Harbor Breeze WO52BB5C User manual

ITEM #0373645
E124404
WOLCOTT CEILING FAN
MODEL #WO52BB5C
Questions, problems, missing parts? Before returning to your retailer, call or contact our
customer service department at 1-800-527-1292, 8:30 a.m. - 5:00 p.m., CST, Monday - Friday.
Harbor Breeze® is a registered trademark of
LF, LLC. All Rights Reserved. Español p. 19
ATTACH YOUR RECEIPT HERE
Serial Number Purchase Date
1

2
TABLE OF CONTENTS
Safety Information .....................................………………………………………………...… ….. 2 - 3
Package Contents .....……………………………………………………………..….
…. ......... ... 4
Hardware Contents ...................................................................................................................
... 5
Preparation ...............….…………………..……………………….…………….………………....5
Initial Installation ............….……………..……………………….……….
…..…. ..........................6 - 7
Wiring ...............….…………………..……………………….…………….……………...........7 - 9
Final Installation .....……………………………………………………………..….
…. ..... . 10 - 13
Lighted Housing Bulb Replacement ...........................................................................................14
Operation Instructions ............................................................……………………
…… …. ........ 14 - 15
Care and Maintenance …
….… …………………………………………………..…....... ..... .. .... 15
Troubleshooting .............………...………………………….……………..………....
…........... .16
Warranty ……………………………….…………………………………………..…
…. ......... ..... 17
Replacement Parts List ...........................................................................................
......... ...... . ........ 18
SAFETY INFORMATION
READ AND SAVE THESE INSTRUCTIONS
Please read and understand this entire manual before attempting to assemble, install or operate the
product. If you have any questions regarding the product, please call customer service at
1-800-527-1292, 8:30 a.m. - 5:00 p.m., CST, Monday - Friday.
• Do not discard fan carton or foam inserts. Should this fan need to be returned to the factory for
repairs, it must be shipped in its original packaging to ensure proper protection against damage that
might exceed the initial cause for return.
• Make sure that all electrical connections comply with local codes, ordinances, the National Electrical
Code and ANSI/NFPA 70-1999. Hire a qualified electrician or consult a do-it-yourself wiring handbook,
available at Lowe's, if you are unfamiliar with installing electrical wiring.
• Make sure the installation site you choose allows a minimum clearance of 7 feet from the blades to
the floor and at least 30 in. from the end of the blades to any obstruction.
• After you install the fan, make sure that all connections are secure to prevent the fan from falling.
• The net weight of this fan including the light kit is: 20.5 lbs. (9.3 kg).

3
To reduce the risk of fire, electrical shock, or personal injury, mount fan to outlet box
marked "ACCEPTABLE FOR FAN SUPPORT OF 35 LBS (15.9 KG) OR LESS" and use
mounting screws provided with the outlet box. Most outlet boxes commonly used for the
support of lighting fixtures are not acceptable for fan support and may need to be replaced.
Consult a qualified electrician if in doubt.
When mounting fan to a ceiling outlet box, use a METAL octagonal outlet box. Secure the outlet
box directly to the building structure. The outlet box and its support must be able to support the
moving weight of the fan (at least 35 lbs.). Do NOT use a plastic outlet box.
To avoid personal injury, the use of gloves may be necessary while handling fan parts with
sharp edges.
To reduce the risk of fire, electrical shock, or personal injury, wire connectors provided with this
fan are designed to accept only one 12 gauge house wire and two lead wires from the fan. If your
house wire is larger than 12 gauge or there is more than one house wire to connect to the two fan
lead wires, consult an electrician for the proper size wire connectors to use.
To reduce the risk of fire or electrical shock, do not use the fan with any solid state speed
control device or control fan speed with a full range dimmer switch.
To reduce the risk of fire, electrical shock, or personal injury, do not bend the blade arms when
installing them, balancing the blades, or cleaning the fan. Do not insert objects between the
rotating fan blades.
To reduce the risk of personal injury, use only parts provided with this fan. The use of parts
OTHER than those provided with this fan will void the warranty.
WARNINGS
CAUTIONS
Before proceeding, be sure to shut off electricity at main switch or circuit breaker in order to avoid
electrical shock.
Read all instructions and safety information before installing your new fan. Review the
accompanying assembly diagrams.
SAFETY INFORMATION

