HE-VA Tip-Roller User manual

+
Manual no. 8000331-03 150121

Contents
EC DECLARATION OF CONFORMITY...............................................................................................4
Description of the machine .........................................................................................................................5
Delivery Check.............................................................................................................................................5
Transport Brackets .....................................................................................................................................5
Specifications................................................................................................................................................6
Tecnical specifickations ...........................................................................................................................6
Operating Instructions................................................................................................................................6
Attachment .................................................................................................................................................6
Transport ....................................................................................................................................................7
When rolling...............................................................................................................................................7
Maintenance.................................................................................................................................................8
Safety at the Tip-Roller...............................................................................................................................9
Safety Instructions, regarding Hydraulic System...................................................................................10
Disposal.......................................................................................................................................................10
Markings on the machine..........................................................................................................................11
Safety –and other markings on the machine.......................................................................................11
Spring-Board..............................................................................................................................................12
Installation of Cylinder on Spring-Board.................................................................................................12
Notes............................................................................................................................................................13
Spare Parts List..........................................................................................................................................14
Drawbar before June 2010 .......................................................................................................................14
Drawbar after June 2010 ..........................................................................................................................16
Center Section ..........................................................................................................................................19
Wing - Side Section..................................................................................................................................21
Roller section...........................................................................................................................................23
Support bearing.......................................................................................................................................24

Roller Rings.............................................................................................................................................25
Roller, only 6,3m and 9,5m......................................................................................................................28
Hydraulic brakes.......................................................................................................................................29
Air brakes .................................................................................................................................................30
Hydraulics ..................................................................................................................................................32
Tip and folding.........................................................................................................................................32
Hydraulic circle: Supporting leg ..............................................................................................................34
Spring-Board Center Section 6.3m –9.5m - 10.2m................................................................................35
Spring-Board Side Section (left) 6.3 m....................................................................................................38
Spring-Board Side Section (left) 7.3 - 8.2m.............................................................................................39
Spring-Board Side Section (left) 9.5m + 10.2m.......................................................................................40
Easy –Change............................................................................................................................................43
Lights ..........................................................................................................................................................44
LED - Light set.........................................................................................................................................44
Lighting set: El. diagram..........................................................................................................................45

EC DECLARATION OF CONFORMITY
in accordance with the EU Machinery Directive 2006/42/EC
applicable as from December 29th 2009:
HE-VA ApS
N. A. Christensensvej 34,
DK-7900 Nykøbing Mors
hereby confirms that the following machine has been manufactured in accordance with the Council
Directive 2006/42/EC.
The declaration comprises the following machine:
Tip –Roller 6,3m –7,3m –8,2m –9,5m –10,2m
Nykøbing the 29th December 2009 Villy Christiansen
The undersigned is furthermore authorised to compile technical documentation for the above machine.

UK Tip-Roller 6,3 - 7,3 - 8,2 - 9,5 - 10,2 15-01-2021
5
Description of the machine
The Tip-Roller is a 3-sectioned hydraulic, wheel mounted roller. Tip-Roller is to be used for packing the
top soil, to maintain the content of moisture in it, and to eliminate not solid stones from the surface of the
cultivated area.
The roller sections has an independent suspension. Side sections are center-mounted in an intermediate
joint, connecting the side sections to the wheel frame, which gives the sections a perfect adaption to the
ground in uneven areas. The changing between transport- and work position is by hydraulic force. The
roller has a low and compact transport position with a width of 2,42 meters.
Read the manual before operating the roller and strictly follow the safety instructions.
The design is subject to modification without notice.
Delivery Check
Check the roller for any damages. Check the hydraulic hoses for cuts and squeezing damages. Check also
the other hydraulic components, are not damaged during transport.
Check that the frame construction has not been damaged. You should also check that the roller blocks
have not been exposed to impacts, which may have damaged the cast roller rings or the double-sealed ball
bearings.
Finally check that the transport wheels are tightened and OK.
Check the air pressure in the tyres: approx. 3.8 bar / 55 psi
Instructions for unloading and final assembly
In order to minimize the roller´s space during transport, the roller is
supplied partially separated from the factory. If the machine is delivered
unassembled, it must therefore be completely installed first.
Transport Brackets
At delivery the machine is mounted with brackets for hoisting gear,
which is not painted.
These brackets is for attachment of chains or straps, when loading or
unloading the machine from the transport vehicle, and they must be
dismantled before use.

