INSTALL INSTRUCTIONS C-TMW-F250-02
HEAVY DUTY TUNNEL PLATE
2011-2016 F-250, 350, 450, & 550
TOOLS REQUIRED:
Ratcheting wrench Metric socket set
Standard socket set T-55 Torx Bit
7/16” wrench
Pencil
PARTS and MOUNTING HARDWARE:
QTY DESCRIPTION PART #
1 Front transmission hump bracket set C-B59
1 Rear transmission hump bracket set C-B51
1 28” x 8” Tunnel Plate C-TMW-28E
2 Extrusion plastic end caps CM002527A
20 ¼” x ¾” hex head bolt GSM33001
12 ¼” Flat Washers GSM31005
12 ¼” Lock Washers GSM31026
8 ¼” Serrated nut GSM30023
C-TMW-F250-02
ASSEMBLY
C-TMW-28E
28” Tunnel Plate
C-B59
3-Piece transmission hump bracket
(2 –Legs and 1 –Crossover Bracket)
C-B51
3-Piece transmission hump bracket
(2 –Legs and 1 –Crossover Bracket
CM002527A
Extrusion plastic end cap

C-TMW-F250-02_INST_7-10
2
INSTALLATION:
NOTES:
A.If you removed the OEM center seat, there will be studs in the floor
for the center seat belt. You must remove the center seat belt studs
with 9mm socket. The rear hump bracket will attach to the front seat
rear bolts.
B. If you have an Extended or Crew cab truck, there will be an air duct
underneath the floor mat. The C-B59 front hump bracket does allow
clearance for the duct.
C. The C-B59 Front Hump bracket also works with the C-HDM-142
Computer mount.
D.This mount does work with OEM 4 x 4 floor shifter.
E. This mount does NOT work with OEM Manual Transmission
floor shifter.
1. Remove Front and rear seat bolts.
OEM plastic trim caps may have to be removed from seat brackets.
2. Determine parts and place front and rear hump brackets legs in under
seat brackets. Loosely attach seat bolts, but do not tighten yet.
3. Place the crossover bracket on the legs and place the Tunnel Plate
extrusion on the crossover brackets. Determine the desired position of
the tunnel plate and mark the parts with a pencil. Remove Tunnel Plate
and crossover brackets.
4. Flip Tunnel Plate upside down and attach front and rear crossover
bracket to Tunnel extrusion with ¼” x ¾” bolts and serrated nuts.
(bolt heads go into extrusion slots)
5. Attach Tunnel plate with front and rear crossover brackets to hump
bracket legs using ¼” x ¾” hex bolts and flat washers.
6. Tighten seat bolts and all hardware.
7. Install bolts and / or nuts in Tunnel Plate slots as needed and attach
console and/or accessories as desired.
8. Attach plastic end caps to ends Tunnel Plate extrusion. (peel and stick)
Always!
Read all instructions before installing any Havis, Inc. products.
Use hardware provided with install kit
For product support, email [email protected] or call 1-800-524-9900.
