independent wall switch for the
fan. Connect BLUE wire from fan to the BLACK wire
from the other independent wall switch for the light.
Connect WHITE wire from fan to WHITE wire from
ceiling. Connect GROUND (GREEN) wire together from
mounting bracket to BARE/GREEN wire from ceiling.
(Fig. 1C)
Fig. 1A
WARNING: If house wires are different colors than
referred to in the following steps, stop immediately. A
professional electrician is recommended to determine wiring.
WARNING: To reduce the risk of fire, electrical
shock, or personal injury, wire connectors provided with
this fan are designed to accept only one 12 gauge house
wire and two lead wires from the fan. If your house wire is
larger than 12 gauge or there is more than one house wire
to connect to the two fan lead wires, consult an electrician
for the proper size wire connectors to use.
Note: Black wire is hot power for fan. Blue wire is hot
power for light kit. White wire is common for fan and light
kit. Green or bare wire is ground.
FAN AND LIGHT CONTROLLED BY PULL CHAINS
BLACK
WHITE
GROUND/GREEN (BARE)
WHITE
BLUE
WHITE
FROM FAN
120 V Power
FROM
CEILING
FAN CONTROLLED BY PULL CHAIN, LIGHT BY
WALL SWITCH
WHITE
BLACK
BLACK (WALL SWITCH)
GROUND/GREEN (BARE)
BLACK
BLUE
WHITE
FROM FAN
Fig. 1B
FAN
120 V Power
FROM
CEILING
WHITE
BLACK (WALL SWITCH)
BLACK (WALL SWITCH FOR LIGHT)
GROUND/GREEN (BARE)
BLACK
BLUE
WHITE
FROM FAN
FAN
120 V Power
FROM
CEILING
FAN AND LIGHT CONTROLLED BY TWO WALL
SWITCHES
GREEN
GREEN
GREEN
FAN
BLACK
WHITE
WHITE

9
1
2
3
IMPORTANT: Using a full range dimmer switch to
control fan speed will cause a loud humming noise
from fan. To reduce the risk of fire or electric shock,
do NOT use a full range dimmer switch to control fan
speed. (Fig. 3)
Dimmer
Switch Speed
Switch
WIRING
2. Wrap electrical tape around each wire connector
(EE) down to the wire as shown in Fig. 2.
WARNING: Make sure no bare wire or wire
strands are visible after making connections. Place
green and white connections on opposite side of box
from the black and blue (if applicable) connections.
Turn spliced/taped wires upward and gently push
wires and wire connectors (EE) into outlet box.
N
EE
EE
EE
EE
Hardware Used
E3 Wire Connector x 4
Fig. 2
Fig. 3
For illustrative purposes only--not
intended to cover all types of controls
FINAL INSTALLATION
A
Fig. 1
1. Temporarily raise motor housing (A) to mounting
bracket (B) to determine which two screws (FF) align
with slotted holes in motor housing (A) and partially
loosen these two screws (FF). Remove the other two
screws (FF). Now, lift motor housing (A) to mounting
bracket (B) again, aligning slotted holes in motor
housing (A) with loosened screws (FF) in mounting
bracket (B). Twist motor housing (A) to lock. Re-insert
screws (FF) that were previously removed. Tighten all
four screws (FF) securely. (Fig. 1)
FF
Motor Housing x 4
Mounting Screw
Hardware Used
B
FF

Switch
Housing
Plate
FINAL INSTALLATION
2. Partially insert three blade screws (BB), along with
three blade washers (DD), to attach one blade arm
(G) to a blade (H). Then, tighten each blade screw
(BB), starting with the one in the middle (Fig. 2)
Repeat with remaining blades (H).
G
DD
BB
H
Fig. 2
Fig. 3
Fig. 4
DD
BB
3/16 Blade Screw x 15
Blade Washer x 15
Hardware Used
3. Locate motor screws (AA) and lock washers (CC)
that were removed in Step 4 on page 7.
Insert one motor screw (AA), along with lock a
washer (CC), through one blade arm (G) to attach
blade arm (G) to motor. Partially tighten motor screw
(AA). Now, insert another motor screw (AA), along
with lock washer (CC), to secure blade arm (G).
Tighten both motor screws (AA) securely. (Fig. 3)
Note: For easy access to motor screws (AA), turn
motor so that the flat part of the switch housing plate
aligns with the two motor screw (AA) holes on blade
arm (G).
Repeat Step 3 with remaining blade arms (G),
making sure to completely secure each blade arm
(G) before proceeding with the next.
CC
AA
Motor Screw x 10
Hardware Used
5.4 M/M Lock Washer x 10
4. If you wish to USE the light kit, remove three
screws from switch housing plate on underside of
motor. Locate BLUE and WHITE wires in switch
housing plate labeled “FOR LIGHT” and remove
cardboard label and plastic from these two wires.
Connect WHITE wire from light kit fitter (E) to WHITE
wire from switch housing plate. Connect BLACK wire
from light kit fitter (E) to BLUE wire from switch
housing plate. Make sure that molex connections are
secure. (Fig. 4) Continue with Step 5.
If you do NOT wish to use the light kit, please go
to section entitled “Using Fan Without Light Kit” on
page 12.
A
E
Molex
Connections
A
GH
CC
AA
Switch
Housing
Plate
10

