HK Instruments DPT-2W- 100-R2 User manual

DPT-2W - 2-wire differential pressure transmitter
USER GUIDE

Published: 31.05.2023 2 (11)
Contents
1 Introduction........................................................................................................... 3
1.1 About this user guide.....................................................................................................................................3
1.2 Intended use...................................................................................................................................................3
1.3 Applications.....................................................................................................................................................3
2 Description of the product.................................................................................. 4
2.1 Overview of the main parts............................................................................................................................4
2.2 Technical specifications..................................................................................................................................4
2.3 Dimensions..................................................................................................................................................... 5
3 Safety precautions................................................................................................6
4 Commissioning..................................................................................................... 7
4.1 Mounting the product......................................................................................................................................7
4.2 Measuring range selection.............................................................................................................................8
4.3 Selecting response time.................................................................................................................................8
4.4 Wiring..............................................................................................................................................................9
4.5 Zeroing............................................................................................................................................................9
5 Disposal...............................................................................................................10
6 Warranty policy...................................................................................................11
Copyright HK Instruments 2023 www.hkinstruments.fi User guide Version 1.0 2023
Information is subject to change without prior notice. EN - 104.004.008ug

Published: 31.05.2023 3 (11)
1 Introduction
Thank you for choosing an HK Instruments DPT series differential pressure transmitter. The DPT series is intended
for use in commercial environments. The DPT-2W series differential pressure transmitter provides a 4...20 mA loop
output.
All DPT-2W differential pressure transmitters are available with display.
1.1 About this user guide
This user guide contains important information about the installation, wiring, configuration and use of the product.
Read this guide carefully before you install the product, connect the wires, or operate the product. Make sure that you
fully understand all instructions before you start work. If you are not sure what the instructions mean, contact the seller
or the manufacturer.
Follow all instructions in this user guide carefully. Always obey the applicable local rules and regulations.
The original instructions were written in English. If there are differences between the English instructions and the
translations, refer to the English instructions.
If you find a mistake in the English instructions or in the translations, please send the details to the manufacturer.
1.2 Intended use
The DPT-2W differential pressure transmitter is intended to be used to measure differential pressure in ventilation
ducts.
These transmitters are intended to be connected to building automation systems in the HVAC/R industry.
1.3 Applications
DPT-2W devices are commonly used in HVAC/R systems for:
• fan, blower and filter monitoring
• pressure and flow monitoring
• valve and damper control
• pressure monitoring in cleanrooms
Copyright HK Instruments 2023 www.hkinstruments.fi User guide Version 1.0 2023
Information is subject to change without prior notice. EN - 104.004.008ug

Published: 31.05.2023 4 (11)
2 Description of the product
This section introduces the main parts of the product and contains the technical specifications.
2.1 Overview of the main parts
A
B
C
E
F
D
A Display connectors D Pressure range selection jumpers
B Zeroing button E Pressure sensor
C Indicator light F Wiring terminal
2.2 Technical specifications
Property Value
Supply 10...35 Vdc
Pressure measurement ranges
-250 models ±25 / ±50 / ±100 / ±150 / 0...25 / 0...50 / 0...100 / *0...250 Pa
-2500 models ±100 / 0...100 / 0...250 / 0...500 / 0...1000 / 0...1500 / 0...2000 / *0...2500 Pa
-7000 models 0...750 / 0...1000 / 0...1250 / 0...2250 / 0...2500 / 0...3750 / 0...5000 / *0...7000 Pa
Accuracy (temperature compensated) ±1.5 % + 2 Pa from value
Overpressure
Proof pressure 25 kPa
Burst pressure 30 kPa
Long term stability
-250 and -2500 models typ. -8…8 Pa / year
-7000 models typ. -22…22 Pa / year
Response time *0.8 s / 4 s
Zeroing Manually by push button
Sensor MEMS, no flow-through
Output
Signal 4...20 mA, >20 Ω
Accuracy typ. ±0.04 mA at 25 °C, load 100 Ω
Display (-D models) 3 1/2 digit display
Operating conditions
Copyright HK Instruments 2023 www.hkinstruments.fi User guide Version 1.0 2023
Information is subject to change without prior notice. EN - 104.004.008ug

