Honeywell LYNX Touch L5210 Series User manual

LYNX Touch
L5210/L7000 Series
Security Systems
Home Automation Guide
800-19979 12/14Rev. B

Home Automation
Table of Contents
Z-Wave Programming...................................................................................................................................................3
General Information......................................................................................................................................................3
Including Z-Wave Devices............................................................................................................................................5
Including Light Switches or Outlet Modules .............................................................................................................6
Including Door Locks................................................................................................................................................6
Including Thermostats, IR Extenders and Water Valves..........................................................................................6
Thermostat Energy Saving Mode.............................................................................................................................6
Edit and Exclude/Delete Z-Wave Devices...................................................................................................................7
Edit Z-Wave Device Names .....................................................................................................................................7
Exclude/Delete a Z-Wave Device.............................................................................................................................7
Controlling Z-Wave Devices.........................................................................................................................................7
Turn On/Off All Lights...............................................................................................................................................7
Z-Wave Operation ....................................................................................................................................................8
Scenes............................................................................................................................................................................9
General Information..................................................................................................................................................9
Programming a Scene..............................................................................................................................................9
Editing/Deleting a Scene........................................................................................................................................10
Running a Scene....................................................................................................................................................11
Schedules ....................................................................................................................................................................12
General Information................................................................................................................................................12
Programming a Scheduled Function......................................................................................................................12
Editing a Scheduled Function.................................................................................................................................13
Deleting a Scheduled Function...............................................................................................................................13
Rules.............................................................................................................................................................................14
General Information................................................................................................................................................14
Programming Rules................................................................................................................................................14
Editing or Deleting Rules........................................................................................................................................17
Garage Door Opener Operation.................................................................................................................................18
General Information................................................................................................................................................18
Enrolling the 5877 Relay Receiver.........................................................................................................................18
Garage Door Feature Operation.............................................................................................................................18
Operate Garage Door from LYNX Touch Control Panel........................................................................................19
Advanced Z-Wave Operations...................................................................................................................................20
View Enrolled Z-Wave Devices or Controllers .......................................................................................................20
Remove/Delete All Z-Wave Devices (Reset Controller).........................................................................................20
Shift Primary Control...............................................................................................................................................20
Failed Devices (Nodes)...............................................................................................................................................20
Z-Wave Glossary.........................................................................................................................................................21
Z-Wave Compatibility..................................................................................................................................................22
Compatible Z-Wave Devices..................................................................................................................................22
Important Notes...........................................................................................................................................................23
Wireless Range ......................................................................................................................................................23
Additional Z-Wave Information...............................................................................................................................23
- 2 -

Home Automation
Z-Wave® Programming
General Information
The Honeywell LYNX Touch L5210 and L7000 controls are security enabled Z-Wave® devices. The controls
feature Z-Wave technology that is designed to automate devices in a home control network. The control allows
you to easily add and control multiple devices with the press of a button and supports Z-Wave Network Wide
Inclusion (NWI) Mode. Check with your installer to see if these features are available.
Your control and every Z-Wave device you add are linked together into a wireless network. Each device in your
network has a unique address assigned to it and cannot be activated by your neighbor's Z-Wave controller. The
Z-wave network supports multiple controllers allowing additional Z-wave remotes to be used throughout the
home. Management of Z-Wave devices, which are also known as modules or nodes, includes two main
operations; inclusion/exclusion and association (or controlling). Refer to the Controlling Z-Wave Devices section
for information regarding “association”. The LYNX Touch supports the Association Command Class.
This section describes how to Include (add) devices into your home control network, edit devices and Exclude
(delete) devices. Automation and Z-Wave functions are accessed via the LYNX Touch Automation icon, Z-Wave
Device Management and Z-Wave Advanced Tools screens. The devices can be controlled from the LYNX Touch
control or a Mobile Internet Device (MID). Check with your Installer to see which features are available with
your system. Once the Z-Wave devices have been Included (added) to the network they can be controlled either
manually or through “Scenes” that are programmed in your LYNX Touch control’s Automation feature.
The Automation icon on the LYNX Touch Home Screen provides access to Z-Wave Home Automation features.
Refer to the Z-Wave Glossary for additional information regarding terms and functions. A list of compatible
devices can be found in the Z-Wave Compatibility Chart contained in this document.
LYNX Touch Home Screen
LYNX Touch Home Screen
(Total Connect Remote Services Enabled)
Automation is intended for lifestyle convenience. It should not be used for life safety or property protection.
U
L
Z-Wave automation functionality is supplementary only and has not been evaluated by UL.
- 3 -

