DF-60599:B • 02/11/2011 — Page 1 of 4
MS-9200UDLSC
Intelligent Addressable FACP
with Built-In Communicator
Addressable Fire Alarm Control Panel
Canadian DF-60599:B
General
The Fire•Lite MS-9200UDLSC Rev 3 with Version 5.0 firmware
is a combination FACP (Fire Alarm Control Panel) and DACT
(Digital Alarm Communicator/Transmitter) all on one circuit
board. This compact intelligent addressable control panel has
an extensive list of powerful features.
While the MS-9200UDLSC may be used with a DCL configured
in the CLIP (Classic Loop Interface Protocol) mode, it can also
operate in LiteSpeed™ mode—Fire•Lite’s latest polling technol-
ogy—for a quicker device response time. LiteSpeed’s patented
technology polls 10 devices at a time. This improvement allows
a fully-loaded panel with up to 198 devices to report an incident
and activate the notification circuits in under 10 seconds. With
Litespeed polling, devices can be wired on standard twisted,
unshielded wire up to a distance of 3,000 meters.
The MS-9200UDLSC’s quick-remove chassis protects the elec-
tronics during construction. The backbox can be installed allow-
ing field wiring to be pulled. When construction is completed, the
electronics can be quickly installed with just two bolts.
Features include removable terminal blocks, improved transient
protection, additional secondary ANN-BUS, increased resetta-
ble power, and remote sync output.
Available accessories include ANN-BUS devices as well as ACS
LED, graphic and LCD annunciators, and reverse polarity/city
box transmitter.
The integral DACT transmits system status (alarms, superviso-
ries, troubles, AC loss, etc.) to a Central Station via the public
switched telephone network. It also allows remote and local pro-
gramming of the control panel using the PS-Tools Upload/Down-
load utility. In addition, the control panel may be programmed or
interrogated off-site via the public switched telephone network.
Any personal computer with Windows® XP or greater, a com-
patible modem, and PS-Tools, the Fire•Lite Upload/Download
software kit, may serve as a Service Terminal. This allows
download of the entire program or upload of the entire program,
history file, walktest data, current status and system voltages.
The panel can also be programmed through the FACP’s keypad
or via a standard PS-2 computer keyboard, which can be
plugged directly into the printed circuit board. This permits easy
typing of address labels and other programming information.
Version 5.0 firmware supports the following: ANN-bus devices,
AD355 (LiteSpeed), USB port, and NAC circuit diagnostics. A
new report has been added to the walk-test that lists untested
devices, Photo Supervisory and auto-resettable Drill (non-latch-
ing).
Features
• ULC Listed.
• On-board DACT.
• Remote site or local USB port upload/download, using PS-
To o l s .
• Four Style Y (Class B) NAC circuits, which can be converted
to four Style Z (Class A) circuits with optional ZNAC-92 con-
verter module. (Up to 6.0 amps total NAC power when using
optional XRM-24B.)
• Selectable strobe synchronization for System Sensor, and
Wheelock.
• Primary and secondary ANN-BUS for connection to following
optional modules (cannot be used if ACS annunciators are
used):
–ANN-80C Remote LCD Annunciator
–ANN-I/O LED Driver
–ANN-S/PG Printer Module
–ANN-RLY Relay Module
–ANN-LED Annunciator Module
–ANN-RLED Annunciator Module alarms only
•ACS/TERM:
–ACS Annunciators: Up to 32 ACM Series annunciators
(ACM-16AT or ACM-32 series). Cannot be used if ANN-
BUS devices are used.
–Terminal-mode Annunciators: Up to 32 LCD-80FC remote
annunciators.
• EIA-232 printer/PC interface (variable baud rate) on main cir-
cuit board, for use with optional ULC-listed printer PRN-6F.
• Integral 80-character LCD display with backlighting.
• Real-time clock/calendar with automatic daylight savings
control.
• History file with 1,000-event capacity.
• Maintenance alert warns when smoke detector dust accumu-
lation is excessive.