UK Tip-Roller 6,3 - 7,3 - 8,2 - 9,5 - 10,2 15-01-2021
6
Specifications
3-section hydraulic wheel-mounted field roller with free movement in all sections. The roller is delivered
with a working width of 6.3 - 7.3 - 8.2 - 9.5 or 10.2 meters, respectively, with 5 different ring types:
cambridge- cam- star- 2D wave- cross-kill ring and rigid roller.
The side sections of 8.2m and all 3 sections of 9.5m and 10.5m are fitted with support bearings.
Tecnical specifickations
Work width
6,3 m
7,3 m
8,2 m
9,5 m
10,2 m
Width in workposition
6,55 m
7,55 m
8,45 m
9,75 m
10,45 m
Length
4.95 m
4,95 m
4,95 m
5,8 m
5,8 m
Transport width
2,42 m
2,42 m
2,42 m
2,46 m
2,46 m
Transport hight
w / without add.equipment
1,72 /
2,54 m
1,72 /
2,54 m
1,72 /
2,54 m
1,72 /
2,54 m
1,72 /
2,54 m
Wheel size
11.5/80x15.
3 –14 PLY
11.5/80x15.
3 –14 PLY
11.5/80x15.
3 –14 PLY
400/60x15,5
- 10 PLY
400/60x15,5
- 10 PLY
Tyre pressure
3,8 bar / 55 psi
Oil pressure
min. 150 bar
Hydraulic outlets
2 pc doubble function
Quick couplings, standard
Sterling type E 402
Hydraulic oil
System is filled with Hydro Texaco HD32
Operating Instructions
Attachment
On delivery the roller is in transport position. When the roller is attached, check that the towing hook
height is 400-500 mm. Reverse the tractor, put in and secure the draw bolt.
+÷
+
÷
Raise the support leg and place it in the transport fittings on top of the drawbar. Now fit the four
hydraulic hoses.

UK Tip-Roller 6,3 - 7,3 - 8,2 - 9,5 - 10,2 15-01-2021
7
The hoses for the tip cylinder are provided with red tie strap.
The hoses for the wing cylinder are provided with blue tie strap.
Important:
Transport
At change-over for transport, the roller is tipped totally backward by pressurising the tip cylinder.
Now pressurise the wing cylinder so that the side sections turn forward, towards the stop on the transport
fittings of the drawbar.
When both sides lie in parallel with the drawbar, they are lowered down into the transport fittings by
unpressurising the tip cylinder. Then relieve the pressure on all hydraulic hoses, and the roller is ready for
transport.
INSTRUCTIONS FOR TRANSPORT AT PUBLIC ROADS:
Before transport at public roads, make sure that the attachment of the implement to the tractor, is in accordance
with the local rules and regulations in force (permitted total weight, permitted axel load, transport width,
lights and warning signs).
FRONT AXEL LOAD:
When the implement is attached and at maximum load, the tractors driving properties must be ensured.
Check that the front axel is sufficiently loaded. The front axel load must be at least 20% of the tractors
weight. Permitted axel load and total weight for the tractor must be respected.
NB! The driving, controlling and braking properties are affected by the attached implement
When rolling
Speed: max. 10 km/h.
When turning, drive in wide curves as far as possible. The turning should be performed no sharper, than
all roller rings are still rotating forward.
Only lower the wheels when making ready for transport position.
Do not drive over any large stones, which are not moveable.
Check that the male end mounted by the factory fits the female end of the
quick couplings of the tractor.
Now pressurise the tip cylinder (red) so that the side sections are tipped free of the
transport fittings.
Then the wing cylinder (blue) is pressured so that the wings are turned as much
back as possible.
Now relieve the pressure on the tip cylinder, and the roller will tip forward down
to working position. When the bottom has been reached, let go of the hydraulic
handle and the roller is ready for use.

