Hioki CM4001 User manual
May 2020 Edition 1
CM4001A961-00 20-05H
AC LEAKAGE
CLAMP METER
Instruction Manual
CM4001
EN
Warranty
Warranty malfunctions occurring under conditions of normal
use in conformity with the Instruction Manual and Product
Precautionary Markings will be repaired free of charge. This
warranty is valid for a period of three (3) years from the date
of purchase. Please contact the distributor from which you
purchased the product for further information on warranty
provisions.
Introduction
Thank you for choosing the Hioki CM4001 AC Leakage
Clamp Meter. To ensure your ability to get the most out of
this instrument over the long term, please read this manual
carefully and keep it available for future reference.
Familiarize yourself with the separate document entitled
“Operating Precautions” before using the instrument.
Overview
The instrument is an AC leakage clamp meter capable of true
RMS value measurement of current ranging from 0.60 mA to
a comparator function to facilitate instantaneous pass/fail
judgments.
Intended audience
This manual has been written for use by individuals who
use the product or provide information about how to use the
product.
In explaining how to use the product, it assumes electrical
knowledge (equivalent of the knowledge possessed by a
graduate of an electrical program at a technical high school).
Notations
In this document, the severity levels of risk and hazard are
DANGER
Indicates an imminently hazardous situation
that will result in death of or serious injury to the
operator.
WARNING
Indicates a potentially hazardous situation that
may result in death of or serious injury to the
operator.
CAUTION
Indicates a potentially hazardous situation
that may result in minor or moderate injury to
the operator or damage to the instrument or
malfunction.
Indicates an action that must not be performed.
Indicates an action that must be performed.
Indicates the need for caution or the presence
of danger. For more information about locations
where this symbol appears on instrument
components, see the “Usage Notes” section,
warning messages listed at the beginning of
operating instructions, and accompanying the
document entitled “Operating Precautions”.
Indicates that the instrument may be connected to
or disconnected from a live conductor.
[ ] The names of user interface elements on the
screen are enclosed in brackets ([ ]).
Bold Operation keys are printed in bold.
The instrument screen displays the alphanumeric characters
as follows.
1 2 3 4 5 6 7 8 9 0
A B C D E F G H I J K L M N O P Q R S T U V W X Y Z
1 2 3 4 5 6 7 8 9 0
A B C D E F G H I J K L M N O P Q R S T U V W X Y Z
Usage Notes
CAUTION
• Avoid dropping or jarring the instrument which could
• Do not place any foreign object between the jaws or
insert any foreign object into the gap of the sensor
head. Doing so may worsen the performance of the
sensor or the opening-closing operation of the sensor
head.
•
potential even when no voltage is applied. This, however, is
not a malfunction.
•
characteristics than the 60 A and above ranges. As a result,
instrument.
•
accessories, options, battery, and other equipment in use.
Specications
Operating
environment
Indoors, Pollution Degree 2, altitude up to
2000 m (6562 ft.)
Operating
temperature and
humidity range
Humidity:
(non-condensing)
Storage
temperature and
humidity range
Standards Safety EN 61010
EMC EN 61326
Power supply LR03 alkaline battery × 1
Rated power voltage: 1.5 VDC
Maximum rated power: 450 mVA
voltage 1.5 V, ACA measurement, LCD
Continuous
operating time
• Approx. 32 hours (without Z3210)
• Approx. 16 hours (with Z3210, wireless
communication)
•
Dimensions Approx. 37W × 160H × 27D mm
(1.46”W × 6.3”H × 1.06”D)
(excluding the protruding parts, operation
grip, and jaw)
Jaw dimensions
Jaw cross-sectional
minimum dimension
Maximum measurable
φ24 mm
conductor diameter
Mass Approx. 115 g (4.1 oz.)