PACKAGE CONTENTS
IMPORTANT REMINDER: You must use the parts
provided with this fan for proper installation and safety.
PART DESCRIPTION QUANTITY
A Mounting Plate 1
B
Motor Assembly 1
C
Candelabra-base 7-watt 4
Bulb
D
Blade Arm 5
E
Blade 5
F Light Kit Fitter 1
G
Glass Shade 4
H Candelabra-base 60-watt 4
Bulb
I Pull Chain Extension 2
J Motor Screw 10
(preassembled) + 1 extra
K
Lock Washer 10
(preassembled) + 1 extra
L Motor Housing
1
M Switch Housing Screw
3
(preassembled)
4
A
E
F
C
H
I
G
J
K
BL
D
M

HARDWARE CONTENTS (shown actual size)
Fiber
Blade
Washer
Qty. 15
+ 1 extra
BB CC
AA
Blade
Screw
Qty. 15
+ 1 extra
E3 Wire
Connector
Qty. 4
Before beginning assembly and installation of product, make sure all parts are present. Compare
parts with package contents list and hardware contents above. If any part is missing or
damaged, do not attempt to assemble, the product. Contact customer service for replacement parts.
Estimated Assembly Time: 120 minutes
Tools Required for Assembly (not included): Electrical Tape, Phillips Screwdriver, Pliers, Safety
Glasses, Stepladder and Wire Strippers
Helpful Tools (not included): AC Tester Light, Tape Measure, Do-It-Yourself Wiring Handbook
(available at Lowe’s) and Wire Cutters
Bulbs Required (included): 4 candelabra-base 7-watt max. bulbs--for lighted housing
4 candelabra-base 60-watt max. bulbs--for light kit
DANGER: When using an existing outlet box, make sure the outlet box is securely attached to
the building structure and can support the full weight of the fan. Failure to do this can result in serious
injury or death. The stability of the outlet box is essential in minimizing wobble and noise in the fan
after installation is complete.
CAUTION: Be sure outlet box is properly grounded and that a ground wire (green or bare) is
present.
After opening top of carton, remove mounting hardware package from foam inserts. Remove motor
from packing and place on carpet or on foam to avoid damage to finish.
CAUTION: Carefully check all screws, bolts and nuts on fan motor assembly to ensure that they
are secured.
PREPARATION
5
DD
Thumb
Screw
Qty. 12
+ 1 extra
EE
Mounting
Plate
Nut
Qty. 4
FF
Motor
Housing
Mounting
Screw
Qty. 4
GG
Bushing
Qty. 4

INITIAL INSTALLATION
Check to make sure blades (E) are at least 30 in.
from any obstruction and at least 7 ft. above the
floor. (Fig. 2)
1
ON
OFF
ON
OFF
Turn off circuit breakers and wall switch to the fan
supply line leads. (Fig. 1)
DANGER: Failure to disconnect power
supply prior to installation may result in serious
injury or death.
1.
2.
6
7 ft.
min.
30 in.
min.
2
E
3. Before proceeding, make sure that motor
assembly (B) and mounting plate (A) do not
remain connected to one another after they have
been removed from the box. If necessary,
disengage motor assembly (B) from “J” hook on
mounting plate (A) so that motor assembly (B) can
be separated from mounting plate (A). (Fig. 3)
3
4. Secure mounting plate (A) to outlet box using
screws, spring washers, and flat washers
provided with the outlet box. (Fig. 4) Pull wires
from outlet box through center hole in mounting
plate (A).
*Note: It is very important that you use the proper
hardware when installing the mounting plate (A)
as this will support the fan.
CAUTION: Be sure outlet box is properly
grounded or that a ground (green or bare) wire is
present.
A
4
A
B
"J" Hook

