ACME Diamonds II User manual

CONTENTS
7. Troubleshooting ..................................................................................................... ..21
8. Fixture Cleaning ........................................................................................................21
1. Safety Instructions ................................................................................................. 2
2. Technical Specifications .......................................................................................... 4
3. Control Panel ......................................................................................................... 5
4. How To Set The Unit ............................................................................................... 6
6.Control By Universal DMX Controller ......................................................................11
6.1 DMX512 Connection ...................................................................................... ..11
6.2 Address Setting ................................................................................................ 12
6.3 DMX512 Configuration ..................................................................................... 13
5. How to Control the Unit.......................................................................................... 10

1. Safety Instructions
WARNING
Please keep this User Guide for future consultation. If you sell the unit to another user,
be sure that they also receive this instruction manual.
Important:
Damages caused by the disregard of this user manual are not subject to warranty.
The dealer will not accept liability for any resulting defects or problems.
Unpack and check carefully that there is no transportation damage before using
the unit.
This product is for indoor use only.
DO install and operate by qualified operator.
DO NOT allow children to operate the fixture.
Please read the instruction carefully which includes important information about
the installation, usage and maintenance.
1C
Use safety chain when fixing the unit. Handle the unit by carrying its base instead
of head only.
The unit must be installed in a location with adequate ventilation, at least 50cm
from adjacent surfaces.
Be sure that no ventilation slots are blocked, otherwise the unit will be
overheated.
Please keep this User Guide for future consultation. If you sell the unit to another user, be sure
that they also receive this instruction booklet.

40℃.
DO NOT connect the device to any dimmer pack.
Make sure there are no flammable materials close to the unit while operating to
avoid fire hazard.
Examine the power wires carefully; replace them immediately if there is any
damage.
Unit’s surface temperature may reach up to 65℃. DO NOT touch the housing
bare-handed during its operation.
Avoid any inflammable liquids, water or metal objects entering the unit. Once it
happens, cut off the mains power immediately.
DO NOT operate in dirty or dusty environment, do clean fixtures regularly.
DO NOT touch any wire during operation as there might be a hazard of electric
shock.
2C
Before operating, ensure that the voltage and frequency of power supply match
the power requirements of the unit.
It’s important to ground the yellow/green conductor to earth in order to avoid
electric shock.
Minimum ambient temperature TA: 0℃. Maximum ambient temperature TA:
Avoid power wires together twist other cables.
The minimum distance between light output and the illuminated surface must be
more than 0.5 meters.
In the event of serious operating problem, stop using the unit immediately.
Never turn on and off the unit time after time.
The housing, the lenses, or the ultraviolet filter must be replaced if they are
visibly damaged.

DO NOT start on the unit without bulb enclosure or when housing is damaged.
Installation:
The fixture should be mounted via its Omega Quick Release Clamp bracket. Always
ensure that the unit is firmly fixed to avoid vibration and slipping while operating and
make sure that the structure to which you are attaching the unit is secure and is able
to support a weight of 10 times of the fixtures weight. Always use a safety cable that
can hold 12 times of the weight of the fixture when installing.
The equipment must be installed by professionals. It must be installed in a place
where is out of the reach of people and no one can pass by or under
3C
DO NOT open the unit as there are no user serviceable parts inside.
Never try to repair the unit by yourself. Repairs carried out by unskilled people
can lead to damage or malfunction. Please contact the nearest authorized
technical assistance center if needed.
Disconnect the mains power if the fixture is has not been used for a long time.
DO use the original packing materials before transporting it again.
DO NOT look directly at the light while the bulb is on.

