Hisense AS-09CR4SVDTD5 User manual

1
Version: 1.3
Hisense Corporation

2
MODEL:
AS-09CR4SVDTD5
AS-09HR4SVDTD5
AS-12CR4SVETE3
AS-12HR4SVETD2
AS-18CR4SXATE
AS-18HR4SXATE
AS-22CR4SXBTE
AS-22HR4SBBTE
AS-30HR4SBBTG00
AS-12CR1FVDTD1
AS-12HR1FVDTD1
AS-12CR5FVDDA
AS-12HR5FVDDA
AS-12CR5FVETE1
AS-12HR5FVETE1
AS-18CR5FWATE
AS-18HR5FWATE
AS-22CR5FFBTE
AS-22HR5FFBTE
AS-36CT2FDKVQ
AS-36HR5FDKVQ
AS-09CR4SVDDF5
AS-12CR4SVEDA3
AS-18CR4SXADA
AS-22CR4SXBDA
AS-30HR4SQBDK
AS-36HR4SDKDK
AS-09HR4SVDTE5
AS-12HR4SVETE2

3
Contents
1. Safety Considerations ......................................................................................................................... 4
2. Product Specifications......................................................................................................................... 6
3. Product Picture and Drawing............................................................................................................. 14
3-1. Product Pictures ...................................................................................................................... 14
3-2. Product dimensions................................................................................................................. 16
4. Installation Instruction...................................................................................................................... 18
4-1. Installation Place and Condition .............................................................................................. 20
4-2. Electric Wiring Diagram ........................................................................................................... 21
4-3. Refrigerant Flow System.......................................................................................................... 25
4-4. Air Purging and Leakage Test ................................................................................................... 26
4-5. Test Running ........................................................................................................................... 27
5. Function Operation ........................................................................................................................... 28
5-1. Operation Range (cooling and heating）.................................................................................. 28
5-2. Remote Controller Operation & Function................................................................................. 28
5-3. Special Function Fnstruction.................................................................................................... 30
6. Electrical Characteristics.................................................................................................................... 37
6-1. Print Circuit Board (Indoor & Outdoor) .................................................................................... 37
6-2. Fan Motor ............................................................................................................................... 41
6-3. Temperature Sensor................................................................................................................ 42
7.Trouble Shooting................................................................................................................................ 46
7-1. Error Code Table...................................................................................................................... 46

4
1. Safety Considerations
IMPORTANT!
Please Read Before Starting
This air conditioning system meets strict safety and operating standards. As the installer or service
person, it is an important part of your job to install or service the system, so it operates safely and
efficiently.
For safe installation and trouble-free operation, you must:
●Carefully read this instruction booklet before beginning.
●Follow each installation or repair step exactly as shown.
●Observe all local, state, and national electrical codes.
●Pay close attention to all warning and caution notices given in this manual.
This symbol refers to a hazard or unsafe practice which can result in severe
personal injury or death.
This symbol refers to a hazard or unsafe practice which can result in personal
injury or product or property damage.
If Necessary, Get Help
These instructions are all you need for most installation sites and maintenance conditions. If you
require help for a special problem, contact our sales/service outlet or your certified dealer for
additional instructions.
In Case of Improper Installation
The manufacturer shall in no way be responsible for improper installation or maintenance service,
including failure to follow the instructions in this document.
SPECIAL PRECAUTIONS
When Wiring
ELECTRICAL SHOCK CAN CAUSE SEVERE PERSONAL INJURY OR DEATH. ONLY A
QUALIFIED, EXPERIENCED ELECTRICIAN SHOULD ATTEMPT TO WIRE THIS SYSTEM.
●Do not supply power to the unit until all wiring and tubing are completed or reconnected and
checked.
●Highly dangerous electrical voltages are used in this system. Carefully refer to the wiring diagram
and these instructions when wiring. Improper connections and inadequate grounding can cause
accidental injury or death.
●Ground the unit following local electrical codes.
●Connect all wiring tightly. Loose wiring may cause overheating at connection points and a possible

