Home Styles Storage Island 20 05530 0942 User manual

Hardware List
Part List
Home Styles Customer Service: www.homestyles-furniture.com,
[email protected], 888-680-7460, 877-831-0319
Tool(s) required for assembly: Phillips screwdriver, Level, Drill (8 volts or less), 3/16” Drill Bit, 3/8” Drill Bit
IMPORTANT
Carefully remove all the parts from the carton and
place them individually on a soft cloth to prevent
scratches or other damage.
Carefully and strictly follow these assembly instructions
to ensure a completed product as designed.
Do not use power tools above 8 volts to assemble.
Cartons 20 05530 0941, 0943 are also needed for assembly.
20 05530 0942
Storage Island
B.
Bottom
1 pc.
E.
Back Panel
1 pc.
F.
Shelf
6 pcs.
C.
Plinth
2 pcs.
D.
Back Panel
1 pc.
G.
Front Rail
4 pcs.
M4x25
Machine Screw
20 pcs.
Adjustable Pin
24 pcs. (+1 extra)
Cam Lock
30 pcs. (+4 extra)
M3.5x20
Wood Screw (short)
60 pcs. (+1 extra)
Knob (small)
8 pcs.
Knob (large)
12 pcs.
M x430
Wood Screw (long)
80 pcs. (+1 extra)
M x254
Wood Screw
8 pcs. (+1 extra)
M6x25
Head Cap Bolt
20 pcs. (+1 extra)
Hex Wrench
1 pc.
Small Hex Wrench
1 pc.
Cam Lock Screw
30 pcs. (+2 extra)

Assembly Instructions 2/9
STEP 1
Insert Cam Lock Screws into
pre-drilled holes in Plinths (C),
Side Panels (H), (I) and Middle Panel (J),
then tighten. (See Figure 1)
Cam Lock Screw
Figure 1
J
IMPORTANT
Use a soft cloth between these parts and the floor.
Do not use power tools above 8 volts to assemble.
Do not tighten all the bolts until each part is properly assembled.
The unit must be level to work properly. Use the included adjustable levelers to level.
Keep Hex Wrench as the bolts may need to be tightened in future.
HI
Cam Lock Screw
C
C
Cam Lock Screw

STEP 3
Attach Bottom (B) to unit
with Head Cap Bolts,
tightening bolts only halfway.
(See Figure 3)
Note: Arrow label indicates
front of Bottom (B).
Tighten Head Cap Bolts.
Arrow label at front
STEP 2
Attach Back Panels (D) and (E) to
Middle Panel (J) with Cam Locks.
(See Figure 2)
Attach Front Rails (G) to unit.
Cam Lock
Assembly Instructions 3/9
Figure 2
Figure 3
E
D
G
G
G
G
B
J
Head Cap Bolt

STEP 4
Attach Side Panels (H) and (I)
to unit with Cam Locks.
Cam LockWood Screw
Assembly Instructions 4/9
I
H
STEP 5
Attach Plinths (C) to unit
with Cam Locks
and Wood Screws.
Attach Leg Support (K) to unit.
(See Figure 4)
Figure 4
Cam Lock
C
C
K

STEP 6
Turn unit over to its upright position.
Attach Top (A2) to unit with Head Cap Bolts,
tightening bolts only halfway.
Note: Arrow label indicates
front of Top (A2).
Tighten Head Cap Bolts.
Level unit by adjusting the adjustable
levelers on bottom of unit. (See Figure 5)
Note: Unit must be level to work properly.
STEP 7
Attach Top (A1) to unit
with Head Cap Bolts,
tightening bolts only halfway.
Tighten Head Cap Bolts.
Assembly Instructions 5/9
A1
Head Cap Bolt
Figure 5
Arrow label at front Head Cap Bolt
A2

Part List
Assembly Instructions 6/9
Drawer (L)
STEP 8
Attach Drawer Front (L1) and Drawer
Back (L2) to Drawer Side (L3)
with Wood Screws (long).
Attach Drawer Side (L4) to unit
with Wood Screws (long).
Roller at back
STEP 9
Slide Drawer Bottom (L5) into groove.
Attach Drawer Bottom (L5) to
unit with Wood Screws (short).
STEP 10
Attach Knobs (small) with Machine Screws.
L1.
Drawer Front
4 pcs.
L5.
Drawer Bottom
4 pcs.
L2.
Drawer Back
4 pcs.
L3.
Drawer Side
4 pcs.
L4.
Drawer Side
4 pcs.
L1
L2
L3
L4
L5
Bottom
Wood Screw (long)
Wood Screw (short)
Machine Screw
Knob (small)