• Automatic device type-code verification.
• One person audible or silent walk test with walk-test log and
printout.
• Point trouble identification.
• Waterflow (nonsilenceable) selection per monitor point.
• System alarm verification selection per detector point.
• PAS (Positive Alarm Sequence) and presignal delay per
point.
NOTE: Only detectors may participate in PAS.
DCL LOOP:
• DCL can be configured for NFPA Style 4, 6, or 7 operation.
• DCL supports up to 198 addressable devices per loop (99
detectors and 99 monitor, control, or relay modules).
• DCL loop maximum length 3,000 m.
See installation manual for wire tables.

Page 2 of 4 — Canadian DF-60599:B • 02/11/2011
NOTIFICATION APPLIANCE CIRCUITS (NACS):
• Four onboard NACs with additional NAC capability using out-
put control modules (CMF-300 or CMF-300-6). The four
Class B NACs can be converted to four Class A NACs with
optional ZNAC-92 converter module.
• Silence-inhibit and Autosilence timer options.
• Continuous, March Time, Temporal or California code for
main circuit board NACs with two-stage capability.
• Selectable strobe synchronization per NAC.
• 2.5 amps maximum per each NAC circuit.
NOTE: Maximum 24VDC system power output is shared among
all NAC circuits and 24VDC special-application auxiliary power
outputs. Total available output is 3.0 amps. Using the optional
XRM-24B transformer increases 24VDC output to 6.0 amps.
PROGRAMMING AND SOFTWARE:
• Autoprogram (learn mode) reduces installation time.
• Custom English labels (per point) may be manually entered
or selected from an internal library file.
• Three Form-C relay outputs (two programmable).
• 99 software zones.
• Continuous fire protection during online programming at the
front panel.
• Program Check automatically catches common errors not
linked to any zone or input point.
•OFFLINE PROGRAMMING: Create the entire program in
your office using a Windows®-based software package
(order programming kit PS-Tools, separately). Upload/down-
load system programming locally to the panel in less than
one minute.
• USB programming with standard Male-A to Male-B cable.
User Interface
LED INDICATORS
• AC Power (green)
• Fire Alarm (red)
• Supervisory (yellow)
• Alarm Silenced (yellow)
• System Trouble (yellow)
• Maintenance/Presignal (yellow)
• Disabled (yellow)
• Battery Fault (yellow)
• Ground Fault (yellow)
KEYPAD CONTROLS
• Acknowledge/Step
• Alarm Silence
•Drill
• System Reset (lamp test)
• 16-key alpha-numeric pad (similar to telephone keypad)
• 4 cursor keys
• Enter
Product Line Information
MS-9200UDLSC: 198-point addressable Fire Alarm Control
Panel, one DCL loop. Includes 80-character LCD display, single
printed circuit board mounted on chassis, and cabinet. 120 VAC
operation.
4XTMF Reverse Polarity Transmitter Module: Provides super-
vised output for local energy municipal box transmitter, alarm,
and trouble.
ZNAC-92: Optional converter module which converts four Style
Y (Class B) NAC circuits to four Style Z (Class A) circuits.
PK-CD: Contains PS-Tools Programming software for Win-
dows®-based PC computer (cable not included).
DP-9692: Required dress panel for MS-9200UDLSC.
TR-CE: Trim Ring for semi-flush mounting.
BB-26: Battery backbox, holds up to two 25 AH batteries.
BB-55F: Battery box, houses two 55 AH batteries.
CHG-120F: Remote battery charging system for lead-acid bat-
teries with a rating of 55 to 120 AH. Requires additional BB-55F
for mounting.
BAT Series: Batteries, see data sheet DF-52397.
XRM-24B: Optional transformer. Increases system power out-
put to 6.0 amps.
PRT/PK-CABLE: Cable printer/personal computer interface
cable; required for printer or for local upload/download program-
ming.
PRN-6F: ULC-listed compatible event printer. Uses tractor-fed
paper.
