EC-Declaration of Conformity
in accordance with the EU Machinery Directive 2006/42/EC
applicable as from December 29th 2009:
HE-VA ApS
N. A. Christensensvej 34,
DK-7900 Nykøbing Mors
Denmark
hereby confirms that the following machine has been manufactured
in accordance with the Council
Directive 2006/42/EC.
The declaration comprises the following machine:
Terra-Dan MKII
4,0 / 5,0 / 6,0 / 7,5m
No : _____________
Nykøbing, 29th Dec. 2009
Villy Christiansen
The undersigned is furthermore authorized to compile technical documentation for the above machine.

Terra-Dan MKII 24-04-2018
6
Delivery check
Upon delivery to the dealer/supplier as well as to the customer, check the Terra-Dan MKII for possible
damages.
Machine description
Range of applications
HE-VA Terra-Dan MKII is a trailed seedbed harrow which is available in 4,0m, 5,0m, 6,0m and 7,5m
working width. The standard Terra-Dan MKII has a strong frame construction with 4 bars, and either a
double roller, or a single roller with long finger harrow in front. The long finger harrow adjusts the
harrow depth centrally via the lift arms, ensuring a precise harrow depth in all soil types.
HE-VA Terra-Dan MKII has a wide range of extra equipment, meaning that the harrow may be built
individually depending on the actual soil conditions and harrow tasks.
Technical specifications
Working width 4,0m 5,0m 6,0m 7,5m
Transport width 2,45m 2,45m 2,45m 2,45m
Transport height 2,4m 2,9m 3,4m 3,9m
Power required HP 105+ 120+ 135+ 150+
Required no. of
double-acting oil outlets 2 pcs. 2 pcs. 2 pcs. 2 pcs.
No. of tines 47/26 pcs. 59/33 pcs. 70/40 pcs. 82/46 pcs.

Terra-Dan MKII 24-04-2018
7
Safety instructions for Terra-Dan MKII
Do not start-up the machine if there are persons in exposed positions* within a hazardous area**.
When persons are in exposed positions (e.g. in connection with adjustment, maintenance, attachment and
uncoupling), the following conditions must be observed:
1. The machine must be lowered to firm ground.
2. The hydraulics must be relieved.
3. The tractor must be stopped and the key removed from the ignition switch.
4. The driver must ensure that no persons are in exposed positions during the operation.
* Persons in exposed positions: Any person who is wholly or partly within a hazardous area.
** Hazardous area: On and under the machine within a distance of 10 m from the machine.
Most accidents that happen in connection with the operation, transport and maintenance of machines are
caused by non-compliance with the most elementary safety conditions.
Therefore it is vital that anybody working at the machine carefully complies with the safety instructions
as well as other instructions applying to the machine.
The machine may only be operated, maintained and repaired by persons, who are familiar with this work
and who are further familiar with the possible elements of danger with this particular machine.
CAREFUL! Rotating parts and loose-fitting clothing make up a dangerous combination.
IMPORTANT! Due to the risk of falling down, it is extremely hazardous to stand on the machine
frame during operation of the machine attached to a tractor.

Terra-Dan MKII 24-04-2018
8
Safety and instructions on hydraulics
1. The maximum working pressure is 225 bar.
2. It is advisable to label the attachment parts at hydraulic connections between the tractor
and the tool in order to eliminate incorrect operation!
3. When checking for hydraulic leaks, use suitable safety wear (eye protectors, gloves, etc.)
High-pressure hydraulic oil may penetrate the skin and cause dangerous injuries.
In case of injury, consult a doctor immediately. RISK OF INFECTION!
4. Before operating the hydraulics, lower the machine to firm ground.
Relieve the hydraulics, stop the motor and remove the ignition key.
5. Check the hydraulic hoses on a regular basis, however, every six months as a minimum due to
any cracks, wear and tear, etc. Replace any defective hoses immediately.
The life of hydraulic hoses is maximum 5 years.
New hydraulic hoses must meet the manufacturer's requirements.
Transport on public roads
Check before transport on public roads that the attachment of the machine at the tractor is in accordance
with the local rules and regulations in force (permitted total weight, permitted axle load, transport width,
lights, warning signs, etc.).