7
A
"J" Hook
Bar
B
INITIAL INSTALLATION
6
Locate holes that are reinforced with black rubber
in bar at top of motor assembly (B). Insert one
bushing (GG) into each of these holes. (Fig. 6)
Now, using the SLOTTED hole in the bar at the top
of the motor assembly (B), slide the bar over the "J"
hook on the mounting plate (A)--this will support the
fan during wiring. (Fig. 6)
WARNING: To reduce the risk of personal
injury, do not use any of the other holes in the bar
at the top of the motor assembly (B) to hang the
motor assembly (B) on the mounting plate (A).
6.
Caution: Be sure wiring box is properly
grounded and that a ground (green or bare) wire is
present.
WIRING
Warning: If house wires are different colors than
referred to in the following steps, stop immediately. A
professional electrician is recommended to determine
wiring.
WARNING: To reduce the risk of fire, electrical
shock, or personal injury, wire connectors provided
with this fan are designed to accept only one 12
gauge house wire and two lead wires from the fan. If
your house wire is larger than 12 gauge or there is
more than one house wire to connect to the two fan
lead wires, consult an electrician for the proper size
wire connectors to use.
5. Remove motor screws (J) and lock washers (K)
from underside of motor and save for blade arm
(D) attachment later on. (Fig. 5) 5
K
J
Bushing x4
Hardware Used
GG
GG
GG

8
WIRING
Choose wiring diagram (Fig. 1A, Fig. 1B or Fig. 1C)
that fits your situation and make appropriate wiring
connections as follows: [NOTE: For each wire
connection below, use one of the wire connectors
(CC) provided, making sure to screw wire connector
(CC) on in a clockwise direction.]
1A. FAN AND LIGHT CONTROLLED BY PULL
CHAINS: Connect BLACK and BLUE wire from fan
to BLACK wire from ceiling. Connect WHITE wire
from fan to WHITE wire from ceiling. Connect all
GROUND (GREEN) wires together from fan (on
motor assembly (B) and mounting plate (A)) to
BARE/GREEN wire from ceiling. (Fig. 1A)
1B. FAN CONTROLLED BY PULL CHAIN, LIGHT
BY WALL SWITCH: If you intend to control the fan
light with a separate wall switch, connect BLACK
wire from fan to BLACK wire from ceiling. Connect
BLUE wire from fan to the BLACK wire from the
independent wall switch for the light. Connect
WHITE wire from fan to WHITE wire from ceiling.
Connect all GROUND (GREEN) wires together from
fan (on motor assembly (B) and mounting plate (A))
to BARE/GREEN wire from ceiling. (Fig. 1B)
1C. FAN AND LIGHT CONTROLLED BY TWO
WALL SWITCHES: If you intend to control the fan
and light with separate wall switches, connect
BLACK wire from fan to BLACK wire from the
independent wall switch for the fan. Connect BLUE
wire from fan to the BLACK wire from the other
independent wall switch for the light. Connect
WHITE wire from fan to WHITE wire from ceiling.
Connect all GROUND (GREEN) wires together from
fan (on motor assembly (B) and mounting plate (A))
to BARE/GREEN wire from ceiling. (Fig. 1C)
Note: Black wire is hot power for fan. Blue wire is
hot power for light kit. White wire is common for fan
and light kit. Green or bare wire is ground.
1.
FAN AND LIGHT CONTROLLED BY PULL CHAINS
BLACK
WHITE
GROUND/GREEN (BARE)
WHITE
BLUE
WHITE
FROM FAN
120 V Power
FROM
CEILING
FAN CONTROLLED BY PULL CHAIN, LIGHT BY
WALL SWITCH
WHITE
BLACK
BLACK (WALL SWITCH)
GROUND/GREEN (BARE)
BLACK
BLUE
WHITE
FROM FAN
FAN
120 V Power
FROM
CEILING
WHITE
BLACK (WALL SWITCH)
BLACK (WALL SWITCH FOR LIGHT)
GROUND/GREEN (BARE)
BLACK
BLUE
WHITE
FROM FAN
FAN
120 V Power
FROM
CEILING
FAN AND LIGHT CONTROLLED BY TWO WALL
SWITCHES
FAN
GREEN
GREEN
BLACK
GREEN
WHITE
WHITE
1A
1B
1C
GREEN
GREEN
GREEN