11
FINAL INSTALLATION
Switch
Housing
Plate
Pull Chain Slot
Fig. 5
A
E
6. Remove socket ring (L) from each socket. Use
one socket ring (L) to attach each glass shade
(F). (Fig. 6)
Note: Do not overtighten socket rings (L) as
glass may crack or break.
7. Install four candelabra base 60 watt max.
bulbs (I) included. (Fig. 7)
Important: When you need to replace bulbs,
please allow bulbs and glass shades (F) to cool
down before handling them.
5. Gently push wires and molex connections into switch
housing plate. Align fan pull chain slot with fan pull
chain and attach light kit fitter (B) to fan with screws that
were removed in the previous step. Use a Phillips
screwdriver to secure all three screws. (Fig. 5)
Fig. 6
F
F
L
Fig. 7
I
Fig. 7
I

12
FINAL INSTALLATION
Switch
Housing
Plate
1. If you do NOT wish to use the light kit, remove
three screws from switch housing plate. (Fig. 1)
Fig. 1
2. Align holes in extra switch housing (C) with holes
on outer edge of switch housing plate. (Note: The
wide gap in the top edge of the extra switch housing
(C) should align with the reverse switch on the switch
housing plate for the proper fit.) Re-insert screws that
were just removed. Use a Phillips screwdriver to
secure all screws. (Fig. 2)
Fig. 2
8. The pull chain extensions (J) supplied in one
of the hardware packs or custom pull chain
extensions (not included) may be attached to fan
and light pull chains. (Fig. 8)
C
USING FAN WITHOUT LIGHT KIT (OPTIONAL)
Switch
Housing
Plate
3. The pull chain extension (J) supplied in one of the
hardware packs or custom pull chain extension (not
included) may be attached to fan. (Fig. 3) J
Fig. 3
1. The pull chain on the switch housing plate has four
positions to control fan speed. One pull is HIGH, two is
MEDIUM, three is LOW and four turns the fan OFF.
(Fig. 1)
FAN OPERATION
Fig. 9
(For Fan)
(For Light)
J
J
Fig. 1

13
At least twice each year, lower motor housing (A) to check motor assembly (D), and then
tighten all screws on fan. Clean motor housing (A) with only a soft brush or lint-free cloth to
avoid scratching the finish. Clean blades (H) with a lint-free cloth. You may occasionally apply a
light coat of furniture polish to wood blades for added protection.
Important: Shut off main power supply before beginning any maintenance. Do not use water or
a damp cloth to clean the ceiling fan.
CARE AND MAINTENANCE
FAN OPERATION
3A. In warmer weather, setting the reverse switch
in the LEFT position will result in downward
airflow creating a wind chill effect. (Fig. 3A)
3B. In cooler weather, setting the reverse switch in
the RIGHT position will result in upward airflow
that can help move stagnant, hot air off the ceiling
area. (Fig. 3B)
IMPORTANT: Reverse switch must be set either
completely LEFT or completely RIGHT for fan to
function. If the reverse switch is set in the middle
position (Fig. 3C), fan will not operate.
Fig. 3A Fig. 3B
Fig. 3C
3. Use the fan reverse switch, located on the light kit
fitter (E), to optimize your fan for seasonal
performance. (Fig. 3) A ceiling fan will allow you to
raise your thermostat setting in summer and lower your
thermostat setting in winter without feeling a difference
in your comfort.
Note: Wait for fan to stop before moving the reverse
switch.
Reverse Switch
Fig. 3
2. The pull chain in the center is used to turn the lights
ON or OFF. (Fig. 2)
Fig. 2
E