Terra-Dan MKII 24-04-2018
9
Labels on the machine
On your machine there are several labels containing both practical advice and safety precautions.
Please be sure to read the labels and inform all those who operate the machine of the safety instructions
in the manual.
Keep the labels clean and legible –if not they should be replaced.
Forklaring på maskinens mærkater
A Plate with number and year of manufacture.
B Study the Operating Instructions thoroughly before any operation of the machine and
observe all safety instructions.
C Tighten up the bolts regularly. If this is not respected, our warranty obligations will no
longer apply.
D Make sure that the working area is clear before unfolding the wing sections. Never walk
under a suspended section.
A
B
C
D

Terra-Dan MKII 24-04-2018
10
Start-up of the machine
General information
Terra-Dan MKII lift-mounted requires 1 double-acting oil outlet.
Terra-Dan MKII trailed requires 2 double-acting oil outlets.
Attachment and uncoupling
From transport to working position:
1. Raise the machine to maximum transport height.
2. First, fold in the wings to relieve the locking pawls, then, extend the wings completely, and put
the hydraulic outlet in neutral, NOT flow position.
3. Lower the machine and adjust the working depth.
(See section: Instructions and adjustment of the harrow)
From working to transport position:
1. Raise the machine to maximum transport height.
2. Fold in the wing sections. Make sure that the wing sections are locked.
Maintenance
After the first 10 hours of operation, retighten the machine. Check hydraulic hoses, fittings and
cylinders for leaks and retighten.
Ensure on a regular basis that all bolts are tightened.
Before the winter storage, wash and lubricate the machine. If you use high-pressure cleaner, do
not spray directly on the ball bearings. After the washing, you may spray the machine with oil.

Terra-Dan MKII 24-04-2018
11
Lubrification
For lubrication, maintenance and repair, the Terra-Dan MKII must be lowered, the tractor must be braked
and the motor stopped.
The trailed Terra-Dan MKII has 36 lubrication points, and the lift-mounted model has 28. The typical
lubrication points are located at spindles, wheel bearings and wing arms. All Terra-Dan MKII have to be
lubricated after 8 working hours as well as after cleaning in order to press out any water and dirt.
Note! However, the double-sealed ball bearings in the roller should only be lubricated every
20 working hours and by 1-2 strokes so that the sealing rings are not pressed out.
Important! The hydraulic system is filled with oil type Hydro Texaco HD32.
Terra-Dan MKII 7,5m trailed
w/single roller

Terra-Dan MKII 24-04-2018
12
Assembly instructions
Assembling the drawbar and wheel support
Mount the drawbar and its cylinder in the lowest holes of the three-
point linkage.
Mount the wheel support at the rear of the main frame, using the
Ø50mm pin. Next, mount the wheel cylinder between the frame and
the support.
Connect hydraulic hoses and fasten them to the parking device on
the drawbar.
Mounting the square tube roller / V-profile roller
Mount the roller arms (pos. 6 og 7) onto the harrow.
Pos. 6 should be mounted towards the centre of the harrow.
Mount the roller bar and the roller, as shown below.

Terra-Dan MKII 24-04-2018
13
Instructions and adjustment of the harrow
Attaching the harrow
Attach the Terra-Dan MKII in the lift arms of the tractor.
Connect hydraulic hoses.
Adjusting the parallel operation of the harrow
Fold out the harrow, and lower it to the ground. Make sure the
working depth is even on all the tine bars by comparing the end
plates. They should be parallel to the ground on both sides.
* If they are not, adjust the length of the top link (lift-mounted
models). On trailed models, either adjust the height of the tractor lift
arms or use the clips of the drawbar cylinder.
Depth adjustment of the harrow
Adjust the depth by re-positioning the pin in the adjustment plate
by the roller arms. The pins must be in the same position on
all 4 plates to avoid torsion of the harrow frame.
If a significant adjustment is needed, follow the above procedure
for resetting the parallel operation of the harrow.
Adjusting the Spring-Board
The height of the Spring-Board is adjusted using
the 2 spindles, or by raising / lowering the tractor lift arms.
Please note, that this may affect the parallel operation of the harrow.
A hydraulic angle adjustment for the Spring-Board is available as extra
equipment.
Locking device
Make sure that the wing sections are locked before transport.
1
1

