Honeywell ADEMCO 4110XM User manual

ADEMCO 4110XM
ADEMCO 4110XMADEMCO 4110XM
ADEMCO 4110XM
SECURITY SYSTEM
SECURITY SYSTEMSECURITY SYSTEM
SECURITY SYSTEM
User Guide
User GuideUser Guide
User Guide
N5100V5 4/99 Rev. C

– 2 –
IMPORTANT!
PROPER INTRUSION PROTECTION
For proper intrusion coverage, sensors should be located at every possible point of entry to a home or
commercial premises. This would include any skylights that may be present, and the upper windows in a
multi-level building.
In addition, we recommend that radio backup be used in a security system so that alarm signals can still
be sent to the Central onitoring Station in the event that the telephone lines are out of order (alarm
signals are normally sent over the phone lines).
EARLY WARNING FIRE DETECTION
Early warning fire detection is important in a home. Smoke and heat detectors have played a key role in
reducing fire deaths in the United States. With regard to the number and placement of smoke/heat
detectors, we subscribe to the recommendations contained in the National Fire Protection Association's
National Fire Alarm Code (NFPA 72). These recommendations can be found in the “National Fire
Protection Association Recommendations” section of this manual.
SYSTEM COMPATIBILITY NOTICE
Your Honeywell security system is designed for use with devices manufactured or approved by Honeywell
for use with your security system. Your Honeywell security system is not designed for use with any device
that may be attached to your security system's keypad or other communicating bus if Honeywell has not
approved such device for use with your security system. Use of any such unauthorized device may cause
damage or compromise the performance of your security system and affect the validity of your Honeywell
limited warranty. When you purchase devices that have been manufactured or approved by Honeywell,
you acquire the assurance that these devices have been thoroughly tested to ensure optimum
performance when used with your Honeywell security system.
A out This Manual
This manual is a step-by-step guide that will acquaint you with the system's features and benefits. It defines
the components and their functions, describes their operation, and provides clear step-by-step instructions
for normal and emergency procedures. Keep this manual in a convenient place so that you can refer to it
as necessary.
Congratulations on your ownership of a Honeywell Security System. You have made a wise decision in
choosing it, for it represents the latest in security protection technology today, including microcomputer
technology to monitor all system status. Honeywell is the world's largest manufacturer of security
systems and millions of premises are protected by Honeywell systems.

– 3 –
TABLE OF CONTENTS
System Overview ......................................................................................................................................... 5
General ...................................................................................................................................................... 5
Keypads ..................................................................................................................................................... 5
Zones .......................................................................................................................................................... 5
Alarms........................................................................................................................................................ 5
Fire Protection ........................................................................................................................................... 6
Burglary Protection ................................................................................................................................... 6
Memory of Alarm....................................................................................................................................... 6
Pager Notification ..................................................................................................................................... 6
About the Keypad ...................................................................................................................................... 7
Keypad tyles ........................................................................................................................................... 7
Keypad Functions ....................................................................................................................................... 8
ummary of ystem tatus Displays ....................................................................................................... 8
ummary of Keypad Functions ................................................................................................................ 9
Security Codes ........................................................................................................................................... 11
General .................................................................................................................................................... 11
Duress Code ............................................................................................................................................. 11
Quick Arming .......................................................................................................................................... 11
Assigning, Changing or Deleting User Codes ........................................................................................ 12
Entry/Exit Delays ...................................................................................................................................... 13
General Information ............................................................................................................................... 13
Checkin for Open Zones ........................................................................................................................ 14
Using the 6 READY Key ..................................................................................................................... 14
Armin The System ................................................................................................................................. 15
Using The 3 TAY Key ....................................................................................................................... 15
Using The 7 IN TANT Key ................................................................................................................ 16
Using The 2 AWAY Key ....................................................................................................................... 17
Using The 4 MAXIMUM Key............................................................................................................... 18
Disarmin and Silencin Alarms ......................................................................................................... 19