9
WIRING
Wrap electrical tape (not included) around each
individual wire connector (CC) down to the wire as
shown in Fig. 3.
WARNING: Make sure no bare wire or wire
strands are visible after making connections. Place
green and white connections on opposite side of box
from the black and blue (if applicable) connections.
Turn spliced/taped wires upward and gently push
wires and wire connectors (CC) into outlet box.
E3 Wire Connector x4
3.
Hardware Used
3
CC
CC
CC CC
CC
Locate the two WHITE wires labeled "INTERIOR
LIGHT" in the mounting plate (A) and the two molex
connections (one RED wire, one WHITE wire) at the
top of the motor assembly (B) and connect these
wires. (Fig. 2) Make sure that molex connections are
secure.
2. 2
B
A
IMPORTANT: Using a full range dimmer switch to
control fan speed will cause a loud humming noise
from fan. To reduce the risk of fire or electrical shock,
do NOT use a full range dimmer switch to control fan
speed. (Fig. 4)
*PLEASE NOTE: Must have third wire in wall to use
wall control (speed switch) such as the one shown at
right.
4
1
2
3
Dimmer
Switch Speed
Switch
For illustrative purposes only--not
intended to cover all types of controls
4.

10
FINAL INSTALLATION
Install the four 7-watt candelabra base bulbs (C)
provided into the sockets on the mounting plate (A).
(Fig. 2)
2.
1. A
B
1
Locate mounting plate nuts (EE) in one of the
hardware packs.
Remove motor assembly (B) from "J" hook. Align
holes in the bar at the top of the motor assembly (B)
with bolts on underside of mounting plate (A) and
push up until bolts come all the way through the
holes. Secure motor assembly (B) with mounting
plate nuts (EE). (Fig. 1) Make sure to tighten all
mounting plate nuts (EE) completely.
Socket
CC
EE
EE
2
BC
ASocket
Mounting Plate Nut x4
Hardware Used
EE
It is advisable to check that the wiring has been
done correctly before proceeding. Connect the
male plug from the switch housing to the female
plug from the light kit fitter (F). Make sure that the
plugs connect tightly. (Fig. 3)
Turn power on and then pull the chain on the light
kit fitter (F). The lights on the mounting plate (A)
should light up. Turn power back off and
disconnect male and female plugs. If mounting
plate (A) lights came on, please continue with
Step 4 on the following page; if mounting plate (A)
lights did not come on, repeat instructions in
“WIRING” section.
3. 3
Switch
Housing
Male Plug
Female Plug
F
A

Locate four motor housing mounting screws (FF) in
hardware pack. Temporarily lift motor housing (L)
to mounting plate (A) to determine which of the
four holes in motor housing (L) align with the two
slotted holes in mounting plate (A). Lower motor
housing (L) and partially insert one motor housing
mounting screw (FF) in each hole in motor housing
(L) that aligned with one of the slotted holes. Slide
motor housing (L) over mounting plate (A), aligning
loosened motor housing mounting screws (FF) in
motor housing (L) with slotted holes in mounting
plate (A). Twist motor housing (L) to lock. Insert the
other two motor housing mounting screws (FF) and
tighten all four motor housing mounting screws
(FF) securely. (Fig. 4)
CAUTION: Do NOT use power tools to
avoid breakage or cracking of the motor housing
(L). Use a HAND screwdriver to tighten screws
instead.
FINAL INSTALLATION
11
4. 4
L
B
FF
FF
B
AA Blade Screw x15
Fiber Blade Washer x15
BB
Hardware Used
5. Before proceeding, make sure electricity has
been SHUT OFF.
Partially insert three blade screws (AA), along with
three fiber blade washers (BB), to attach one blade
arm (D) to a blade (E). Then, tighten each blade
screw (AA), starting with the one in the middle.
(Fig. 5) Repeat with remaining blades (E). E
5
D
AA BB
Motor Housing Mounting x4
Screw
Hardware Used
FF