Terra-Dan MKII 24-04-2018
14
Spare parts list
Drawbar (befor Feb. 2016)
Drawbar (after Feb. 2016)

Terra-Dan MKII 24-04-2018
15
Pos.
Item no.
Designation
No.
1
630931052
Drawbar (for Feb. 2016)
1
630931057
Drawbar (from Feb. 2016)
1
2
630771200
Parking device (for Feb. 2016)
1
3
0449430
Tube support, double Ø14/Ø14 (for Feb. 2016)
4
4
690210211
Top plate f/double tube support (for Feb. 2016)
1
5
0234790
Bolt M8x40 (for Feb. 2016)
1
6
0462750
Cylinder 90/40x280 Ø35/Ø32,5 for 4,0m, 5,0m and 6,0m
1
690200274
Gasket kit
0463302
Cylinder 100/40x280 Ø35/Ø32 for 7,5m
1
0463372
Gasket kit
7
69435155G
Pin Ø35 L=155mm (for Feb. 2016)
1
69435170G
Pin Ø35 L=170mm (from Feb. 2016)
1
8
630532600
Lock bush f/pin head
1
9
0235330
Bolt M12x25mm
1
10
690103173
Bolt M20x70 10.9
6
11
0272310
Facet plate M20
12
12
0264110
Self-locking nut M20
6
13
630757034
Pivoting crossbar
1
14
630757017
Pivoting towing eye (strong)
1
15
630757043
Pivoting towing eye (strong)
1
16
690136029
Lubricating nipple M8
2
17
690200664
Distance clip, 6.2mm, blue
18
690200665
Distance clip, 9.4mm, red
19
690200666
Distance clip, 18.8mm, yellow
20
690200667
Distance clip, 31.6mm, black
21
690200668
Distance clip, 50.8mm, silver
22
0272380
Facet plate ø36 (from Feb. 2016)
4
23
7345004
Parking device (from Feb. 2016)
1
24
7345003
Screen for parking device (from Feb. 2016)
1
25
0246060
Carriage bolt M6x16 (from Feb. 2016)
4
26
0272240
Facet plate Ø6 (from Feb. 2016)
4
27
0264040
Self-locking nut M6 (from Feb. 2016)
4
28
0235360
Bolt M12x40 (from Feb. 2016)
2
29
0272270
Facet plate Ø12 (from Feb. 2016)
4
30
0264070
Self-locking nut M12 (from Feb. 2016)
2