– 4 –
(continued) TABLE OF CONTENTS
Using the 1 OFF Key ............................................................................................................................ 19
To Disarm the ystem .................................................................................................................................. 19
To ilence a Burglary Alarm .................................................................................................................. 19
Bypassin Protection Zones ................................................................................................................... 20
Using The 6 BYPA Key ......................................................................................................................... 20
Quick Bypass ........................................................................................................................................... 21
Usin the Keyswitch ................................................................................................................................. 22
General .................................................................................................................................................... 22
Arming ..................................................................................................................................................... 22
Disarming ................................................................................................................................................ 22
Chime Mode ................................................................................................................................................ 23
Using the 9 CHIME Key ...................................................................................................................... 23
Panic Keys .................................................................................................................................................. 24
Using Panic Keys .................................................................................................................................... 24
Testin the System ................................................................................................................................... 26
Using the 5 TE T Key .......................................................................................................................... 26
Trouble Conditions ................................................................................................................................... 27
"Check" and "Battery" Displays .............................................................................................................. 27
Power Failure .......................................................................................................................................... 27
Other Displays ......................................................................................................................................... 28
Fire Alarm System .................................................................................................................................... 29
General .................................................................................................................................................... 29
In Case of Fire Alarm .............................................................................................................................. 29
ilencing Fire Alarms ............................................................................................................................. 30
National Fire Protection Association Recommendations on moke Detectors .................................... 31
Emergency Evacuation ........................................................................................................................... 32
Quick Guide to Alarm System Functions ............................................................................................ 33
Summary of Audible/Visual Notification ............................................................................................ 34
Protection Zones List ............................................................................................................................... 35
Owner's Insurance Premium Credit Request .................................................................................... 36
Re ulatory Statements and Warnin s ................................................................................................. 38
In The Event of Telephone Operational Problems ............................................................................ 40
Limitations of this Alarm System ......................................................................................................... 41
Servicin Information ............................................................................................................................. 42
Two Year Limited Warranty ................................................................................................................... 43

System Overview
– 5 –
General
This system offers you three forms of protection: burglary, fire and emergency. Your
system may consist of at least one keypad which provides full control of system
operation, various sensors such as motion detectors and door and window sensing
devices, plus a selected number of strategically placed smoke or combustion detectors
designed to provide early warning in case of fire. Your system may also have been
programmed to automatically transmit alarm or status messages over the phone
lines to a central alarm monitoring station.
Keypads
All system functions are controlled by your keypad(s). The keypads feature a
telephone style (digital) keypad and a Liquid Crystal Display (LCD) which shows the
nature and location of all occurrences. Their built-in sounder will sound during alarm
and trouble conditions.
For additional information, see the following section: ABOUT THE KEYPAD.
Zones
Your system's sensing devices have been assigned to various zones. For example, the
sensing device on your Entry/Exit door may have been assigned to zone 01, sensing
devices on windows in the master bedroom to zone 02, and so on. These zone numbers
will appear on the display when an alarm or trouble condition occurs.
Alarms
When an alarm occurs, both the keypad and external sounders will sound, and a mes-
sage at the keypad will identify the zone(s) causing the alarm. In addition, if your
system is connected to a central monitoring station, an alarm message will be sent.
To stop the alarm sounding, you simply disarm the system.

System Overview (cont’d)
– 6 –
Fire Protection
The fire protection portion of your security system (if used) is always on and will
sound an alarm if a fire condition is detected. Refer to the FIRE ALARM SYSTEM
section for important information concerning fire protection, smoke detectors and
planning emergency exit routes from your premises.
Burglary Protection
The burglary protection portion of your system must be turned on or "armed" before
it will sense burglary alarm conditions and sound an alarm. Your system can be
armed in one of four modes: TAY, AWAY, IN TANT and MAXIMUM. Refer to the
ARMING THE SYSTEM sections for instructions in using these modes of operation.
Your system also provides a CHIME mode for alerting you to the opening and closing
of doors and windows while the system is disarmed.
Memory of Alarm
When an alarm or trouble condition occurs, the keypad displays the number(s) of the
zone(s) that caused the problem, and displays the type of alarm or trouble (ex. FIRE,
ALARM, CHECK). The display remains until it is cleared by entering the OFF
sequence (security code + OFF key) twice.
Pager Notification
If you have chosen to be notified of alarms or other system conditions by pager, the
following codes will be sent to your pager by the control:
1811=Trouble 1911=Alarm
1001=Open 1002=Close