5
fire hazard.
When Transporting
Be careful when picking up and moving the indoor and outdoor units. Get a partner to help, and bend
your knees when lifting to reduce strain on your back. Sharp edges or thin aluminum fins on the air
conditioner can cut your fingers.
When Installing
●In a Ceiling or Wall
Make sure the ceiling/wall is strong enough to hold the unit’s weight. It may be necessary to
construct a strong wood or metal frame to provide added support.
●In a Room
Properly insulate any tubing run inside a room to prevent“sweating” that can cause dripping and
water damage to walls and floors.
●In Moist or Uneven Locations
Use a raised concrete pad or concrete blocks to provide a solid, level foundation for the outdoor unit.
This prevents water damage and abnormal vibration.
●In an Area with High Winds
Securely anchor the outdoor unit down with bolts and a metal frame. Provide a suitable air baffle.
●In a Snowy Area (for Heat Pump-type Systems)
Install the outdoor unit on a raised platform that is higher than drifting snow. Provide snow vents.
When Connecting Refrigerant Tubing
△Use the flare method for connecting tubing.
△Apply refrigerant lubricant to the matching surfaces of the flare and union tubes before connecting
them, then tighten the nut with a torque wrench for a leak free connection.
△Check carefully for leaks before starting the test run.
When Servicing
△Turn the power OFF at the main power box (mains) before opening the unit to check or repair
electrical parts and wiring.
△Keep your fingers and clothing away from any moving parts.
△Clean up the site after you finish, remembering to check that no metal scraps or bits of wiring have
been left inside the unit being serviced.
Others
△Ventilate any enclosed areas when installing or testing the refrigeration system. Escaped
refrigerant gas, on contact with fire or heat, can produce dangerously toxic gas.
△Confirm upon completing installation that no refrigerant gas is leaking. If escaped gas comes in
contact with a stove, gas water heater, electric room heater or other heat source, it can produce
dangerously toxic gas.
NOTE:
The figure 、 size and parameter of the product may not be identical with the service manual, please
take the actual product as the standard.

6
2. Product Specifications
Model No.
AS-12CR5FVETE1
AS-12HR5FVETE1
AS-12CR5FFDA
AS-12HR5FFDA
Type
T1, COOLING-ONLY
T1, HEAT PUMP
T1,
COOLING-ONLY
T1, HEAT PUMP
Ratings
Cooling Capacity
W
3520
3520
3370
3370
Heating Capacity
W
/
3600
3400
Rated Input-Cooling
W
1215
1225
1170
1170
Rated Input-Heating
W
/
1200
1165
Moisture Removal
L/h
1.2
1.2
/
/
Air Circulation
High m3/h
680
680
550
550
Mid m3/h
610
610
/
/
Low m3/h
540
540
/
/
EER for Cooling
W/W
2.90
2.87
2.88
2.88
COP for Heating
W/W
/
3.00
/
2.92
Refrigerant
R22
R22
R22
R22
Refrigerant charge volume （5M）
g
650
980
720
860
Additional ref. Volume
g
20
20
20
20
Indoor Unit Noise Level
High(dB (A))
39
39
39
39
Mid(dB (A))
37
37
/
/
Low(dB (A))
34
34
/
/
Outdoor Unit Noise Level
dB (A)
55
55
55
55
Power Supply
Voltage, Frequency, Phase
ph, V, Hz
230V~,60Hz,1P
230V~,60Hz,1P
1, 208-230, 60
1, 208-230, 60
Rated Current
Cooling (A)
5.3
5.4
5.2
5.2
Heating (A)
/
5.3
5.2
LRA
A
31
31
20
20
System pressures in cooling rated conditions
Max suction pressure
MPa
1.4
1.4
1.4
1.4
Max discharge pressure
MPa
3.1
3.1
3.1
3.1
System
Compressor
Compressor type
Rotary
Rotary
Rotary
Rotary
Compressor Model No.
HSM170N2UFZ
HSM170N2UFZ
44R292BK-FJSC
44R292BK-FJSC
Compressor MFG
GMCC
GMCC
RECHI
RECHI
Connecting Pipe Diameter
Liquid Pipe
inch
3/8
1/4
1/4
1/4
Gas Pipe
inch
5/8
1/2
12
12
Features
Display on Front Panel
LED
LED
LED
LED
LCD Wireless Remote Controller
Yes
Yes
Yes
Yes
Removable and washable Panel
Yes
Yes
Yes
Yes
Washable PP Filter
Yes
Yes
Yes
Yes
24 Hours Timer
Yes
Yes
Yes
Yes
3 Speed and Auto Indoor Fan Control
Yes
Yes
Yes
Yes