COMPATIBLE ANNUNCIATORS
ANN-80C: Remote LCD indicator that mimics the information
displayed on the FACP LCD display. Recommended wire type is
un-shielded. (Basic model is red; order -W version for white; see
DF-52417.)
ANN-LED: Annunciator Module provides three LEDs for each
zone: Alarm, Trouble and Supervisory. Ships with red enclosure
(see DF-60241).
ANN-RLED: Provides alarm (red) indicators for up to 30 input
zones or addressable points. (See DF-60241).
ANN-RLY: Relay Module, which can be mounted inside the cab-
inet, provides 10 programmable Form-C relays. (See DF-
52431.)
ANN-S/PG: Serial/Parallel Printer Gateway module provides a
connection for a serial or parallel printer. (See DF-52429.)
ANN-I/O: LED Driver Module provides connections to a user
supplied graphic annunciator. (See DF-52430.)
ACM-8RF: Relay module provides 8 Form-C 5.0 amp relays.
ACS-LED Zone Series: LED-type fire annunciators capable of
providing up to 99 software zones of annunciation. Available in
increments of 16 or 32 points to meet a variety of applications.
LDM Graphic Series: Lamp Driver Module series for use with
custom graphic annunciators.
LCD-80FC (Liquid Crystal Display) point annunciator:
80-character, backlit LCD-type fire annunciators capable of dis-
playing English-language text.
LITESPEED COMPATIBLE ADDRESSABLE DEVICES
All feature a polling LED and rotary switches for addressing.
CP355A: Addressable low-profile ionization smoke detector.
SD355A: Addressable low-profile photoelectric smoke detector.
SD355TA: Addressable low-profile photoelectric smoke detector
with thermal sensor.
H355A: Fast-response, low-profile heat detector.
H355RA: Fast-response, low-profile heat detector with rate-of-
rise option.
H355HTA: Fixed high-temperature detector that activates at
190F/88C.
AD355A: Low-profile, intelligent, “Adapt” multi-sensor detector
(B350LP base included).
BEAM355A: Intelligent beam smoke detector.
BEAM355SA: Intelligent beam smoke detector with integral
sensitivity test.
D350PL: Photoelectric low-flow duct smoke detector.
D350RPL: Photoelectric low-flow duct smoke detector with relay
option.
D355PLA: Innovair Flex low-flow non-relay duct-detector hous-
ing; includes SD355A Photoelectric detector
DNRA: Innovair Flex low-flow non-relay duct-detector housing.
(Order SD355A separately.)

Canadian DF-60599:B • 02/11/2011 — Page 3 of 4
MMF-300A: Addressable Monitor Module for one zone of nor-
mally-open dry-contact initiating devices. Mounts in standard
10.16 cm box. Includes plastic cover plate and end-of-line resis-
tor. Module may be configured for either a Style B (Class B) or
Style D (Class A) IDC.
MDF-300A: Dual Monitor Module. Same as MMF-30A except it
provides two Style B (Class B) only IDCs.
MMF-301A: Miniature version of MMF-300A. Excludes LED and
Style D option. Connects with wire pigtails. May mount in device
backbox.
MMF-302A: Similar to MMF-300A, but may monitor up to 20
conventional two-wire detectors. Requires resettable 24 VDC
power. Consult factory for compatible smoke detectors.
CMF-300A: Addressable Control Module for one Style Y/Z
(Class B/A) zone of supervised polarized Notification Appli-
ances. Mounts directly to a 10.16 cm electrical box. Notification
Appliance Circuit option requires external 24 VDC to power noti-
fication appliances.
CRF-300A: Addressable relay module containing two isolated
sets of Form-C contacts, which operate as a DPDT switch.
Mounts directly to a 10.16 cm box, surface mount using the
SMB500.
BG-12LX: Addressable manual pull station with interface mod-
ule mounted inside.
I300A: Fault Isolator Module. This module isolates the DCL loop
from short circuit conditions (required for Style 6 or 7 operation).
SMB500: Used to mount all modules except the MMF-301A and
M301A.