About the Keypad
– 7 –
Keypad Styles
The 6150 is a Fixed-Word keypad. The keys on the keypads are located behind a flip-down
door which can be removed, if desired.
1OFF
4MAX
7
INSTANT
READY
2AWAY
5TEST
8CODE
0
3STAY
6
BYPASS
9CHIME
#
ARMED
READY
6150-00-001-V0
SHOWN WITH DOOR RE OVED

About the Keypad (cont’d)
– 8 –
SUMMARY OF SYSTEM STATUS DISPLAYS
AWAY All burglary zones, interior & perimeter, are
armed.
STAY Perimeter burglary zones, such as windows
and doors are armed.
INSTANT Perimeter burglary zones armed and entry
delay is turned off.
BYPASS One or more burglary protection zones have
been bypassed.
NOT READY Appears when burglary portion of the system
is not ready for arming (due to one or more
open protection zones).
READY The burglary portion of the system is ready to
be armed.
NO AC Appears when AC power has been cut off.
ystem is operating on backup battery power.
AC Appears when AC power is present.
CHIME Appears when the CHIME feature is ON.
BAT Low system battery.
ALARM Appears when an intrusion has been detected
and the system is armed (also appears during
a fire alarm). Accompanied by the ID # of the
protection zone in alarm.
CHECK Appears when a malfunction is discovered in
the system at any time or if a fault is detected
in a FIRE zone at any time or in a DAY
(Trouble)/NIGHT (Alarm) burglary zone
during a disarmed period. Accompanied by a
display of zone number in trouble.
FIRE Appears when a fire alarm is present.
Accompanied by a display of the zone in
alarm.
ALARM
FIRE
AWAY
BYPASS
STAY
CHECK INSTANT
NO AC
NOT READY
CHIME BAT
00
style B_disp.
FIXED-WORD KEYPAD
DISPLAY

Keypad Functions
– 9 –
SUMMARY OF KEYPAD FUNCTIONS
1. DISPLAY WINDOW: Displays protection
zone ID and system status messages.
2. 1 OFF KEY: Disarms burglary portion
of the system, silences alarms and
audible trouble indicators, and
clears visual display after problem's
correction.
3. 2 AWAY KEY: Arms the entire
burglary system, perimeter and
interior.
4. 3 STAY KEY: Arms perimeter portion
of burglary system only. Interior
protection is not armed, which
allows movement within premises
without causing alarm.
5. 4 MAXIMUM KEY: Arms in manner
similar to AWAY mode, but without
the entry delay feature, thus provid-
ing maximum protection. An alarm
will occur immediately upon
opening any protection point,
including the entry/exit door.
6. 5 TEST KEY: Tests the system and
alarm sounder if disarmed. Refer to
TESTING THE SYSTEM section
for test procedures.
7. 6 BYPASS KEY: Removes individual
protection zones from being
monitored by the system.
8. 7 INSTANT KEY: Arms in manner
similar to TAY mode, but without
the entry delay feature. Entering via
the entry/exit door will cause an
instant alarm.
9. 8 CODE KEY: Used to assign
additional user codes for other users
of the system.
10. 9 CHIME KEY: Turns CHIME mode on
and off. When on, the opening of
windows or doors while the system is
disarmed will sound 3 beeps at the
keypad(s).
11. 6 READY KEY: Displays all open
protection zones.
12. # KEY: "Quick Arm" key permits
ARMING of the sys
tem without use of
a security code (if so programmed).
13. KEYS 0–9
†
: Used to enter your security
code(s).
14. READY INDICATOR: (GREEN) Lit when
the system is ready to be armed (no faults
present). While the system is disarmed,
this indicator will go on and off as
protection zones are closed and opened.
Note: On some keypads a POWER INDICATOR
(GREEN) is lit when AC power is present. If
the indicator is off, the system may still be
operating, but on its backup battery power.
See Power Failure in TROUBLE CONDITIONS
section.

