Herman Miller Mora Cantilever Installation instructions

Parts Included
Additional Products Needed - Sold Seperately
Tools Required
HermanMiller
Mora™System Cantilever Installation and
Disassembly for Recycling Instructions.
How to assemble your Cantilever.
Wall Cabinet Bracket
CH646. Surface Wall Attachment Support (2)
Power Driver
Level
CH Series Wall Mounted Cabinet or Work Surface
Toggle Bolt (4)
#10-12 x 5/8 Pan Head
Tapping Screw(4) #8-32 x 1 Pan Head
Machine Screw(4)
Cantilever
Step 1
Phillips Bit
1/2” Drill Bit
1/8” Drill Bit
Safety Glass
. Position top Wall Cabinet Bracket on back of Cantilever, flush with top
edge, vertically centered on cantilever.
. Position other Wall Cabinet Bracket flush with back edge of Cantilever,
centered on horizontal center.
. Mark holes.
. Remove brackets. Drill /” pilot holes /” deep. Be careful not to drill
through cantilever.
. Re-position brackets onto cantilever. Secure to cantilever with  # - /”
pan head tapping screws provided with bracket.
Pan Head Tapping Screw
Pan Head Tapping Screw
Wall Cabinet Bracket
Back Edge
Mark Holes
Mark Holes
Mark Holes
Mark Holes
Wall Cabinet Bracket
Centerline of Cantilever
Centerline of Cantilever
Cantilever
HermanMiller for Healthcare Assembly Instructions11BLHZT rev B

HermanMiller for Healthcare Assembly Instructions21BLHZT rev B
. Mark holes on wall and underside of surface.
. Remove candilever assembly.
. Drill /” pilot holes using drill stop or tape set at a depth of /” max.
This ensure clearance into the Corian for the tip of the screw.
. Drill /” holes through drywall. Make sure there are no utilities present.
. Insert wall anchors into holes. Orient toggles vertically. Secure to wall.
. Aer surface has been mounted on cabinets, position cantilever assembly
under end of surface.
Machine Screw
Tapping Screw
Toggle Bolt
. Reposition cantilever assembly under surface. Check to make sure that it
is still level.
. Secure cantilever to wall with pan head machine screws provided with
toggle bolt.
. Secure cantilever to surface with  # - /” pan head tapping screws
provided with each bracket.
Step 2 Step 3
Step 4
Cantilever Assembly
Surface
Mark Holes
Mark Holes
Correct Incorrect

HermanMiller for Healthcare Assembly Instructions31BLHZT rev B
Disassembly and Recycling:
Materials Identication and Segregation:
Where possible, plastic components are marked with ASTM recycling
codes. Use these codes to identify material type for recycling. Non marked
components should be treated as mixed plastic. Ferrous metals can be
identied using a small magnet for recycling. Non-ferrous metals should be
separated and recycled separately.
To disassemble product, reverse the above installation steps.