7
Vertical Auto Swing Louver
Yes
Yes
Yes
Yes
Manual Adjustable Horizontal Swing Louver
Yes
Yes
Yes
Yes
Sleep Operation
Yes
Yes
Yes
Yes
Smart Function
Yes
Yes
Yes
Yes
Super Function
Yes
Yes
Yes
Yes
Auto Restart
Yes
Yes
Yes
Yes
Dimmer
Yes
Yes
Yes
Yes
Other
Net Dimensions WxHxD (mm)
Indoor Unit
850×270×212
850×270×212
780×270×202
780×270×202
Outdoor Unit
715x240x482
715x240x482
715×482×240
715×482×240
Net Weight (Kg)
Indoor Unit
8.5
8.5
8
8
Outdoor Unit
25
27
25
26
Packing Dimensions WxHxD (mm)
Indoor Unit
900x335x260
900x335x260
800×260×335
800×260×335
Outdoor Unit
830x315x530
830x315x530
830×530×315
830×530×315
Gross Weight (Kg)
Indoor Unit
11
11
9.5
9.5
Outdoor Unit
27.5
29.5
27
28
Model No.
AS-12CR4SVETE3
AS-12CR4SVEDA3
AS-09CR4SVDTD5
AS-09CR4SVDDF5
AS-09HR4SVDTE5
AS-09HR4SVDTD5
Type
T1, COOLING-ONLY
T1, COOLING-ONLY
T1, HEAT PUMP
Ratings
Cooling Capacity
W
3500
2600
2600
Heating Capacity
W
NA
2600
Rated Input-Cooling
W
1090
810
810
Rated Input-Heating
W
NA
720
Moisture Removal
L/h
/
0.9
0.9
Air Circulation
High m3/h
660
600
600
Mid m3/h
/
Low m3/h
/
EER for Cooling
W/W
3.21
3.21
3.21
COP for Heating
W/W
/
NA
3.61
Refrigerant
R410A
R410A
R410A
Refrigerant charge volume （5M）
g
500
570
640
Additional ref. Volume
g
20
20
20
Indoor Unit Noise Level
High(dB (A))
39
38
38
Mid(dB (A))
/
/
/
Low(dB (A))
/
/
/
Outdoor Unit Noise Level
dB (A)
55
53
53
Power Supply
Voltage, Frequency, Phase
ph, V, Hz
1, 220-240, 50
220-240V~,50Hz,1P
220-240V~,50Hz,1P
Rated Current
Cooling (A)
5.1
3.8
3.8
Heating (A)
NA
3.4
LRA
A
20
20
20
System pressures in cooling rated conditions
Max suction pressure
MPa
1.6
1.6
1.6
Max discharge pressure
MPa
4.15
4.15
4.15

8
System
Compressor
Compressor type
Rotary
Rotary
Rotary
Compressor Model No.
44B263DK&FJKC
ASM99V1VDZ
ASM99V1VDZ
Compressor MFG
RECHI
GMCC
GMCC
Connecting Pipe Diameter
Liquid Pipe
inch
1/4
1/4
1/4
Gas Pipe
inch
12
3/8
3/8
Features
Display on Front Panel
LED
LED
LED
LCD Wireless Remote Controller
Yes
Yes
Yes
Removable and washable Panel
Yes
Yes
Yes
Washable PP Filter
Yes
Yes
Yes
24 Hours Timer
Yes
Yes
Yes
3 Speed and Auto Indoor Fan Control
Yes
Yes
Yes
Vertical Auto Swing Louver
Yes
Yes
Yes
Manual Adjustable Horizontal Swing Louver
Yes
Yes
Yes
Sleep Operation
Yes
Yes
Yes
Smart Function
Yes
Yes
Yes
Super Function
Yes
Yes
Yes
Auto Restart
Yes
Yes
Yes
Dimmer
Yes
Yes
Yes
Other
Net Dimensions WxHxD (mm)
Indoor Unit
808×270×202
780×270×202
780×270×202
Outdoor Unit
715×482×240
715x482x240
715x482x240
Net Weight (Kg)
Indoor Unit
8.5
8
8
Outdoor Unit
27
25
26
Packing Dimensions WxHxD (mm)
Indoor Unit
900×260×335
830×335×260
830×335×260
Outdoor Unit
830×530×315
830×530×315
830×530×315
Gross Weight (Kg)
Indoor Unit
11
9.5
9.5
Outdoor Unit
30.5
27
28
Model No.
AS-12CR1FVDTD1
AS-12HR1FVDTD1
AS-12HR4SVETD2
AS-12HR4SVETE2
Type
T1, C/P, ON/OFF
T1, H/P, ON/OFF
T1, HEAT-PUMP
Ratings
Cooling Capacity
W
3375
3225
3500
Heating Capacity
W
——
3225
3500
Rated Input-Cooling
W
1170
1120
1090
Rated Input-Heating
W
——
1075
1026
Moisture Removal
L/h
1.1
1.1
/
Air Circulation
High m3/h
580
580
620
Mid m3/h
——
——
/
Low m3/h
——
——
/
EER for Cooling
W/W
2.88
2.88
3.21
COP for Heating
W/W
——
3
3.41