Keypad Functions (cont’d)
– 10 –
15. ARMED INDICATOR: (RED) Lit when
the system has been armed ( TAY,
AWAY, IN TANT or MAXIMUM).
16. INTERNAL SOUNDER: The built-in
keypad sounder mimics the alarm
sounder during alarms, and will also
"beep" during certain system functions.
(see SUMMARY OF AUDIBLE/
VISUAL NOTIFICATION).
17. EMERGENCY KEYS:
Individual keys A, B, and C (key D not
used). On some keypads, these keys are
not present, and the following key pairs
may be available, instead, for
emergency functions:
6 & # , 6 & 1 , # & 3
ome or all of these keys/pairs may be
programmed for panic functions by your
installer (see PANIC KEYS section).
IMPORTANT! When entering codes and
commands, sequential key depressions must
be made within 2 seconds of one another. If 2
seconds elapses without a key depression,
the entry is aborted and must be repeated
from its beginning.
13
24
6
89
10
12
15
16
6150-007-V0
14
B
C
A1OFF 2AWAY 3STAY
0#
456
7
MAX TEST
BYPASS
9CHIME
8CODE
13
7
INSTANT
READY
11
17
ARMED
READY
5
†
Note: Keys 1 through 9 each perform their associated companion functions (OFF, AWAY, STAY,
etc.) when preceded by an entry of the security code (as described later).

Security Codes
– 11 –
General
At the time of installation, your installer programmed a personal four-digit Master
code, known only to you and yours. This code is used to perform most system
functions, including arming and disarming of the system. As an additional safety
feature, temporary user codes can be assigned (see next page) for use by those not
having a need to know the Master code. Note that the Master code remains in effect
even when other user codes are assigned.
Duress Code
Ask your installer if "Duress" is active for your system. If so, check here:
This feature is intended for use when you are forced to disarm or arm the system
under threat. When used, the system will act normally, but can silently notify the
central station of your situation, if that service has been provided.
The Duress code is defined as User number 8.
Important: The Duress code is useful only when connected to a central station.
Quick Arming
Ask your installer if "Quick Arming" is active for your system. If so, check here:
If your system supports "Quick Arming", the "#" key can be pressed in place of the
security code when arming the system. The security code is always required,
however, when disarming the system.

Security Codes (cont’d)
– 12 –
Assigning, Changing, or Deleting User Codes
4-DIGIT USER CODES
It is recommended that obvious codes
such as 1 1 1 1 or 1 2 3 4 not be
assigned.
1. Enter your Master code and press the CODE key.
2. Enter single-digit user number ('2', '3', '4', '5', '6' or '7') for which a code is to be
assigned, changed, or deleted.
3. If assigning or changing a user's code, enter the desired 4-digit code for use
by that user number. The keypad will beep once.
If deleting a user's code, perform steps 1 & 2 and stop. In a few moments the
keypad will beep once, indicating that the existing code has been deleted.
To assign your Duress code, perform the following:
Enter your [Master code] + [8] + [8] + [desired 4-digit code]. The keypad will
beep once.
The Master code can be changed by the main user of the system. To change it,
perform the following:
Enter your [Master code] + [8] + [1] + [new Master code] + [new Master code]
again. The keypad will beep once.
Important: Temporary users should not be shown how to use any system function
they do not need to know (e.g., bypassing protection zones).