UK Tip-Roller 6,3 - 7,3 - 8,2 - 9,5 - 10,2 15-01-2021
8
Maintenance
A. After approximately 10 hours of operation, retighten wheels, ball bearings and stop rings. Check
hoses, fittings and cylinders for any leaks and retighten.
Maximum torque in Nm. w/lubricated thread
Metric thread
Quality 8.8
Quality 10.9
Quality 12.9
M10x1,5
47
65
79
M12x1,75
81
114
136
M14x2,0
128
181
217
M16x2,0
197
277
333
M18x2,5
275
386
463
M20x2,5
385
541
649
M22x2,5
518
728
874
M24x3,0
665
935
1120
Wheel nut M18x1,5 fine thread
433 Nm
Wheel nut M22x1,5 fine thread
803Nm
Controle tightening:
•of hub bolts, 386 Nm according to specifications
•flange for towing eye, 6 pc of bolts 541 Nm
B. After approximately every 10 hours of operation, lubricate all movable parts of the side sections
as well as the three lubricating points of the wing cylinder and cylinder pins and suspension at
Spring-Board. After approximately every 30 hours of operation, lubricate the 3 pins in the
drawbar.
C. After the season, clean the roller and lubricate with grease and oil.
Important:
Lubricate the piston rods with grease.

UK Tip-Roller 6,3 - 7,3 - 8,2 - 9,5 - 10,2 15-01-2021
9
Safety at the Tip-Roller
Do not operate the machine, if any people
1
are at risk in the dangerous area.
2
When persons are at risk in the dangerous area (e.g. when doing adjustments, maintenance or connect or
disconnecting), the following points must be met:
•Lower the machine on solid ground.
•Hydraulic must be relieved.
•Tractor must be turned off, and the key removed.
•Driver must be aware of, when operating that there is no persons at risk in the
dangerous area.
Most accidents when operating the machine, transporting and doing maintenance occurs, when avoiding
the most simple safety regulations.
For this reason, it is of highest importance, that any person who is operating the machine, strictly follows
the safety regulations and other instructions, which belongs the machine.
The machine must only be operated, maintained and fixed by persons, who is confidential with and
skilled for this work and is aware of moments of danger, which can occur.
ATTENTION!! Rotating parts and loose in a loose condition, is a dangerous combination.
IMPORTANT!! It is strictly prohibited for any person to take place on the frame of the
machine, when it is either operating or the tractor is idling.
1
People at risk: Any person, who is completely or partially in the dangerous area.
2
Dangerous area: At the machine and underneath it, and in distance of 4 m from it.

UK Tip-Roller 6,3 - 7,3 - 8,2 - 9,5 - 10,2 15-01-2021
10
Safety Instructions, regarding Hydraulic System
1. The highest allowable pressure, is 225 bar.
2. It is recommended to mark the hydraulic connections between the implement and tractor, to avoid
incorrect operation!
3. When checking for hydraulic leeks, suitable safety gear must be used due to danger. (Safety
goggles , gloves, etc.)
At high pressure, Hydraulic oil can penetrate the skin and course serious injuries.
At injuries, consult a doctor immediately. RISK OF INFECTION!
4. Before any work at the hydraulic system, the implement must be lowered to solid ground.
Pressure must be relieved, engine stopped, and ignition key removed.
5. Check the hydraulic hoses on a regular basis, however, every six months as a minimum due to any
cracks, wear and tear, etc. Replace any defective hoses immediately.
6. Hydraulic hoses lasts for no more than 5 years.
New hydraulic hoses must be identical to the manufacturers specifications.
Disposal
When, after many years of use, the machine is to be regarded as end-of-life, it must be disposed of to a
registered and approved product dealer. This will carry out the statutory discharge and disposal of
hydraulic oil, as well as sorting materials for further processing for recycling.

UK Tip-Roller 6,3 - 7,3 - 8,2 - 9,5 - 10,2 15-01-2021
11
Markings on the machine
Several markings are located at your machine, which contains safety regulations and other instructions to inform
about correct operating.
Please read these instructions carefully, and make the driver aware about the markings and safety regulations in
this Operating Instructions. Keep the markings clean and readable. If they are not, they must be replaced.
Safety –and other markings on the machine
Study the Operating Instructions thoroughly before any operation
of the machine and observe all safety instructions.
Take care that no persons are within the machine’s hazardous
area during the unfolding and folding procedure.
Plate with number and year of manufacture.
Tighten up the bolts regularly. If this is not performed, our
warranty obligations will no longer apply.