Published: 31.05.2023 5 (11)
Property Value
Temperature -10...50 °C
Humidity 0...95 %rH (non-condensing)
Wire 0.2...1.5 mm2(24...16 AWG)
Housing
Materials ABS and PC plastic
Protection class IP54
Cable gland M16
Mounting 2 x Ø4.3 mm screw holes, one slotted
Dimensions (w x h x d) 90 x 95 x 36 mm
Weight 150 g
Storage temperature -40...70 °C
Conformance CE UKCA
EMC 2014/30/EU S.I. 2016 No. 1091
RoHS 2011/65/EU S.I. 2012 No. 3032
WEEE 2012/19/EU S.I. 2013 No. 3113
* factory setting
2.3 Dimensions
95
53
Ø4.3
77
36
90
Copyright HK Instruments 2023 www.hkinstruments.fi User guide Version 1.0 2023
Information is subject to change without prior notice. EN - 104.004.008ug

Published: 31.05.2023 6 (11)
3 Safety precautions
The product is developed, manufactured and tested according to high quality standards. However, instructions for
safe use shall be taken account when installing, using or disposing the product or parts of product.
Read this user guide carefully before commissioning, using or servicing this device. To avoid any kind of damage to
people or property, follow the instructions carefully. HK Instruments is not liable for any hazards or damages to people
or property which are caused by ignoring the using or installation instructions.
To avoid electrical shock or damage to equipment, disconnect power before installing or servicing the product. Use
only a proper wiring rated for the full operating voltage and maximum current in the system even in the event of a
fault.
To avoid potential fire and/or explosion, do not use the product in potentially flammable or explosive atmosphere.
The product condition must be checked before installation. Do not drop the product or use excessive force during
installation. Do not use the product if any damages are visible.
After installation the product will be part of a system whose specifications and performance characteristics are not
designed or controlled by HK Instruments. Refer to national and local authorities to ensure that the installation is
functional and safe.
The product should only be used in professionally designed applications. Unauthorised modifications are not allowed.
The product must not be used in relation with any equipment that in case of a failure may threaten, directly or
indirectly, human health or life or result in danger to human beings, animals or property.
In this document, there are different kind of warnings and notes. The warning and note types are defined in the
following table.
Sign Description
WARNING: The warning symbol indicates a potentially hazardous situation which, if not avoided, could result
in death or serious injury.
CAUTION: The caution symbol indicates a potentially hazardous situation which, if not avoided, could result
in minor or moderate injury.
Important: The important symbol indicates a potentially hazardous situation which, if not avoided, could
result in damage to the device or property.
Note: The note symbol indicates a useful tip or a recommended way to complete a task. These notes
also provide information that is useful but not critical to the user.
Copyright HK Instruments 2023 www.hkinstruments.fi User guide Version 1.0 2023
Information is subject to change without prior notice. EN - 104.004.008ug

Published: 31.05.2023 7 (11)
4 Commissioning
4.1 Mounting the product
WARNING: Handle the product with care. Dropping the product may cause internal damage and unwanted
functions in the connected system.
1. Check that the product is not damaged during transportation.
2. Select the mounting location.
CAUTION: Place the product outside the reach of children and animals.
Important: The product may only be installed in a location where the ambient conditions meet the
operating condition requirements.
Operating conditions
Temperature -20...50 °C
Humidity 0...95 %rH (non condensing)
3. Mount the product on flat surface using the mounting points.
A
A
A. Mounting point
Mounting orientation:
Select the mounting screws according to the mounting surface. The maximum screw diameter is 4.3 mm.
Important: Don't use excessive force when tightening the mounting screws.
4. Install the measuring hoses carefully so that the hoses don't bend too tightly.
Too tight curves may prevent the air flow to the sensor.
Copyright HK Instruments 2023 www.hkinstruments.fi User guide Version 1.0 2023
Information is subject to change without prior notice. EN - 104.004.008ug