2. Technical Specifications
Power Voltage:
100-240V~ 50/60Hz
Power Consumption:
185W
Light Source:
10W RGB
Beam Angle:
30°
Dimmer/Shutter:
Smooth dimming from 0-100%; outstanding strobe effect with variable speed
Control:
DMX Channel:：27 / 52 CH
Control Mode: Voice CONTROL/SELF-WALKING/DMX512/Master/Slave/ILDA
Construction:
Display: OLED
Data In/Out: 3-pin (5-pin XLR is optional)
Power In/Out: Power Connector in/out
Protection Rating: IP20
Features:
Results: equipped with 50K Vibration Mirror, provide beam and a variety of built-
in laser patterns and animation effects
For Pangolin, Phoenix, Mamba and other laser light show software
4C

Suitable for clubs, bars, nightclubs, TV stations, advertising promotion and other
places
The chassis adopts dustproof design, follows the classic double-layer design, the
enclosure of the chassis is better, can effectively insulate the lampblack of the bar
Lightweight, easy to transport and hanging lights, high brightness, color unity.
尺寸/重量：
9.1”x12.6”x7.2”, 28lbs
5C
3. Control Panel
POWERCON Version:

1. POWER SWITCH: Turn Power On/off
2. KNOB
3. Power Input (POWERCON version) : connect power supply
4：EASY ILDA
5. Screen: Liquid Crystal Display
6.Ilda interface
7. DMX INPUT: For DMX512 connections, use a 3-core XLR signal line to connect the
lamp to the DMX console, and enter DMX signal (optional)
8. DMX output: For DMX512 connections, use 3-core XLR signal lines to connect to
the next machine (optional 5-core)
9. Key Switch: to set to RUN, the lamp will light up
4.How To Set The Unit
4.1 Main Function
Turn on the unit, press the MENU button into menu mode, and press the UP/DOWN button until
the required function is shown on the monitor. Select the function by the ENTER button. Use the
UP/DOWN button to choose the submenu, press the ENTER button to store and automatically
return to the last menu. Press the MENU button or let the unit idle One Minute to exit menu mode.
6C
TFT screen menu list as following
First menu Secondary menu
DMX address 1 - 512
Auto in-play
Fast Beat ON/OFF
Medium Beat ON/OFF
Slow Beat ON/OFF
Animation ON/OFF
Music in-play
Fast Beat ON/OFF
Medium Beat ON/OFF
Slow Beat ON/OFF

7C
Animation ON/OFF
SD card Mode
Repeat ON/OFF ONE / FILE / ALL
Music ON/OFF
Directory 1/8
F i l e 1/4 8
Test Mode Image 1-3
System
Setting
Channel Setting 27CH /
52CH
Master / Slave
ON/OFF
Scan-safety ON/OFF
EASY ILDA ON/OFF
Language CH/EN
Sound Sense 0-100
About
Channel Num
Operational Mode
DMX Address
Case temperature
Running Time
Hardware version
Software version
Reset Setting
Master
Setting
Color RGB/G
Scan 15-50K
Brightness 0-255
Design
R Fade 0-255
G Fade 0-255
B Fade 0-255
Zoom 0-255
X Size 0-255
Y Size 0-255
Invert X ON/OFF
Invert Y ON/OFF

8C
DMX Addresses
To select DMX Addresses，Press the ENTER button to confirm that the current mode
will be displayed on the display, use the UP/DOWN button to select the DMX entry
address, use the Knob to find the start address (001-512) , and then press the Knob to
confirm and set. Go back to the main menu and select exit
Auto in-play
To select Auto in-play，Press the ENTER button to confirm that the current mode is
displayed on the screen, using the UP/DOWN button to select: Fast Beat，Medium
Beat，Slow Beat，Animation，press the Knob to confirm and set. Go back to the
main menu and select exit.
Music in-play
To select Music in-play，Press the ENTER button to confirm that the current mode is
displayed on the screen, using the UP/DOWN button to select: Fast Beat，Medium
Beat，Slow Beat，Animation，press the Knob to confirm and set. Go back to the main
menu and select exit.
SD card mode
To select SD card mode ，Press the ENTER button to confirm that the current mode
will be displayed on the display, using the UP/DOWN button to select: Repeat, Music,
Directory, File , press the button to confirm. Go to the SD file, select the file or folder
you want to play, and press the button to confirm. Go back to the main menu and
select exit.