UK Tip-Roller 6,3 - 7,3 - 8,2 - 9,5 - 10,2 15-01-2021
12
Spring-Board
The Spring-Board requires 1 double-acting Hydraulic outlet on the tractor. The tine angle is hydraulically
controlled from the driver's cab and the depth control is done manually. The tine work independently, but
may be connected by means of transverse locking fittings (additional equipment) if a greater levelling
effect is required. The change-over is done very easily and quickly without any tools.
Installation of Cylinder on Spring-Board
The hydraulic cylinders are installed as shown below. It is important that the installation is performed
properly to get the correct force on the cylinders.
The ring type decides whether the cylinders must be installed in hole 1 or 2. If the machine has 450 or
550 mm rings, the cylinders must be located in hole 1 and hole 1a or 1b. If with 620 mm rings, the
cylinders must be located in hole 2 and hole 2a or 2b.

UK Tip-Roller 6,3 - 7,3 - 8,2 - 9,5 - 10,2 15-01-2021
13
Notes

UK Tip-Roller 6,3 - 7,3 - 8,2 - 9,5 - 10,2 15-01-2021
14
ATTENTION: Parts list must be read as follows: Drawings are always placed before/above the belonging
parts list
Spare Parts List
Drawbar before June 2010
Pos.
Art. No.
Designation
6,3
7,3
8,2
9,5
10,2
1
630771010
Front drawbar (Danish)
1
1
1
1
630831000
Front drawbar (Danish)
1
1
1
630771100
Front drawbar (German)
1
1
1
1
630831100
Front drawbar (German
1
1
2
690141102
Support leg 6000 kg
1
1
1
1
1
2
690141004
Support leg 6000 kg (German)
1
1
1
1
1
3
69516094A
Pin ø16 L=94
1
1
1
1
1
4
690133005
Hairpin split ø4
1
1
1
1
1
5
690103075
Bolt M10x25
2
2
2
2
2
6
630771200
Parking device f/hose
1
1
1
1
1

UK Tip-Roller 6,3 - 7,3 - 8,2 - 9,5 - 10,2 15-01-2021
15
Pos.
Art. No.
Designation
6,3
7,3
8,2
9,5
10,2
7
690210212
Welding plate f.double pipe support
1
1
1
1
1
8
690210210
Pipe support double ø14/ø14
4
4
4
4
4
9
690210211
Top plate f/double pipe support
1
1
1
1
1
10
690210213
Screw f/double pipe support
1
1
1
1
1
11
630775000
Rear drawbar
1
11
630785000
Rear drawbar
1
11
630765000
Rear drawbar
1
11
630835000
Rear drawbar
1
1
12
690103190
Bolt M16x65 8.8
6
6
6
12
690103164
Bolt M20x70 8.8
6
6
13
690117013
Faceted disc ø16
12
12
12
13
690117005
Faceted disc ø20
12
12
14
690113008
Self-locking nut M16
6
6
6
14
690113009
Self-locking nut M20
6
6
15
630530300
Transport fittings 18”/ø450 mm
2
2
2
2
2
15
630530400
Transport fittings 21”/ø500 mm
2
2
2
2
2
15
630805100
Transport fittings 24”/ø625 mm
2
2
2
2
2
16
690117013
Faceted disc ø16
4
4
4
4
4
17
690103128
Bolt M16x55 8.8
4
4
4
4
4
18
69435175G
Pin ø35 L=175
2
2
2
2
2
19
630532600
Locking sleeve for pin head
4
4
4
4
4
20
690101101
Bolt M12x25
4
4
4
4
4
21
69435185G
Pin ø35 L=185
1
1
1
1
1
22
69435170G
Pin ø35 L=170
1
1
1
1
1
23
690136029
Lubricating nipple M8
3
3
3
3
3
24
690141211
Towing eye (Danish)
1
1
1
1
1
25
690105003
Towing eye (German)
1
1
1
1
1
26
630801001
Drawbar extension 500mm (Extra
equipment)
1
1
1
26
630801003
Drawbar extension 500mm
1
1