Entry/Exit elays
– 13 –
General Information
Your system has preset time delays, known as exit delay and entry delay. When you
arm your system, exit delay gives you time to leave through the entry/exit door
without setting off an alarm. Entry delay gives you time to disarm the system when
you re-enter through the entry/exit door. The system must be disarmed, however,
before the entry delay period ends, or an alarm will occur. The keypad will beep
slowly during the entry delay period, reminding you to disarm the system.
You can also arm the system with no entry delay at all by using either IN TANT or
MAXIMUM arming modes. These modes can provide greater security while you are
sleeping or while you are away for extended periods of time.
ee your installer for your delay times and record them here:
Exit Delay: seconds
Entry Delay: seconds

Checking for Open Zones
– 14 –
Using the 6
66
6 READY Key
Before your system can be armed, all protected doors, windows and other protection
zones must be closed or bypassed (see BYPASSING PROTECTION ZONES section),
otherwise the keypad will display a "Not Ready" message, and if your keypad has a
READY indicator light, it will not be lit. The READY key can be used to display all
faulted zones, making it easier for you to secure any open zone.
To display faulted zones, simply press and release the READY key (do not enter code
first). ecure or bypass the zones displayed before arming the system.
A "Ready" message will be displayed when all protection zones have been either
closed or bypassed and the keypad's READY indicator light (if present) will be lit.
TYPICAL DISPLAYS
WHEN NOT READY TO ARM
AC
N O T R E A D Y
4110-002-V0
INDICATING FAULTED PROTECTION ZONE
(AFTER PRESSING READY KEY)
0 3
AC
N O T R E A D Y
4110-003-V0
INDICATING "READY TO ARM"
AC
4110-004-V0

Arming the System
– 15 –
Using the 3 STAY Key (Arms Perimeter Only, Entry Delay On)
Use this key when you are stayin inside, but expect someone to use an
entry/exit door later.
Before Arming close all doors and windows (see CHECKING FOR OPEN ZONES).
1. Enter your security code and press the STAY key.
2. The keypad will beep three times and will display the armed message. The red
ARMED indicator will light.
3. The system will arm. An alarm will sound immediately if a protected perimeter
window or non-entry/exit door is then opened, but you may otherwise move freely
throughout the premises.
Later arrivals can enter through an entry/exit door without causing an alarm, but
they must disarm the system within the entry delay period to avoid sounding an
alarm.
TYPICAL DISPLAY
"ARMED STAY"
ALARM
AWAY
BYPASS
STAY
SUPV NO AC
PHONE TEST
NOT READY
CHIME BAT
FIRE
CHECK INSTANT TAMPER
FIXED-WORD

Arming the System (cont’d)
– 16 –
Using the 7 INSTANT Key (Arms Perimeter Only, Entry Delay Off)
Use this key when you are stayin inside, and do not expect anyone to use
an entry/exit door.
Before Arming close all doors and windows (see CHECKING FOR OPEN ZONES).
1. Enter your security code and press the INSTANT key.
2. The keypad will beep three times and will display the armed message. The red
ARMED indicator will light.
3. The system will arm. An alarm will sound immediately if any protected perimeter
window or door is then opened, but you may otherwise move freely throughout the
premises.
An alarm will sound immediately if anyone opens an entry/exit door.
TYPICAL DISPLAY
"ARMED INSTANT"
ALARM
AWAY
BYPASS
STAY
SUPV NO AC
PHONE TEST
NOT READY
CHIME BAT
FIRE
CHECK INSTANT TAMPER
FIXED-WORD

Arming the System (cont’d)
– 17 –
Using the 2 AWAY Key (Arms Entire System, Entry Delay On)
Use this key when no one will be stayin inside.
Before Arming close all doors and windows (see CHECKING FOR OPEN ZONES).
1. Enter your security code and press the AWAY key.
2. The keypad will beep twice and will display the armed message. The red ARMED
indicator will light.
3. You may leave through an entry/exit door during the exit delay period without
causing an alarm.
After exit delay, the system arms and will sound an alarm if a protected window or
non-entry/exit door is then opened, or if any movement is detected inside your
premises.
You may reenter through an entry/exit door, but must disarm the system within the
entry delay period to avoid an alarm.
TYPICAL DISPLAY
"ARMED AWAY"
ALARM
AWAY
BYPASS
STAY
SUPV NO AC
PHONE TEST
NOT READY
CHIME BAT
FIRE
CHECK INSTANT TAMPER
FIXED-WORD