Home Automation
Z-Wave® Programming
LYNX Touch Automation Screen (Page 1)
Button Function
Switches
Provides access to the Switches Screen
Thermostats Provides access to the Thermostats Screen
Locks
Provides access to the Locks Screen
Garages
Provides access to control Garage Door operation.
Water Valves
Provides Access to control Water Valve operation.
Press to see
Failed devices
Displayed only when device failures have been detected in the
Z-Wave network (Refer to the Failed Device section for
additional information).
Use the down arrow to scroll to the next page.
LYNX Touch Automation Screen (Page 2)
Button Function
Scenes
Provides access to the Scenes Screen. Scenes are used to
control a single or group of devices, turning them Off/On, to a
preset level, temperature or mode. Up to 20 scenes can be
programmed.
Schedules
Provides access to the Schedules Screen. Schedules are used
to activate Scenes based on a specified time and repeat
frequency.
Rules
Provides access to the Rules Screen. Rules are used to
automate Z-Wave devices based on specified Zone Activity,
Alarm Status or Alarm Conditions.
Tools
Provides access to the Z-Wave Device Management Screen
and Advanced Tools option.
Garage door
setup
Provides access to program/enroll Garage Door Openers.
Other Devices
Provides access to control Unknown or Unsupported Devices.
Basic On/Off commands are included. The action or response
to this command is implemented by the Device Manufacturer.
Note: Z-Wave devices that appear in the “Other Devices”
category are not supported and are not deemed to be
interoperable in LYNX Touch Z-Wave system.”
Z-Wave Device Management Screen
Button Function
Include Devices
Enroll Z-Wave Devices/Modules
Exclude Devices
Delete Z-Wave Devices/Modules
View Failed Devices
Displayed only when device failures have been detected
in the Z-Wave network (Refer to the Failed Devices
section for additional information).
Advanced Tools
Provides access to additional Z-Wave options
- 4 -

Home Automation
Z-Wave® Programming
Z-Wave® Advanced Tools Screen
Button Function
View Enrolled
Devices
View Z-Wave device information: System Index/name,
Secured or Non-Secured, device type, device ID,
manufacturer, node number
View Enrolled
Controllers
View Controller Information: Controller role: (Primary
or Secondary), Z-Wave Library Rev., Home ID, device
type, device ID, node number, manufacturer, Secured
or Non-Secured.
Reset Controller Deletes all nodes and generates a new random Home
ID. Resetting the Controller does not Exclude the
individual devices; therefore, each device will need to
be Excluded before being Included into a Controller.
Pri. Controller Shift
to Secondary
Transfers the role of primary controller to another
controller (i.e.; a Z-
Wave remote control) and
duplicates the Z-Wave network.
Note: Although both controllers can operate the Z-
Wave devices, only the Primary can
Include/Exclude devices.
Locking Door
Enable Arm Stay, Arm Away or Arm without Auto-Stay
when Z-Wave door lock is locked. Causes the system
to arm in the selected mode, Away, Stay, or Away
without Auto-Stay when the Z-Wave Door is Locked.
Learn
Includes the panel as secondary controller, usually on
a Z-Wave remote control, and duplicates the Z-Wave
network.
Devices (switches and thermostats only) may be
Included using the Z-
Wave remote control and the
information can be transferred to the control panel
using this feature. The secondary controller (control
panel) cannot have Z-
Wave devices Included. The
Learn button is selected after Include process is
started on the primary controller.
All Devices Off Allows User to “manually” turn Off all switches.
Note: Some thermostats will enter Setback mode.
All Devices On
Allows User to “manually” turn On all switches.
Note: Some thermostats will exit Setback mode.
Including Z-Wave®Devices
The functions described below should be accomplished at the LYNX Touch control in order to include (add) Z-
Wave devices to the network.
Z-Wave devices should be in their final location prior to inclusion.
When Including a device, it may be
necessary to perform an Exclude before a successful Include can be achieved. This is particularly true if the
device was previously in another Z-Wave network.
Step
Action
1.
At the Home Screen select the “Automation” icon.
2.
At the second page of the Automation Screen, select “Tools”.
3.
At the “Device Management” screen, select “Include Devices”. The panel displays “Entering Inclusion Mode. Please
Wait…”
4.
The panel displays “Ready to include device. Press the function button on device”. Within one minute press the device’s
Function button or activate the switch, as applicable.
5.
If the module has been successfully enrolled, the panel displays “Device Found! Please Wait” and then the device
information is displayed.
6.
After successfully including a device, the associated information will be added to the top of the inclusion list.
7.
Repeat steps 4 - 6 to enroll additional Z-Wave devices.
8.
Once you have finished including devices, press the “Home” key to return to the Home screen or select the “

