Havis C-VS-1500-DUR-1 Configuration guide

C-VS-1500-DUR-1_INST_12-12 rev10-15
INSTALL INSTRUCTIONS C-VS-1500-DUR-1
15” VEHICLE SPECIFIC CONSOLE for
2011 - 2013 Dodge Durango with OEM Center Shifter
TOOLS NEEDED:
Phillips Screw Driver
Standard Socket set
Metric Socket set
90° Phillips Screw Driver
T-20 Torx Bit
Wire Crimping tool
Wire Cutters
QTY DESCRIPTION PART #
1 Main Console Housing CM005190
1 Base mount bracket CM005005
1 Shifter mount platform CM005006
1 Top console Bezel CM005012
1 Shifter cover CM005011-1
1 Driver side trim panel CM005024
1 Passenger side trim panel CM005025
2 Retaining bracket CM005270
2 10-32 Nylock nut GSM30015
1 Cup Holder CM001629
1 Hardware kit C-HK-211
C-HK-211 Hardware Kit includes the following
2 12 volt socket CM216560
6 1/4 x 1/2” Hex head bolt GSM33000
10 1/4 x 3/4” Hex head bolt GSM33001
3 1/4 x 1 ¼” Hex head bolt GSM34033
4 1/4 x 1/2” Carriage bolt GSM31999
4 1/4 serrated nut GSM30023
15 1/4 Flat washer GSM31005
9 1/4 Lock washer GSM31026
8 # 8 x 1/4” Flat head sheet metal screw GSM33178
8 # 8 x 3/8” Torx head screw CM86508
1 2” x 2 ½” x 8” foam block CM007533
NOTES!
Read all instructions before installing any Havis, Inc. products.
Use hardware provided with install kit.

C-VS-1500-DUR-1_INST_12-12 rev10-15
C-VS-1500-DUR-1
(Main Housing Assembly)
CM001629
Cup Holder
CM005025
Passenger side trim panel
CM005270
Retaining bracket
CM005024
Driver side cover panel
CM005006
Shifter mount platform
(inside console)
CM005005
Base mount bracket
CM005190
Main Console Housing
CM005011-1
Shifter cover
CM005012
Top Console Bezel

C-VS-1500-DUR-1_INST_12-12 rev10-15
Remove shifter knob
Carefully pop out coin tray from console
top panel and save to be reused.
Note: Some vehicles may have the coin
tray with traction control switch as
shown.
Carefully unclip and remove top
console panel.
Unplug wires as needed.
O.E.M. console prior to removal Carefully slide down (unsnap)
chrome trim piece under shifter
knob.
Carefully remove retaining clip that
holds knob onto shifter shaft.
(Needle nose pliers work well)
Top console panel removed.
Remove two (2) screws for side
trim panels.
(Phillips screwdriver)
Remove bolt cover at lower rear
end of console. (one each side).
Remove bolts.
(10 mm socket)

C-VS-1500-DUR-1_INST_12-12 rev10-15
Remove rear side screws holding
housing to floor bracket.
(90° Phillips screwdriver)
Remove arm rest and hinge
assembly.
(Phillips screwdriver)
Remove four (4) bolts holding the
shifter assembly to holding the
main plastic console housing.
Save Hardware
(10mm socket)
Driver side / forward bolt shown.
Unplug shifter harness from console base.
Carefully unclip and remove
console rear end panel.
Note:
Some vehicles may have rear
controls in panel that will require
removal of electrical connectors.
Carefully unclip and remove
console side panels.
Remove four (4) bolts holding the
main plastic console housing to
floor and Save hardware
Unplug wire harnesses.

C-VS-1500-DUR-1_INST_12-12 rev10-15
Place # CM005005 base mount
bracket into vehicle.
Attach bracket to rear O.E.M. floor
mount with O.E.M screws
previously removed.
(10 mm socket)
Carefully unclip shift cable mount
and unbolt cable end.
Take note of correct position of
cable mount parts.
Save Hardware
Remove shifter assembly Remove forward base screws from
lower dash and save screws
.(one each side)
(7 mm socket)
Unplug main console harness from
lower end of dash. Remove OEM plastic base plate O.E.M. console housing removed.
Carefully remove wire harness
from O.E.M. console housing.

C-VS-1500-DUR-1_INST_12-12 rev10-15
Carefully place main console
housing into vehicle.
Loosely attach rear housing sides
to base bracket with 1/4” x 1/2"
Carriage bolts and serrated nuts.
(two each side)
Do not tighten hardware yet.
Now coin tray is mounted to the
console bezel.
Proceed with installation of
bezel.
Note: Some vehicles may not
have the traction control knob as
shown.
Place coin tray on the underside of top
console bezel. Clamp on with
CM005270 brackets as shown.
(11/32” socket)
Insert 2” x 2.5” x 8” foam block
into lower dash air duct to prevent
air from blowing into console.
Foam part number - CM007533
Place shifter assembly into base
bracket. Do not bolt in yet.
Carefully reattach shifter cable
back onto original location and
tighten cable end bolt.
Attach # CM005006 front shifter
platform to base bracket with six
(6) 1/4 x 1/2 Hex head bolts, lock
washers and flat washers.
(7/16 wrench)
Attach shifter assembly to shifter
platform with three (3) 1/4 x 1¼”
hex head bolts lock washers and
flat washers.
(7/16 socket)
Attach base bracket to front
O.E.M. floor mount with O.E.M
screws previously removed.
(10 mm socket)
Reattach O.E.M. harnesses and
plugs.
Note: There some holes for
attaching cable clips.

C-VS-1500-DUR-1_INST_12-12 rev10-15
Attach driver side trim panel to
console housing with # 8 x 1/4"
flat head sheet metal screws.
.
Attach passenger side trim panel
to console housing with # 8 x 1/4"
flat head sheet metal screws.
Note: If mounting a C-HDM-204
side computer mount, use the
existing 1/4" hex bolts and nuts
with 1/2" hex bolts in upper side
extrusion.
Before inserting cup holder, run
necessary wiring and wire tie as
needed. Make sure wiring is not
stressed or that it does not interfere
with shifter mechanism.
Loosely attach forward housing
sides to base bracket with 1/4” x
3/4" hex bolts and flat washers.
(two each side)
Tighten all console mount hardware.
Loosely attach front driver side
console housing to lower dash with
previously removed O.E.M. screw.
(7mm socket)
Loosely attach front passenger side
console housing to lower dash with
previously removed O.E.M. screw.
(7mm socket)
Place top console bezel onto console.
Note: Wire in the 12 volt sockets and
run aftermarket wire harnesses before
closing up front end of console.
Attach angled shifter cover plate to
top console bezel with four (4) # 8 x
1/4" flat head sheet metal screws.
Note: You may need to slide bezel
back to access forward screws.
Push top console bezel forward and
attach to console housing with # 8 x
3/8” Torx head screws
(T-20 Torx)
Reattach shifter knob and insert cup
holder

C-VS-1500-DUR-1_INST_12-12 rev10-15
New console housing with control
heads and accessories installed.
View of console at rear end.
View of completed installation on passenger side.
Console includes mounting
provisions for side mounted
C-HDM-204 computer mount
bracket.
View of C-HDM side computer mount.
View of completed console and laptop mount in a 2012 Dodge Durango.