Part List
Assembly Instructions 7/9
Drawer (M)
STEP 12
Slide Drawer Bottom (M5) into groove.
Attach Drawer Bottom (M5) to
unit with Wood Screws (short).
STEP 13
Attach Knobs (large) with Machine Screws.
M1.
Drawer Front
6 pcs.
M5.
Drawer Bottom
6 pcs.
M2.
Drawer Back
6 pcs.
M3.
Drawer Side
6 pcs.
M4.
Drawer Side
6 pcs.
Roller at back
M1
M2
M3
M4
M5
Bottom
Wood Screw (long)
Wood Screw (short)
Machine Screw
Knob (large)
STEP 11
Attach Drawer Front (M1) and Drawer
Back (M2) to Drawer Side (M3)
With Wood Screws (long).
Attach Drawer Side (M4) to unit
With Wood Screws (long).

Assembly Instructions 8/9
L
M
L
M
M
L
M
L
M
M
STEP 14
Slide Drawers (L) and (M) into position.
STEP 15
Insert Adjustable Pins into
side panels and middle panel
at desired level.
Place Shelves (F) into position.
F
F
F
F
F
F
Adjustable Pin

Assembly Instructions 9/9
Hardware List
STEP 16
Drill a 3/16” hole 1/2” deep 1” from top in
middle of side panel that is against a wall.
Place unit at desired location.
Drill a 3/8” hole in wall in-line with
3/16” hole drilled in side panel.
Move unit.
Insert Anchor into the wall hole
and attach Bracket with Wall Screw.
Attach Bracket at drilled hole in
side panel with Wood Screw.
Move unit back into place.
Slide Tipover Restraint through
Bracket on wall and Bracket on side panel.
(See Figure 6)
Put tie end of Tipover Restraint into lock
end of Tipover Restraint and pull until tight.
Anchor
1 pc. (+1 extra)
Bracket
2 pcs. (+1 extra)
Tipover Restraint
1 pc. (+1 extra)
M3.5x40
Wall Screw
1 pc. (+1 extra)
M3.5x16
Wood Screw
1 pc. (+1 extra)
Figure 6
Wood Screw
Wall Screw
Bracket
on wall
Anchor in wall
3/8” wall hole
3/16” hole in
side panel
Tie end
Lock end
Bracket
on side panel
Tipover
Restraint
Per regulatory requirements, a Tip-over Restraint is included. Follow Step 16 to install it.
Drill 3/16” hole in side panel
Drill 3/8” hole in wall

NEVER
use glass cleaners on
finished furniture. Ammonia
chemically attacks the finish.
allow liquids to remain on furniture.
Absorption causes parts to warp
and split and finishes to delaminate.
NEVER
CARE INSTRUCTIONS
Do not use rubber
based placemats.
PREVENT
DISCOLORING
Do not use commercial
waxes and polishes.
PREVENT
YELLOWING
Do not place hot
objects on surface.
PREVENT
FINISH DAMAGE
Do not write
directly on surface.
PREVENT
MARKING
Do not use power tools
above 8 volts to assemble.
PREVENT
CRACKING
Do not place
in direct sunlight.
PREVENT
FADING
with a soft cloth moistened
in lukewarm soap and water.
Buff with a dry clean cloth.
CLEAN
Home Styles will provide replacements free of charge for missing or damaged hardware or parts within 30 days of
purchase. Digital images of the defective parts may be required. If the product was not purchased from an authorized
retail affiliate, Home Styles is under no obligation to provide replacement parts. Parts are not available for fully assembled
items nor are parts available for sale. Replacements for missing or damaged hardware or parts may be requested at:
www.homestyles-furniture.com/customer-service/replacement-parts
Home Styles Customer Service: www.homestyles-furniture.com,
[email protected], 888-680-7460, 877-831-0319

Part List
Home Styles Customer Service: www.homestyles-furniture.com,
[email protected], 888-680-7460, 877-831-0319
A2.
Top
1 pc.
For assembly see instructions in carton 20 05530 0942.
IMPORTANT
Carefully remove all the parts from the carton and
place them individually on a soft cloth to prevent
scratches or other damage.
Carefully and strictly follow these assembly instructions
to ensure a completed product as designed.
Do not use power tools above 8 volts to assemble.
20 05530 0941
Storage Island
A1.
Top
1 pc.

STEP 3
Remove foam and Tops (A1), (A2).
Carton
Top (A1)
Foam
Wood Crate
STEP 1
Open carton.
Figure 1
Unpacking Instructions
Wood Support
A2
STEP 2
Use a hammer to remove
wood supports.
(See Figure 1)
Note: Do not hit top with
hammer.
Top (A2)
A1