9
Refrigerant
R22
R22
R410A
Refrigerant charge volume （5M）
g
470
690
920
Additional ref. Volume
g
20
20
20
Indoor Unit Noise Level
High(dB (A))
40
40
39
Mid(dB (A))
Low(dB (A))
Outdoor Unit Noise Level
dB (A)
52
52
55
Power Supply
Voltage, Frequency, Phase
V
115V~,60Hz,1P
115V~,60Hz,1P
1, 220-240, 50
Rated Current
Cooling
(A)
10.5
10
5.1
Heating
(A)
——
9.6
4.8
LRA
A
56
56
20
System pressures in cooling rated conditions
Max suction pressure
MPa
1.0
1.0
1.6
Max discharge pressure
MPa
3.1
3.1
4.15
System
Compressor
Compressor type
Rotary
Rotary
Rotary
Compressor Model No.
QK164CBJ
QK164CBJ
ASM135V1VDZ
Compressor MFG
LG
LG
GMCC
Connecting Pipe Diameter
Liquid Pipe
inch
1/4
1/4
1/4
Gas Pipe
inch
1/2
1/2
1/2
Features
Display on Front Panel
LED
LED
LED
LCD Wireless Remote Controller
Yes
Yes
Yes
Removable and washable Panel
Yes
Yes
Yes
Washable PP Filter
Yes
Yes
Yes
24 Hours Timer
Yes
Yes
Yes
3 Speed and Auto Indoor Fan Control
Yes
Yes
Yes
Vertical Auto Swing Louver
Yes
Yes
Yes
Manual Adjustable Horizontal Swing Louver
Yes
Yes
Yes
Sleep Operation
Yes
Yes
Yes
Smart Function
Yes
Yes
Yes
Super Function
Yes
Yes
Yes
Auto Restart
Yes
Yes
Yes
Dimmer
Yes
Yes
Yes
Other
Net Dimensions WxHxD (mm)
Indoor
Unit
780×270×208
780×270×208
850×270×202
Outdoor
Unit
715×482×240
715×482×240
715×482×240
Net Weight (Kg)
Indoor
Unit
8
8
8.5
Outdoor
26
27
28

10
Unit
Packing Dimensions WxHxD (mm)
Indoor
Unit
830×335×260
830×335×260
900×260×335
Outdoor
Unit
830×530×315
830×530×315
830×530×315
Gross Weight (Kg)
Indoor
Unit
9.5
9.5
11
Outdoor
Unit
28
29
31.5
Model No.
AS-18CR4SXATE
AS-18CR4SXADA
AS-18HR4SXATE
AS-18HR5FWATE
AS-18CR5FWATE
Type
T1, Cooling
T1, Heat-pump
T1, Heat-pump
T1, Cooling
Ratings
Cooling Capacity
W
5200
5200
5280
5280
Heating Capacity
W
/
5400
5550
/
Rated Input-Cooling
W
1620
1620
1820
1770
Rated Input-Heating
W
/
1585
1680
/
Moisture Removal
L/H.r
/
/
/
/
Air Circulation
High m3/h
950
950
1000
1000
Mid m3/h
/
/
/
/
Low m3/h
/
/
/
/
EER for Cooling
W/W
3.21
3.21
2.90
2.98
COP for Heating
W/W
/
3.40
3.30
/
Refrigerant
R410A
R410A
R22
R22
Refrigerant charge volume（5M）
g
750
1460
1270
710
Additional ref. Volume
g
20
20
25
25
Indoor Unit Noise Level
High(dB (A))
43
43
45
45
Mid(dB (A))
/
/
40
40
Low(dB (A))
/
/
35
35
Outdoor Unit Noise Level
dB (A)
54
54
58
58
Power Supply
Voltage, Frequency, Phase
V, Hz, ph
220-240V~,50Hz,1P
220-240V~,50Hz,1P
230V~,60Hz,1P
230V~,60Hz,1P
Rated Current
Cooling (A)
7.6
7.6
8.2
8.0
Heating (A)
7.4
7.4
7.6
/
LRA
A
43
43
45
45
System pressures in cooling rated conditions
Max suction pressure
Mpa
1.6
1.6
1.4
1.4
Max discharge pressure
Mpa
4.15
4.15
3.1
3.1
System
Compressor
Compressor type
Rotary
Rotary
Rotary
Rotary
Compressor Model No.
ASH201RV-C8DQ
ASH201RV-C8DQ
SL260DG-C8EU
SL260DG-C8EU
Compressor MFG
Hitachi
Hitachi
Hitachi
Hitachi
Connecting Pipe Diameter

