Havis C-DMM-2005 Configuration guide



  C‐DMM‐2005_INST_1‐17


Notes:
1. The C-DMM-2000 series Dash Monitor Mount brackets are specifically designed to work with
Havis, Inc, model # TSD-101 Touch Screen Display.
2. The display mount bracket includes a VESA 75 hole pattern that can also be used for some light
weight tablet docking station applications. Acceptable positioning must be determined by end user.
3. The C-DMM-2005 will work with all Havis, Inc. consoles made for the Transit van .
4. The C-DMM-2005 Does NOTwork with the 58V, 58W, 58X, 58Y, or 584radio package.
TOOLSREQUIRED:(sometoolsnotneededforallvehicleinstallations)
•Socketset‐metric&standard  •Drill&drillbits  •Tapemeasure
•Phillipsscrewdriver   •Trimremovaltools •Pencil/Marker

MOUNTBRACKETPARTSandHARDWARE:
Installationpartswith*comelooseinhardwarekitbag.Otherpartsarepreassembled

QTY: DESCRIPTION:     PART#:  
1MaindashmountbracketMT‐0294‐SA
1MaindashmountbaseMT‐0295‐SM*
1 Pivot/displaymountbracket   MT‐0320‐SA*
1TiltswivelhingeGSM22005
6 M5‐18mmThreadformingscrew   GSM33778*
1PVCspacerwasherCM008582
1TiltswiveladaptorCM008531
21/4"X3/4"CarriageboltsGSM32000
21/4"NylocknutGSM30016
21/4"FlatwasherGSM31005
2Nylon1/16”spacerwasherCM86600
1M8hexnutSSGSM30113
68‐32x5/8”MachinescrewGSM34117*
1M8lockwasherSSGSM31217
1 8‐32x.312”Phillipstrussheadmachinescrew GSM34077*
1 Vinylcap(.50”highx.312‐.375id)  GSM41127
2 Pullthroughbumper(3mmhead)   GSM21109
2 Pushinbumper (10mmhead)  GSM21108
1StopbracketMT‐0291‐SM
2 M5x10mmThreadformingscrew  GSM33774
INSTALL INSTRUCTIONS
C-DMM-2005 Dash Monitor Mount
2015-2019 Ford Transit Van
withRadiocode58Uor58T



  
C‐DMM‐2005_INST_1‐17

C-DMM-2005 assembly
ALWAYS!
• Read all instructions before installing any Havis, Inc products.
• Use hardware provided with install kit
GSM30113
GSM41127
GSM22005
MT‐0320‐SA *
GSM31217
MT‐0294‐SA
MT‐0295‐SM*
GSM33778 *
GSM34117*
GSM33778*
MT‐0291‐SM‐Awith
GSM21108
CM008531
CM008582
CM86600
GSM31005
GSM30016
GSM32000



  
C‐DMM‐2005_INST_1‐17
VeiwofTransitdashbeforeinstall Carefullyremovetoppocketbygently
p
r
y
in
g
alon
g
seams
Runningcomputerwiresthroughthedashis
recommenedatthistime
Placethemaindashmountbasetothe
bottomofthepreviouslyremovedtray
Lineuptrianglecutoutsinthebrackettothe
seamsinthetray.
Markfour(4)holesinthetrayusingapick
oranawl.





  
C‐DMM‐2005_INST_1‐17








Removefactoryhardwarefromtopofradio
housingusing.(7mmsocket)
Installthedashmountbaseusingfour(4)
M5‐18mmThreadformingscrewssupplied. Re‐installuppertrayassembly.
Installmainmountingbracketontothetray
andsecuretothelowermountingbaseusing
four(4)8‐32x5/8”machinesscrews.
Highlightmarkswithapaintmarkerand
thendrillouteachholeto1
/
4”.
Completedbracketinstall
11/8”holeforwirepassthrou
g
h



  
C‐DMM‐2005_INST_1‐17







ConnectharnessestothebackoftheTSD‐101display.
Itisimportanttoalsodoublewiretietheharnessesto
providesturdystrainrelieffortheplugs.
USBconnectionfromremoteDockingstationmustplug
intoUSBplugclosesttofrontofdisplay.
Attachpivot/displaymountbrackettodisplaywith
M4x0.7x10mmPhillipsheadmachinescrews,lock
washersandflatwashers.Displaymounthardwareis
includedwithTSD‐101hardwarekit

Attachbracketwithdisplaytothetiltswivelhinge
withM8hexnutandlockwasher.Tightennutand
attachvinylcaponM8boltthreads.
Runwiresthroughholeintrayortheycanberun
neatlyalongtheoutsideofthedash.
RefertoTSD‐101owner’smanualfor
p
owerandcom
p
uterconnectiondetails.
InstallationofC‐DMM‐2005withTSD‐101
complete.
