1-05-2100-1
1
Recommended Tools and Materials / Herramientas y Materiales Recomendados
teflón
plumber’s tape
MAGNA
Wall Mount Tub Spout
Salida para Tina de Pared
llave allen 1/2"
1/2" allen wrench
mixing valve
(not included)
cuerpo mezclador
(no incluido)
*15,7"
40 cm
*47,2"
120 cm
finished wall
pared con
acabado final
(Finished Floor Level)
(Nivel de Piso Terminado)
NPT
FFL 1/2-14 NPT - 1/2-14 NPSM nipple (included)
niple 1/2-14 NPT - 1/2-14 NPSM (incluido)
*1,37"
(3,5 cm)
1/2-14 NPT connector (not incluided)
conector 1/2-14 NPT (no incluido)
water supply line
línea de alimentación
UTV-048
This product can expose you to chemicals including lead, wich is known to the State of California to cause cancer.
For more information go to www.P65Warnings.ca.gov.
Este producto puede exponerlo a sustancias químicas, incluido el plomo, que es conocido por el estado de
California como causante de cáncer. Para obtener más información, visite www.P65Warnings.ca.gov.
Requerimientos de Instalación
Installation Requirements
1,40
20 137,89
Requerimientos de Instalación
Installation Requirements
Model / Modelo
Minimum / Mínima Maximum / Máxima
kg/cm²
PSI kPa kg/cm²
PSI kPa
UTV-048 5,624
80 551,58
Caution: Do not exceed the pressure of:
Precaución: No exceder la presión de: 8,788
125 861,84
This Installation Guide Applies to the Product in any Finishing.
Esta Guía de Instalación Aplica al Producto en Cualquier Acabado.
Thank you for choosing HELVEX products.
We are confident that the product reliably will exceed your highest expectations. This product's functionality,
aesthetics, durability, quality and support will grant you full satisfaction for years, thus reflecting Helvex's
commitment to quality, innovation and the environment.
Agradecemos su elección por los productos HELVEX.
Estamos seguros de que la confiabilidad del producto excederá sus más altas expectativas, cuya
funcionalidad, estética, durabilidad, respaldo integral y alta calidad le otorgarán plena satisfacción por años,
reflejando el compromiso con la calidad, innovación y el medio ambiente que forman parte de Helvex.
To reduce the risk of injury or property damage, please read all instructions before installing the product.
Wear safety glasses. For any construction, installation, alteration, extension or repair, comply with your
local building codes. The product's illustration may vary in appearance to the actual product as result of
the continuous improvement process it is subject to.
For the correct functioning of these products, the recommended water pressures is:
Para el correcto funcionamiento de estos productos, se recomiendan las siguientes presiones:
*Recommended Dimensions
*Medidas Recomendadas
Unscrew the nipple (included) from the tub spout. / Desenrosque el niple
(incluido) de la salida de tina .
Screw the nipple (included) to the connector (no included). / Enrosque
el niple (incluido) en el conector (no incluido).
Screw the tub spout in to the nipple. / Enrosque la salida de tina en el niple.
2
Troubleshooting / Posibles Causas y Soluciones
2
1/2-14 NPT - 1/2-14 NPSM nipple (included)
niple 1/2-14 NPT - 1/2-14 NPSM (incluido)
tub spout
salida de tina
1/2" allen wrench (not included)
llave allen 1/2” (no incluida)
3
1/2-14 NPT connector ( not incluided)
conector 1/2-14 NPT (no incluido)
Apply plumber´s tape
around the threads.
Coloque teflón en las
cuerdas.
4
Problem / Problema Causes / Causas Solutions / Solución
Plumber’s tape was not applied on the connections. /
No se colocó teflón en las conexiones.
Apply plumber´s tape on the connections. (Page 2, step 3 and 4). /
Coloque teflón en las conexiones (Pág. 2, paso 3 y 4).
There is a leak in the spout. /
Hay fuga en la salida.
gasket
empaque
It is very important to follow the instructions below to preserve HELVEX products
finishings, shiny and in perfect conditions:
1. Use only water and a clean cloth.
2. Do not use fibers, powders, abrasives, or chemicals.
3. Do not use sharp objects to clean the finishings.
4. It is recommended to clean your device daily.
Visit our website www.helvexusa.com
Es muy importante seguir las siguientes instrucciones para conservar los
acabados de los productos HELVEX, con brillo y en perfecto estado:
1. Utilice únicamente agua y un paño limpio.
2. No utilice fibras, polvos, abrasivos, ni productos químicos.
3. No utilice objetos punzo-cortantes para limpiar los acabados.
4. Se recomienda realizar la limpieza de su producto diariamente.
Visite nuestra página www.helvexusa.com
Cleaning Recommendations / Recomendaciones de Limpieza
Apply plumber´s tape
around the threads.
Coloque teflón en las
cuerdas.