UK Tip-Roller 6,3 - 7,3 - 8,2 - 9,5 - 10,2 15-01-2021
16
Drawbar after June 2010
Machine no: 341713

UK Tip-Roller 6,3 - 7,3 - 8,2 - 9,5 - 10,2 15-01-2021
17
Pos.
Art. No.
Designation
6,3
7,3
8,2
9,5
10,2
1
630771000
Drawbar
1
1
1
1
630771020
Drawbar (after machin no. 344524)
1
1
1
1
630831015
Drawbar (after machin no. 341713)
1
1
1
630831021
Drawbar w/centre mounted supportle
(after machin no. 342015)
1
1
1
630771023
Drawbar prepared for new parking device f/hose
1
1
1
1
630831027
Drawbar prepared for new parking device f/hose
1
1
2
690141102
Support leg 6000 kg
1
1
1
1
1
2
690141099
Support leg hydraulisk (after machin no. 341713)
1
1
2
690141098
Support leg hydraulisk (after machin no. 342015)
1
1
3
69516094A
Pin Ø16 L=94
1
1
1
1
1
4
690133005
Hairpin splitØ4
1
1
1
1
1
5
690103075
Bolt M10x25
2
2
2
2
2
6
630771200
Parking device f/hose
1
1
1
1
1
7
690210212
Welding plate f/double pipe support
1
1
1
1
1
8
690210210
Pipe support double Ø14/Ø14
4
4
4
4
4
9
690210211
Top plate f/double pipe support
1
1
1
1
1
10
690210213
Screw / double pipe support M8x65 mm
1
1
1
1
1
11
630775000
Rear drawbar
1
11
630775020
Rear drawbar (after machin no 344524)
1
11
630785000
Rear drawbar
1
11
630785020
Rear drawbar (after machin no 344524)
1
11
630765000
Rear drawbar
1
11
630765020
Rear drawbar (after machin no 344524)
1
11
630835000
Rear drawbar
1
1
11
630835025
Rear drawbar (after machin no 348298)
1
1
12
690103275
Bolt M16x65 10.9
6
6
6
12
690103173
Bolt M20x70 10.9 (after machin no 344524)
6
6
6
12
690103173
Bolt M20x70 10.9
6
6
13
690117013
Faceted disc Ø16
12
12
12
13
690117005
Faceted disc Ø20 (after machin no 344524)
12
12
12
13
690117005
Faceted disc Ø20
12
12
14
690113008
Self locking nut M16
6
6
6
14
690113009
Self locking nut M20 (after machin no 344524)
6
6
6
14
690113009
Self locking nut M20
6
6
15
630530300
Transport fitting 18”/Ø450 mm
2
2
2
2
2
15
630530400
Transport fitting 21”/Ø500 mm
2
2
2
2
2
15
630805100
Transport fitting 24”/Ø625 mm
2
2
2
2
2
16
690119008
Faceted discØ16_
4
4
4
4
4