” button to
return to the previous screen..
- 5 -

Home Automation
Z-Wave® Programming
Including Light Switches or Outlet Modules
Install the receptacle, wall switch or lamp/appliance module (refer to the Module’s Instruction Guide) before
including the Light switch or outlet module into the Z-Wave network.
Note: Z-Wave light modules may vary; refer to the instructions provided with your specific device to ensure it is Included
correctly in the network.
Including Door Locks
Z-Wave® door locks are encrypted, and for security purposes, enroll at a low power transmission range,
approximately 6 feet. This may require enrolling the lock before it is installed in the door.
Assemble the Z-Wave® door lock (if required); install batteries and connect necessary cables (refer to the Door
Lock’s Instruction Guide) before including the Lock into the Z-Wave network. Enroll the door lock adjacent to
the control (within 6 feet) and mount within the proper Z-Wave range (refer to the “Important Notes” section for
further information).
Notes: •Program the 4-digit User Code in the control. When programming user codes into the panel, determine if the user
code will have access to the Z-Wave lock. If so, the user code will be transferred to the lock.
•Door lock devices may vary; follow the instructions provided with your specific door lock to Include properly and to
program a new user code.
•If locks will be associated with a Scene, the lock’s autolock feature must be disabled.
•Due to Low Power Inclusion Mode of secure devices, Include the Z-Wave Lock first, if not using an Inclusion
Tool/Remote Control. The lock should be installed before including other devices.
•During operation, the system will display “JAMMED” and will revert to “Unlocked” status if a jammed lock is detected.
Including Thermostats, IR Extenders and Water Valves
Install the Thermostat or Water Valve according to the device’s instructions. The device should be mounted in
the final location and tested before adding it to the system.
IMPORTANT: Honeywell is not responsible for property damages due to improper setting of the thermostat modes.
Notes:
•Some thermostats do not update temperature status automatically (i.e., Wayne Dalton).
•When using Z-wave thermostat control on the LYNX Touch, the thermostat’s scheduling feature should not be used.
•When the HOLD button on the LYNX Touch Thermostat control screen is highlighted, Z-wave scenes driven by rules or
schedules will not affect the thermostat operation. Additionally, if your system is connected to TotalConnect Service,
the remote 7-day schedules will also not affect the thermostat operation.
•For threshold monitoring to be configurable on the Total Connect Remote Services and LYNX TOUCH Z-wave
thermostat screens, the respective zones will first need to be assigned with a response type in zone programming.
Threshold monitoring is not available on all thermostats.
•You must program both Zones for each respective thermostat (i.e..; for L5210 Zone 180 & 181 for thermostat #1, Zone
182 & 183 for thermostat #2 and Zone 184 & 185 for thermostat #3 OR for L7000 Zone 180 & 181 for thermostat #1,
Zone 182 & 183 for thermostat #2, Zone 184 & 185 for thermostat #3 and 186 & 187 for Thermostat #4).
•When temperature is represented in Celsius, the LYNX Touch matches the temperature increment of the particular
thermostat for Heat, Emergency Heat and Cool set points. Depending on the thermostat it can be either half or one
degree increments.
•When Celsius scale is used in a thermostat or with the ZXT-120 IR Extender, the LYNX Touch must also be set to
Celsius.
•If the Energy Saving mode is set, the LYNX Touch displays Energy Saving Heat/Cooling Setpoint Temperatures that
are programmed at the Thermostat.
•An additional “Energy Saving” function in the Thermostat is used to set/unset the Energy Saving mode.
LYNX Touch Z-Wave Thermostat Functions
Button Function
Mode
Select between HEAT, COOL and OFF.
Fan Select between ON, CIRCULATE and AUTO.
HOLD Allows temporary override of the programmed rules and schedules from operating on the thermostat.
NORMAL
Allows selected thermostat to run programmed schedules and rules.
NO SCHED
Prevents rules and schedules from operating on the selected thermostat
Threshold Monitoring
Enable/Disable Threshold Monitoring Feature (if available)
Saving Off/Saving On
Enables/disables the thermostat’s Energy Saving Schedule Function.
EDIT
Used to edit Thermostat name.
BACK Used to return to Thermostats screen.
- 6 -