12
FINAL INSTALLATION
Re-connect male plug from switch housing to
female plug from light kit fitter (F). Make sure that
the plugs connect tightly. (Fig. 8)
Align holes in switch housing with holes in light kit
fitter (F)--the opening in the top edge of the light kit
fitter (F) should align with the reverse switch for a
secure fit. Attach light kit fitter (F) with the three
switch housing screws (M) that were removed in
the previous step. (Fig. 8)
8.
Switch
Housing
Reverse
Switch
Male Plug
Female Plug
8
F
M
Remove three switch housing screws (M) from light
kit fitter (F) and set aside. Then, locate thumb
screws (DD) provided in one of the hardware
packs. Partially insert thumb screws (DD) into
holes in socket covers on light kit fitter (F). (Fig. 7)
7.
Socket
Cover
F
7
DD
DD
DD
M
M
Thumb Screw x12
Hardware Used
DD
Locate motor screws (J) and lock washers (K) that
were removed in Step 5 on page 7.
Insert two motor screws (J), along with lock
washers (K), through one blade arm (D) to attach
blade arm (D) to motor. Tighten motor screws (J)
securely. (Fig. 6) Repeat with remaining blade
arms (D), making sure to completely secure each
blade arm (D) before proceeding with the next.
6.
K
JD
6L
Motor

FINAL INSTALLATION
Install glass shades (G) by tightening thumb
screws (DD) that were installed in Step 7 on the
previous page. (Fig. 9)
CAUTION: Do NOT use power tools to tighten
thumb screws in order to avoid breakage of glass.
Tighten thumb screws (DD) HAND-tight ONLY.
Note: Do not overtighten thumb screws (DD) as
glass may crack or break.
9.
13
9
G
DD DD
L
Hardware Used
The pull chain extensions (I) supplied in one of the
hardware packs or custom pull chains extensions
(sold separately) may be attached to fan and light
pull chains. (Fig. 11)
11.
I
11
Install four candelabra-base 60-watt max. bulbs (H)
included. (Fig. 10)
IMPORTANT: When you need to replace bulbs,
please allow the bulbs and glass shades to cool
down before touching them.
10. 10
G
H
L
Thumb Screw x12
DD

14
Locate four access covers in the bottom of the
motor housing (L). Determine which access cover(s)
will need to be removed to access burned out
bulb(s) (C). Remove two screws from each access
cover that will need to be removed. Remove each
burned out bulb (C) and replace with a
candelabra-base 7-watt max. bulb. (Fig. 1)
LIGHTED HOUSING BULB REPLACEMENT
CAUTION: Allow motor housing (L) and bulbs
(C) to cool before trying to access bulbs (C) in
lighted housing.
Replace access cover(s) with screws that were
removed.
1
Access
Cover
C
1. L
The pull chain located on the switch housing has
four positions to control fan speed. One pull is
HIGH, two is MEDIUM, three is LOW and four
turns the fan OFF. (Fig. 1)
1.
OPERATION INSTRUCTIONS
The pull chain located in the center has four
positions to control the lights. One pull turns the
LOWER lights (light kit) on, two pulls turns the
UPPER lights (lighted housing) on, three pulls turns
ALL of the lights on, and four pulls turns ALL of the
lights OFF. (Fig. 2)
2.
Switch
Housing
1
2

15
OPERATION INSTRUCTIONS
3. Use the fan reverse switch, located on the switch
housing, to optimize your fan for seasonal
performance. (Fig. 3) A ceiling fan will allow you to
raise your thermostat setting in summer and lower
your thermostat setting in winter without feeling a
difference in your comfort.
Note: Wait for fan to stop before moving the
reverse switch.
3A 3B
3
Switch
Housing
3A. In warmer weather, setting the reverse
switch in the DOWN position will result in
downward airflow creating a wind chill effect.
(Fig. 3A)
3B. In cooler weather, setting the reverse switch
in the UP position will result in upward airflow
that can help move stagnant, hot air off the
ceiling area. (Fig. 3B)
At least twice each year, tighten all screws on fan. Clean motor housing unit (B) with only a soft brush
or lint-free cloth to avoid scratching the finish. Clean blades (E) with a lint-free cloth. You may
occasionally apply a light coat of furniture polish to wood blades for added protection.
IMPORTANT: Shut off main power supply before beginning any maintenance. Do not use water or a
damp cloth to clean the ceiling fan.
CARE AND MAINTENANCE
3C
3C. IMPORTANT: Reverse switch must be set
either completely UP or completely DOWN
for fan to function. If the reverse switch is set
in the middle position (Fig. 3C), fan will not
operate.