UK Tip-Roller 6,3 - 7,3 - 8,2 - 9,5 - 10,2 15-01-2021
18
Pos.
Art. No.
Designation
6,3
7,3
8,2
9,5
10,2
17
690103128
Bolt M16x55 8.8
4
4
4
4
4
18
69435175G
Pin Ø35 L=175
2
2
2
2
2
19
630532600
Locking sleeve for pin head
4
4
4
4
4
20
690101101
Bolt M12x25
4
4
4
4
4
21
69435185G
Pin Ø35 L=185
1
1
1
1
1
22
69435170G
Pin Ø35 L=170
1
1
1
1
1
23
690136029
Lubricating nipple M8
3
3
3
3
3
24
630757023
Drawbar ball type
1
1
1
1
1
24a
690105012
Loose towing eye ball type
1
1
1
1
1
25
630757028
Drawbar Ø50 pivoted M16 bolts
1
1
1
25a
690141211
Loose towing eye, Ø50 turnable
1
1
1
26
630779000
Drawbar extension 500mm (extra equipment)
1
1
1
26
630779020
Drawbar extension 500mm (extra equipment)
(after machin no 344524)
1
1
1
26
630801003
Drawbar extension
1
1
27
630757013
Drawbar Ø40 solid M16 bolts
1
1
1
27a
690105003
Loose towing eye, Ø40
1
1
1
27
630757030
Drawbar Ø40 solid , strong model M20 bolts
1
1
27b
690105009
Loosse drawbar, ø40, strong model
1
1
28
630757017
Drawbar Ø50 pivoted M20 bolts
1
1
28a
690105006
Loose towing eye, Ø50 turnable
1
1
29
690103069
Bolt M20x80 10.9
6
6
29
690103275
Bolt M16x65 10.9
6
6
6
30
0272310
Faceted disc Ø20
12
12
30
0272290
Faceted disc Ø16
12
12
12
31
0264110
Self locking nut M20
6
6
31
0264090
Self locking nut M16
6
6
6
32
630757043
Drawbar pivoted M16 bolts, homologated
1
1
1
32a
690105004
Loose towing eye turnable, homologeret
1
1
1
33
7345001
Plate for parking device f/hose. 8 seats
1
1
1
1
1
33
7345002
Plate for parking device f/hose. 14 seats
1
1
1
1
1
34
7345003
Cover for parkingdevice hydr. hose
1
1
1
1
1
35
0246060
Bolt M6x16 FZB DIN603
4
4
4
4
4
36
0272240
Faceted disc 6mm, fzb
4
4
4
4
4
37
0264040
Self locking nut M6, fzb DIN985
4
4
4
4
4
38
0235360
Bolt (setbolt) M12x40mm,8.8 fzg
2
2
2
2
2
39
0272270
Faceted disc Ø12
4
4
4
4
4
40
0264070
Self locking nut M12
2
2
2
2
2
41
7345010
Complete parking device 8 seats (pos 33-40)
41
7345019
Complete parking device 14 seats (pos 33-40)

UK Tip-Roller 6,3 - 7,3 - 8,2 - 9,5 - 10,2 15-01-2021
19
Center Section

UK Tip-Roller 6,3 - 7,3 - 8,2 - 9,5 - 10,2 15-01-2021
20
Pos.
Art. No.
Designation
6.3
7.3
8.2
9.5
10,2
1
690141215
Wheel 11,5 / 80 x 15,3 - 14 PLY
2
2
2
1
690141335
Wheel 400/60 x 15,5 –14 PLY
2
2
2
630762000
Center frame
1
1
1
2
630832000
Center frame
1
1
2
630832039
Center frame
(from machin no. 341663)
1
1
2
630762100
Center frame with brake spider
1
1
1
2
630832100
Center frame with brake spider
1
1
2
630832110
Center frame with brake spider
(from machin no. 341663
1
1
3
690142001
Warning triangle
1
1
1
1
1
3a
690103014
Bolt M5x20
2
2
2
2
2
3b
690113002
Self-locking nut M5
2
2
2
2
2
3c
690117002
Faceted disc ø5
2
2
2
2
2
4
690141025
Hub 1700 kg
2
2
2
4
690141030
Hub 2500 kg
2
2
4
690141032
Hub w/brake 3750 kg TVZ, Axle 70x70
2
2
2
2
2
4a
690141039
Hub bolt M18x1.5x49
12
12
12
12
12
4b
690141055
Hub nut M18
12
12
12
12
12
4f
690141314
Hub cap ø62 (1700 kg hub)
2
2
2
4f
690141033
Hub cap ø80 (2500 kg hub)
2
2
4f
690141033
Hub cap ø80 (2500 kg hub w/brake)
2
2
5
690103138
Bolt M16x130
4
4
4
4
4
5a
690113008
Self-locking nut M16
4
4
4
4
4
5b
690117013
Faceted disc øØ16
8
8
8
8
8
5
69435148I
Pin Ø35 L=148
(from machin no. 341663)
2
2
5a
690136029
Lubricating nipple
(from machin no. 341663)
2
2
6
630532600
Locking sleeve for pin head
(from machin no. 341663)
2
2
7
690101101
Bolt M12x25 8.8
(from machin no. 341663)
2
2