Terra-Dan MKII 24-04-2018
16
Middle frame

Terra-Dan MKII 24-04-2018
17
Pos.
Item no.
Designation
No.
1
1160246
Middle frame (to machine no 32432)
1
1300114
Middle frame (from machine no 32433)
1
2
69537129B
Pin for lift arm Ø37 L=129
2
3
690134008
Ring split (Øll,5 m/Ø60)
2
4
1140361
Pin Ø32 L= 149
2
5
1069950
Washer Ø33
2
6
0378600
Ring split (Ø11 w/Ø40 ring)
7
1160274
Support leg
2
8
1030280
Pin Ø16
2
9
0377400
R-clip Ø4
2
10
690109202
Plug
2
11
690200270
Cylinder f/wheel support for 4m, 5m and 6m
(to machine nr 33644)
1
690200274
Gasket kit
1141135
Cylinder f/wheel support for 7,5m (to machine nr 33644)
1
0463372
Gasket kit
7345079
Cylinder f/wheel support (from machinnr 33645)
for 4m, 5m, 6m og 7,5m
1
0463372
Gasket kit
12
69440110G
Pin Ø40 L=110
1
13
630532600
Lock bush
8
14
0235330
Set bolt M12x25mm
8
15
69440255G
Pin Ø40 L=255 (to machine no 32432)
4
69440280G
Pin Ø40 L=280 (from machine no 3243)
4
16
1160344
Cylinder f//side section for 4,0m, 5,0m, 6,0m and 7,5m
2
1160344
Cylinder f//side section (for 7,5m with V-profile models)
4
690200268
Gasket kit
17
69440195G
Pin Ø40 L=195
2
18
69450400G
Pin Ø50 L=400
1
19
1160193
Pawl (L)
1
20
1160276
Pawl (R)
1
21
690200170
Cylinder
1
690200175
Gasket kit
22
690103130
Bolt M16x70 10.9
1
23
690103133
Bolt M16x60 10.9
1
24
690103135
Bolt M16x80 10.9
2
25
0272290
Facet plate Ø16
8
26
0264090
Lock bush M16
8
27
1300120
Screen (from machine no 32433)
1
28
0272250
Facet plate Ø8
10
29
0234750
Bolt M8x20
6
30
1140951
Pin f/wing
2
31
0234833
Bolt M8x70
2
32
0264050
Lock bush M8
2

Terra-Dan MKII 24-04-2018
18
Wheel support

Terra-Dan MKII 24-04-2018
19
Pos.
Item no.
Designation
No.
1
1160565
Wheel support, 1700 kg hub (long 2418mm) (to machine no. 31283)
(For machines with after harrow behind the roller)
1
1160565
Wheel support, 2500 kg hub (from machine no. 31284 to 33644)
(long 2418mm)
(For machines with after harrow behind the roller)
1
1160939
Wheel support, 2500 kg hub (long 2418mm) (from machine no. 33645)
(For machines with after harrow behind the roller)
1
1140873
Wheel support, 1700 kg hub (short 1738mm) (to 1/9 2015)
1
1140873
Wheel support, 2500 kg hub (from 1/9 2015 to machine no. 33644)
(short 1738mm)
1
1141258
Wheel support, 2500 kg hub (from machine no. 33645)
(short 1738mm)
1
2
690141025
Hub 1700 kg
0395230
Sealing ring
0395210
Bearing 30206
0479000
Bearing 30209
0396470
Hub nut
690141039
Hub bolt
690141314
Hub cap
0396480
Castellated nut
690141030
Hub 2500 kg
0396420
Sealing ring
690140105
Bearing 30208
690140111
Bearing 30211
0396470
Hub nut
0396460
Hub bolt
690141033
Hub cap
0396480
Castellated nut
3
0396300
Wheel (complete) 400/60 15,5 14 Ply
2
4
0396650
Wheel (complete) 500/50 17 14 Ply
2
5
69450400G
Pin Ø50 L=400
1
6
0475400
Inner tension bush EG Ø60/50 L= 50mm
2
7
630532600
Lock bush
2
8
0235330
Set bolt M12x25mm
2
9
69430095G
Pin Ø30 L= 95 (to machine no. 33644)
1
69440090G
Pin Ø40 L= 90 (from machine no. 33645)
1
10
630835015
Lights bar
1
11
0521010
Warning triangle
1
12
0233860
Bolt M5x20
2
13
0272230
Facet plate Ø5
4
14
0264030
Lock bush M5
2
15
690103197
Bolt M16x50
4
16
0272290
Facet plate Ø16
8
17
0264090
Lock bush M16
4

Terra-Dan MKII 24-04-2018
20
Wing section
Pos.
Item no.
Designation
4 m
5 m
6 m
7,5m
1
1141108
Wing (L)
1
1141116
Wing (R)
1
1140997
Wing (L)
1
1140996
Wing (R)
1
1140901
Wing (L)
1
1140902
Wing (R)
1
1141012
Wing (L)
1
1141013
Wing (R)
1
2
1141112
Top wing (L)
1
1141117
Top wing (R)
1
1140992
Top wing (L)
1
1140991
Top wing (R)
1