Home Automation
Z-Wave® Programming
Thermostat Energy Saving Mode
Step Action
1. At the Home Screen select the “Automation” icon.
2.
At the Automation Screen, select “Thermostats”.
3.
Select the desired Thermostat from the displayed list.
4.
At the Thermostat control screen select the “Saving Off” button OR “Saving On” to activate or deactivate the
thermostat’s Energy Saving Schedule Function when a heating or cooling operation is selected.
Edit and Exclude/Delete Z-Wave® Devices
Edit Z-Wave Device Names
To Edit a device name, perform the following:
Step Action
1.
At the Home Screen select the “Automation” icon.
2. At the Automation Screen, select the type of device that you wish to edit. (i.e.; Switches, Thermostats or Locks as
applicable.).
3.
Select the device that you wish to edit from the displayed list.
4. Select the edit button
5. Enter the desired information (limited to 14 characters) on the displayed keypad and then select “Done”. The system
returns to the previous screen.
6. Select “Back” to return to the Automation Screen or press the “Home” key to return to the Home screen or select the
“” button to return to the previous screen.
Exclude/Delete a Z-Wave Device
Notes:
•Excluding a device sends a command to the Node erasing any previous network information that was learned into it.
•Previously deleted devices (but not Excluded) will still need to be Excluded before they can be re-Included into a
controller.
The functions described below should be accomplished at the LYNX Touch control in order to Exclude a Z-Wave
device(s) from the network.
Step
Action
1.
At the Home Screen select the “Automation” icon.
2.
At the Automation Screen, select “Tools”.
3.
At the “Device Management” screen, select “Exclude Devices”.
4. The panel displays “Entering Exclusion Mode. Please Wait…” followed by “Ready to Exclude device. Press the function
button on device”. Within one minute press the device’s Function button or activate the switch.
5.
If the device has been successfully excluded, the device’s information will be added to the excluded list. If a device
which is not known to the panel is excluded “Unknown Device Excluded” will be added to the excluded list.
6.
Once you have finished excluding devices, press the “Home” key to return to the Home screen or select the “

” button
to return to the previous screen..
Controlling Z-Wave® Devices
Turn On/Off All lights
Note: If All Devices On OR All Devices Off is selected, some thermostats will exit OR enter Setback mode.
To turn all lights On or Off, perform the following:
Step
Action
1.
At the Home Screen select the “Automation” icon.
2.
At the Automation Screen, select “Tools”.
3.
At the “Device Management” screen, select “Advanced Tools”.
4. Enter the Master User Code on the displayed keypad.
5. To turn all lights On, select “All Devices On” OR to turn all lights Off, select “All Devices Off”.
6.
Press the “Home” key to return to the Home screen or select the “

” button to return to the previous screen.
- 7 -

Home Automation
Z-Wave® Programming
Z-Wave®Operation
Scenes are used to control a single or group of devices, by turning them OFF, ON, ON to a preset lighting level,
temperature or mode, and/or to lock/unlock a door. The LYNX Touch has 20 Scenes which may each be
configured to control up to 10 devices each. Scenes can be activated manually or by a Schedule or Rule.
Schedules and Rules are used to control Scenes by pre-set “Conditions” and “Triggers”. Up to 20 Rules may be
programmed locally into the LYNX Touch (refer to the applicable section in this guide for additional
information). To manually activate devices perform the following steps:
Step Action
1.
At the Home Screen select the “Automation” icon.
2. At the Automation Screen, select the type of device (i.e.; Switches, Thermostats, Locks or Water Valves) that you wish
to control.
3.
Select the device that you wish to control from the displayed list.
4. Refer to the figures below for typical examples of the features that can be controlled manually for the devices.
5. Press the “BACK” key to return to the previous screen. Select the “” button to return to the previous screen.
6.
Select the “

” button to return to the Automation screen.
Note:
The
features and functions that can be controlled vary by manufacturer. Refer to the User Manual that was provided with the Z-Wave
device to determine the specific capabilities.
Switch Control Screen
Dimmer Switch Control Screen
Thermostat Energy Savings Control Screen
Thermostat Dual Setback Control Screen
Thermostat ZXT-120 IR Extender Control Screen
Lock Control Screen
Unsupported Device Control Screen
Water Valve Control Screen
- 8 -

Home Automation
Scenes
General Information
Scenes are used to control a single or group of devices together, turning them OFF, ON, ON to a preset lighting
level, temperature or mode, or lock/unlocked. The LYNX Touch has 20 Scenes which may each be configured
with up to 10 devices each. Scenes can be manually activated or activated by a Rule or a Scheduled event.
Rules and Schedules are used to control Scenes by pre-set “Conditions” and “Triggers”. Up to 20 Rules may be
programmed locally into the LYNX Touch.
Programming a Scene
1. With the system in the disarmed state, select the “Automation”
icon from the Home Screen. The system displays the first page
of the Automation screen. Select the “” icon to advance to
the second page of the Automation screen.
2. Select the “Scenes” icon
from the second page of the
Automation screen. The system displays the Scenes screen.
3. Select “Add New Scene”. The system displays a keypad along
with the next available Scene number.
4. If desired, select clear then enter up to 13 characters of text
on the displayed keyboard to assign a name to the scene,
then select “Done”.
5. Select the “Add New Device” button. The system displays the
available Z-Wave device types.
6. Select one of the following options:
Switches
Thermostats
Locks
Garages
Water Valves
Sirens
7.
Select the desired device type, then select the applicable
device from the l
ist of installed devices. The device’s
operational screen is displayed. Select “Save” when finished.
Up to 10 devices may be associated with a scene.
- 9 -

