INST LL INSTRUCTIONS C-VS-1800-ESC-1
2008 - 2011 FORD
ESCAPE
VEHICLE SPECIFIC CONSOLE
TOOLS REQUIRED:
• Phillips Screw dri er
• T-20 Torx Bit
• Ratchet Wrench
• 7mm, 10mm sockets
H RDW RE:
QTY: DESCRIPTION: PART #:
18 8 x 1/4” Flat Head Phillips SMS GSM33187
2 3/4” Plugs GSM 20016
1 Torx screws C-HK-1
2 Bracket, Spacer, Front Gear Box Console CM002140
1 Bracket, Cons, Fuse Co er CM002142
1 Bracket, Co er, Shift Gear Box CM002150
1 Panel, DS, Front Console, Shift Gear Box CM002151
1 Panel, PS, Front Console, Shift Gear Box CM002152
1 2” Faceplate to hold the OEM optional
110 olt outlet CM003656
lways!
• Read all instructions before installing any Ha is, Inc. products.
• Use hardware pro ided with install kit
1
C-VS-1800-ESC-1_INST_6-09 re 5-10

Havis, Inc .
75 Jacksonville R oad, PO Box 2099
Warminster, P 18974
T 800-524-9900 F 215-957-0729
www .havis .c om
Carefully remo e shift le er trim
bezel (unsnap)
Carefully remo e top of OEM
console (unsnap)
Remo e screw front lower sides
(7mm socket)
**SAVE HARDWARE**
Remo e rear lower side screws
(10mm socket)
**SAVE HARDWARE**
Remo e front upper screws
(7mm socket)
Unplug 12 olt socket power
Remo e OEM console Attach new “Z” brackets (one
each side) with pre iously remo ed
OEM hardware. (7mm socket)
New “Z” brackets installed
**DO NOT FULLY
TIGHTEN YET**

Havis, Inc .
75 Jacksonville R oad, PO Box 2099
Warminster, P 18974
T 800-524-9900 F 215-957-0729
www .havis .c om
Place new console housing
between seats
Attach to “Z” brackets with 1/4 x
3/4 Phillips head bolts
Tighten screws that attaches “Z”
bracket to OEM mount
Attach rear lower console to OEM
floor mount with OEM hardware
(10mm socket)
Mo e shift le er to rear position Place front console co er plate
around shift le er
Make sure plate is e enly spaced
to allow trim bezel remounting
**DO NOT ATTACH
YET**
Passenger side filler panel Attach to console with #8 x
1/4” flat head sheet metal
screws

Havis, Inc .
75 Jacksonville R oad, PO Box 2099
Warminster, P 18974
T 800-524-9900 F 215-957-0729
www .havis .c om
Attach filler panel to OEM mounts
with OEM hardware
(7mm socket)
Dri er side filler panel Attach same as passenger side
panel
Make sure top plate is e enly
spaced to allow trim bezel to snap
back in.
Attach plate with #8 x 1/4” flat
head sheet metal screws
Attach fuse panel co er
(#8 x 1/4” SMS)
Insert 3/4” plugs in “Z” bracket
holes
Reattach trim bezel 1/4” nuts for side mount
accessories
(i.e. TCB-7, Mic-clip brackets, etc)

-
5
2
4
-
9
9
0
0
F
2
1
5
-
9
5
7
-
0
7
2
9
w
w
w
.
h
a
v
i
s
.
c
o
m
NOTE:
Console kit includes 2” accessory plate for the OEM 110 volt outlet. f this plate is
used, there will be only 16” of mounting space. 110v outlet in Hybrid vehicles only.
(replacement plate part number - CM003656)
Finish wiring and complete installation.