Published: 31.05.2023 8 (11)
4.2 Measuring range selection
Settings for -250 models
±25 ±50 ±100 ±150 0...25 0...50 0...100 1) 0...250
Jumper 1
Jumper 2
Jumper 3
Settings for -2500 models
±100 0..100 0...250 0...500 0...1000 0...1500 0...2000 1) 0...2500
Jumper 1
Jumper 2
Jumper 3
Settings for -7000 models
0..750 0..1000 0...1250 0...2250 0...2500 0...3750 0...5000 1) 0...7000
Jumper 1
Jumper 2
Jumper 3
1) Factory setting
4.3 Selecting response time
The response time affects how fast the transmitter reacts to changes in the system. The response time is the time
the device takes to reach 63 % of the measured value. To smooth out unstable pressure fluctuations in applications,
select a longer response time.
1. Open the cover.
2. Press the zeroing button briefly.
The indicator light and display (-D models) indicate the selected response time.
Indicator light Display Response time
Three short flashes 0.8 0.8 seconds
Two long flashes 4.0 4 seconds
3. Close the cover.
Copyright HK Instruments 2023 www.hkinstruments.fi User guide Version 1.0 2023
Information is subject to change without prior notice. EN - 104.004.008ug

Published: 31.05.2023 9 (11)
4.4 Wiring
4-20 mA
4-20 mA
A
10...35 Vdc
Wiring polarity is free.
4.5 Zeroing
The possible zero point drifting can be eliminated by using the zeroing button on the circuit board.
Note: Supply voltage must have been connected for one hour prior the zeroing.
1. Disconnect both pressure measurement hoses.
2. Push the zeroing button until the indicator light turns on.
The indicator light turns on approximately after 4 seconds.
3. Release the zeroing button.
Zeroing starts and the indicator turns off. The zeroing is complete when the indicator light flashes two times.
4. Connect the pressure measurement hoses.
Copyright HK Instruments 2023 www.hkinstruments.fi User guide Version 1.0 2023
Information is subject to change without prior notice. EN - 104.004.008ug

Published: 31.05.2023 10 (11)
5 Disposal
The device is considered as electrical and electronic equipment for disposal in terms of the applicable European
Directive. At the end of life the product must enter the recycling system at an appropriate collection point.
• The device must be disposed through channels provided for this purpose.
• The disposal must be completed according to the local and currently applicable laws and regulations.
Generally all metals can be recycled as material. Plastics and cardboard packaging material can be used in energy
recovery. Printed circuit boards need selective treatment according to IEC 62635 guidelines. To aid recycling, plastic
parts are marked with an appropriate identification code. Contact your local HK Instruments distributor for further
information on environmental aspects and recycling instructions for professional recyclers.
Copyright HK Instruments 2023 www.hkinstruments.fi User guide Version 1.0 2023
Information is subject to change without prior notice. EN - 104.004.008ug

Published: 31.05.2023 11 (11)
6 Warranty policy
The seller is obligated to provide a warranty of five years for the delivered goods regarding material and
manufacturing. The warranty period is considered to start on the delivery date of the product. If a defect in raw
materials or a production flaw is found, the seller is obligated, when the product is sent to the seller without delay
or before expiration of the warranty, to amend the mistake at his/her discretion either by repairing the defective
product or by delivering free of charge to the buyer a new flawless product and sending it to the buyer. Delivery
costs for the repair under warranty will be paid by the buyer and the return costs by the seller. The warranty does not
comprise damages caused by accident, lightning, flood or other natural phenomenon, normal wear and tear, improper
or careless handling, abnormal use, overloading, improper storage, incorrect care or reconstruction, or changes
and installation work not done by the seller. The selection of materials for devices prone to corrosion is the buyer’s
responsibility, unless otherwise is legally agreed upon. Should the manufacturer alter the structure of the device, the
seller is not obligated to make comparable changes to devices already purchased. Appealing for warranty requires
that the buyer has correctly fulfilled his/her duties arisen from the delivery and stated in the contract. The seller will
give a new warranty for goods that have been replaced or repaired within the warranty, however only to the expiration
of the original product’s warranty time. The warranty includes the repair of a defective part or device, or if needed,
a new part or device, but not installation or exchange costs. Under no circumstance is the seller liable for damages
compensation for indirect damage.
Copyright HK Instruments 2023 www.hkinstruments.fi User guide Version 1.0 2023
Information is subject to change without prior notice. EN - 104.004.008ug