Problem Possible Cause Corrective Action
Fan does not move. 1. Reverse switch not engaged. 1. Push switch firmly either left or
right.
2. Power is off or fuse is blown. 2. Turn power on or check fuse.
3. Faulty wire connection. 3. Turn power off. Loosen motor
housing (A) and check all
connections.
Noisy operation. 1. Blades (H) are loose. 1. Tighten all blade screws (BB).
2. Cracked blade (H). 2. Replace blade (H).
3. Full range dimmer switch. 3. Replace with an approved
speed control device.
4. Fan is new. 4. Allow fan a "break in" period of a
few days, especially when running
the fan at Medium and High
speeds.
5. Motor housing (A) is loose. 5. Turn power off. Carefully loosen
motor housing (A) and verify that
mounting bracket (B) is secure
according to instructions on page
9.
Excessive wobbling. 1. Blades (H) are loose. 1. Tighten all blade screws (BB).
2. Blade arms (G) incorrectly 2. Re-install blade arms (G).
attached.
3. Unbalanced blades (H). 3. Switch one blade (H) with a
blade (H) from the opposite side.
4. Fan not securely mounted. 4. Turn power off. Carefully loosen
motor housing (A) and verify that
mounting bracket (B) is secure.
Fan operates but lights 1. Bulb(s) not installed correctly. 1. Re-install bulb(s).
fail (if applicable). 2. Wires in outlet box not wired 2. Check wires in outlet box and, if
properly. necessary, re-wire according to
instructions on pages 8 and 9.
3. Wall switch to fan is off. 3. Make sure that wall switch to fan
is on.
4. Wires light kit fitter (E) not 4. Check wires in light kit fitter (E)
wired correctly. and, if necessary, re-wire
according to instructions on page
10.
Note: A small amount of "wobble" is normal and should not be considered a defect.
TROUBLESHOOTING
WARNING: Before beginning work, shut off the power supply to avoid electrical shock.
14

15
WARRANTY
LIMITED LIFETIME WARRANTY: Litex Industries warrants this fan to be free from defects in
workmanship and materials present at time of shipment from the factory for Lifetime limited from
the date of purchase. This warranty applies only to the original purchaser. Litex Industries
agrees to correct any defect at no charge or, at our option, replace the ceiling fan with a
comparable or superior model.
To obtain warranty service, present a copy of your sales receipt as proof of purchase. All cost of
removal and reinstallation are the express responsibility of the purchaser. Any damage to the
ceiling fan by accident, misuse or improper installation, or by using parts not produced by the
manufacturer of this fan or affixing accessories not produced by the manufacturer of this fan, are
the purchaser's own responsibility. Litex Industries assumes no responsibility whatsoever for fan
installation during the limited lifetime warranty. Any service performed by an unauthorized
person will render the warranty invalid.
Due to varying climatic conditions, this warranty does not cover changes in brass finish, rusting,
pitting, tarnishing, corroding or peeling. Brass finish fans maintain their beauty when protected
from varying weather conditions. Any glass provided with this fan is not covered by the
warranty.
Any replacement of defective parts for the ceiling fan must be reported within the first year from
the date of purchase. For the balance of the warranty, call our customer service department (at
1-800-527-1292)for return authorization and shipping instructions so that we may repair or
replace the ceiling fan. Any fan or parts returned improperly packaged is/are the sole
responsibility of the purchaser. There is no further express warranty. Litex Industries disclaims
any and all implied warranties. The duration of any implied warranty which cannot be disclaimed
is limited to the limited lifetime period as specified in our warranty. Litex Industries shall not be
liable for incidental, consequential or special damages arising at or in connection with product
use or performance except as may otherwise be accorded by law. This warranty gives you
specific legal rights and you may also have other rights which vary from state to state. This
warranty supersedes all prior warranties.

16 Printed in China
REPLACEMENT PARTS LIST
For replacement parts, call our customer service department at 1-800-527-1292, 8:30 a.m.-5:00 p.m.,
CST, Monday-Friday. When ordering parts, please have the Model # or Item # of the fan available,
which can be found on page 1.
AC
H
FG
E
B
J
Part Description
A Motor Housing
B
Mounting Bracket
C Extra Switch Housing
E
Light Kit Fitter
F
Glass Shade
G Blade Arm
H Blade
J
Pull Chain Extension
K Plastic Lock Tab
L Socket Ring
K L

ARTICULO #18037
18038
MODELO #CSD52FBZ5C4S
CSD52BNK5C4S
E124404
17
Harbor Breeze® es marca registrada de
LF, LLC. Reservados todos los derechos.
VENTILADOR DE TECHO CHESHIRE II
¿Preguntas, problemas, faltan piezas? Antes de regresar a la tienda, llame o póngase en
contacto con nuestro departamento de servicio al cliente al 1-800-527-1292, de 8:30 a.m. a
5:00 p.m., hora central, de lunes a viernes.