11
Liquid Pipe
inch
3/8
3/8
1/4
1/4
Gas Pipe
inch
5/8
5/8
1/2
1/2
Features
Display on Front Panel
LED
LED
LED
LED
LCD Wireless Remote Controller
Yes
Yes
Yes
Yes
Removable and washable Panel
Yes
Yes
Yes
Yes
Washable PP Filter
Yes
Yes
Yes
Yes
24 Hours Timer
Yes
Yes
Yes
Yes
3 Speed and Auto Indoor Fan Control
Yes
Yes
Yes
Yes
Vertical Auto Swing Louver
Yes
Yes
Yes
Yes
Manual Adjustable Horizontal Swing Louver
Yes
Yes
Yes
Yes
Sleep Operation
Yes
Yes
Yes
Yes
Smart Function
Yes
Yes
Yes
Yes
Super Function
Yes
Yes
Yes
Yes
Auto Restart
Yes
Yes
Yes
Yes
Dimmer
Yes
Yes
Yes
Yes
Other
Net Dimensions WxHxD (mm)
Indoor Unit
960×230×315
960×230×315
960×315×235
960×315×235
Outdoor Unit
810×280×585
810×280×585
761×544×256
761×544×256
Net Weight (Kg)
Indoor Unit
12.5
12.5
12.5
12.5
Outdoor Unit
36
40.5
35
35
Packing Dimensions WxHxD
(mm)
Indoor Unit
1022×302×380
1022×302×380
1022×380×302
1022×380×302
Outdoor Unit
940×385×630
940×385×630
890×580×350
890×580×350
Gross Weight (Kg)
Indoor Unit
15.5
15.5
15.5
15.5
Outdoor Unit
39.5
44.5
38
38
Model No.
AS-22HR5FFBTE
AS-22CR5FFBTE
AS-22CR4SXBTE
AS-22CR4SXBDA
AS-22HR4SBBTE
Type
T1, Heat-pump
T1, Cooling
T1, Cooling
T1, Heat-pump
Ratings
Cooling Capacity
W
6600
6600
6600
6600
Heating Capacity
W
6800
——
6600
Rated Input-Cooling
W
2275
2275
2055
2055
Rated Input-Heating
W
2265
/
——
1850
Moisture Removal
L/H.r
/
/
1.74
2
Air Circulation
High m3/h
1150
1150
1200
1200
Mid m3/h
/
/
——
/
Low m3/h
/
/
——
/
EER for Cooling
W/W
2.9
2.9
3.21
3.21
COP for Heating
W/W
3
3
——
3.57
Refrigerant
R22
R22
R410A
R410A
Refrigerant charge volume（5M）
g
1400
860
980
1580
Additional ref. Volume
g
30
30
30
30
Indoor Unit Noise Level
High(dB (A))
46
46
45
45
Mid(dB (A))
/
/
——
41
Low(dB (A))
/
/
——
37