MMF-300-10A: Ten-input monitor module. Mount one or two
modules in a BB-2F cabinet (optional). Mount up to six modules
on a CHS-6 chassis in a BB-6F.
MMF-302-6A: Six-zone interface module for compatible conven-
tional two-wire detectors. Mount one or two modules in a BB-2F
cabinet (optional). Mount up to six modules on a CHS-6 chassis
in a BB-6F.
CMF-300-6A: Six-circuit supervised control module. Mount one
or two modules in a BB-2F cabinet (optional). Mount up to six
modules on a CHS-6 chassis in a BB-6F.
CRF-300-6A: Six Form-C relay control module. Mount one or
two modules in a BB-2F cabinet (optional). Mount up to six mod-
ules on a CHS-6 chassis in a BB-6F.
ADDRESSABLE DEVICE ACCESSORIES
End-of-Line Resistor Assembly (R-47K and R-3.9K):
47k ohm supervises the MMF-300A, MDF-300A, MMF-301A,
and CMF-300A module circuits. 3.9k ohm End-of-Line Resistor
assembly supervises the MMF-302A module circuit. These
resistors are included with each module.
Power Supervision Relay: Supervises the power to 4-wire
smoke detectors and notification appliances.
EOL-CR, EOL-CW: Single End-of-Line resistor plate (required).
EOL-CR is red; EOL-CW white.
NOTE: 1) For more information on compatible equipment, see the
following data sheets (document numbers): ACM-8RF (DF-
51555), ACS/ACMSeries (DF-52378), LDM Series (DF-51384),
LCD-80FC (DF-52185), AD355 (DF-52324), BG-12LX (DF-
52013), CMF-300-6 (DF-52365), CRF-300-6 (DF-60379), CMF/
CRF Series (DF-52130), CP355 (DF-52383), D355PL (DF-52398),
H355 Series (DF-52385), I300 (DF-52389), MMF-300 Series/
MDF-300 (DF-52121), MMF-300-10 (DF-52347), MMF-302-6 (DF-
52356), SD355/SD355T (DF-52384). 2) Legacy 300 Series detec-
tion devices such as the CP300/CP350, SD300(T)/SD350(T) and
older modules such as the M300, M301, M302, C304, and BG-
10LX are not compatible with LiteSpeed polling. If the DCL con-
tains one of these devices, polling must be set for standard
LiteSpeed protocol. Please consult factory for further information
on previous 300 Series devices.
Wiring Requirements
While shielded wire is not required, it is recommended that all
DCL wiring be twisted-pair to minimize the effects of electrical
interference. Wire size should be no smaller than 18 AWG (0.78
mm²) and no larger than 12 AWG (3.1 mm²). The wire size
depends on the length of the DCL circuit. Refer to the panel
manual for wiring details.
Fire Alarm Control Panel
LCD-80FC
80-Character backlit LCD
remote fire annunciator
DCL Loop
SD355A
Photo Detector
AD355A
Adapt Detector
H355A, H355RA/
H355HTA
Heat Detector
MDF-300A
Dual Monitor Module
SD355TA
Photo/Thermal
MMF-302A
2-Wire Detector
Monitor Module
Multi-Modules
• CRF-300-6A Six-Relay Control Module
• CMF-300-6A Six-Circuit
Supervised Control Module
• MMF-302-6A Six-Zone Interface Module
• MMF-300-10 Ten-Input Monitor Module
MMF-300A
Monitor Module
BG-12LX Addressable
Manual Pull Station
Beam Detector/Beam 355A/Beam 355SA
D355PLA / D350RPLA
(with relay)
Duct Detector
Power Supply
FCPS-24FS6C
FCPS-24FS8C
P2RA Strobe
P2RA Strobe
P2RA Strobe
SPSRVA
Series
Speaker
Strobes
ANN-80C
OR

This document is not intended to be used for
installation purposes. We try to keep our
product information up-to-date and accurate.