18
INDICE DE MATERIAS
Información de seguridad ......……………………………………………............................19
Contenido del paquete ...................……………………………………………………….....20
Contenido de artículos de ferretería ...................………………………………....................21
Preparación ...............................................................................................................21 - 22
Instalación inicial ............................................…………………………………….........22 - 23
Conexión de los cables .........................................…………………………………….24 - 25
Instalación final ............……………….…………….…….………………….…...............26 - 28
Uso del ventilador sin el juego de luz (opcional) .........................................................................28
Funcionamiento del ventilador ............…..................................................................28 - 29
Cuidado y mantenimiento ........................…....……………………………………………....29
Localización de fallas .........................................…….......…………………………............30
Garantía ........................…………………………………….………………………..........…....32
Lista de piezas de repuestos …........................................................................................33

19
INFORMACION DE SEGURIDAD
POR FAVOR LEA Y GUARDE ESTAS INSTRUCCIONES
Por favor lea el instructivo entero antes de tratar de ensamblar, instalar o hacer funcionar el
producto. Si tiene alguna pregunta acerca del producto, por favor llame al servicio al cliente al
1-800-527-1292, de 8:30 a.m. a 5:00 p.m., hora central, de lunes a viernes.
1. Antes de empezar a instalar el ventilador, desconecte la electricidad, quitando los fusibles o
cortando el suministro de energía de los circuitos.
2. PRECAUCION: Lea todas las instrucciones y la información de seguridad antes de
instalar su ventilador nuevo. Revise los diagramas de ensamblaje acompañantes.
3. ADVERTENCIA: Para reducir el riesgo de daño corporal, es posible que sea necesario
usar guantes al manejar las piezas del ventilador que tengan bordes afilados.
4. Asegúrese de que todas las conexiones eléctricas cumplen con los códigos y las ordenanzas
locales, con el Código Nacional Eléctrico (NEC, por sus siglas en inglés), y ANSI/NFPA 70-199.
Contrate un electricista calificado o consulte una guía de instalación eléctrica de hágalo usted
mismo, disponible en Lowe's, si no está familiarizado con la instalación eléctrica.
5. Asegúrese de que el lugar de instalación que usted escogió tiene un mínimo de 2,13 m de
desde las paletas hasta el piso y que la punta de las paletas quede a por lo menos 76,2 cm de
cualquier obstrucción.
6. ADVERTENCIA: Para reducir el riesgo de incendio, choque eléctrico o daño corporal,
sujete el ventilador a una caja de salida marcada "Aceptable para sostener ventilador"
("ACCEPTABLE FOR FAN SUPPORT" en inglés) y use los tornillos de montaje proporcionados
con la caja de salida. La mayoría de las cajas de salida que se usan comúnmente para sostener
aparatos de alumbrado no son aceptables para sostener ventiladores y es posible que sea
necesario reemplazarla. Consulte con un electricista calificado si tiene alguna duda. Asegure la
caja de salida directamente a la estructura del edificio. La caja de salida y el soporte deben ser
capaces de sostener el peso móvil del ventilador (por lo menos 15,88 kg). NO use una caja de
salida plástica.
7. Después de instalar el ventilador, verifique que todas las conexiones estén seguras para que
no se caiga el ventilador.
8. ADVERTENCIA: Para reducir el riesgo de incendio, choque eléctrico o daño corporal,
los conectores para cable provistos con este ventilador son diseñados para aceptar sólo un
cable de calibre 12 de la casa y dos cables principales del ventilador. Si el calibre del cable de la
casa es superior al 12 o hay más de un cable de la casa para conectar a los cables principales
del ventilador, consulte con un electricista para informarse sobre el tamaño correcto de
conectores para cable que se debe usar.
9. ADVERTENCIA: Para reducir el riesgo de incendio o un choque eléctrico, no
use el ventilador con ningún control de velocidad de estado sólido ni controle la velocidad del
ventilador con un interruptor con reductor de luz de gama completa.
10. ADVERTENCIA: Para reducir el riesgo de incendio, choque eléctrico o lesión personal,
no doble los brazos de las paletas mientras las esté instalando, ni cuando esté balanceando las
paletas ni cuando esté limpiando el ventilador. No inserte objetos entre las paletas giratorias del
ventilador.
11. ADVERTENCIA: Para reducir el riesgo de lesión personal, use sólo las piezas provistas
con este ventilador. Al usar piezas DISTINTAS a las provistas con este ventilador se
invalidará la garantía.
12.El peso neto del ventilador con el juego de luz es de: 8,3 kg.

20
AC
I
L
H
F
G
DE
B
J K
Pieza Descripción Cantidad
A Bastidor del motor 1
B Soporte de montaje 1
C Cubierta de la caja del interruptor 1
adicional (para uso sin el juego de luz)
D Unidad del motor 1
E Conectador para el juego de luz 1
F Pantalla de vidrio 4
G
Brazo para la paleta 5
H Paleta 5
I Bombilla de base candelabro 4
J Extensión para la cadena de en- 2
cendido (en paquete de artículos de ferretería)
K Seguro de plástico 1
L Anillo de portalampara (sujetado 4
al conectador para el juego de luz)
RECORDATORIO IMPORTANTE: Se tienen
que utilizar las piezas provistas con este ventilador
para una instalación adecuada y su seguridad.
CONTENIDO DEL PAQUETE