If you have any questions regarding the product please call customer service at 1-800-527-1292, 8:30
a.m. - 5 p.m., CST, Monday - Friday.
WARNING: Before beginning work, shut off the power supply to avoid electrical shock.
Fan does not operate. 1. Reverse switch not engaged. 1. Push switch firmly either up or
down.
2. Power is off or fuse is blown. 2. Turn power on or check fuse.
3. Male and female plugs not 3. Check that male and female
connected properly. plugs are connected properly
according to instructions on page
12.
Noisy operation. 1. Blades (E) are loose. 1. Tighten all blade screws (AA).
2. Cracked blade (E). 2. Replace blade (E).
3. Full range dimmer switch. 3. Replace with an approved speed
control device.
4. Fan is new. 4. Allow fan a "break in" period of a
few days, especially when running
the fan at Medium and High
speeds.
5. Motor housing (L) is loose. 5. Turn power off. Carefully loosen
motor housing (L) and verify that
mounting plate (A) is secure
according to instructions on
page 6.
Excessive wobbling. 1. Blades (E) are loose. 1. Tighten all blade screws (AA).
2. Blade arms (D) incorrectly 2. Re-install blade arms (D).
attached.
3. Unbalanced blades (E). 3. Switch one blade (E) with blade
(E) from opposite side.
4. Fan not securely mounted. 4. Turn off power. Carefully loosen
motor housing (L) and verify that
mounting plate nuts (EE) are
secure.
Fan operates but lights 1. Bulb(s) not installed correctly. 1. Re-install bulb(s).
fail. 2. Wires in outlet box not wired 2. Check wires in outlet box and, if
properly. necessary, re-wire according to
"Wiring" instructions on pages 8
and 9.
3. Wall switch to fan is off. 3. Make sure that wall switch to fan
is on.
4. Plugs not connected properly. 4. Check that plugs are connected
properly according to instructions
on page(s) 9 and/or 12.
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
16
Note: A small amount of "wobble" is normal and should not be considered a defect.

17
WARRANTY
LIMITED LIFETIME WARRANTY: Litex Industries warrants this fan to be free from defects in
workmanship and materials present at time of shipment from the factory for Lifetime limited from the
date of purchase. This warranty applies only to the original purchaser. Litex Industries agrees to
correct any defect at no charge or, at our option, replace the ceiling fan with a comparable or superior
model.
To obtain warranty service, present a copy of your sales receipt as proof of purchase. All cost of
removal and reinstallation are the express responsibility of the purchaser. Any damage to the ceiling
fan by accident, misuse or improper installation, or by using parts not produced by the manufacturer
of this fan or affixing accessories not produced by the manufacturer of this fan, are the purchaser's
own responsibility. Litex Industries assumes no responsibility whatsoever for fan installation during
the limited lifetime warranty. Any service performed by an unauthorized person will render the
warranty invalid.
Due to varying climatic conditions, this warranty does not cover changes in brass finish, rusting,
pitting, tarnishing, corroding or peeling. Brass finish fans maintain their beauty when protected from
varying weather conditions. Any glass provided with this fan is not covered by the warranty.
Any replacement of defective parts for the ceiling fan must be reported within the first year from the
date of purchase. For the balance of the warranty, call our customer service department (at
1-800-527-1292)for return authorization and shipping instructions so that we may repair or replace
the ceiling fan. Any fan or parts returned improperly packaged is/are the sole responsibility of the
purchaser. There is no further express warranty. Litex Industries disclaims any and all implied
warranties. The duration of any implied warranty which cannot be disclaimed is limited to the limited
lifetime period as specified in our warranty. Litex Industries shall not be liable for incidental,
consequential or special damages arising at or in connection with product use or performance except
as may otherwise be accorded by law. This warranty gives you specific legal rights and you may also
have other rights which vary from state to state. This warranty supersedes all prior warranties.