Home Automation
Scenes
8. Set the desired options. Typical operations are shown below:
Switches/Outlets
Set Switch/Outlet On
Set Switch/Outlet Off
Dim Switch (-/+)
Thermostats
Set Temperature Mode (Heat, Cool, Off)
Set Fan Mode (Auto, On, Circulate)
Select Hold Mode (Temperature hold)
Setback
Select Energy Saving Mode
Locks
Lock
Unlock
Water Valve
Turn Valve On
Turn Valve Off
Sirens
Turn On
Turn Off
(+/-)
Siren Settings (+/-)
0% - Sounder and strobe Off.
10-30% Turn On strobe only
40-60% Turns On sounder only.
100% - Turns On sounder and strobe
Garages
Press to open
Press to close
Notes:
•If Schedules/Scenes feature will be used to control the
thermostat set points, do not use the daily schedules in
the thermostat itself
•For compatibility, do not include a door lock as part of a
scene that has auto-lock enabled. Auto-
lock may be
disabled. For details, please refer to the documentation
provided with the lock.
9. Select Save when complete. The system returns to the Z-Wave
device screen. Select the “” button as required to return to the
Automation programming screen or the Home key to return to
the Home screen.
Editing/Deleting a Scene
1.
With the system in the disarmed state, select the “Automation”
icon from the Home Screen. The system displays the first page
of the Automation screen. Select the “” icon to advance to the
second page of the Automation screen.
2. Se
lect the “Scenes” icon from the second page of the
Automation screen. The system displays the Scenes screen.
- 10 -

Home Automation
Scenes
3. Select the scene you wish to edit or delete.
4. Select the “Edit” or “Delete” button.
5. If “Edit” was selected, the system advances to the Scene. Edit as
required and proceed to step 6. If delete was selected proceed to
step 7.
6. Select Save when complete. The system returns to the Z-Wave
device screen. Select the “” button as required to return to the
Automation programming screen or the Home screen.
7. The system displays a confirmation screen and then returns to
the previous screen. Select the “” button as required to return
to the Automation programming screen or the Home key to
return to the Home screen.
Running a Scene
1. With the system in the disarmed state, select the “Automation”
icon from the Home Screen. The system displays the first page
of the Automation screen. Select the “” icon to advance to the
second page of the Automation screen.
2. Select the “Scenes
” icon from the second page of the
Automation screen. The system displays the Scenes screen.
3. Select the scene you wish to run.
4. Select the “”button to run the scene.
- 11 -

Home Automation
Schedules
General Information
The Schedules Feature can be used to program the system to automatically perform certain functions (i.e.;
automatically arming the system in Stay mode and activating output [Z-Wave] devices) at a scheduled time,
day of the week or month, as applicable.
Programming a Scheduled Function
1. With the system in the disarmed state, select the “Automation”
icon from the Home Screen. The system displays the first page
of the Automation screen. Select the “” icon to advance to the
second page of the Automation screen.
2. Select the “Schedules” icon
from the second page of the
Automation screen. The system displays the Schedules screen.
Note: Rules 21-
40 are only accessible through TotalConnect
Service.
3. Select “Add New”. The system displays the schedules options
screen.
4. Select “Name”. The system displays a keypad.
5. Enter a name (up to 13 digits long) for the scheduled function
on the displayed keypad then select “Done”.
6. Select “Type” then scroll through and select on
e of the
following options:
None
Auto Night Stay (displayed if Arm Night zone is enabled)
Auto Stay
Rules
Disarm Notification
Scene
7. Select “Frequency” then select one of the following displayed
options:
None Once
Daily Weekday
Weekly Monthly
Sunrise Sunset
If Sunrise or Sunset is selected, the Type option defaults to
“Scene”. Select “Location” and proceed to step 8, otherwise
proceed to step 9. If Total Connect Services are enabled and
Sunrise or Sunset is selected, the Type option defaults to
“Scene”. Proceed to step 13.
- 12 -