We cannot cover all specific applications or
anticipate all requirements. All specifications
are subject to change without notice.
For more information, contact Fire•Lite Alarms.
[phone]
10 Whitmore Road
Woodbridge, Ontario LZL 7Z4
www.firelite.com
System Capacity
• Intelligent Digital Communication Loops .............................. 1
• Addressable device capacity ............................................ 198
• Programmable software zones ........................................... 99
• ACS Annunciators .............................................................. 32
• ANN-bus devices ................................................................ 16
Electrical Specifications
AC Power: MS-9200UDLSC Rev 3 120 VAC, 60 Hz, 3.0 amps.
Wire size: minimum 14 AWG (2.00 mm²) with 600 V insulation.
Minimum Battery Size: 7 AH batteries.
Battery charger capacity: Up to two 18 AH batteries can be
housed in the FACP cabinet. Larger batteries require separate
battery box such as the BB-26 or BB-55.
DCL Communication Loop: Supervised and power-limited.
Notification Appliance Circuits: Each terminal block provides
connections for two Style Y (Class B) for a total of four Style Y
(Class B) or four Style Z (Class A) NACs with the use of the
optional ZNAC-92 converter module. Maximum signaling current
per circuit: 2.5 amps. End-of-Line Resistor: 4.7K ohm, 1/2 watt
(P/N 71252 UL listed) for Style Y (Class B) NAC. Refer to panel
documentation and Fire•Lite Device Compatibility Document for
listed compatible devices.
Two Programmable Relays and One Fixed Trouble Relay:
Contact rating: 2.0 amps @ 30 VDC (resistive), 0.5 amps @ 30
VAC (resistive). Form-C relays.
Special Application Power (24 VDC Nominal): Jumper select-
able (JP4) for conversion to resettable power output. Up to 1.0
amp total DC current available from each output. Power-limited.
Four-Wire Resettable Special Application Smoke Detector
Power (24 VDC nominal): Up to 1.0 amp for powering four-wire
smoke detectors. Power-limited. Refer to the Fire•Lite Device
Compatibility Document for listed compatible devices.
Remote Sync Output: Remote power supply synchronization
output. Nominal special application power: 24 VDC. Maximum
current: 300 mA. End-of-Line Resistor: 4.7K ohm. Output linked
to NAC 1 control. Supervised and power-limited.
Telephone Interface: Requires dedicated business telephone
number with a minimum of 5 volts DC (off-hook voltage). Obtain
dedicated phone line directly from your local phone company.
Do not use shared phone lines or PBX (digital) type phone line
extensions.
Cabinet Specifications
Door: 48.92 cm high x 42.73 cm wide x .30 cm deep. Backbox:
48.26 cm high x 42.29 cm wide x 13.34 cm deep. Trim Ring
(TR-CE): 55.88 cm high x 49.91 cmwide.
Shipping Specifications
Weight: 12.20 kg Dimensions: 50.80 cm high x 57.15 cm wide
x 21.59 cm deep.
Temperature and Humidity Ranges
This system operates at 0 – 49°C and at a relative humidity
93% ± 2% RH (noncondensing) at 32°C ± 2°C. However, the
useful life of the system's standby batteries and the electronic
components may be adversely affected by extreme temperature
ranges and humidity. Therefore, it is recommended that this
system and its peripherals be installed in an environment with a
normal room temperature of 15 – 27°C.
Agency Listings and Approvals
The listings and approvals below apply to the basic MS-
9200UDLSC control panel. In some cases, certain modules may
not be listed by certain approval agencies, or listing may be in
process. Consult factory for latest listing status.
•ULC: S624
FireLite® Alarms® is a registered trademark of Honeywell International Inc.
Wheelock® is a registered trademark of and Exceder™ is a trademark of
Cooper Notification.
©2011 by Honeywell International Inc. All rights reserved. Unauthorized use
of this document is strictly prohibited.
Page 4 of 4 — Canadian DF-60599:B • 02/11/2011
SYSTEM SPECIFICATIONS