1.The native system can read the SD card 8 already fixed folder, each folder can read 48
pattern file, pattern file format (. ILD) format file. The UP/DOWN button allows you to
select a pattern file. If the looping is set to ON, the entire SD folder will be looped.
(single file name selection is invalid.) If you want to select a single file name, you need
to return the looping to OFF. With the UP/ DOWN button, you can choose the way to
trigger the pattern file to play, ON is the voice trigger, OFF is the automatic trigger.
2. Insert the SD card into the light fixture and use the UP,
DOWN button to select the SD card mode, or use the console to
press the channel to play the SD card file, or use the console to find the files you
need and select the SD card mode on the light fixture (ONE is a single FILE
looping, FILE is a single folder ALL files looping, ALL is the entire SD card looping) .
3. The content of SD card can be played by console
(1). In SD card, you can find 8 folders, folder naming rule as following
(2). Add file (.ild) to folder, (note:file name could be number or letter, and
should not exceed 32 letters) as following
9C

(3). Folder and content play sequence as following
The files in folder will be played in the order in which the files are copied to the SD
card. That is, the first copied, first play. If you want to change the play sequence, you
can copy them in the sequence you want. The folders will be played according to the
fixed folder number(From LF001 ...LF008) in the sequence of copying.
Test Mode
To select Test Mode，Press the ENTER button to confirm that the current mode is
displayed on the display, selected using the UP/DOWN button, press the Knob to
confirm and test the pattern 1-6. Go back to the main menu and select exit.
System Setting
To select System Setting，Press the ENTER button to confirm that the current
mode will be displayed on the display, use the UP/DOWN button to select:
Channel Settings, Master,slave settings, EASY ILDA, Language,Sound
Sense,About,Reset Setting, press the Knob to confirm. Go back to the main menu
and select exit.
10C
The name of the SD card folder
File folder (EN)
LF001 Animals
LF002 Abstracts1
LF003 Abstracts2
LF004 Music+Dancers
LF005 People+Characters
LF006 Themes
LF007 Logos+Text
LF008 Shows

Select the MANUFACTURER menu to display the manufacturer of the fixture.
Select the SOFTWARE VERSION menu and the program version number of the fixture will be
displayed.
Select the DMX START ADDRESS menu to change the DMX 512 address (001-512).
Select the DEVICE MODEL DESCRIPTION menu to display the model of the fixture.
Select the DEVICE LABEL menu to change the model of the fixture.
Select the DMX PERSONALITY menu to set the channel mode of the fixture (27/52channel).
Select the DMX PERSONALITY DESCRIPTION menu to display the current channel mode of the
fixture.
Select the DEVICE HOURS menu to display the running time of the fixture.
Select the RESET DEVICE menu, the WARM RESET/COLD RESET option will be displayed. When
WARM RESET is selected, the fixture will start a warm reset, and exit when COLD RESET is selected.
5.How to Control the Unit
1. By ILDA;
Connect the unit to the computer with ILDA wire and control the software by computer laser;
Priority to control the unit: ILDA﹥DMX﹥Sound active﹥Auto play
2.By universal DMX controller;
Set the DMX address, the unit will be ready to receive DMX signal.
3. Sound active;
The unit will run show by the sound active.
4. Auto play;
The unit will auto play when no signal.
11C
RDM FUNCTIONS
Master Setting
To select Master Setting，Press the ENTER button to confirm that the current mode
will be displayed on the display, use the UP/DOWN button to select: Color ,Scan
Brightness,Design , Invert X ,Invert Y , press the Knob to confirm. Go back to the main
menu and select exit.