12
Outdoor Unit Noise Level
dB (A)
58
58
56
55
Power Supply
Voltage, Frequency, Phase
V, Hz, ph
1, 230~, 60
1, 230~, 60
220-240V~,50Hz,1P
220-240V~,50Hz,1P
Rated Current
Cooling (A)
10.2
10.2
14.5
9.6
Heating (A)
10.2
/
——
8.7
LRA
A
61
61
50
50
System pressures in cooling rated conditions
Max suction pressure
Mpa
1.4
1.4
1.6
1.6
Max discharge pressure
Mpa
3.1
3.1
4.15
4.15
System
Compressor
Compressor type
Rotary
Rotary
Rotary
Rotary
Compressor Model No.
PH330G2C-3KTS
PH330G2C-3KTS
ASH244MV-C7HQ
ASH244MV-C7HQ
Compressor MFG
GMCC
GMCC
Hitachi
Hitachi
Connecting Pipe Diameter
Liquid Pipe
inch
3/8
3/8
3/8
3/8
Gas Pipe
inch
5/8
5/8
5/8
5/8
Features
Display on Front Panel
LED
LED
LED
LED
LCD Wireless Remote Controller
Yes
Yes
Yes
Yes
Removable and washable Panel
Yes
Yes
Yes
Yes
Washable PP Filter
Yes
Yes
Yes
Yes
24 Hours Timer
Yes
Yes
Yes
Yes
3 Speed and Auto Indoor Fan Control
Yes
Yes
Yes
Yes
Vertical Auto Swing Louver
Yes
Yes
Yes
Yes
Manual Adjustable Horizontal Swing Louver
Yes
Yes
NO(Auto)
Yes
Sleep Operation
Yes
Yes
Yes
Yes
Smart Function
Yes
Yes
Yes
Yes
Super Function
Yes
Yes
Yes
Yes
Auto Restart
Yes
Yes
Yes
Yes
Dimmer
Yes
Yes
Yes
Yes
Other
Net Dimensions WxHxD (mm)
Indoor Unit
1131×315×230
1131×315×230
1131x315x235
1131×315×235
Outdoor Unit
830×287×634
830×287×634
810x280x585
860×310×650
Net Weight (Kg)
Indoor Unit
14.5
14.5
14.5
14.5
Outdoor Unit
44
40
39
17
Packing Dimensions WxHxD
(mm)
Indoor Unit
1220×400×310
1220×400×310
1220×400×310
1220×400×310
Outdoor Unit
980×385×665
980×385×665
940×385×630
995×420×720
Gross Weight (Kg)
Indoor Unit
17
17
17
47
Outdoor Unit
48
45
42
51
Model No.
AS-30HR4SBBTG00
AS-36CT2FDKVQ
AS-36HR5FDKVQ
Type
T1, Heat-pump
T3
T3
Ratings
Cooling Capacity
W
8200
T1:9085/T3:8060
9379
Heating Capacity
W
8000
/
9379

13
Rated Input-Cooling
W
2720
T1:3190/T3:3870
3225
Rated Input-Heating
W
2490
/
3115
Moisture Removal
L/H.r
2.6
2.7
2.7
Air Circulation
High m3/h
1200
1680
1680
Mid m3/h
/
1300
1300
Low m3/h
/
950
950
EER for Cooling
W/W
3.01
T1:2.85/T3:2.08
2.91
COP for Heating
W/W
3.21
/
3.01
Refrigerant
R410A
R22
R22
Refrigerant charge volume（5M）
g
1920
2060
2080
Additional ref. Volume
g
30
40
40
Indoor Unit Noise Level
High(dB (A))
45
50
50
Mid(dB (A))
42
45
45
Low(dB (A))
39
36
36
Outdoor Unit Noise Level
dB (A)
56
64
64
Power Supply
Voltage, Frequency, Phase
V, Hz, ph
220-240V~,50Hz,1P
220-230V~,60Hz,1P
220-230V~,60Hz,1P
Rated Current
Cooling (A)
12.1
T1:14.9/T3:18.1
14.6
Heating (A)
11.5
/
14
LRA
A
90
90
System pressures in cooling rated conditions
Max suction pressure
Mpa
1.6
1.4
1
Max discharge pressure
Mpa
4.15
4.1
3.1
System
Compressor
Compressor type
Rotary
Rotary
Rotary
Compressor Model No.
PA311X3CS-4MTL
C-3RT438H2ABL
C-3RT438H2ABL
Compressor MFG
GMCC
SANYO
SANYO
Connecting Pipe Diameter
Liquid Pipe
inch
3/8
3/8
3/8
Gas Pipe
inch
5/8
3/4
3/4
Features
Display on Front Panel
LED
LED
LED
LCD Wireless Remote Controller
Yes
Yes
Yes
Removable and washable Panel
Yes
Yes
Yes
Washable PP Filter
Yes
Yes
Yes
24 Hours Timer
Yes
Yes
Yes
3 Speed and Auto Indoor Fan Control
Yes
Yes
Yes
Vertical Auto Swing Louver
Yes
Yes
Yes
Manual Adjustable Horizontal Swing Louver
Yes
Yes
Yes
Sleep Operation
Yes
Yes
Yes
Smart Function
Yes
Yes
Yes
Super Function
Yes
Yes
Yes
Auto Restart
Yes
Yes
Yes
Dimmer
Yes
Yes
Yes
Other