Home Automation
Schedules
8. Select “City”, “Country”, “State” and “Zip Code” and enter the
required information on the displayed keypad then select
“Done”. Select “Save” when all fields are complete. Proceed to
step 13.
9. Program the options below, based upon the Type selected in
Step 6 and the Frequency selected in step 7 or if “Scene” is
selected proceed to Step 13.
Once Start Time/End Time/ Date
Daily Start Time/End Time
Weekday Start Time/End Time
Weekly Start Time/End Time/Day of the Week
Monthly Start Time/End Time/Day of the Month
10. Select “Rules” then select a Rule from the displayed list (Rules
1 through Rules 20).
11.
Enter a Start Time and End Time on the displayed keypad
then select “Save”.
12. Select the “” button to return to the Automation programming
screen or the Home key to return to the Home Screen.
13. Select “Scenes”. Select the desired scene from the displayed
list.
14.
Enter a Start Time and End Time on the displayed keypad
then select “Done”.
15. If “Daily”, “Weekday”, “Weekly” or “Monthly” was selected for
“Frequency”, the Randomization field is displayed. Select
“Randomization”, the system toggles between “No” and Yes”.
Note: If using the Randomization feature scheduled events should
not be programmed within one hour of each other.
16. Select “Save”. The system displays to the list of programmed
Schedules.
17. Select the “” button to return to the Automation programming
screen or the Home key to return to the Home Screen.
Editing a Scheduled Function
1. At the Schedules screen, select the Schedule you wish to edit.
Note: Rules 21-40 are only accessible through TotalConnect Service.
2.
Select the “Edit” button. The Schedule programming screen
will appear. Follow the steps as noted above i
n the
programming a Scheduled Function section to edit and save
your changes.
Deleting a Scheduled Function
1.
At the Schedules screen, select the Schedule you wish to
delete.
Note: Rules 21-40 are only accessible through TotalConnect Service.
2. Sele
ct the “Delete” button. A confirmation screen will be
displayed. Select “Yes” to confirm the deletion.
3. Select the “” button. The system returns to the Automation
programming screen.
- 13 -

Home Automation
Rules
General Information
Up to 40 rules can be programmed. Rules 1 through 20 are used for Triggers, Z-Wave Scenes and Follow-Me
Messages. Rules 21 through 40 are used for Z-Wave Scenes and for E-mail notification but are only accessible
through TotalConnect Service. Check with your Installer to see which options are available to you.
The following options are programmed in this section:
Programming Field
Action
Rule 1 - 20:
Select Rule 1 -20
Note:
Rules 21-40 are only accessible through TotalConnect Service.
Name:
Name the device
Type:
Select the output type
Action:
Select the action required for the device
Start Zone Type OR Zone Type Fault:
Select Zone Type to start event*
Stop Zone Type OR Zone Type Restore:
Select Zone Type to stop event*
Start System Operation OR
System Operation 1:
Select System Operation to start event*
Stop System Operation OR
System Operation 1
Select System Operation to stop event*
Zone Number Operation:
Select Zone Number to trigger event upon fault, trouble or alarm as selected.
* The displayed field is dependent upon the Type selection.
Programming Rules
1. With the system in the disarmed state, select the “Automation”
icon from the Home Screen. The system displays the first
page of the Automation screen. Select the “
” icon to
advance to the second page of the Automation screen.
2.
Select the “Rules” button. The system displays the Rules
screen.
3. Select a “Rules” key followed by the Edit button.
Note: Rules 21-40 are only accessible through TotalConnect
Service.
- 14 -

Home Automation
Rules
4. Select the “Name” key
and then enter up to 13 characters of
text on the displayed keyboard to assign a name to the Rule.
Note:
Select the “ABC…” key to switch the keyboard between
upper/lower case or the “123!@#” key to switch to numbers.
5. Once you are finished, select “Done”. The system returns to the
Rules screen.
6. Select the “Type” button. Dependant upon what features are
programmed in your control the system toggles between the
following Types:
Disabled
Trigger Output
Scene (displayed when Z-Wave has been enabled)
To Ph. 1 (Message to Phone 1) (L5210/L5210-CN only)
To Ph. 2 (Message to Phone 2) (L5210/L5210-CN only)
To Ph. 1 & 2 (Message to Phone 1 & 2) (L5210/L5210-CN only)
Depending upon the Type selected, the system displays
several new programming fields. If Scene is selected, you must
program a scene in order for it to run.
OR
7. Select “Action”. Dependent upon the Type selected previously,
the system scrolls between several options:
None
Permanent On
On for 2 sec
Pulsing
Send (L5210/L5210CN only)
Run Scene*
* If Scene was selected in step 6, you must select Run Scene.
8. Select “Start Zone Type” OR “Zone Type Fault” (if Scene was
selected in the Type field). The system displays the following
options (dependent upon the Type that was selected):
Not Used
Entry Exit 1
Entry Exit 2
Perimeter
Interior Follower
Day / Night
24 Hour Silent
24 Hour Audible
Use the “” “” buttons to scroll to second page of zone type
options.
Silent Burglary
24 Hour Auxiliary
Interior With Delay
Fire No Verification
Carbon Monoxide
Trouble
No Response
Arm Stay
Use the “” “
” buttons to scroll to third page of zone type
options.
Arm Away
Disarm
Monitor
Resident Monitor
Resident Response
General Monitor
General Response
Garage Door
Garage Monitor
- 15 -