Arming the System (cont’d)
– 18 –
Using the 4 MAXIMUM Key (Arms Entire System, Entry Delay OFF)
Use this key when the premises will be vacant for extended periods of time
such as vacations, etc, or when no one will be movin throu h protected
areas.
Before Arming close all doors and windows (see CHECKING FOR OPEN ZONES).
1. Enter your security code and press the MAX key.
2. The keypad will beep twice and will display the armed message. The red ARMED
indicator will light.
3. You may leave through an entry/exit door during the exit delay period without
causing an alarm.
After exit delay, the system arms and will sound an alarm if a protected window or
door is then opened, or if any movement is detected inside your premises.
An alarm will sound immediately if anyone opens an entry/exit door.
TYPICAL DISPLAY
"ARMED MAXIMUM"
ALARM
AWAY
BYPASS
STAY
SUPV NO AC
PHONE TEST
NOT READY
CHIME BAT
FIRE
CHECK INSTANT TAMPER
FIXED-WORD

isarming and Silencing Alarms
– 19 –
Using the 1 OFF Key
The OFF key is used to disarm the system and to silence alarm and trouble sounds.
IMPORTANT: If you return and the main bur lary sounder is on: DO NOT
ENTER, but CONTACT THE POLICE from a nearby safe location.
If you return after an alarm has occurred and the main sounder has shut
itself off: the keypad will beep rapidly upon your entering, indicating that an alarm
has occurred during your absence (the Memory of Alarm feature).
LEAVE IMMEDIATELY and CONTACT THE POLICE from a nearby safe location.
WHEN AFE TO DO O, re-enter and follow the procedure for silencing an alarm.
To Disarm the System
Enter your security code and press the OFF key. The "Ready" message will be
displayed, and the keypad will emit a single tone to confirm that the system is
disarmed.
To Silence a Burglary Alarm
Enter your security code and press the OFF key to silence the alarm (or warning
tones of a Memory of Alarm). Note the zone in alarm on the keypad display, and
make that zone intact (close door, window, etc.). Now enter the security code plus
OFF sequence again to clear the keypad's Memory of Alarm display. If the display
will not clear and does not provide a "Ready" message, notify the alarm agency.
To ilence a Fire Alarm simply press the OFF key (the security code is not needed to
silence FIRE alarms). To then clear the keypad's Memory of Alarm display, enter
your security code and press the OFF key again.
Refer to the Fire Alarm System section for additional information.
Refer to the Summary of Audible/Visual Notification section for information
which will help you to distinguish between FIRE (Interrupted/Pulsed) and
BURGLARY (Continuous/ teady) alarm sounds.

Bypassing Protection Zones
– 20 –
Using the 6 BYPASS Key
This key is used when you want to arm your system with one or more zones
intentionally unprotected. The system must be disarmed first.
When bypassing zones:
• The system will not allow fire zones to be bypassed.
• All bypasses are removed when an OFF sequence (security code plus OFF) is
performed.
• Bypassed zones are unprotected and will not cause an alarm if violated while
your system is armed.
1. Enter your security code and press the BYPASS key.
2. Enter zone number(s) for the zone(s) to be bypassed (e.g., 06, 10, 13, etc.). Si gle
digit zo e umbers must be preceded by a zero (e.g. 05, 06).
3. When finished, the keypad will display a "Bypass" message along with each by-
passed zone number, accompanied by a beep for each. Wait for these zones to be
displayed, to confirm their bypass.
4. Arm the system as usual.
TYPICAL MOMENTARY DISPLAY
OF BYPASSED ZONE
0 3
BYPASS
ACAC
4110-001-V0
FIXED-WORD