14
Net Dimensions WxHxD (mm)
Indoor Unit
1080×315×230
1350×364×266
1350×364×266
Outdoor Unit
860×310×650
884×365.5×793
884×365.5×793
Net Weight (Kg)
Indoor Unit
15
19.5
19.5
Outdoor Unit
54
66
67
Packing Dimensions WxHxD
(mm)
Indoor Unit
1170×390×315
1425×435×325
1425×435×325
Outdoor Unit
995x420x720
1050×890×500
1050×890×500
Gross Weight (Kg)
Indoor Unit
18
23
23
Outdoor Unit
57
72
73
Model No.
AS-30HR4SQBDK
AS-36HR4SDKDK
Type
T1, Heat-pump
T1, Heat-pump
Ratings
Cooling Capacity
W
8200
9400
Heating Capacity
W
8600
9600
Rated Input-Cooling
W
2985
3345
Rated Input-Heating
W
2860
2990
Moisture Removal
L/h
/
/
Air Circulation
High m3/h
1200
1680
Mid m3/h
/
/
Low m3/h
/
/
EER for Cooling
W/W
2.75
2.81
COP for Heating
W/W
3.01
3.21
Refrigerant
R410A
R410A
Refrigerant charge volume （5M）
g
1830
2150
Additional ref. Volume
g
40
/
Indoor Unit Noise Level
High(dB (A))
50
50
Mid(dB (A))
/
/
Low(dB (A))
/
/
Outdoor Unit Noise Level
dB (A)
60
64
Power Supply
Voltage, Frequency, Phase
V
220-240V~,50Hz,1P
220-240V/50Hz,1P
Rated Current
Cooling (A)
13.5
14.8
Heating (A)
12.9
14.3
LRA
A
68
66
System pressures in cooling rated conditions
Max suction pressure
MPa
1.6
1.6
Max discharge pressure
MPa
4.15
4.15
System
Compressor
Compressor type
Rotary
Rotary
Compressor Model No.
ATH325CV-C9LU
ATH356CV-C9LU
Compressor MFG
Hitachi
Hitachi
Connecting Pipe Diameter
Liquid Pipe
inch
3/8
3/8
Gas Pipe
inch
5/8
3/4
Features
Display on Front Panel
LED
LED

15
LCD Wireless Remote Controller
Yes
Yes
Removable and washable Panel
Yes
Yes
Washable PP Filter
Yes
Yes
24 Hours Timer
Yes
Yes
3 Speed and Auto Indoor Fan Control
Yes
Yes
Vertical Auto Swing Louver
Yes
NO
Manual Adjustable Horizontal Swing Louver
Yes
Yes
Sleep Operation
Yes
Yes
Smart Function
Yes
Yes
Super Function
Yes
Yes
Auto Restart
Yes
Yes
Dimmer
Yes
Yes
Other
Net Dimensions WxHxD
(mm)
Indoor Unit
1131×315×230
1350×364×260
Outdoor Unit
832×312×702
884×365.5×793
Net Weight (Kg)
Indoor Unit
15
19.5
Outdoor Unit
54.5
60
Packing Dimensions WxHxD (mm)
Indoor Unit
1220×400×310
1425*435*325
Outdoor Unit
980×420×770
1050*500*890
Gross Weight (Kg)
Indoor Unit
17.5
23
Outdoor Unit
58.5
68
3. Product Picture and Drawing
3-1. Product Pictures
Indoor units:
Front Panel
DA
View
Front Panel
TG
View
Front Panel
TD

16
View
Front Panel
VQ
View
Front Panel
TE
View
Front Panel
DK
View
Outdoor Units:
Unit
V（W1M）
X（W1P）
View
Unit
F（W2M）
D（W5F）
View