6. Control By Universal DMX Controller
6.1 DMX512 Connection
1. At last unit, the DMX cable has to be terminated with a terminator. Solder a 120-ohm 1/4W
resistor between pin 2(DMX-) and pin 3(DMX+) into a 3-pin XLR-plug and plug it in the DMX-output
of the last unit.
2. Connect the unit together in a “daisy chain” by XLR plug cable from the output of the unit
to the input of the next unit. The cable cannot be branched or split to a “Y” cable. DMX 512 is a
very high-speed signal. Inadequate or damaged cables, soldered joints or corroded connectors
can easilydistort the signal and shut down the system.
3. The DMX output and input connectors are pass-through to maintain the DMX circuit, when one
of the units’ power is disconnected.
4. Each lighting unit needs to have a DMX address to receive the data by the controller. The
address number is between1-508.
5. The end of the DMX 512 system should be terminated to reduce signal errors.
6. 3 pin XLR connectors are more popular than 5 pins XLR.
3 pin XLR: Pin 1: GND, Pin 2: Negative signal (-), Pin 3: Positive signal (+)
5 pin XLR: Pin 1: GND, Pin 2: Negative signal (-), Pin 3: Positive signal (+), Pin4, Pin5 not used.
12C

6.2 Address Setting
If you use a universal DMX controller to control the units, you have to set DMX address from 1 to
512 so that the units can receive DMX signal.
Press the MENU button to enter menu mode, select DMX Settings, press the ENTER button to
confirm, use the UP/DOWN button to select DMX Address, press the ENTER button to confirm, the
present address will blink on the display, use the UP/DOWN button to adjust the address from 001
to 512, press the ENTER button to store. Press the MENU button back to the last menu or let the
unit idle one minute to exit menu mode.
Please refer to the following diagram to address your DMX512 channel for the first 4 units.
Channel mode Unit 1
Address
Unit 2
Address
Unit 3
Address
Unit 4
Address
27 channels 1 28 55 82
52 channels 1 53 105 157
6.3DMX512 Configuration
Please refer to the following channel Diagram to control the lights note: 1. If you
disconnect the DMX signal, the lamp will remain in the state it was before the signal
was disconnected, unless you reset it. 2. In the "function" channel, hold the channel
value for about 25 seconds and the lamp will run the corresponding function. This
lamp IPLAY mode has 2 kinds of channel modes 27CH and 52CH (channel mode can
be selected from system setting → channel number setting) , SD mode is not affected
by channel number setting, SD PLAY only has 1 channel mode, the mode and
explanation are as follows:
13C

14C
DMX-512 channel
CH1=32-63, CH2 - CH27 or CH2 - CH52 valid
CH1=64-127, CH2, CH6 valid
Channel Parameter Value Parameter description
CH1
IPL AY mode
0～31 Black
32～63 Manual play
64～95 Auto play
96～127 Music play
SD mode
128～159 Manual play
160～191 Auto play
192～223 Music play (one file)
224～255 Music play (all files loop)
CH2 Dimmer 0～255 Fade 0% .... 100%
CH3 CH28 Red 0～255 Fade 0% .... 100%
CH4 CH29 Green 0～255 Fade 0% .... 100%
CH5 CH30 Blue 0～255 Fade 0% .... 100%
CH6 CH31 List 0～255 Each 32 value be 1 list，total 8 list
Macro Each 64 value be 1 macro，total 4 macro
CH7 CH32 Cue 0～15 Black
16～255 Each 12 value be 1 cue, total 20 cues
CH8 CH33 X position 0～255 Left .... right（128 center）
CH9 CH34 X fine 0～255 X fine position
CH10 CH35 Y position 0～255 Down ....up（128 center）
CH11 CH36 Y fine 0～255 Y fine position
CH12 CH37 Rotation 0～255 Clockwise rotation (0°-360°)
CH13 CH38 Fine rotation 0～255 Fine rotation
CH14 CH39 Zoom 0～255 100%....0%
CH15 CH40 X flip 0～255 Left...right
CH16 CH41 Y flip 0～255 Down ... up
CH17 CH42 Color
0～7 Default
8～15 White
16～23 Red
24～31 Yellow
32～39 Green
40～47 Cyan
48～55 Blue
56～63 Purple
64～127 Each 8 value be 1 color effect， total 8
128～143 Macro 1
144～159 Macro 2
160～175 Macro 3
176～191 Macro 4
192～207 Macro 5