Printed in China
PART DESCRIPTION
A Mounting Plate
D
Blade Arm
E
Blade
F Light Kit Fitter
G
Glass Shade
I
Pull Chain Extension
J
Motor Screw
K
Lock Washer
L
Motor Housing
M Switch Housing Screw
AA Blade Screw
BB
Fiber Blade Washer
CC E3 Wire Connector
DD
Thumb Screw
EE
Mounting Plate Nut
FF
Motor Housing Mounting
Screw
GG
Bushing
REPLACEMENT PARTS LIST
For replacement parts, call our customer service department at 1-800-527-1292, 8:30 a.m. - 5:00
p.m., CST, Monday - Friday. When ordering parts, please have the Model # or Item # of the fan
available, which can be found on page 1.
A
E
G
K
JL
M
D
BB
FF
18
F
AA
GG
CC
DD EE
I

ARTICULO#0373645
E124404
VENTILADOR DE TECHO WOLCOTT
MODELO #WO52BB5C
19
Harbor Breeze® es marca registrada de
LF, LLC. Reservados todos los derechos.
¿Preguntas, problemas, faltan piezas? Antes de regresar a la tienda, llame o póngase en
contacto con nuestro departamento de servicio al cliente al 1-800-527-1292, de 8:30 a.m. a
5:00 p.m., hora central, de lunes a viernes.
ADJUNTE SU RECIBO AQUI
Número de serie Fecha de compra

20
POR FAVOR LEA Y GUARDE ESTAS INSTRUCCIONES
Por favor lea el instructivo entero antes de tratar de ensamblar, instalar o hacer funcionar el producto.
Si tiene alguna pregunta acerca del producto, por favor llame al servicio al cliente al 1-800-527-1292,
de 8:30 a.m. a 5:00 p.m., hora central, de lunes a viernes.
• No deseche la caja del ventilador ni la goma espuma incluida. Si hay que mandar el ventilador a la
fábrica por alguna reparación, se debe enviar en su paquete original para asegurar la protección
apropiada contra daños que podrían exceder la causa inicial por la cual se devolvió.
• Asegúrese de que todas las conexiones eléctricas cumplen con los códigos y las ordenanzas
locales, con el Código Nacional Eléctrico (NEC, por sus siglas en inglés), y ANSI/NFPA 70-1999.
Contrate un electricista calificado o consulte una guía de instalación eléctrica de hágalo usted mismo,
disponible en Lowe's, si no está familiarizado con la instalación eléctrica.
• Asegúrese de que el lugar de instalación que usted escogió tiene un mínimo de 2,13 m de desde las
paletas hasta el piso y que la punta de las paletas quede a por lo menos 76,2 cm de cualquier
obstrucción.
• Después de instalar el ventilador, verifique que todas las conexiones estén seguras para que no se
caiga el ventilador.
• El peso neto del ventilador con el juego de luz es de: 9,3 kg.
INDICE DE MATERIAS
Información de seguridad ......…………………………………………
….. ..................20 - 21
Contenido del paquete ...................……………………………………………………….....22
Contenido de artículos de ferretería ...................………………………………....................23
Preparación .............................................….…………………..……………….................23
Instalación inicial ............................................…………………………………….........24 - 25
Conexión de los cables .........................................…………………………………….25 - 27
Instalación final ............……………….…………….…….………………….…...............28 - 31
El reponer las bombillas del bastidor iluminado ..........................................................................32
Instrucciones de funcionamiento ..............................................................................32 - 33
Cuidado y mantenimiento ........................…....……………………………………………....33
Localización de fallas .........................................…….......…………
……… . ................. .. 34 - 35
Garantía ........................……………………………
……….…………… .... … … …... ...... .… .. ...... 35
Lista de piezas de repuestos ....................................................................................................36
INFORMACION DE SEGURIDAD