Product warranty
period
3 years
(number of jaw open/close cycles: 10000)
Accessories LR03 Alkaline battery × 1, Carrying case,
Instruction Manual, Operating Precautions
Option Z3210 Wireless Adapter
Option is subject to change. Check Hioki’s
website for the latest information.
Measurement items AC Current ( A), Frequency (Hz)
Maximum rated
terminal-to-ground
voltage
300 V AC (Measurement Category III)
Anticipated transient overvoltage: 4000 V
Measurement method
True RMS value measurement
Display update rate Measured value:
frequency)
1 time to 2 times/sec. (frequency)
(does not include range change time)
Zero-display range 5 counts or less
Crest factor For the 60.00 mA range/ 600.0 mA range/
6.000 A range/ 60.00 A range/600.0 A range
4.5 (4000 counts or less)
3 (more than 4000 counts, 6000 counts or less)
Maximum input
current
As per frequency derating (within 5 min.)
Accuracy Specications
rdg.: The value currently being measured and indicated on the measuring instrument.
Accuracy guarantee
conditions
Accuracy guarantee period: 1 year
Accuracy guarantee period after adjustment made by Hioki: 1 year
Accuracy guarantee temperature and humidity range:
Number of jaw open/close cycles: 10000 or less
Accuracy guarantee
input conditions
Sine wave input
Eect of external
magnetic eld
Max. 7.0 mA (6.000 A range and below)
Max. 4.0 A (60.00 A range and above)
Eects of conductor
position
(At any positions, based on the center of sensor)
Temperature
coecient
AC current RMS value measurement (ACA/ACA MAX/ACA MIN/ACA AVG)
Range
(Display range)
Resolution
(Accuracy
guarantee range)
Accuracy
guarantee
frequency range
Measurement accuracy
Filter o Filter on
60.00 mA
(0.00 mA to 60.00 mA)
0.01 mA
(0.60 mA rms to
60.00 mA rms)
–
600.0 mA
(0.0 mA to 600.0 mA)
0.1 mA
(6.0 mA rms to
600.0 mA rms)
–
6.000 A
(0.000 A to 6.000 A)
0.001 A
(0.060 A rms to
6.000 A rms)
–
60.00 A
(0.00 A to 60.00 A)
0.01 A
(0.60 A rms to
60.00 A rms)
–
600.0 A
(0.0 A to 600.0 A)
0.1 A
(6.0 A rms to
600.0 A rms)
–
AC current peak measurement (ACA PEAK MAX/ACA PEAK MIN)
Range
(Display range)
Resolution
(Accuracy
guarantee range)
Accuracy
guarantee
frequency range
Measurement accuracy
Filter o Filter on
60.00 mA
(0.0 mA to
0.1 mA
–
600.0 mA
(0 mA to
1 mA
–
6.000 A
(0.00 A to
0.01 A
–
60.00 A
(0.0 A to
0.1 A
–
600.0 A
1 A
–
AC inrush current measurement (ACA INRUSH)
Range
(Display range)
Resolution
(Accuracy
guarantee range)
Accuracy
guarantee
frequency range
Trigger
threshold
value (PEAK
value)
Measurement
accuracy
Filter o
600.0 mA
(0.0 mA to
600.0 mA)
0.1 mA
(60.0 mA rms to
600.0 mA rms)
+60.0 mA or more
or
6.000 A
(0.000 A to
6.000 A)
0.001 A
(0.600 A rms to
6.000 A rms)
+0.600 A or more
or
60.00 A
(0.00 A to
60.00 A)
0.01 A
(6.00 A rms to
60.00 A rms)
+2.00 A or more
or
600.0 A
(0.0 A to
600.0 A)
0.1 A
(60.0 A rms to
600.0 A rms)
+20.0 A or more
or
Frequency measurement (Current)
Range
(Display range)
Resolution
(Accuracy guarantee range)
Measurement
accuracy
0.1 Hz
10000100010010
0
100
200
300
400
500
600
700
GENNECT Cross
special site
https://gennect.net/en/cross/index
