Havis C-TCB-7 Configuration guide

C-TCB-7_INST_6-096-09
INSTALL INSTRUCTIONS C-TCB-7
MEDIUM DUTY PASSENGER-SIDE MOUNT
UNIVERSAL CONSOLE MOUNT OR
FLAT SURFACE MOUNT
FOR USE ON CONSOLES
TOOLS REQUIRED:
3/16” Allen wrench
Powered drill and ¼” drill bit (if necessary) Open-end wrench set
HARDWARE & COMPONENTS:
QTY DESCRIPTION PART #
1 Pole support assembly CM93071-7
1 Passenger-side mount assembly CM93072-1
4 ¼-20 x ½” Hex head bolt GSM33000
4 ¼-20 Hex nut GSM30005
4 ¼”Flat washer GSM31005
Always!
Read all instructions before installing any Havis, Inc. products.
Check for obstructions (Wire, brake lines, fuel tank, etc.) before drilling any holes!
Use hardware provided with install kit
SUB ASSEMBLY:
1. Confirm receipt of all hardware and components.
2. C-TCB-7 offers multiple mounting options.
Side of C-Series or AS-Series consoles.
Any flat surface with access to nut and bolt.
3. Mounting option to be determined by installer.
Pole support
assembly
Passenger-side mount
assembly
¼-20 x ½” Hex
head bolt & ¼”Flat
washer

C-TCB-7_INST_6-096-09
INSTALLATION:
C-TCB-7 w/ C-SERIES CONSOLIDATOR® INSTALLATION:
1. Mount C-Series console into vehicle per installation instructions provided. :
Console must be mounted leaving room for C-TCB-7.
2. Mount C-TCB-7 on side of C-Series console.
Position C-TCB-7 on Passenger side of console.
Mount using (4) ¼-20 x ½” Hex head bolts and washers. (2 on top rail and 2 on
bottom rail)
Rails of console have (4) ¼-20 hex nuts on both top and bottom. (Extra nuts are
provided if needed)
Attach optional C-3090 Computer mounting platform to Passenger-side mount
assembly.
C-TCB-7 MOUNTING TO FLAT SURFACE WITH ACCESS TO NUT & BOLT:
1. Location to be determined by installer.
Position pole support assembly at determined location.
Mark (4) mounting holes using slots in the pole support assembly.
Drill ¼” holes on marked locations being sure not to drill into wires, controls, etc…
Re-position pole support assembly and mount using ¼-20 x ½” Hex head bolts,
washers and nuts.
Slide passenger-side mount assembly into pole support.
Mount optional C-3090 computer mounting platform to passenger-side mount
assembly using hardware and instructions provided with C-3090.
C-TCB-7 mounted on C-1800
console (sold separately)