17
Unit
W（W2F）
B（W2N）
View
Unit
Q（W3A）
View
Remote controller:
Model
L1
J1
View
3-2. Product dimensions
Indoor units:

18
Model
W (mm)
H (mm)
D (mm)
AS-09CR4SVDTD5
780
270
208
AS-09CR4SVDDF5
800
270
214
AS-09HR4SVDTD5
780
270
208
AS-09HR4SVDTE5
780
270
212
AS-12CR4SVETE3
850
270
212
AS-12CR4SVEDA3
850
270
202
AS-12HR4SVETD2
850
270
208
AS-12HR4SVETE2
850
270
212
AS-18CR4SXATE
960
315
235
AS-18CR4SXADA
915
315
236
AS-18HR4SXATE
960
315
235
AS-22CR4SXBTE
1130
315
235
AS-22CR4SXBDA
1085
315
236
AS-22HR4SBBTE
1130
315
235
AS-30HR4SBBTG00
1220
320
235
AS-12CR1FVDTD1
780
270
208
AS-12HR1FVDTD1
780
270
208
AS-12CR5FVDDA
745
270
214
AS-12HR5FVDDA
745
270
214

19
AS-12CR5FVETE1
850
270
212
AS-12HR5FVETE1
850
270
212
AS-18CR5FWATE
960
315
235
AS-18HR5FWATE
960
315
235
AS-22CR5FFBTE
1130
315
235
AS-22HR5FFBTE
1130
315
235
AS-36CT2FDKVQ
1350
364
260
AS-36HR5FDKVQ
1350
364
260
AS-30HR4SQBDK
1130
315
235
AS-36HR4SDKDK
1350
364
260
Outdoor units:
Model
L1
(mm)
L2
(mm)
L3
(mm)
L4
(mm)
L5
(mm)
L6
(mm)
L7
(mm)
AS-09CR4SVDTD5
443
264
776
715
240
486
290
AS-09CR4SVDDF5
443
264
776
715
240
486
290
AS-09HR4SVDTD5
443
264
776
715
240
486
290
AS-09HR4SVDTE5
443
264
776
715
240
486
290
AS-12CR4SVETE3
443
264
776
715
240
486
290
AS-12CR4SVEDA3
443
264
776
715
240
486
290

20
AS-12HR4SVETD2
443
264
776
715
240
486
290
AS-12HR4SVETE2
443
264
776
715
240
486
290
AS-18CR4SXATE
510
310
873
810
280
585
338
AS-18CR4SXADA
510
310
873
810
280
585
338
AS-18HR4SXATE
510
310
873
810
280
585
338
AS-22CR4SXBTE
510
310
873
810
280
585
338
AS-22CR4SXBDA
510
310
873
810
280
585
338
AS-22HR4SBBTE
542
341
935
860
310
667
368
AS-30HR4SBBTG00
542
341
935
860
310
667
368
AS-12CR1FVDTD1
443
264
776
715
240
486
290
AS-12HR1FVDTD1
443
264
776
715
240
486
290
AS-12CR5FVDDA
443
264
776
715
240
486
290
AS-12HR5FVDDA
443
264
776
715
240
486
290
AS-12CR5FVETE1
443
264
776
715
240
486
290
AS-12HR5FVETE1
443
264
776
715
240
486
290
AS-18CR5FWATE
493
284
835
761
256
544
320
AS-18HR5FWATE
493
284
835
761
256
544
320
AS-22CR5FFBTE
565
314
913
832
287
635
350
AS-22HR5FFBTE
565
314
913
832
287
635
350
AS-36CT2FDKVQ
662
390
959
898
365.5
793
414
AS-36HR5FDKVQ
662
390
959
898
365.5
793
414
AS-30HR4SQBDK
518
350
908
832
312
702
380
AS-36HR4SDKDK
662
390
959
898
365.5
793
414
4. Installation Instruction
To prevent abnormal heat generation and the possibility of fire, do not place
obstacles, enclosures and grilles in front of or surrounding the air conditioner in a
way that may clock air flow. And, more than 1 meter away from any antenna or power lines or connecting
wires used for TV, radio, telephone, security system, or intercom. Electrical noise from any of these
sources may affect operation.
4-1. Installation Place and Condition
Indoor unit
Avoid:
△direct sunlight.
△nearby heat sources that may affect performance of the unit.
△areas where leakage of flammable gas may be expected.
△places where large amounts of oil mist exist.
Do:
△Select an appropriate position from which every corner of the room can be uniformly cooled.
△Select a location that will hold the weight of the unit.
△Select a location where tubing and drain hose have the shortest run to the outside. (See a)