208～223 Macro 6
224～239 Macro 7
240～255 Macro 8
CH18 CH43 Write in 0～255 Visible point 100%-0
CH19 CH44 Deformation
0～15 Invalid
16~31 Macro 1（valid for 14CH 25CH ）
32~47 Macro 2（valid for 14CH 25CH ）
48~63 Macro 3（valid for 14CH 25CH ）
64~79 Macro 4（valid for 14CH 25CH ）
80~95 Macro 5（valid for 14CH 25CH ）
96~111 Macro 6（valid for 14CH 25CH ）
112~127 Macro 7（valid for 14CH 25CH ）
128~143 Macro 8（valid for 14CH 25CH ）
144~159 Macro 9（valid for 14CH 25CH ）
160~175 Macro 10（valid for 14CH 25CH ）
176~191 Macro 11（valid for 14CH 25CH ）
192~207 Macro 12（valid for 14CH 25CH ）
208~223 Macro 13（valid for 14CH 25CH ）
224～255 Default
CH20 CH45 Wave
0 Invalid
1～39 Macro 1
40～79 Macro 2
80～119 Macro 3
120～159 Macro 4
160～199 Macro 5
200～255 Macro 6
CH21 CH46 Write in
0 Invalid
1～42 Macro 1
43～84 Macro 2
15C

16C
85～126 Macro 3
Strobe 127～255 Slow... fast
CH22 CH47 X position
0 Invalid
1～32 Macro 1
33～64 Macro 2
65～96 Macro 3
97～128 Macro 4
129～160 Macro 5
161～192 Macro 6
193～224 Macro 7
225～255 Macro 8
CH23 CH48 Y position
0 Invalid
1～32 Macro 1
33～64 Macro 2
65～96 Macro 3
97～128 Macro 4
129～160 Macro 5
161～192 Macro 6
193～224 Macro 7
225～255 Macro 8
CH24 CH49 Z rotation
0 Invalid
1～32 Macro 1
33～64 Macro 2
65～96 Macro 3
97～128 Macro 4
129～160 Macro 5
161～192 Macro 6
193～224 Macro 7
225～255 Macro 8
CH25 CH50 Zoom 0 Invalid
1～32 Macro 1

17C
33～64 Macro 2
65～96 Macro 3
97～128 Macro 4
129～160 Macro 5
161～192 Macro 6
193～224 Macro 7
225～255 Macro 8
CH26 CH51 X flip
0 Invalid
1～32 Macro 1
33～64 Macro 2
65～96 Macro 3
97～128 Macro 4
129～160 Macro 5
161～192 Macro 6
193～224 Macro 7
225～255 Macro 8
CH27 CH52 Y flip
0 Invalid
1～32 Macro 1
33～64 Macro 2
65～96 Macro 3
97～128 Macro 4
129～160 Macro 5
161～192 Macro 6
193～224 Macro 7
225～255 Macro 8

18C
SD card 20CH
Channel Parameter Value Parameter description
CH1
IPLAY mode
0～31 Black
32～63 Manual play
64～95 Auto play
96～127 Music play
SD mode
128～159 Manual play
160～191 Auto play
192～223 Music play (one file)
224～255 Music play (all files loop)
CH2 Dimmer 0～255 Brightness 0% .... 100%
CH3 Red 0～255 Brightness 0% .... 100%
CH4 Green 0～255 Brightness 0% .... 100%
CH5 Blue 0～255 Brightness 0% .... 100%
CH6 List 0～255 Each 32 value be 1 list，total 8 list
Macro each 10 value be 1 macro，total 25 macro
CH7 Cue 0～15 Black
16～255 Each 12 value be 1 cue,total 20 cues
CH8 X position 0～255 Left .... right（128 center）
CH9 X fine 0～255 X fine position
CH10 Y position 0～255 Up ....down（128 center）
CH11 Y fine 0～255 Y fine position
CH12 Rotation 0～255 Clockwise rotation (0°-360°)
CH13 Fine rotation 0～255 Fine rotation
CH14 Zoom 0～255 100%....0%
CH15 X flip 0～255 Left...right
CH16 Y flip 0～255 Down ... up
