INSTALL INSTRUCTIONS C-TMW-ECO-01
1997 – 2014 FORD E-150, 250 & 350 VAN
1997 – 2020 FORD E-450 Cutaway Chassis
TUNNEL MOUNT KIT
TOOLS REQUIRED:
Ratcheting Wrench
Standard Socket Set
T-55 Torx Bit
7/16” wrench
Tape Measure and pencil
HARDWARE:
QTY DESCRIPTION PART #
20 ¼” x ¾” Hex head bolt GSM33001
8 ¼” Serrated nut GSM30023
12 ¼” Flat washer GSM31005
12 ¼” Split lock washer GSM31026
4 ¼” Hex Nut GSM30005
Always!
Read all instructions before installing any Havis, Inc. products.
Use only hardware provided with install kit.
NOTE: Additional ¼” hardware provided to mount C-HDM-200 Series Poles to C-TMW Series
Front of
Vehicle
TUNNEL MOUNT ASSEMBLY
(2) Part # CM003355
Hump Bracket
Driver side le
g
(2) Part # CM93346
Hump Bracket Center Plate
(2) Part # CM003354
Hump Bracket
Passenger side leg
CM009431-03
24” Tunnel
Mount Extrusion

C-TMW-EC-01_INST-1-19
2
Remove the Front and Rear inboard seat bolts.
(Bolts closest to center of vehicle)
T-55 Torx bit needed.
Place passenger side forward leg in position
between the floor and seat base.
Re-attach seat bolt. Do not tighten bolt yet.
Repeat on driver side forward leg.
Place passenger side rear leg in position
between the floor and seat base.
Re-attach seat bolt. Do not tighten bolt yet.
Re
p
eat on driver side rear le
g
.
Loosely attach center plates to legs with ¼” x ¾”
hex head bolts and flat washers.
Note: You may want to remove these plates to
attach the extrusion hardware in the next ste
p
.
Attach Tunnel Extrusion to center plates with
¼” x ¾” hex head bolts and serrated nuts.
Note: The head of the bolt slides into the
bottom of extrusion.
Position extrusion as desired and tighten all hardware.
The C-TMW-ECO-01 is now ready to mount a console
or other accessories.
The self adhesive plastic end caps go on after the top
mounted hardware is inserted into extrusion slots.
