Home Styles Modern Craftsman Bar Table User manual

IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damage occuring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Part List
Home Styles ConsumerAssistance: www.homestyles-furniture.com,
[email protected], 888-680-7460, 877-831-0319
Hardware List
Hex Wrench
1 Pc.
Small Hex Wrench
1 Pc.
Head Cap Bolt
16 Pcs. (+1 extra) Wood Screw
8 Pcs. (+1 extra)
Tools required for assembly : Phillips screwdriver
88 5050 351
Modern Craftsman Bar Table
A.
Table Top
1 Pc.
B.
Apron
4 Pcs.
Also need the Parts in carton 88 5050 352
Tools recommended for assembly : Level

Assembly Instructions 2
IMPORTANT
* Please keep Hex Wrench in a safe place as you may need to tighten up the Head Cap Bolts in the future.
* Do not tighten up all the screws until each part is properly assembled.
* Use a soft cloth between these parts and the floor.
STEP 2
Place Table Top (A)
upside down on a soft cloth.
Attach unit to Top (A)
with Wood Screws.
Turn the unit over its’ upright position.
To the level the unit,
adjust the adjustable levelers
on the bottom of legs.
(see Figure 2)
Note: Unit must be level to work properly.
B
B
B
B
B
CB
CB
C
B
C
B
A
/2
Head Cap Bolt
Wood Screw
STEP 1
Assemble Legs (C)
with Apron (B) by using
Head Cap Bolts.
(see Figure 1)
Figure 1
Figure 2
B
B
B
B