Home Automation
Rules
OR
9
.
Select “Stop Zone Type” OR “Zone Type Restore” (if Scene
was selected in the Type field). The system displays the same
options as the previous step.
Note: If a Rule is being used to trigger a Z-Wave door lock, when the system is
Armed Stay or Armed Away, it is recommended that “End of Exit Delay” be
selected for System Operation 1 or System Operation 2.
1
0.
Select “Start System Operation” OR “System Operation 1” (if
Scene was selected in the Type field). The system displays the
following options (dependent upon the Type that was selected):
Not Used
Arm Stay
Arm Away
Disarm
Any Burglary Alarm
Any Fire Alarm
Bell Timeout
End of Exit Delay
Use the “
” “
” buttons to scroll to second page of zone type
options.
Start of Entry Delay
Chime
Kissoff
Bypass
System Low Battery
Reporter Failure
Duress Alarm
Note: The 24 Hour Silent Alarm or 24 Hour Auxiliary Alarm Zone Types will not
trigger the selected System Operation if the “Any Burglary Alarm” option has
been programmed.
1
1. Select “S
top System Operation” OR “System Operation 2” (if
Scene was selected in the Type field).. The system displays the
same options as step 10.
12. Use the “” buttons to advance to the next page, then select
“Zone Number Operation”. The system toggles betwe
en the
following options:
Not Used
Fault
Trouble
Alarm
Notes:
•For Fault, the following zone types should not be used:
General Monitor, General Response, Resident Monitor,
and Resident Response.
•
When a zone has been deleted, please verify the
programming selection for Zone Number Operation.
If Trouble, Fault or Alarm is selected, the system displays
several new options. Proceed to Step 13.
13.
Select the First, Second or Third “Start Zone” Select the Zone
from the list displayed by the system.
14.
Select the First, Second or Third “Stop Zone” Select the Zone
from the list displayed by the system.
15. Select “Save” when programming is complete.
16. Select the “
” button. The system returns to the Automation
programming screen.
- 16 -

Home Automation
Rules
Editing or Deleting Rules
1.
At the Rules Programming Screen, select the Rule that you
wish to edit or delete.
Note: Rules 21-40 are only accessible through TotalConnect Service.
2. To edit the rule select the Edit button and proceed to step 3. To
delete the rule, select the Delete button and proceed to step 4.
3.
Select the field that you wish to edit and follow the steps as
outlined in the Programming Rules procedure.
4. Select the “” button or press the Home key to return to the
Automation programming or the Home screen.
- 17 -

Home Automation
Garage Door Opener Operation
General Information
If your system has been equipped with a 5877 Relay Receiver and 5822T Tilt Sensor or Door/Window
Transmitter (i.e.; 5616), it can be used to remotely operate and/or view the status of up to three Garage Doors.
The System can be armed when the garage door is open, and once the garage door has been closed, the zone will
be monitored as part of the system without providing burglary protection. It can also be programmed for
monitoring only. The panel includes the option to automatically close the Garage Door(s) if it has been left open
for more than a specified (programmable) period time or at a specified time.
Do not use the LYNX Touch garage door automation with any garage door opener that lacks the safety
features required by U.S. federal safety standards (this includes any garage door opener model manufactured
before January 1, 1993). A garage door opener that cannot detect an object and stop and reverse the doo –
does not meet current U.S. federal safety standards. Your garage door opener also must signal before
unattended door operation. For more information please consult your garage door opener manual.
Notes:
•Ensure that the 5877 Relay Receiver is in close proximity to the LYNX Touch while it is being enrolled. After the
device has been enrolled it can be mounted in its permanent position but should be tested to make sure that it
receives the Open/Close signals from the LYNX Touch.
•System Status is desired, a House ID must be enrolled in the LYNX Touch. Refer to the System Type Programming
Section of the LYNX Touch Installation and Setup Guide P/N 800-19974 (or higher) or to the LYNX Touch
Programming Guide P/N 800-19976 (or higher) OR 800-20379 (or higher) (Canada).
•The 5877 Relay Receiver should be enrolled in the LYNX Touch before it is permanently mounted.
•In order to display the garage door status, you must also enroll a 5816 sensor or a 5822T Tilt Sensor. Refer to the
Zone Programming Section of the LYNX Touch Installation and Setup Guide P/N 800-19974 (or higher) or to the
LYNX Touch Programming Guide P/N 800-19976 (or higher) OR 800-20379 (or higher) (Canada).
•The 5816 or 5822T is enrolled on Zones 45, 46, 47 or 48 (which are reserved for the Garage Door operation) as
Loop 3.
Enrolling the 5877 Relay Receiver
Step Action
1. At the Home screen select the “Automation” icon.
2. At the second page of the Automation Screen, select the Garage door setup icon.
3.
Select the Garage door to be enrolled, from the displayed list.
4.
Select “Assign device”. The control advances to the Garage Door operation screen.
5.
Enter the 7-digit serial number associated with the 5877 Relay Receiver then select “Done”.
6.
To confirm enrollment, at the LYNX Touch select the “Learn” button and listen for a click at the relay.
7.
Select the “

