Horizon Fitness T51 User manual

OPERATION GUIDE
BEDIENUNGSANLEITUNG
GEBRUIKERSHANDLEIDING
GUIDE D’UTILISATION
T5.1 T7.1
HZ16_OG_ELITE_5.1_7.1_Rev_1_A.indd 1 12/6/16 11:55 AM

32
TREADMILL OPERATION
This section explains how to use your treadmill’s console and programming.
2
3 ENGLISH
27 DEUTSCH
51 NEDERLANDS
75 FRANÇAIS
ENGLISH
HZ16_OG_ELITE_5.1_7.1_Rev_1_A.indd 2-3 12/6/16 11:55 AM

4 5
T5.1
T5.1 CONSOLE OPERATION
Note: There is a thin protective sheet of clear plastic on the overlay
of the console that should be removed before use.
A) DOT MATRIX DISPLAY WINDOW: Displays workout level
and progress.
B) LED DISPLAY WINDOWS: Time, Incline, Distance, Speed.
C) ALPHANUMERIC DISPLAY WINDOW: Calories, Heart Rate,
Steps.
D) START: Press to begin exercising, Start your workout, or
resume exercising after pause.
E) STOP: Press to pause/end your workout. Hold for 3 seconds
to reset the console.
F) ENTER/CHANGE DISPLAY BUTTON: Press to confirm the
setting. Press to change display feedback during workout.
G) PROGRAMMING BUTTON: Used to select program.
H) KEYPAD:
(1) Quickly access any speed or incline level by typing the
number and pressing SET SPEED (L) or SET INCLINE(K)
keys. Examples: • To change the speed to 12 KMH, press
1-2-0- SET SPEED. • To change the incline to 4%, press
4-0-SET INCLINE (Note, increment of incline is 0.5%).
(2) Setup Time, Speed, Incline, etc. After selecting
program.
(3) Setup xID and Passcode.
I) INCLINE KEYS: Used to adjust incline in small increments
(0.5% Increments).
J) SPEED KEYS: Used to adjust speed in small increments (0.1
KMH increments).
K) SET INCLINE: Used to change incline to level entered into
keypad.
T5.1
R Q B A
U
OS
V
T
V
D NI
K
E M J
L
G W F H
C P
L) SET SPEED: Used to change speed to level entered into keypad.
M) VOLUME: Used to adjust volume up or down.
N) BACK: Used to go back to last step.
O) AUDIO IN JACK: Plug your media player into the console using
the included audio adaptor cable.
P) ENERGY SAVER INDICATOR/INSTANT ON & OFF: Indicates if
machine is in energy saver mode. Press to quickly enter sleep
mode. Under energy saver mode or sleep mode, press to wake
the console up.
Q) PASSPORT CONNECT & SYNC: Press to reset and connect to your
Passport Box for Virtual Active programing.
R) WIFI CONNECT: Press to reset and connect to your wireless
connection.
S) BLUETOOTH CONNECT:
(1) Audio streaming: use smart phone or tablet to connect
Bluetooth device (WLT2564M) to play music via speakers.
(2) Bluetooth heart rate: press and hold for 3 seconds to
connect your Bluetooth heart rate device.
T) SPEAKERS: Music plays through speakers when your media
player is connected to the console.
U) MEDIA PLAYER HOLDER: Holds your media player.
V) WATER BOTTLE HOLDER: Holds personal workout equipment.
W) SAFETY KEY POSITION: Enables treadmill when safety key is
inserted .
ENGLISH
ENGLISH
HZ16_OG_ELITE_5.1_7.1_Rev_1_A.indd 4-5 12/6/16 11:55 AM

6 7
T7.1
H
O N
I
A
R
L JP M
S
Q Q
S
F
F
G
G
U
B H JD T E C
T7.1
T7.1 CONSOLE OPERATION
Note: There is a thin protective sheet of clear plastic on the
overlay of the console that should be removed before use.
A) LCD DISPLAY WINDOW: Time, Distance, Speed,
Calories, Incline, Laps, and Heart rate.
B) START: Press to begin exercising, start your workout, or
resume exercising after pause.
C) STOP: Press to pause/end your workout. Hold for 3
seconds to reset the console.
D) INTELLIGENT DRIVE: Turn to select, press to confirm.
E) INDICATORS LED FOR PROGRAMS: Help users to realize
what program category they use.
F) INCLINE KEYS: Used to adjust incline in small
increments (0.5% Increments).
G) SPEED KEYS: Used to adjust speed in small
increments (0.1 KMH increments).
H) SET INCLINE: Used to change incline to level entered
into keypad.
I) SET SPEED: Used to change speed to level entered into
keypad.
J) VOLUME: Used to adjust volume up or down.
K) BACK: Used to go back to last step.
L) AUDIO IN JACK: Plug your media player into the console
using the included audio adaptor cable.
M) ENERGY SAVER INDICATOR/INSTANT ON & OFF:
Indicates if machine is in energy saver mode. Press to
quickly enter sleep mode. Under energy saver mode or
sleep mode, press to wake the console up.
N) PASSPORT CONNECT & SYNC: Press to reset and connect to
your Passport Box for Virtual Active programing.
O) WIFI CONNECT: Press to reset and connect to your wireless
connection.
P) BLUETOOTH CONNECT:
(1) Audio streaming: Use smart phone or tablet to connect
Bluetooth device (WLT2564M) to play music via speakers.
(2) Bluetooth heart rate: Press and hold for 3 seconds to
connect your Bluetooth heart rate device.
Q) SPEAKERS: Music plays through speakers when your media
player is connected to the console.
R) MEDIA PLAYER HOLDER: Holds your media player.
S) WATER BOTTLE HOLDER: Holds personal workout
equipment.
T) SAFETY KEY POSITION: Enables treadmill when safety key is
inserted.
U) INTELLIGENT SENSOR: There are two functions of this
sensor, the first one, once user steps on the running
deck, then it turns on the power of console automatically,
convenient for the user to use the machine. Second function
is “belt stop”, when user goes away from the treadmill
without pressing PAUSE or STOP, it turns off the power and
stops the machine automatically 3 minutes later to protect
people get injury.
ENGLISH
ENGLISH
HZ16_OG_ELITE_5.1_7.1_Rev_1_A.indd 6-7 12/6/16 11:55 AM

8 9
T5.1 DISPLAY T7.1 DISPLAY
A
D
B
C
ENGLISH
