HBM SomatXR 1-CASEMOUNT2-2 Operator's manual

For use with
SomatXR Ultra-Rugged DAQ
SomatXR Features
– Rugged, mobile data acquisition in a
flexible, modular system
– Waterproof, dustproof, shockproof,
vibrationproof
– Ultra-rugged: IP65/IP67, MIL202
– Wide thermal range: -40 to 80 °C
– Secure and efficient storage of
measurement data
– Accessible from anywhere through the
CX23-R web interface
NOTE
HBM recommends mounting modules individually in high vibration environments. Individually mounted
SomatXR modules are vibration- and shock-proof according to MIL-STD-202G. Stacked upper modules
in high vibration environments may exceed vibration and shock specifications. Make sure mounted
modules will not exceed vibration and shock specifications (see module data sheets).
B4547-1.0 en HBM: public
1-CASEMOUNT2-2 and
1-CASEMOUNT3-2
The casemount kits enable SomatXR
modules to be mounted on any surface.
– Two kits are available for mounting stacked
SomatXR modules
– Use 1-CASEMOUNT2-2 to mount one or
two modules
– Use 1-CASEMOUNT3-2 to mount two or
three modules
– These brackets can be used in conjunction
with the 1-CASEMOUNT-UMB-2 kit
– All components in these kits are ROHS
compliant

1-CASEMOUNT2-2 kit contents
Part Number Description Quantity Graphic
SO-227-1001727 M5 18-8 SS, Flat, Socket Cap,12 mm, 0.8 pitch 32 A
SO-227-1001804 M6 18-8 SS, Socket Cap 25 mm 6 B
1-CASELINK-RUG-2 Fastener CASELINK-RUG (4 pieces per package) 1 D, E
SO-095-1001428 Bracket, 2 Unit Machined Mounting Bracket 2 F
1-CASEMOUNT3-2 kit contents
Part Number Description Quantity Graphic
SO-227-1001727 M5 18-8 SS, Flat, Socket Cap,12 mm, 0.8 pitch 64 A
SO-227-1001804 M6 18-8 SS, Socket Cap, 25 mm 6 B
1-CASELINK-RUG-2 Fastener CASELINK-RUG (4 pieces per package) 2 D, E
SO-095-1001427 Bracket / 3 Unit Machined Mounting Bracket 2 G
Instructions
1. Apply serviceable (blue) threadlock to the four (4) M5 set screws (E) in each caselink (D). Use a 2.5
mm hex wrench to turn set screws back in the caselink before installing the caselink on a module.
2. Connect two (2) stacked modules by inserting two (2) caselinks (D) in the slots on each end of the
modules.
3. A set of four (4) caselinks can hold two (2) stacked modules together. Kit 1-CASEMOUNT2-2 includes
1-CASELINK-RUG-2 for two (2) modules. Kit 1-CASEMOUNT3-2 includes 1-CASELINK-RUG-2 for
three (3) modules.
HBM 2 B4547-1.0 en HBM: public

4. Connect a bracket (F or G) to the caselinks using M5 flat screws (A), serviceable threadlock and a 3
mm hex wrench. Apply serviceable threadlock and tighten the M5 flat screws (A) to 3.6 N-m (32 in-lbs)
torque. If the screws are not tightened, vibration may loosen screws and damage caselink threads.
5. Tighten the set screws (E) in each caselink using a 2.5 mm hex wrench. Tighten the screws to 3.6 N-m
(32 in-lbs) torque.
6. Install brackets (F or G) on modules and verify measurements before drilling and tapping holes (M6
18-8 1.0 pitch). The Mounting diagram below is not at 1:1 scale. The dimensions can be used as a
guide to tap the holes. The mounting holes in the brackets area slightly oversized to allow for assembly
tolerances. Apply serviceable threadlock to M6 screws (B) and install them through the three (3) holes
in each bracket (F or G) and into the tapped holes. Tighten the screws to 6.1 N-m (54 in-lbs) torque.
Installing a UPX kit (1-UPX002-2) Uninterruptible Power Supply
Each UPX kit includes four (4) SO-227-1002109 (M4) screws to install
the uninterruptible power supply on a mounting bracket.
1. Mount a UPX unit (H) on a bracket (F or G) using serviceable
threadlock, four (4) M4 screws (C) and a 3 mm hex wrench.
2. Apply serviceable threadlock and tighten the screws (C) to 1.8 N-m
(16 in-lbs) torque or vibration may loosen screws and damage
bracket threads.
B4547-1.0 en HBM: public 3 HBM

measure and predict with confidence
B4547-1.0 en SO-269-1002182 HBM: public