” button to return to the Automation screen.
Garage Door Feature Operation
Notes:
•The Garage Zone and Response Type must be assigned to in order to view garage door status.
•The Switches button on the Garage Door Setup screen is used to assign a Z-Wave Binary Garage Door Opener.
•The RF Openers on the Garage Door Setup screen is used to assign RF Garage Door Openers.
Step
Action
1.
At the Dashboard screen select the “Automation” icon.
2.
At the Automation Screen, select the Garages icon.
3.
Select the Garage door that you wish to control/program from the displayed list. The control advances to the Garage
Door operation screen.
4.
Refer to the table and procedures below for additional operation/programming information.
- 18 -

Home Automation
Garage Door Opener Operation
Garage Door Operation Screen
Button or Icon
Function
Edit
Used to modify description of Garage Door
Close in
Provides access to keypad used to set a specific period of
time (up to 12 hours and 59 minutes) before an open garage
door closes automatically. If programmed the time will also be
displayed.
Close at
Provides access to keypad used to set a specific time that an
open garage door closes automatically. If programmed the
time will also be displayed.
Back
Used to return the control to the Garage Door list.
Press to open
Indicates Garage Door is Closed. Select to Open Garage
Door.
Press to close
Indicates Garage Door is Open. Select to Close Garage
Door.
Operate Garage Door from LYNX Touch Control Panel
Notes:
•When the garage door is open, “Ready to Arm – Fault” is displayed in a yellow band at the top of the display.
•If a “Close in” or “Close at” time has been programmed, the garage door will always operate as programmed until the
selection has been cleared.
Step
Action
1.
At the Garage Door operation screen, select the Opened or Closed Garage Door icon to Close or Open the door.
2.
When the door position has changed the icon will switch from Opened to Closed, as applicable, and CLOSED or
OPENED is displayed
- 19 -

Home Automation
Advanced Z-Wave Operations
View Enrolled Z-Wave Devices or Controllers
To View a list of the enrolled devices perform the following:
Step Action
1.
At the Home Screen select the “Automation” icon.
2. At the Automation Screen, select “Tools”.
3. At the “Device Management” screen, select “Advanced Tools”.
4.
Enter the Master User Code on the displayed keypad.
5.
At the Advanced Tools Screen, select “View Enrolled Devices” OR “View Enrolled Controllers”.
6.
Use the down

arrow to scroll to the next page of options. Use the

arrow to return to the previous page.
7.
Press the “Home” key to return to the Dashboard screen or select the “” button to return to the previous screen.
Remove/Delete All Z-Wave® Devices (Reset Controller)
Note: Resetting the Controller does not Exclude the devices individually; therefore, each device will need to be Excluded before
being Included into a controller.
To Remove all Z-Wave devices, perform the following:
Step Action
1.
At the Home Screen select the “Automation” icon.
2.
At the Automation Screen, select “Tools”.
3.
At the “Device Management” screen, select “Advanced Tools”.
4.
Enter the Master User Code on the displayed keypad.
5.
At the Advanced Tools Screen, select “Reset Controller”.
6. The panel displays “This will delete all nodes and generate a new home ID”.
7. Select “Yes”. The panel displays “All nodes deleted and new home ID generated”.
8.
Select “OK”. The system returns to the previous screen.
Shift Primary Control
After all Z-Wave devices have been Included into the Primary Controller, control can be shifted to a Secondary
Controller. To shift primary control to the secondary Z-Wave controller, perform the following:
Step
Action
1.
At the Home Screen select the “Automation” icon.
2.
At the Automation Screen, select “Tools”.
3.
At the “Device Management” screen, select “Advanced Tools”.
4. Enter the Master User Code on the displayed keypad.
5. Select “Pri. Controller Shift to Secondary”.
6.
The panel displays “Shifting”.
7.
Put the controller you are shifting to in “learn” mode. Refer to the documentation provided with the controller for
additional information.
Failed Devices (Nodes)
If a Z-Wave device is not plugged into an AC outlet and the user attempts to control it, the LYNX Touch will
recognize it as a Failed device and the Z-Wave Device Failed icon will be displayed on the Home Screen. The
LYNX Touch will take up to a minute to detect a failed device after and attempt has been made by the User or
Scene to control the device. It may take an additional minute for the failed device to be displayed.
Note: The LYNX Touch will take up to a minute to detect a failed device after and attempt has been made by the User or Scene to
control the device. It may take an additional minute for the failed device to be displayed.
Step Action
1.
At the Home Screen select the “Automation” icon.
2.
At the Automation Screen, select “Press to see Failed devices”.
3.
Select OK when “Failed Devices Found!” is displayed. At the “Device Management” screen, select “Advanced Tools”.
4.
Ensure that the module has electrical power. If the device is defective, or not available for any reason, select the “Fix All”
button.
5.
A confirmation screen displays “This will delete all failed devices.” Select the “Yes” button. The affected device will be
deleted.
- 20 -
